TSC 100

Transcoder and Standards Converter

e n co D e r S , D e c o De r S , an D T r a n Sc o D e r S

FeatUres

• Video standards converter from PAL to NTSC or NTSC to PAL

• Inputs: Composite video on a BNC with buffered loop-through, S-video on a 4-pin
mini DIN with buffered loop-through

• Outputs: Composite video on a BNC, S-video on a 4-pin mini DIN

• Encodes S-video to composite video

• Decodes composite video to S-video

• Accepts NTSC 3.58, NTSC 4.43, PAL, and SECAM composite video or S-video

• Outputs NTSC 3.58 and PAL

• Factory aspect ratio presets for PAL and NTSC centering

• Front panel security lockout

• RS-232 serial control port

• Rack-mountable 1U, quarter rack width metal enclosure

• External universal power supply included, part # 70-056-01

descriPti on

The Extron TSC 100 Transcoder and Standards Converter accepts NTSC 3.58, NTSC 4.43,
PAL, or SECAM composite video or S-video signals, and converts them to NTSC 3.58 or PAL
composite video or S-video. The incoming video standard is auto-detected, and NTSC or PAL
output is selected using the front panel buttons. A high quality, four-line adaptive comb filter
performs the Y/C separation, virtually eliminating chroma noise.

Input selection, standard selection, and picture controls are accessible on the front panel of
the TSC 100. The autoswitching feature allows any input to be selected automatically when a
video sync signal is detected, making the TSC 100 ideal for automatic routing and unattended
operation. Autoswitching can be activated or de-activated via RS-232. In addition, RS-232
allows the user to select full screen black or color bars as the output when no input is present
after being selected. It also enables users to select three factory sizing options for scaling
between NTSC and PAL video signals.

Impedance .. .. . .. .. . .. .. . .. .. . .. .. 75 ohms

Return loss . .. .. . .. .. . .. .. . .. .. .. . <-13 dB @ 5 MHz

DC offset (max. allowable) .. .. .. . 1.5 V

vid eo Pro ces sin g

Encoder . .. .. . .. .. . .. .. .. . .. .. . .. .. 10 bit digital

Decoder .. .. . .. .. . .. .. . .. .. . .. .. . .. 9 bit digital

Digital sampling .. . .. .. . .. .. . .. .. 24 bit, 8 bits per color

Colors .. .. . .. .. . .. .. . .. .. . .. .. . .. .. . 16.78 million

vid eo oUt PUt

Number / Signal type . .. .. . .. .. . 1 S-video and composite video (one buffered loop-through in the same format

Connectors . .. .. . .. .. . .. .. . .. .. .. . 1 female 4-pin mini DIN

Nominal level . .. . .. .. . .. .. . .. .. . . 1 Vp-p for Y of S-video and for composite video, 0.3 Vp-p for C of S-video

Minimum / maximum levels . . 0 V to 2.0 Vp-p

Impedance .. .. . .. .. . .. .. . .. .. . .. .. 75 ohms

Return loss . .. .. . .. .. . .. .. . .. .. .. . -30 dB @ 5 MHz

DC offset .. .. . .. .. . .. .. . .. .. . .. .. . . ±5 mV maximum

as the input, one converted output in the other format)

1 female BNC

syn c

Standards .. . .. .. . .. .. .. . .. .. . .. .. . Sync input: NTSC 3.58, NTSC 4.43, PAL, SECAM

con tro l / re Mot e

Serial control port . .. .. . .. .. . .. .. RS-232, 9-pin female D connector

Baud rate and protocol .. . .. .. . . 9600 baud, 8 data bits, 1 stop bit, no parity

Program control . .. .. .. . .. .. . .. .. Extron’s control/configuration program for Windows

Sync output: NTSC 3.58, PAL

—

tra nsc ode r / co nve rte r

Extron’s Simple Instruction Set (SIS™)

®

gen era l

External power supply . .. . .. .. . 100 VAC to 240 VAC, 50/60 Hz, external, universal; to 9 VDC, 1 A, regulated

Power input requirements .. . .. 9 VDC, 0.15 A

Rack mount . .. . .. .. . .. .. . .. .. . .. . Yes, with optional rack shelf, part #60-190-01 or 60-604-01

Enclosure type .. .. .. . .. .. . .. .. . .. Metal

Enclosure dimensions . .. .. . .. .. 1.75" H x 4.4" W x 6.5" D (1U high, quarter rack wide)

Product / shipping weight .. . .. 0.8 lbs (0.4 kg) / 3 lbs (2 kg)

4.4 cm H x 11.1 cm W x 16.5 cm D
(Depth excludes connectors and knobs.)

sPeciFicat io ns

vid eo

Gain .. .. . .. .. .. . .. .. . .. .. . .. .. . .. .. . Unity

Bandwidth .. .. . .. .. . .. .. . .. .. . .. .. 10 MHz (-3 dB)

Crosstalk . .. .. .. . .. .. . .. .. . .. .. . .. . -60 dB @ 3.58 MHz

vid eo inP Ut

Number / signal type .. . .. .. . .. . 1 NTSC/PAL S-video

Connectors . .. .. . .. .. . .. .. . .. .. .. . 1 female 4-pin mini DIN

Nominal level . .. . .. .. . .. .. . .. .. . . 1 Vp-p for Y of S-video and for composite video, 0.3 Vp-p for C of S-video

Minimum / maximum level(s) . S-video: luma: 2 Vp-p, chroma: 0.6 Vp-p

Model version d escriPtion Part #

TSC 100 Transcoder/Standards Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-451-01

oPtional accessorie s Model des criPtion Page Part #

1 NTSC/PAL composite video

1 female BNC

Composite video: 2 Vp-p with no offset

RSU 129 1U 9.5" Deep Universal Rack Shelf Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 819 60-190-01

RCAF-BNCM/10 RCA Female to BNC Male Adapter - Qty. 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 791 100-229-01

MHR-2 SVM-M/6 4-pin Mini DIN Male-Male 6' (1.8 m) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 786 26-316-02

SVHSM-BNCF 8" (20 cm) S-Video Male to 2 BNC Female Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 795 26-353-01

SVHSM-BNCM 1' (30 cm) S-Video Male to 2 BNC Male Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 795 26-353-02
