Extron electronic SF 228T User Manual

SF 228T

2’ x 2’ Ceiling Speakers

User Guide

Audio Products

68-2018-01 Rev. A

05 11

Safety Instructions • English

This symbol is intended to alert the user of important operating and mainte­nance (servicing) instructions in the literature provided with the equipment.

This symbol is intended to alert the user of the presence of uninsulated
dangerous voltage within the product feets enclosure that may present a risk
of electric shock.

Caution

Read Instructions • Read and understand all safety and operating instructions before using the equipment.
