Extron electronic SMX User Manual

Specifications — SMX System MultiMatrix Switchers
Video — composite video (SMX 84/88/1616 V)
Routing
SMX 84 V ���������������������������� 8 x 4 matrix SMX 88 V ���������������������������� 8 x 8 matrix
SMX 1616 V ������������������������ 16 x 16 matrix Gain ������������������������������������������������� Unity Bandwidth �������������������������������������� 150 MHz (-3 dB), fully loaded Differential phase error ���������������� 1�0° at 3�58 MHz and 4�43 MHz Differential gain error ������������������� 1�0% at 3�58 MHz and 4�43 MHz Crosstalk ����������������������������������������� -60 dB @ 5 MHz Switching speed ���������������������������� 100 ms (max�)
Video input — composite video (SMX 84/88/1616 V)
Number/signal type ��������������������� 8 or 16 composite video Connectors ������������������������������������� 8 or 16 female BNC Nominal level �������������������������������� 1 Vp-p for composite video Minimum/maximum levels �������� Analog: 0�1 V to 2�0 Vp-p with no offset Impedance �������������������������������������� 75 ohms Return loss �������������������������������������� <-40 dB @ 5 MHz DC offset (max� allowable)����������� 1�5 V
Video output — composite video (SMX 84/88/1616 V)
Number/signal type ��������������������� 4, 8, or 16 composite video Connectors ������������������������������������� 4, 8, or 16 BNC female Nominal level �������������������������������� 1 Vp-p for composite video Minimum/maximum levels �������� 0�1 V to 2�0 Vp-p (follows input) Impedance �������������������������������������� 75 ohms Return loss �������������������������������������� <-40 dB @ 5 MHz DC offset ����������������������������������������� ±5 mV with input at 0 offset
Sync — composite video (SMX 84/88/1616 V)
Standards ���������������������������������������� NTSC 3�58, NTSC 4�43, PAL, SECAM
Video — S-video (SMX 84/88/1616 SV, SMX 84/88/1616 YC)
Routing
SMX 84 SV/YC ������������������ 8 x 4 matrix
SMX 88 SV/YC ������������������ 8 x 8 matrix
SMX 1616 SV/YC �������������� 16 x 16 matrix Gain ������������������������������������������������� Unity Bandwidth �������������������������������������� 150 MHz (-3 dB), fully loaded Differential phase error ���������������� 1�0° at 3�58 MHz and 4�43 MHz Differential gain error ������������������� 1�0% at 3�58 MHz and 4�43 MHz Crosstalk ����������������������������������������� -60 dB @ 5 MHz Switching speed ���������������������������� 100 ms (max�)
Video input — S-video (SMX 84/88/1616 SV, SMX 84/88/1616 YC)
Number/signal type ��������������������� 8 or 16 S-video Connectors
SMX 84/88/1616 SV ��������� 8 or 16 female 4-pin mini DIN
SMX 84/88/1616 YC ��������� 8 or 16 x 2 female BNC Nominal level �������������������������������� 1 Vp-p for Y S-video
0�3 Vp-p for C of S-video
Minimum/maximum levels �������� Analog: 0�1 V to 2�0 Vp-p with no offset
Extron SMX System MultiMatrix Modular, Multi-plane Matrix Switchers • Specications
1
Specifications — SMX System MultiMatrix Switchers, cont’d
Impedance �������������������������������������� 75 ohms Return loss �������������������������������������� <-40 dB @ 5 MHz DC offset (max� allowable)����������� 1�0 V
Video output — S-video (SMX 84/88/1616 SV, SMX 84/88/1616 YC)
Number/signal type ��������������������� 4, 8, or 16 S-video Connectors
SMX 84/88/1616 SV ��������� 4, 8, or 16 female 4-pin mini DIN
SMX 84/88/1616 YC ��������� 4, 8, or 16 x 2 female BNC Nominal level �������������������������������� 1 Vp-p for Y S-video
0�3 Vp-p for C of S-video Minimum/maximum levels �������� 0�1 V to 2�0 Vp-p (follows input) Impedance �������������������������������������� 75 ohms Return loss �������������������������������������� <-40 dB @ 5 MHz DC offset ����������������������������������������� ±5 mV with input at 0 offset
Sync — S-video (SMX 84/88/1616 SV, SMX 84/88/1616 YC)
Standards ���������������������������������������� NTSC 3�58, NTSC 4�43, PAL, SECAM
Video — wideband (SMX 84/88/1616 WB)
Routing
SMX 84 WB ������������������������� 8 x 4 matrix SMX 88 WB ������������������������� 8 x 8 matrix
SMX 1616 WB ��������������������� 16 x 16 matrix Gain ������������������������������������������������� Unity Bandwidth �������������������������������������� 400 MHz (-3 dB), fully loaded Crosstalk ����������������������������������������� -91 dB @ 1 MHz, -72 dB @ 5 MHz, -68 dB @ 10 MHz, -61 dB @30 MHz,
-53 dB @ 100 MHz
Switching speed ���������������������������� 200 ms (max�)
Video — wideband (SMX 84/88/1616 WB)
Number/signal type ��������������������� 8 or 16 VGA-QXGA RGBHV, RGBS, RGsB, RsGsB Connectors ������������������������������������� 8 or 16 female BNC Nominal level �������������������������������� 0�7 Vp-p for RGB Minimum/maximum levels �������� Analog: 0�3 V to 1�5 Vp-p with no offset Impedance �������������������������������������� 75 ohms Horizontal frequency �������������������� 15 kHz to 150 kHz Vertical frequency �������������������������� 30 Hz to 150 Hz Return loss �������������������������������������� <-30 dB @ 5 MHz DC offset (max� allowable)����������� 1�0 V
Video — wideband (SMX 84/88/1616 WB)
Number/signal type ��������������������� 4, 8, or 16 VGA-QXGA RGBHV, RGBS, RGsB, RsGsB Connectors ������������������������������������� 4, 8, or 16 female BNC Nominal level �������������������������������� 0�7 Vp-p for RGB Minimum/maximum levels �������� 0�3 V to 1�5 Vp-p (follows input) Impedance �������������������������������������� 75 ohms Return loss �������������������������������������� <-30 dB @ 5 MHz DC offset ����������������������������������������� ±5 mV with input at 0 offset Switching type ������������������������������� Triple-Action
2
Extron SMX System MultiMatrix Modular, Multi-plane Matrix Switchers • Specications
Sync — SMX 88 SYNC, SMX 88 H+V, SMX 1616 SYNC
Input type
SMX 88 SYNC, SMX 1616 SYNC
Composite sync (S)
SMX 88 H+V ���������������������� Separate H and V sync Output type (follows input)
SMX 88 SYNC, SMX 1616 SYNC
Composite sync (S)
SMX 88 H+V ���������������������� Separate H and V sync Input level �������������������������������������� 0�5 V to 5�0 Vp-p, 4�0 Vp-p normal Output level ����������������������������������� AGC to TTL: 4�0 V to 5�0 V p-p, unterminated Input impedance ��������������������������� 510 ohms Output impedance ������������������������ 75 ohms Horizontal frequency �������������������� 15 kHz to 150 kHz Vertical frequency �������������������������� 30 Hz to 150 Hz Max� propagation delay ��������������� 35 ns Max� rise/fall time ������������������������ 4 ns Polarity�������������������������������������������� Positive or negative (follows input)
Video — VGA (SMX 84/88/1616 VGA)
Routing
SMX 84 VGA ���������������������� 8 x 4 matrix
SMX 88 VGA ���������������������� 8 x 8 matrix
SMX 1616 VGA ������������������ 16 x 16 matrix Gain ������������������������������������������������� Unity Bandwidth �������������������������������������� 350 MHz (-3 dB), fully loaded Crosstalk ����������������������������������������� -91 dB @ 1 MHz, -72 dB @ 5 MHz, -68 dB @ 10 MHz, -61 dB @30 MHz,
-53 dB @ 100 MHz
Switching speed ���������������������������� 200 ms (max�)
Video input — VGA (SMX 84/88/1616 VGA)
Number/signal type ��������������������� 8 or 16 VGA-QXGA RGBHV, RGBS, RGsB, RsGsB Connectors ������������������������������������� 8 or 16 female 15-pin HD Nominal level �������������������������������� 0�7 Vp-p for RGB Minimum/maximum levels �������� Analog: 0�3 V to 1�5 Vp-p with no offset Impedance �������������������������������������� 75 ohms Horizontal frequency �������������������� 15 kHz to 150 kHz Vertical frequency �������������������������� 30 Hz to 150 Hz Return loss �������������������������������������� <-36 dB @ 5 MHz DC offset (max� allowable)����������� 1�0 V
Video output — VGA (SMX 84/88/1616 VGA)
Number/signal type ��������������������� 4, 8, or 16 VGA-QXGA RGBHV, RGBS, RGsB, RsGsB Connectors ������������������������������������� 4, 8, or 16 female 15-pin HD Nominal level �������������������������������� 0�7 Vp-p for RGB Minimum/maximum levels �������� 0�3 V to 1�5 Vp-p (follows input) Impedance �������������������������������������� 75 ohms Return loss �������������������������������������� <-36 dB @ 5 MHz DC offset ����������������������������������������� ±6 mV with input at 0 offset Switching type ������������������������������� Triple-Action
Extron SMX System MultiMatrix Modular, Multi-plane Matrix Switchers • Specications
3
Specifications — SMX System MultiMatrix Switchers, cont’d
Sync — VGA (SMX 84/88/1616 VGA)
Input type ��������������������������������������� RGBHV, RGBS, RGsB, RsGsBs Output type ������������������������������������ RGBHV, RGBS, RGsB, RsGsBs (follows input) Input level �������������������������������������� 0�5 V to 5�0 Vp-p, 4�0 Vp-p normal Output level ����������������������������������� AGC to TTL: 4�0 V to 5�0 V p-p, unterminated Input impedance ��������������������������� 510 ohms Output impedance ������������������������ 75 ohms Horizontal frequency �������������������� 15 kHz to 150 kHz Vertical frequency �������������������������� 30 Hz to 150 Hz Max� propagation delay ��������������� 40 ns Max� rise/fall time ������������������������ 18 ns Polarity�������������������������������������������� Positive or negative (follows input)
Digital video — SMX 44/84/88/1616 SDI
Routing
SMX 44 HD SDI ����������������� 4 x 4 matrix SMX 84 HD SDI ����������������� 8 x 4 matrix SMX 88 HD SDI ����������������� 8 x 8 matrix
SMX 1616 HD SDI ������������� 16 x 16 matrix Gain ������������������������������������������������� Unity Maximum data rate����������������������� 2�97 Gbps Data types ��������������������������������������� 8 or 10 bit Operation standards ��������������������� SMPTE 292M, SMPTE 259M, SMPTE 424M, ITU-RBT�601, ITU-RBT�1120
Digital video input — SMX 44/84/88/1616 SDI
Number/signal type ��������������������� 4, 8, or 16 single link SDI, HD-SDI; or dual link HD-SDI Connectors ������������������������������������� 4, 8, or 16 BNC female Nominal level �������������������������������� 0�80 Vp-p ± 10% Impedance �������������������������������������� 75 ohms Return loss �������������������������������������� <-15 dB @ 1 MHz to 1�5 GHz Equalization ����������������������������������� Automatic Input cable equalization distance
HD-SDI
Extron SHR, Belden 1694A cable ��������������������492' (150 m) Extron HR, Belden 1505A cable ������328' (100 m)
SDI
Extron SHR, Belden 1694A cable ��������������������984' (300 m) Extron HR, Belden 1505A cable ������656' (200 m)
N
The transmission distance varies depending on the signal resolution and on the type of cable, graphic card, and display used in the system.
Digital video output — SMX 44/84/88/1616 SDI
Number/signal type ��������������������� 4, 8, or 16 single link SDI, HD-SDI; or dual link HD-SDI Connectors ������������������������������������� 4, 8, or 16 BNC female Nominal level �������������������������������� 0�80 Vp-p ± 10% Impedance �������������������������������������� 75 ohms Return loss �������������������������������������� <-15 dB @ 1 MHz to 1�5 GHz DC offset ����������������������������������������� ±0�5 V with input at 0 offset Re-clocking ������������������������������������� Automatic, or use available bypass mode for nonstandard rates Jitter ������������������������������������������������� <0�2 VI
4
Extron SMX System MultiMatrix Modular, Multi-plane Matrix Switchers • Specications
Rise/fall time (20-80%)
SDI ��������������������������������������� 700 ps ±100 ps HD-SDI ������������������������������� 250 ps ±100 ps
Video — SMX 44/48/84/88 DVI
N
Routing
Gain ������������������������������������������������� Unity Maximum data rate����������������������� 4�95 Gbps (1�65 Gbps per color) Maximum pixel clock ������������������� 165 MHz Resolution range ��������������������������� Up to 1920x1200 @ 48, 50, or 60 Hz; or 1080p @ 60 Hz Signal type �������������������������������������� Single link DVI digital video signals are supported�
N
Standards ���������������������������������������� DVI 1�0, HDMI 1�2 Switching speed ���������������������������� 200 ns, max�
Video input — SMX 44/48/84/88 DVI
Number/signal type ��������������������� 4 or 8 (depending on model) digital RGB single link DVI-D (or HDMI*) Connectors ������������������������������������� 4 or 8 female DVI-I Equalization ����������������������������������� Automatic Input cable length ������������������������� >50' (15�24 m) at 1920x1200 @ 48, 50, or 60 Hz; or 1080p
Video output — SMX 44/48/84/88 DVI
Number/signal type ��������������������� 4 or 8 (depending on model) digital RGB single link DVI-D (or HDMI*) Connectors ������������������������������������� 4 or 8 female DVI-I Re-clocking ������������������������������������� Automatic Peripheral device power �������������� 250 mA per output
Video — SMX 44/48/84/88 DVI PRO
*Appropriate DVI-D-to-HDMI cables or adapters are required for HDMI signal input/output.
SMX 44 DVI ������������������������ 4 x 4 matrix SMX 48 DVI ������������������������ 4 x 8 matrix SMX 84 DVI ������������������������ 8 x 4 matrix SMX 88 DVI ������������������������ 8 x 8 matrix
Digital video ���������������������� RGB digital video (DVI standards), actively buffered (supports all single link
DVI standards from 640x480 @ 60 Hz to 1600x1200 @ 60 Hz computer video)
These SMX DVI Series boards are not compatible with HDMI 1.3.
Digital audio ���������������������� Not supported Consumer Electronics Control (CEC)
Not supported
EDID and DDC ������������������ Supports Extended Display Identification Data (EDID) and Display Data
Channel (DDC) data using DVI and HDMI standards� EDID and DDC
signals are actively buffered� HDCP ���������������������������������� Not supported HPD ������������������������������������� Supports hot plug detection (HPD) of display as a pass-through signal�
N
Routing
Gain ������������������������������������������������� Unity
*Appropriate DVI-D to HDMI cables or adapters are required for HDMI signal input/output.
SMX 44 DVI PRO �������������� 4 x 4 matrix SMX 48 DVI PRO �������������� 4 x 8 matrix SMX 84 DVI PRO �������������� 8 x 4 matrix SMX 88 DVI PRO �������������� 8 x 8 matrix
Extron SMX System MultiMatrix Modular, Multi-plane Matrix Switchers • Specications
5
Specifications — SMX System MultiMatrix Switchers, cont’d
Maximum data rate����������������������� 4�95 Gbps (1�65 Gbps per color) Maximum pixel clock ������������������� 165 MHz Resolution range ��������������������������� Up to 1080p (HDTV) or 1920x1200 (the highest resolution of the single link
DVI standard) @ 60 Hz
Signal type �������������������������������������� Single link DVI digital video signals are supported�
Digital video ���������������������� RGB digital video (DVI and HDMI standards) or Y, Cr, Cb digital component
video (HDMI), actively buffered (supports all single link DVI and HDMI (if using an optional adapter) standards from 640x480 @ 60 Hz to 1600x1200 @ 60 Hz computer video)
N
Maximum data rate����������������������� 4�95 Gbps (1�65 Gbps per color) Maximum pixel clock ������������������� 165 MHz Standards ���������������������������������������� DVI 1�0, HDMI 1�2 Switching speed ���������������������������� 200 ns, max�
Video input — SMX 44/48/84/88 DVI PRO
Number/signal type ��������������������� 4 or 8 (depending on model) digital RGB single link DVI-D (or HDMI*) Connectors ������������������������������������� 4 or 8 female DVI-I (digital only) Equalization ����������������������������������� Automatic Input cable length ������������������������� >50' (15�24 m) at 1920x1200 @ 48, 50, or 60 Hz; or 1080p
Video output — SMX 44/48/84/88 DVI PRO
Number/signal type ��������������������� 4 or 8 (depending on model) digital RGB single link DVI-D (or HDMI*) Connectors ������������������������������������� 4 or 8 female DVI-I (digital only) Re-clocking ������������������������������������� Automatic Peripheral device power �������������� 250 mA per output
Video — SMX 44/48/84/88 HDMI
These SMX DVI PRO Series boards are not compatible with HDMI 1.3.
Digital audio ���������������������� Supports HDMI audio (if using an HDMI to DVI adapter) transmitted
through the RGB and Y, Cr, Cb lines, actively buffered�
Consumer Electronics Control (CEC)
Supports CEC wired infrared data pass-through using the HDMI 1�2 standard�
EDID and DDC ������������������ Supports Extended Display Identification Data (EDID) and Display Data
Channel (DDC) data using DVI and HDMI standards� EDID and DDC signals are actively buffered�
HDCP ���������������������������������� Compliant with High-bandwidth Digital Content Protection (HDCP) using
DVI and HDMI 1�2 standards
HPD ������������������������������������� Supports hot plug detection (HPD) of display as a pass-through signal�
N
Routing
Gain ������������������������������������������������� Unity Maximum data rate����������������������� 4�95 Gbps (1�65 Gbps per color) Maximum pixel clock ������������������� 165 MHz Resolution range ��������������������������� Up to 1920x1200 or 1080p @ 60 Hz Signal type �������������������������������������� Single link HDMI (or DVI-D*)
6
Extron SMX System MultiMatrix Modular, Multi-plane Matrix Switchers • Specications
*Appropriate HDMI to DVI-D cables or adapters are required for DVI signal input/output.
SMX 44 HDMI ������������������� 4 x 4 matrix SMX 48 HDMI ������������������� 4 x 8 matrix SMX 84 HDMI ������������������� 8 x 4 matrix SMX 88 HDMI ������������������� 8 x 8 matrix
Digital video ���������������������� RGB digital video (DVI and HDMI standards) or Y, Cr, Cb digital component
video (HDMI), actively buffered (supports all single link DVI (if using an
optional adapter) and HDMI standards from 640x480 @ 60 Hz to 1600x1200
@ 60 Hz computer video)
N
Maximum data rate����������������������� 4�95 Gbps (1�65 Gbps per color) Maximum pixel clock ������������������� 165 MHz Standards ���������������������������������������� DVI 1�0, HDMI 1�2 Switching speed ���������������������������� 200 ns, max�
Video input — SMX 44/48/84/88 HDMI
Number/signal type ��������������������� 4 or 8 (depending on model) digital RGB single link HDMI (or DVI-D*) Connectors ������������������������������������� 4 or 8 female HDMI type A Equalization ����������������������������������� Automatic Input cable length ������������������������� >50' (15�24 m) at 1920x1200 @ 48, 50, or 60 Hz; or 1080p
Video output — SMX 44/48/84/88 HDMI
Number/signal type ��������������������� 4 or 8 (depending on model) digital RGB single link HDMI (or DVI-D*) Connectors ������������������������������������� 4 or 8 female HDMI type A Re-clocking ������������������������������������� Automatic Peripheral device power �������������� 250 mA per output
Optical specifications — SMX 88/1616 Fiber Optic I/O board
These SMX HDMI Series boards are not compatible with HDMI 1.3.
Digital audio ���������������������� Supports HDMI audio transmitted through the RGB and Y, Cr, Cb lines,
actively buffered� Consumer Electronics Control (CEC)
Supports CEC wired infrared data pass-through using the HDMI 1�2
standard� EDID and DDC ������������������ Supports Extended Display Identification Data (EDID) and Display Data
Channel (DDC) data using DVI and HDMI standards� EDID and DDC
signals are actively buffered� HDCP ���������������������������������� Compliant with High-bandwidth Digital Content Protection (HDCP) using
DVI and HDMI 1�2 standards HPD ������������������������������������� Supports hot plug detection (HPD) of display as a pass-through signal�
N
The fiber optic I/O cards are class 1 laser products. They meet the safety regulations of IEC-60825, FDA 21 CFR 1040.10, and FDA 21 CFR 1040.11.
Number/type �������������������������������� 8 or 16 single mode, or 8 or 16 multimode fiber optic inputs and outputs per
I/O card
N
Only one fiber is required to transmit video, audio, and unidirectional data. A second fiber is required to transmit return data for bidirectional control/communication.
Connectors ������������������������������������� 8 or 16 LC connectors per I/O card Operating distance ������������������������ 30 km (18�75 miles) with singlemode (SM) cables with a FOX 500 DA6 SM or
FOX 500 TX/RX SM
0�15 km (492') with multimode (MM) cables with a FOX 500 DA6 MM or
FOX 500 TX/RX MM
N
Operating distance is approximate. These are typical distances. The maximum distance may be greater than these typical numbers depending on factors such as fiber type, fiber bandwidth, connector splicing, losses, modal or chromatic dispersion,
Nominal peak wavelength����������� 850 nm for multimode (MM), 1310 nm for single mode (SM)
Extron SMX System MultiMatrix Modular, Multi-plane Matrix Switchers • Specications
7
Specifications — SMX System MultiMatrix Switchers, cont’d
Transmission power
Singlemode ������������������������� -5 dBm, typical Multimode �������������������������� -5 dBm, typical
Optical loss budget
Singlemode ������������������������� 13 dB, maximum Multimode �������������������������� 7 dB, maximum
Maximum channel data rate �������� 4�25 Gbps
Video — SMX 88/1616 Fiber Optic I/O board
Routing ������������������������������������������� 8 x 8 or 16 x 16 unidirectional (TX) matrix or
4 x 4 or 8 x 8 bidirectional (TX/RX) matrix Gain ������������������������������������������������� Unity Pixel data bit depth ����������������������� 8 bits per channel, 3 channels (R, G, B) Maximum resolution �������������������� 1600x1200 @ 60 Hz, digitized pixel for pixel; higher resolutions up to
2048x1120, undersampled
Video/audio input — SMX 88/1616 Fiber Optic I/O board
Number/signal type ��������������������� 8 or 16 fiber optic signals Connectors ������������������������������������� 8 or 16 LC connectors per I/O card
N
Input comes from an Extron FOX 500 TX transmitter, FOX 500 DA6, or FOX 500 DVI transmitter.
Video/audio output — SMX 88/1616 Fiber Optic I/O board
Number/signal type ��������������������� 8 or 16 fiber optic signals Connectors ������������������������������������� 8 or 16 LC connectors per I/O card
N
Audio — SMX 84/88/1616A (analog)
Routing
Gain ������������������������������������������������� Unbalanced output: -6 dB; balanced output 0 dB Frequency response ���������������������� 20 Hz to 20 kHz, ±0�05 dB THD + Noise ���������������������������������� 0�03% @ 1 kHz, 0�3% @ 20 kHz at nominal level S/N �������������������������������������������������� >102 dB at maximum output (21 dBu, unweighted) (balanced) Crosstalk ����������������������������������������� <-95 dB @ 1 kHz, fully loaded Stereo channel separation ������������ >98 dB @ 1 kHz CMRR ���������������������������������������������� >70 dB @ 20 Hz to 20 kHz
Audio input — SMX 84/88/1616 A (analog)
Number/signal type ��������������������� 8 or 16 stereo, balanced/unbalanced Connectors ������������������������������������� (8 or 16) 3�5 mm captive screw connector, 5 pole Impedance �������������������������������������� >10k ohms unbalanced/balanced, DC coupled Nominal level �������������������������������� 0 dBu (0�775 Vrms) Maximum level ������������������������������ +19�5 dBu, (balanced or unbalanced) at 1% THD+N Input gain adjustment ������������������ –18 dB to +24 dB, adjustable per input; default = 0 dB
Output connects to an Extron FOX 500 RX receiver or FOX 500 DVI receiver.
SMX 84 A ���������������������������� 8 x 4 stereo matrix SMX 88 A ���������������������������� 8 x 8 stereo matrix SMX 1616 A ������������������������ 16 x 16 stereo matrix
N
8
Extron SMX System MultiMatrix Modular, Multi-plane Matrix Switchers • Specications
0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu
Audio output — SMX 84/88/1616 A (analog)
Number/signal type ��������������������� 8 or 16 stereo, balanced/unbalanced Connectors ������������������������������������� (8 or 16) 3�5 mm captive screw connector, 5 pole Impedance �������������������������������������� 50 ohms unbalanced, 100 ohms balanced Gain error ��������������������������������������� ±0�1 dB channel to channel Maximum level (Hi-Z) ����������������� >+21 dBu, balanced or unbalanced at 0�1% THD+N Maximum level (600 ohm) ����������� >+15 dBm, balanced or unbalanced at 0�1% THD+N Volume control range ������������������� -85 dB to 0 dB (volume numbers 0 through 64) in a 35 dB increment from
step 0 to step 1, then in 1 dB increments from steps 1 to 64; default = 64 (0 dB)
N
Control/remote — switcher host ports
Serial host control port ����������������� 1 bidirectional RS-232 or RS-422, rear panel 9-pin female D connector
Baud rate and protocol ����������������� 9600 (default), 19200, 38400, 115200 baud (rear port only), adjustable; 8 data
Serial control pin configurations
Ethernet control port��������������������� 1 RJ-45 female Ethernet data rate (for network communication)
Ethernet protocol ��������������������������� ARP, DHCP, ICMP (ping), TCP/IP, Telnet, HTTP, SMTP Ethernet default settings �������������� Link speed and duplex level = autodetected
Web server �������������������������������������� Up to 200 simultaneous sessions
Program control ����������������������������� Extron's control/configuration program for Windows
General
Power ���������������������������������������������� 100 VAC to 240 VAC, 50/60 Hz, 180 watts, internal Temperature/humidity ���������������� Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Cooling ������������������������������������������� Fan, left to right (as viewed from front panel) Rack mount ������������������������������������ Yes Enclosure type ������������������������������� Metal Enclosure dimensions ������������������� (Depth excludes connectors� Width excludes rack ears�)
Attenuation = volume number minus 64. The default is 0 dB = volume number 64.
1 bidirectional RS-232 front panel 2�5 mm mini stereo jack
bits, 1 stop bit, no parity
9-pin female D connector
RS-232 ������������������������� 2 = TX, 3 = RX, 5 = GND RS-422 ������������������������� 2 = TX-, 3 = RX-, 5 = GND, 7 = RX+, 8 = Tx+
Mini stereo jack
RS-232 ������������������������� Tip = TX, ring = RX, sleeve = GND
10/100Base-T, half/full duplex with autodetect
IP address = 192�168�254�254 Subnet mask = 255�255�0�0 Default gateway = 0�0�0�0 DHCP = off
7�0 MB nonvolatile user memory
®
Extron's Simple Instruction Set (SIS™) Microsoft® Internet Explorer ver� 6 or higher, Telnet
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
SMX 300 BME �������������������� 5�25" H x 17�0" W x 12" D (3U high, full rack wide)
(13�3 cm H x 43�2 cm W x 30�5 cm D)
SMX 400 BME �������������������� 7�0" H x 17�0" W x 12" D (4U high, full rack wide)
(17�8 cm H x 43�2 cm W x 30�5 cm D)
SMX 500 BME �������������������� 8�75" H x 17�0" W x 12" D (5U high, full rack wide)
(22�2 cm H x 43�2 cm W x 30�5 cm D)
Extron SMX System MultiMatrix Modular, Multi-plane Matrix Switchers • Specications
9
Specifications — SMX System MultiMatrix Switchers, cont’d
Product weight with cards installed
SMX 300 BME �������������������� 18�1 lbs (8�2 kg) SMX 400 BME �������������������� 20�3 lbs (9�2 kg) SMX 500 BME �������������������� 23�9 lbs (10�8 kg)
Shipping weight with cards installed
SMX 300 BME �������������������� 22 lbs (10 kg) SMX 400 BME �������������������� 26 lbs (12 kg) SMX 500 BME �������������������� 30 lbs (14 kg)
DIM weight with cards installed, all models
25 lbs (12 kg) Vibration ����������������������������������������� ISTA 1A in carton (International Safe Transit Association) Regulatory compliance
Safety ����������������������������������� CE, CUL, UL
EMI/EMC �������������������������� CE, C-tick, FCC Class A, ICES, VCCI MTBF ����������������������������������������������� 30,000 hours Warranty ����������������������������������������� 3 years parts and labor
N
N
All nominal levels are at ±10%.
Specifications are subject to change without notice.
7.6-112008-D8
10
Extron SMX System MultiMatrix Modular, Multi-plane Matrix Switchers • Specications
Loading...
