Extron Electronics CVEQ1, CVEQ1 WM User Manual

User’s Manual

www.extron.com

Extron Electronics, USA

1230 South Lewis Street
Anaheim, CA 92805
USA

714.491.1500
Fax [phone]

Extron Electronics, Europe

Beeldschermweg 6C
3821 AH Amersfoort
The Netherlands
+31.33.453.4040
Fax [phone]

© 2005 Extron Electronics. All rights reserved.

Extron Electronics, Asia

135 Joo Seng Road, #04-01
PM Industrial Building
Singapore 368363
+65.6383.4400
Fax [phone]

Extron Electronics, Japan

Kyodo Building
16 Ichibancho
Chiyoda-ku, Tokyo 102-0082 Japan
+81.3.3511.7655
Fax [phone]

CVEQ1, CVEQ1 WM, CVEQ1 AAP

1-Input, 1-Output Equalizing Composite Video Line Drivers

68-544-01 Rev. C

09 05

Precautions

Safety Instructions • English

This symbol is intended to alert the user of important
operating and maintenance (servicing) instructions
in the literature provided with the equipment.

This symbol is intended to alert the user of the
presence of uninsulated dangerous voltage within
the product's enclosure that may present a risk of
electric shock.

Caution

Read Instructions • Read and understand all safety and operating

instructions before using the equipment.

Retain Instructions • The safety instructions should be kept for future

reference.

Follow Warnings • Follow all warnings and instructions marked on the

equipment or in the user information.

Avoid Attachments • Do not use tools or attachments that are not

recommended by the equipment manufacturer because they may be
hazardous.

Consignes de Sécurité • Français

Ce symbole sert à avertir l’utilisateur que la
documentation fournie avec le matériel contient des
instructions importantes concernant l’exploitation
et la maintenance (réparation).

Ce symbole sert à avertir l’utilisateur de la présence
dans le boîtier de l’appareil de tensions dangereuses
non isolées posant des risques d’électrocution.

Attention

Lire les instructions• Prendre connaissance de toutes les consignes de

sécurité et d’exploitation avant d’utiliser le matériel.

Conserver les instructions• Ranger les consignes de sécurité afin de

pouvoir les consulter à l’avenir.

Respecter les avertissements • Observer tous les avertissements et

consignes marqués sur le matériel ou présentés dans la documentation
utilisateur.

Eviter les pièces de fixation • Ne pas utiliser de pièces de fixation ni

d’outils non recommandés par le fabricant du matériel car cela
risquerait de poser certains dangers.

Sicherheitsanleitungen • Deutsch

Dieses Symbol soll dem Benutzer in der im
Lieferumfang enthaltenen Dokumentation
besonders wichtige Hinweise zur Bedienung und
Wartung (Instandhaltung) geben.

Dieses Symbol soll den Benutzer darauf aufmerksam
machen, daß im Inneren des Gehäuses dieses
Produktes gefährliche Spannungen, die nicht isoliert
sind und die einen elektrischen Schock verursachen
können, herrschen.

Achtung

Lesen der Anleitungen • Bevor Sie das Gerät zum ersten Mal verwenden,

sollten Sie alle Sicherheits-und Bedienungsanleitungen genau
durchlesen und verstehen.

Aufbewahren der Anleitungen • Die Hinweise zur elektrischen Sicherheit

des Produktes sollten Sie aufbewahren, damit Sie im Bedarfsfall darauf
zurückgreifen können.

Befolgen der Warnhinweise • Befolgen Sie alle Warnhinweise und

Anleitungen auf dem Gerät oder in der Benutzerdokumentation.

Keine Zusatzgeräte • Verwenden Sie keine Werkzeuge oder Zusatzgeräte,

die nicht ausdrücklich vom Hersteller empfohlen wurden, da diese eine
Gefahrenquelle darstellen können.

Instrucciones de seguridad • Español

Este símbolo se utiliza para advertir al usuario sobre
instrucciones importantes de operación y
mantenimiento (o cambio de partes) que se desean
destacar en el contenido de la documentación
suministrada con los equipos.

Este símbolo se utiliza para advertir al usuario sobre
la presencia de elementos con voltaje peligroso sin
protección aislante, que puedan encontrarse dentro
de la caja o alojamiento del producto, y que puedan
representar riesgo de electrocución.

Precaucion

Leer las instrucciones • Leer y analizar todas las instrucciones de

operación y seguridad, antes de usar el equipo.

Conservar las instrucciones • Conservar las instrucciones de seguridad

para futura consulta.

Obedecer las advertencias • Todas las advertencias e instrucciones

marcadas en el equipo o en la documentación del usuario, deben ser
obedecidas.

Evitar el uso de accesorios • No usar herramientas o accesorios que no

sean especificamente recomendados por el fabricante, ya que podrian
implicar riesgos.

Warning

Power sources • This equipment should be operated only from the power source

indicated on the product. This equipment is intended to be used with a main
power system with a grounded (neutral) conductor. The third (grounding) pin is
a safety feature, do not attempt to bypass or disable it.

Power disconnection • To remove power from the equipment safely, remove all

power cords from the rear of the equipment, or the desktop power module (if
detachable), or from the power source receptacle (wall plug).

Power cord protection • Power cords should be routed so that they are not likely to

be stepped on or pinched by items placed upon or against them.

Servicing • Refer all servicing to qualified service personnel. There are no user-

serviceable parts inside. To prevent the risk of shock, do not attempt to service
this equipment yourself because opening or removing covers may expose you to
dangerous voltage or other hazards.

Slots and openings • If the equipment has slots or holes in the enclosure, these are

provided to prevent overheating of sensitive components inside. These openings
must never be blocked by other objects.

Lithium battery • There is a danger of explosion if battery is incorrectly replaced.

Replace it only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the manufacturer's
instructions.

Avertissement

Alimentations• Ne faire fonctionner ce matériel qu’avec la source d’alimentation

indiquée sur l’appareil. Ce matériel doit être utilisé avec une alimentation
principale comportant un fil de terre (neutre). Le troisième contact (de mise à la
terre) constitue un dispositif de sécurité : n’essayez pas de la contourner ni de la
désactiver.

Déconnexion de l’alimentation• Pour mettre le matériel hors tension sans danger,

déconnectez tous les cordons d’alimentation de l’arrière de l’appareil ou du
module d’alimentation de bureau (s’il est amovible) ou encore de la prise secteur.

Protection du cordon d’alimentation • Acheminer les cordons d’alimentation de

manière à ce que personne ne risque de marcher dessus et à ce qu’ils ne soient
pas écrasés ou pincés par des objets.

Réparation-maintenance • Faire exécuter toutes les interventions de réparation-

maintenance par un technicien qualifié. Aucun des éléments internes ne peut être
réparé par l’utilisateur. Afin d’éviter tout danger d’électrocution, l’utilisateur ne
doit pas essayer de procéder lui-même à ces opérations car l’ouverture ou le
retrait des couvercles risquent de l’exposer à de hautes tensions et autres dangers.

Fentes et orifices • Si le boîtier de l’appareil comporte des fentes ou des orifices,

ceux-ci servent à empêcher les composants internes sensibles de surchauffer. Ces
ouvertures ne doivent jamais être bloquées par des objets.

Lithium Batterie • Il a danger d'explosion s'll y a remplacment incorrect de la

batterie. Remplacer uniquement avec une batterie du meme type ou d'un ype
equivalent recommande par le constructeur. Mettre au reut les batteries usagees
conformement aux instructions du fabricant.

Vorsicht

Stromquellen • Dieses Gerät sollte nur über die auf dem Produkt angegebene

Stromquelle betrieben werden. Dieses Gerät wurde für eine Verwendung mit
einer Hauptstromleitung mit einem geerdeten (neutralen) Leiter konzipiert. Der
dritte Kontakt ist für einen Erdanschluß, und stellt eine Sicherheitsfunktion dar.
Diese sollte nicht umgangen oder außer Betrieb gesetzt werden.

Stromunterbrechung • Um das Gerät auf sichere Weise vom Netz zu trennen,

sollten Sie alle Netzkabel aus der Rückseite des Gerätes, aus der externen
Stomversorgung (falls dies möglich ist) oder aus der Wandsteckdose ziehen.

Schutz des Netzkabels • Netzkabel sollten stets so verlegt werden, daß sie nicht

im Weg liegen und niemand darauf treten kann oder Objekte darauf- oder
unmittelbar dagegengestellt werden können.

Wartung • Alle Wartungsmaßnahmen sollten nur von qualifiziertem

Servicepersonal durchgeführt werden. Die internen Komponenten des Gerätes
sind wartungsfrei. Zur Vermeidung eines elektrischen Schocks versuchen Sie in
keinem Fall, dieses Gerät selbst öffnen, da beim Entfernen der Abdeckungen die
Gefahr eines elektrischen Schlags und/oder andere Gefahren bestehen.

Schlitze und Öffnungen • Wenn das Gerät Schlitze oder Löcher im Gehäuse

aufweist, dienen diese zur Vermeidung einer Überhitzung der empfindlichen
Teile im Inneren. Diese Öffnungen dürfen niemals von anderen Objekten
blockiert werden.

Litium-Batterie • Explosionsgefahr, falls die Batterie nicht richtig ersetzt wird.

Ersetzen Sie verbrauchte Batterien nur durch den gleichen oder einen
vergleichbaren Batterietyp, der auch vom Hersteller empfohlen wird. Entsorgen
Sie verbrauchte Batterien bitte gemäß den Herstelleranweisungen.

Advertencia

Alimentación eléctrica • Este equipo debe conectarse únicamente a la fuente/tipo

de alimentación eléctrica indicada en el mismo. La alimentación eléctrica de este
equipo debe provenir de un sistema de distribución general con conductor
neutro a tierra. La tercera pata (puesta a tierra) es una medida de seguridad, no
puentearia ni eliminaria.

Desconexión de alimentación eléctrica • Para desconectar con seguridad la

acometida de alimentación eléctrica al equipo, desenchufar todos los cables de
alimentación en el panel trasero del equipo, o desenchufar el módulo de
alimentación (si fuera independiente), o desenchufar el cable del receptáculo de
la pared.

Protección del cables de alimentación • Los cables de alimentación eléctrica se

deben instalar en lugares donde no sean pisados ni apretados por objetos que se
puedan apoyar sobre ellos.

Reparaciones/mantenimiento • Solicitar siempre los servicios técnicos de personal

calificado. En el interior no hay partes a las que el usuario deba acceder. Para
evitar riesgo de electrocución, no intentar personalmente la reparación/
mantenimiento de este equipo, ya que al abrir o extraer las tapas puede quedar
expuesto a voltajes peligrosos u otros riesgos.

Ranuras y aberturas • Si el equipo posee ranuras o orificios en su caja/alojamiento,

es para evitar el sobrecalientamiento de componentes internos sensibles. Estas
aberturas nunca se deben obstruir con otros objetos.

Batería de litio • Existe riesgo de explosión si esta batería se coloca en la posición

incorrecta. Cambiar esta batería únicamente con el mismo tipo (o su equivalente)
recomendado por el fabricante. Desachar las baterías usadas siguiendo las
instrucciones del fabricante.

FCC Class A Notice

Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his
own expense.

Note: This unit was tested with shielded cables on the peripheral devices. Shielded
cables must be used with the unit to ensure compliance.

Extron’s Warranty

Extron Electronics warrants this product against defects in materials and
workmanship for a period of three years from the date of purchase. In the event of
malfunction during the warranty period attributable directly to faulty workmanship
and/or materials, Extron Electronics will, at its option, repair or replace said products
or components, to whatever extent it shall deem necessary to restore said product to
proper operating condition, provided that it is returned within the warranty period,
with proof of purchase and description of malfunction to:

USA, Canada, South America, Europe, Africa, and the Middle East:
and Central America:

Extron Electronics, Europe

Extron Electronics Beeldschermweg 6C

1001 East Ball Road 3821 AH Amersfoort

Anaheim, CA 92805, USA The Netherlands

Asia: Japan:

Extron Electronics, Asia Extron Electronics, Japan
135 Joo Seng Road, #04-01 Kyodo Building
PM Industrial Bldg. 16 Ichibancho
Singapore 368363 Chiyoda-ku, Tokyo 102-0082

Japan

This Limited Warranty does not apply if the fault has been caused by misuse,
improper handling care, electrical or mechanical abuse, abnormal operating conditions
or non-Extron authorized modification to the product.

If it has been determined that the product is defective, please call Extron and ask for
an Applications Engineer at [phone] (USA), 31.33.453.4040 (Europe),

65.6383.4400 (Asia), or 81.3.3511.7655 (Japan) to receive an RA# (Return Authorization
number). This will begin the repair process as quickly as possible.

Units must be returned insured, with shipping charges prepaid. If not insured, you
assume the risk of loss or damage during shipment. Returned units must include the
serial number and a description of the problem, as well as the name of the person to
contact in case there are any questions.

Extron Electronics makes no further warranties either expressed or implied with
respect to the product and its quality, performance, merchantability, or fitness for any
particular use. In no event will Extron Electronics be liable for direct, indirect, or
consequential damages resulting from any defect in this product even if Extron
Electronics has been advised of such damage.

Please note that laws vary from state to state and country to country, and that some
provisions of this warranty may not apply to you.

安全须知 • 中文

这个符号提示用户该设备用户手册中
有重要的操作和维护说明。

这个符号警告用户该设备机壳内有暴
露的危险电压，有触电危险。

注意

阅读说明书 • 用 户使 用该 设备 前必 须阅 读并 理

解 所有 安全 和使 用说 明。

保存说明书 • 用户应保存安全说明书以备将来使

用。

遵守警告 • 用户应遵守产品和用户指南上的所有安

全和操作说明。

避免追加 • 不要使用该产品厂商没有推荐的工具或

追加设备，以避免危险。

警告

电源 • 该 设备 只能 使用 产品 上标 明的 电源 。 设备

必 须使 用有 地线 的供 电系 统供 电。 第 三条 线
（ 地线 ）是 安全 设施 ，不 能不 用或 跳过 。

拔掉电源 • 为安全地从设备拔掉电源，请拔掉所有设备后

或桌面电源的电源线，或任何接到市电系统的电源线。

电源线保护 • 妥善布线， 避免被踩踏，或重物挤压。
维护 • 所有维修必须由认证的维修人员进行。 设备内部没

有用户可以更换的零件。为避免出现触电危险不要自己
试图打开设备盖子维修该设备。

通风孔 • 有些设备机壳上有通风槽或孔，它们是用来防止

机内敏感元件过热。 不要用任何东西挡住通风孔。

锂电池 • 不正确的更换电池会有爆炸的危险。 必须使用与

厂家推荐的相同或相近型号的电池。 按照生产厂的建
议处理废弃电池。

CAUTION

Precautions, continued

Quick Start Guide — CVEQ1 Series

Installation and service must be performed by authorized

personnel only. The CVEQ1 AAP and CVEQ1 WM
must be used with UL approved electrical boxes. See “UL
Requirements”, page 2-3.

To install and set up a CVEQ1, follow these steps:

Step 1

Turn the input and output devices off and unplug their power cords.

Step 2

For the CVEQ1, go to step 3.
For the CVEQ1 AAP,
A. Determine the installation location.
B. If applicable, follow the site preparation (hole cutting, electrical

box installation, and cable preparation) instructions included
with the device or AAP wallplate into which the CVEQ1 AAP
will be installed.

C. Attach the CVEQ1 AAP to the Extron device faceplate or AAP

wallplate.

For the CVEQ1 WM,
A. Determine the installation location.
B. Prepare the site (cut the hole, install the electrical box, and

prepare the cable).

Step 3

Attach output cables to the rear (CVEQ1)/bottom (CVEQ1 AAP)/
side (CVEQ1 WM) panel of the line driver and to the output devices.
See “Rear/Bottom/Side Panel Features and Cabling” in chapter 2.

Step 4

Attach input cables to the input devices and to the line driver’s
front panel connectors. See “Front Panel Features and Cabling” in
chapter 2.

Step 5

Connect power cords and turn on the output devices (projector/
monitor, speakers), buffer, and input devices.

Step 6

The picture should appear, and sound should be audible. If not,
ensure that all devices are plugged in and receiving power. Check
the cabling; make adjustments as needed.

CVEQ1 Series • Quick Start Guide

QS-1

Quick Start Guide — CVEQ1 Series, cont’d

Table of Contents

Step 7

While watching the display, adjust the video gain and equalization
by using the rotary Gain and Equalize controls. An oscilloscope can
be used to achieve a more precise adjustment. See “Top/Side Panel
Features and Adjustments” in chapter 2.

Step 8

For the CVEQ1 AAP or CVEQ1 WM,
A. Disconnect the line driver’s power supply at the source end (not

at the line driver).

B. Disconnect the input and output devices’ power.
C. For the CVEQ1 WM, secure the faceplate onto the UL-approved

electrical wall box in the wall or furniture.
For the CVEQ1 AAP, secure the wallplate/faceplate that the
CVEQ1 AAP is attached to onto the UL-approved electrical wall
box in the wall or furniture.

D. Restore power to the line driver and to input and output devices.

Chapter 1 • Introduction ......................................................... 1-1

About the CVEQ1, CVEQ1 WM, and CVEQ1 AAP ... 1-2

Features ...................................................................................... 1-2

Chapter 2 • Installation, Setup, Operation ................ 2-1

UL Requirements ................................................................... 2-2

Preparing the Site and Installing the Wall Box ..... 2-2

Front Panel Features and Cabling ................................2-5

Rear/Bottom/Side Panel Features and Cabling ...... 2-6

Top/Side Panel Features and Adjustments ............... 2-8

Mounting the CVEQ1 AAP ............................................. 2-10

Mounting the CVEQ1 WM .............................................. 2-11

Appendix A • Specifications, Part Numbers,

and Accessories ..............................................................................A-1

Specifications ..........................................................................A-2

Included Parts .........................................................................A-4

Accessories ...............................................................................A-4

Cables ..........................................................................................A-4

Appendix B • Dimensions and Templates ...................B-1

Dimensions ............................................................................... B-2

Template ....................................................................................B-3

QS-2

CVEQ1 Series • Quick Start Guide

All trademarks mentioned in this manual are the properties of their respective owners.

68-544-01 Rev. C

09 05

CVEQ1 Series • Table of Contents

v

Table of Contents, cont’d

CVEQ1, CVEQ1 WM, CVEQ1 AAP

Chapter One

1

vi

Introduction

About the CVEQ1, CVEQ1 WM, and CVEQ1 AAP

Features

CVEQ1 Series • Table of Contents

Introduction

About the CVEQ1, CVEQ1 WM, and CVEQ1 AAP

The Extron CVEQ1 is a one-input, one-output, composite video
line driver. It features a 185 MHz (-3 dB) video bandwidth.

It accepts one composite video input on a female BNC connector
and one stereo audio input on a pair of female RCA connectors.
One female BNC connector provides equalized video output,
and a five-pole captive screw connector provides for stereo
audio output.

The Extron CVEQ1 AAP is identical to the CVEQ1, except that it
is designed to be mounted in a double-space height architectural
adapter plate bracket (in a device’s faceplate or in an AAP
wallplate) for installation into a wall or furniture.

The CVEQ1 WM shares the features of the other two models,
but it has a 1-gang faceplate for installation into a UL-approved
electrical wall box set into a wall or furniture.

In this manual “CVEQ”, “CVEQ1”, and “line driver” are used to
refer to all models interchangeably unless otherwise noted.

Features

Stereo audio — Unbalanced stereo audio input can be output as

balanced or unbalanced stereo audio.

Gain adjustment — All models offer a video gain adjustment

with a range of -6 dB to +6 dB.

Equalization adjustment — Each model also features an

equalization adjustment that changes the level and
peaking of the output signal to compensate for use of long
cables. The CVEQ1 series line drivers can drive video
signals through up to 1000 feet (300 meters) of Extron RG6
cable.

CVEQ1, CVEQ1 WM, CVEQ1 AAP

Chapter Two

2

Installation, Setup, Operation

UL Requirements

1-2

Preparing the Site and Installing the Wall Box

Front Panel Features and Cabling

Rear/Bottom/Side Panel Features and Cabling

Top/Side Panel Features and Adjustments

Mounting the CVEQ1 AAP

Mounting the CVEQ1 WM

CVEQ1 Series • Introduction

Installation, Setup, Operation

Connecting Shields.eps

Metal Wall Box

Screw

Braided Shield

Install Cable

Foil Shield

Cable Clamp

1-gang wall box.eps

Installation Cable

Cable Clamp

Wall Stud

Installation Cable

Cable Clamp

Wall Stud

Screws or Nails

Screws or Nails

UL Requirements

Preparing the Site and Installing the Wall Box

2-2

The Underwriters Laboratories (UL) requirements listed below
pertain to the installation of the CVEQ1 WM and CVEQ1 AAP.

1. These units are not to be connected to a centralized DC
power source or used beyond their rated voltage range.

The Extron P/S 100, P/S 150, and other Extron power

supplies may be used with the CVEQ.

2. These units must be installed in UL listed junction boxes.

The UL approved electrical wall box (junction box) is not

included with the CVEQ; the installer is responsible for
obtaining and installing the box.

3. These units must be installed with conduit in accordance
with the National Electrical Code.

Choose a location that will allow cable runs without
interference. Allow enough depth for both the wall box and
the cables. You may need to install the cables into the wall,
furniture, or conduits before installing the line driver.

• The CVEQ1 AAP can be installed in an Extron two-gang, four­gang, or half rack width AAP Architectural Adapter Plate or in
the faceplate of another Extron device that accepts AAP plates,
such as an interface or distribution amplifier. Refer to the
mounting instructions for the adapter plate or device.

CVEQ1 WM can be installed in a standard one-gang elec-

• The
trical wall box that is at least 2.5” deep. An optional one-gang
mounting bracket (mud ring) is also available.

The installation must conform to national and local electrical
codes and to the line driver’s size requirements. A dimensional
drawing of the CVEQ1 WM and a template (not to scale) are
provided in appendix B of this manual.

1. Cut out the center portion shown in the template that
corresponds to the wall box.

2. Place the template (or the wall box) against the installation
surface, and mark the guidelines for the opening on the
wall or furniture.

3. Cut out the material from the marked area.

4. Check the opening size by inserting the wall box into the

opening. The box and the line driver’s circuit boards and
connectors should fit easily into the opening. Enlarge or
smooth the edges of the opening if needed.

CVEQ1 Series • Installation, Setup, Operation

5. Feed cables through the wall box punch-out holes, and
secure them with cable clamps to provide strain relief.

6. Exposed cable shields (braids or foil) are potential sources
of short circuits. Trim back and/or insulate shields with
heat shrink.

Grounding outer braided and foil shields

To prevent short circuits, the outer foil shield can be

cut back to the point where the cable exits the cable
clamp. Both braided and foil shields should be con­nected to an equipment ground at the other end of
the cable.

7. Insert the wall box into the opening, and attach it to the
wall stud or furniture with nails or screws, leaving the
front edge flush with the outer wall or furniture surface.
See the following illustration, which applies to one-, two-,
and four-gang wall boxes.

Attaching a wall box to a wall stud

CVEQ1 Series • Installation, Setup, Operation

2-3

CVEQ1 Series • Installation, Setup, Operation

Installation, Setup, Operation, cont’d

CVEQ1 Series • Installation, Setup, Operation

CVEQ1

AUDIO INPUT

VIDEO INPUT

L R

AUDIO INPUT

VIDEO INPUT

L R

CVEQ1 AAP

CV EQ1 W M

L AUDIO IN

R AUDIO IN

VIDEO IN

1

2

3

1

4

4

2

3

1

4

4

2

3

CVEQ1
Front Panel

CVEQ1 AAP

Front Panel

CVEQ1 WM
Front Panel

1

2

3

4

Audio RCA tip-sleeve

connector_052501.eps

Tip

(Signal)

Sleeve (Gnd)

If attaching the wall box to wood, use four #8 or #10 screws

or 10-penny nails. A minimum of ½ inch
(1.3 cm) of screw threads must penetrate the wood.

If attaching the wall box to metal studs or furniture, use

four #8 or #10 self-tapping sheet metal screws or machine
bolts with matching nuts.

8. Set the gain and equalization, and cable and test the
line driver before fastening it into the wall box. The

adjustments and cables will be inaccessible after
installation. See “Top/Side Panel Features and

Adjustments” in this chapter for details.

Front Panel Features and Cabling

Power indicator LED — This

LED lights amber when the
line driver receives power. It
lights green when the line
driver receives power and an
active signal.

Video input connector — Use

a coaxial cable to connect a
composite video source to this
female BNC connector.

Audio input connectors

— Connect an audio source
using these female RCA-style
connectors for left and right
unbalanced stereo audio
input. The male
plugs should be
wired as shown at
right.

2-4

Faceplate screws (CVEQ1 WM and CVEQ1 AAP only) — These

screws fasten the line driver’s faceplate to the rest of the line driver.

Do not remove these faceplate screws while the line driver is

attached to the wall/furniture or the detached line driver may
fall down into the electrical box.

To replace the faceplate with a customized faceplate:

1. Set the line driver in an accessible place (do not attempt to
replace the faceplate while the line driver is installed in a wall or
furniture), and remove the faceplate screws.

2. Remove the hex nut that fastens the video input BNC to the plate.

3. Fasten the new faceplate to the line driver with the faceplate

screws.

4. Replace the video input BNC’s hex nut and tighten it.

2-5

CVEQ1 Series • Installation, Setup, Operation

Installation, Setup, Operation, cont’d

CVEQ1 Series • Installation, Setup, Operation

Power Connector wiring_compact.eps

Tip (+) Sleeve Tip (+)

Sleeve

Power Input

Use a 9 VDC to 24 VDC power supply.
A 12 VDC supply is recommended.

CVEQ1 AAP/CVEQ WM Rear Panel

Power Connector

J2

1

Positive

Negative

N/C

5 mm

2

3

1

J6

J2

1

1

J6

J2

1

RL R

L

VIDEO OUTPUT

POWER

AUDIO OUTPUT

L R

RL R

L

1

2

3

3

2

1

3

2

1

CVEQ1
Rear Panel

CVEQ1 WM
Side Panel

CVEQ1 AAP

Bottom P

anel

1

CVEQ1 Unbalanced Audio Output

Tip
See Caution.

Sleeve(s)

Tip
See Caution.

CVEQ1 Balanced Audio Output

Tip

Ring

Sleeve(s)

Tip

Ring

L R

AUDIO OUTPUT

AU
DIO OUTPUT

L R

CAUTION Connect the sleeve to ground

(Gnd).

Connecting the sleeve to
a negative (–) terminal will
damage the audio output circuits

.

Audio Captive Screw Con_

CVEQ1_090605.eps

5 mm

CVEQ1 WM, CVEQ1 AAP

Unbalanced Audio Output

Tip
See Caution.

Sleeve(s)

Tip
See Caution.

CVEQ1 WM, CVEQ1 AAP

Balanced Audio Output

Tip

Ring

Sleeve(s)

Tip

Ring

L R

AUDIO OUTPUT

AU
DIO OUTPUT

L R

CAUTION Connect the sleeve to ground

(Gnd).

Connecting the sleeve to

a negative (–) terminal will
damage the audio output circuits

.

Audio Captive Screw Con_

CVEQ1 WM-AAP_090605.eps

5 mm

Rear/Bottom/Side Panel Features and Cabling

Audio output connector

— Cable an audio device to
the line driver via this female
5-pole captive screw connector.
Wire the male connector as
shown below.

Video output connector — Using a coaxial cable, connect

a display device to this female BNC connector. For the
CVEQ1 WM and CVEQ1 AAP, the BNC is at the end of a short
pigtail on the circuit board.

Power supply connection — On the CVEQ1 the power input

connector is a 2-pole jack that can be used to connect a 9 VDC
to 24 VDC, 1 A (maximum), external power supply. If you
use an unterminated power supply (Extron parts #70-055-01

or #28-071-02, or #60-357-01 or
#60-432-01), connect the tip of the
jack to the positive (hot) wire, and
the sleeve to the negative/ground
wire, as shown in the illustration at
left.

The CVEQ1 WM and CVEQ1 AAP have a female captive screw

connector instead of a jack for
connecting an external power
source. Wire the power connection
as shown at right.

CVEQ1

2-6

CVEQ1 WM, CVEQ1 AAP

2-7

CVEQ1 Series • Installation, Setup, Operation

Installation, Setup, Operation, cont’d

CVEQ1 Series • Installation, Setup, Operation

CVEQ1

AUDIO INPUT

VIDEO INPUT

L R

VIDEO OUTPUT POWERAUDIO OUTPUT

L R

Front

VCR

Stereo Audio

Stereo Audio

Large Screen

Projection TV

Rear

CVEQ1 Application.eps

V

I

D

E

O

I

N

P

U

T

G

A

IN

EQ

UA

LIZE

A

U

D

I

O

I

N

P

U

T

C

V

E

Q

1

L

R

Gain

Equaliz

e

GAIN EQUALIZE

1

2

1

2

1

2

CVEQ1
Top Panel

CVEQ1 AAP

Top Panel

CVEQ1 WM

Side Panel

2

1

Top/Side Panel Features and Adjustments

Adjust the gain and

equalization before
installing the CVEQ1 AAP
or CVEQ1 WM into a wall
or furniture, as the gain and
equalization adjustment
controls will be inaccessible
after installation.

Gain adjustment control —

This control adjusts picture
brightness by compensating
for signal amplitude loss
caused by cable resistance. To
adjust the output gain, view
the display while using a
small, flat-blade screwdriver
to rotate this two-turn
potentiometer. This control
produces a gain adjustment ranging from

-6 dB to +6 dB. Select the setting that gives the
best picture brightness.

adjustment changes the level and peaking of the output signal
to compensate for capacitance caused by up to 1000 feet
(300 meters) of Extron RG6 cable.

Use a small, flat-blade screwdriver to rotate this control.

View the display and select the setting that gives the sharpest
picture. For a more precise setting you can use an oscilloscope
or a waveform monitor connected to the far end of the output
cable, and adjust the equalization so that the color burst ranges
between -20 IRE and +20 IRE.

The Equalize control is a potentiometer with a soft

mechanical stop at the high and the low end. If you
have reached the high or low end of the adjustment, the
potentiometer makes a clicking sound as you turn it, and
no change is apparent on the display.

2-8

You can judge the adjustment visually by

looking at the display. For a more precise
setting, you can use an oscilloscope or a
waveform monitor connected to the far
end of the output cable, and adjust the
gain so that the level at the waveform
monitor is 100 IRE.

Equalization adjustment control

(Equalize) — To adjust the output level
and peaking to get a sharp picture,
rotate this two-turn potentiometer. This

A typical CVEQ1 application

2-9

CVEQ1 Series • Installation, Setup, Operation

Installation, Setup, Operation, cont’d

CVEQ1 Series • Installation, Setup, Operation

Installation Cable

Cable Clamp

Wa

ll Stud

CVEQ1 WM Install.eps

C

V

E

Q

1

W

M

L

A

U

D

IO

IN

R

AU

D

IO

IN

V

ID

E

O

IN

#4-40 Nut w/ Captive

Washer

CVEQ1 AAP w RGB 568 installation.eps

4-gang Wall Box

RGB 568

CVEQ1 AAP

RGB 568

IN

P

U

T

B

U

F

F

E

R

E

D

L

O

C

A

L

M

O

N

IT

O

R

P

O

W

E

R

A

U

T

O

I

D

P

I

N

1

1

I

D

P

I

N

4

C

S

P

I

N

9

H

.

S

H

I

F

T

A

U

D

I

O

E

Q

U

A

L

I

Z

E

G

A

I

N

A

U

D

I

O

I

N

P

U

T

V

ID

E

O

I

N

P

U

T

L

R

C

V

E

Q

1

A

A

P

Mounting the CVEQ1 AAP

The CVEQ1 AAP and any other adapter plates must be attached
to a device’s faceplate or an AAP wallplate and cabled before the
device or wallplate is installed in a wall or furniture. The screws
needed for installing the CVEQ1 AAP are built into its front
panel, so no additional screws are needed.

1. Insert the CVEQ1 AAP’s screws through the holes in the
faceplate or AAP wallplate. Secure the line driver to the
faceplate or wallplate with the provided captive washers
and #4-40 nuts.

Mounting the CVEQ1 WM

The CVEQ1 WM must have output cables connected before it
is installed in a wall or furniture. Secure the CVEQ1 WM to the
wall box as shown below.

Mounting the CVEQ1 WM into a wall box

2-10

Mounting the CVEQ1 AAP to an interface
or wallplate and into a wall box

2. Follow steps 3 through 8 in the Quick Start Guide at the
front of this manual.

2-11

Installation, Setup, Operation, cont’d

CVEQ1, CVEQ1 WM, CVEQ1 AAP

Appendix A

A

2-12

Specifications, Part Numbers,

and Accessories

Specifications

Included Parts

Accessories

Cables

CVEQ1 Series • Installation, Setup, Operation

CVEQ1 Series • Specifications, Parts, Accessories

Specifications, Part Numbers, Accessories

CVEQ1 Series • Specifications, Parts, Accessories

Specifications

Video

Gain ................................................... -6 dB to +6 dB, adjustable: 0.5 V to 2.0 V

±10% with input at 1 volt

Equalization/peaking gain ........... 4.5 dB max. @ 8 MHz

Bandwidth ....................................... 185 MHz (-3 dB)

Differential phase error .................. 1º at 3.58 MHz

Differential gain error ..................... 0.07% at 3.58 MHz

Video input

Number/signal type ....................... 1 composite video

Connectors ....................................... 1 female BNC

Nominal level ................................... 1 Vp-p

Minimum/maximum levels ........... Analog: 0.3 V to 2.0 Vp-p with no offset at

unity gain

Impedance ........................................ 75 ohms

Return loss ....................................... <-30 dB @ 5 MHz

Video output

Number/signal type ....................... 1 equalized composite video

Connectors ....................................... 1 female BNC

Nominal level ................................... 1 Vp-p at unity gain

Minimum/maximum levels ........... 0.3 V to 2.0 Vp-p

Impedance ........................................ 75 ohms

Return loss ....................................... <-30 dB @ 5 MHz

DC offset ........................................... ±50 mV with input at 0 offset

Sync

Standards .......................................... NTSC 3.58, NTSC 4.43, PAL, SECAM

Audio

Gain ................................................... Unbalanced output: 0 dB; balanced output: +6 dB

Frequency response ........................ 20 Hz to 20 kHz, ±0.5 dB

THD + Noise .................................... 0.025% @ 1 kHz, 0.020% @ 20 kHz at nominal

level

S/N ................................................... >86 dB at output 6 dB, balanced

Stereo channel separation .............. >75 dB @ 20 Hz to 20 kHz

Audio input

Number/signal type ...................... 1 stereo unbalanced

Connectors ....................................... 2 RCA female

Impedance ........................................ >10k ohms unbalanced, DC coupled

Nominal level ................................... -10 dBV (316 mV)

Maximum level ............................... +6 dBV, (unbalanced) at 1% THD+N

0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu

Audio output

Number/signal type ...................... 1 stereo, balanced/unbalanced

Connectors

CVEQ1 .................................. (1) 3.5 mm captive screw connector, 5 pole

CVEQ1 AAP ......................... (1) 3.5 mm direct insertion captive screw

connector, 5 pole

Impedance ........................................ 50 ohms unbalanced, 100 ohms balanced

Nominal level ................................... -2 dBu (632 mV), balanced output

Maximum level (Hi-Z) ................... >+16 dBu, balanced at 1% THD+N

Maximum level (600 ohm) ............. >+9 dBm, balanced at 1% THD+N

General

External power supply .................... 100 VAC to 240 VAC, 50/60 Hz, external,

Power input requirements .............. 12 VDC, 0.4 A

Temperature/humidity ................... Storage: -40 to +158 °F (-40 to +70 °C) /

Rack mount ....................................... No

Enclosure type ................................. Metal

Enclosure dimensions

CVEQ1 .................................. 1.2” H x 3.5” W x 1.8” D

CVEQ1 AAP

Plate .............................. 1.4” H x 3.5” W x 0.1” D

Circuit board ............... 1.1” H x 2.7” W x 1.7” D

CVEQ1 WM

Plate .............................. 4.5” H x 2.8” W x 0.1” D

Circuit board ............... 2.7” H x 1.1” W x 1.7” D

Product weight

CVEQ1, CVEQ1 AAP .......... 0.2 lbs (0.1 kg)

CVEQ1 WM ......................... 0.3 lbs (0.1 kg)

Shipping weight

CVEQ1, CVEQ1 AAP .......... 2 lbs (1 kg)

CVEQ1 WM ......................... 3 lbs (2 kg)

Vibration ........................................... ISTA 1A in carton (International Safe Transit Assn.)

Listings .............................................. UL, CUL

Compliances ..................................... CE, FCC Class A

MTBF ................................................. 30,000 hours

autoswitchable; to 12 VDC, 1 A (max.), regulated

10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing

3.0 cm H x 8.9 cm W x 4.6 cm D
(Depth excludes connectors.)

( 2.8 cm H x 8.9 cm W x 0.3 cm D) (double
space high AAP plate)

(2.8 cm H x 6.9 cm W x 4.3 cm D)
(Height includes connectors, but not cables.)

(11.4 cm H x 7.1 cm W x 0.3 cm D) (1 gang)

(6.9 cm H x 2.8 cm W x 4.3 cm D)
(Width includes connectors, but not cables.)

A-2

A-3

Specifications, Parts, and Accessories, cont’d

Warranty ........................................... 3 years parts and labor

All nominal levels are at ±10%.
Specifications are subject to change without notice.

Included Parts

These items are included in each order for a CVEQ1,
CVEQ1 AAP, or CVEQ1 WM:

Included parts Part number

CVEQ1 60-360-02
CVEQ1 AAP (gray, black, white) 70-146-02, -12, -22

or

CVEQ1 WM (gray, black, white) 60-435-02, -12, -22

or

12 VDC, 1 A max. external power supply 70-055-01
CVEQ1/CVEQ1 AAP/CVEQ1 WM

Accessories

Accessories Part number

BNCM-RCAF adapters (10) 100-234-01

3.5 mm 5-pole captive screw connector 10-319-10
AAP 102 2 gang wall plate
AAP 104 4 gang wall plate
AAP 201 half rack width, 1U high faceplate 60-302-01
AAP 202 half rack width, 2U high faceplate 60-303-01
1-gang mounting bracket/mud ring

P/S 100 universal power supply 60-357-01
P/S 150 universal power supply 60-432-01

User’s Manual

(gray, black, white)

(gray, black, white)

(gray, black, white)

70-086-05, -15, -25

60-300-01,-02,-03
60-301-01,-02,-03

CVEQ1, CVEQ1 WM, CVEQ1 AAP

Appendix B

B

Dimensions and Templates

Dimensions

Template

Cables

A-4

Super high resolution cables Part number

RG6-1, 6’ (1.8 m), 12’ (3.7 m) 26-383-12, -07
RG6-1, 50’ (15.2 m), 100’ (30.5 m) 26-383-05, -03
RG6-1, 500’ (152.4 m) bulk 22-098-02

CVEQ1 Series • Specifications, Parts, Accessories

Dimensions and Templates

4.50"

(16.5 cm)

TEMPLATE IS NOT FULL SIZE.

Cut Out Line for
Installing the
Electrical Box

Top Panel

2.79"

(8.0 cm)

CVEQ1 WM

Cut-Out Template for the Extron

2.24"

(105 cm)

4.13"

(57 cm)

SURFACE

CUT-OUT

AREA FOR

MOUNTING

Location of
CVEQ1 WM
Circuit Board

CV E Q 1 W M

L AUDIO IN

R AUDIO IN

VIDEO IN

0.610

0.000

3.890

4.500

1.045

3.160

3.410

2.720

3.700

0.800

2.024

1.433

0.000

2.790

1.395

1.465

ø 0.156 THRU WITH

ø 0.290 X 82° C'SINK

(2 PLACES)

ø 0.120
THR

U

C'BORE

2.900 x 1.400

x

0.050 DEEP
(FAR SIDE)

ø 0.440 THRU

(2 PLACES)

ø 0.530 THRU

0.100

R 0.060

(TYP)

ø 0.125 THRU

WITH

ø 0.220 X 82°

C'SINK

NEAR SIDE

(2 PLACES)

Dimensions

The dimensions drawing is not 100% of the actual size.

Template

CVEQ1 WM template

B-2

CVEQ1 Series • Dimensions, Templates

CVEQ1 Series • Dimensions, Templates

B-3

Dimensions, Templates, cont’d

B-4

CVEQ1 Series • Dimensions, Templates
