MDA Series

Composite Video, S-Video, and Audio Mini Distribution Amplifiers

A u D i o / vi De o D i s t r i b u t i o n A mp li f i e r s

Commo n feAture s

•

Rack mountable 1U, quarter rack width metal enclosure

•

Versatile mounting options including rack, projector, and under-desk mounts

•

External universal power supply included, part # 70-055-01

DesCr iPtion

The Extr on MDA Series consists of one input, three or five outp ut composite video,
S-video, or stereo audio Mini Distribution Amplifiers. Both composite video and S-video models
output an amplified signal up to 150 feet (45 meters).

Part of the VersaTools® line of economical, compact products, MDA Series mini distribution
amplifiers are rack or under-desk mountable and include an external international power supply.
Their small size makes them the ideal solution for easy integration into both new and existing
A/V systems including boardrooms, training facilities, home theater, command and control
centers, and rental and staging environments.

Continued

513

www.extron.com

© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.

USA West

+1.714.491.1500 / +80 0.633.9876
+1.714.491.1517 FAX

USA East

+1.919.86 3.1794 / +80 0.633.9876
+1.919.86 3.1797 FA X

China

+ 86.21.3760.1568 / +4 00.883.1568
+ 86.21.3760.1566 FAX

Japan

+81.3. 3511.7655
+81.3. 3511.7656 FAX

Europe

+31.33 .453.4 040 / +800. 3987.6673
+31.33 .453.4 050 FA X

Dubai

+97 1.4.299 1800
+97 1.4.299 1880 FAX

Asia

+65.6 383.440 0 / +800.7339. 8766
+65.6 383.4664 FAX

A u D i o / vi De o D i s t r i b u t i o n A mp li f i e r s

MDA Series

Composite Video Models

MDA 3V

Three Output Composite Video Mini Distribution Amplifier

uni que feAt ure s

•

Accepts and distributes composite video on female BNC connectors

•

435 MHz (-3 dB) video bandwidth, fully loaded

moDeL version D esCriPtion PArt #

MDA 3V 1x3 Composite Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-439-01

MDA 3V Dual

Dual Three Output Composite Video Mini Distribution Amplifier

uni que feAt ure s

•

Accepts and distributes composite video on female BNC connectors

•

Two distribution amplifiers in a single enclosure

•

435 MHz (-3 dB) video bandwidth, fully loaded

moDeL version D esCriPtion PArt #

MDA 3V Dual Dual 1x3 Composite Video. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-439-10

MDA 3AV

Three Output Composite Video with Stereo Audio
Mini Distribution Amplifier

uni que feAt ure s

•

Accepts and distributes composite video on female BNC connectors

•

Balanced and unbalanced audio on captive screw connectors

•

Audio output gain dip switch to maintain unity gain

•

435 MHz (-3 dB) video bandwidth, fully loaded

moDeL version D esCriPtion PArt #

MDA 3AV 1x3 Composite w/Stereo Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-439-20

MDA 5V

Five Output Composite Video Mini Distribution Amplifier

uni que feAt ure s

•

Accepts and distributes composite video on female BNC connectors

•

Balanced and unbalanced audio on captive screw connectors

•

Input loop-through

•

435 MHz (-3 dB) video bandwidth, fully loaded

moDeL version D esCriPtion PArt #

MDA 5V 1x5 Composite Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-446-01

514

Continued

China

+ 86.21.3760.1568 / +4 00.883.1568
+ 86.21.3760.1566 FAX

Japan

+81.3. 3511.7655
+81.3. 3511.7656 FAX

Europe

+31.33 .453.4 040 / +800. 3987.6673
+31.33 .453.4 050 FA X

Dubai

+97 1.4.299 1800
+97 1.4.299 1880 FAX

Asia

+65.6 383.440 0 / +800.7339. 8766
+65.6 383.4664 FAX

China

+ 86.21.3760.1568 / +4 00.883.1568
+ 86.21.3760.1566 FAX

Japan

+81.3. 3511.7655
+81.3. 3511.7656 FAX

Europe

+31.33 .453.4 040 / +800. 3987.6673
+31.33 .453.4 050 FA X

Dubai

+97 1.4.299 1800
+97 1.4.299 1880 FAX

Asia

+65.6 383.440 0 / +800.7339. 8766
+65.6 383.4664 FAX

A u D i o / vi De o D i s t r i b u t i o n A mp li f i e r s

MDA Series

S-Video Models

MDA 3SV

Three Output S-Video Mini Distribution Amplifier

uni que feAt ure s

•

Accepts and distributes S-video on female 4-pin mini DIN connectors

•

270 MHz (-3 dB) video bandwidth, fully loaded

moDeL version D esCriPtion PArt #

MDA 3SV 1x3 S-Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-444-01

MDA 3SVA

Three Output S-Video with Stereo Audio
Mini Distribution Amplifier

uni que feAt ure s

•

Accepts and distributes S-video on female 4-pin mini DIN connectors

•

Balanced and unbalanced audio on captive screw connectors

•

Audio output gain dip switch to maintain unity gain

•

270 MHz (-3 dB) video bandwidth, fully loaded

moDeL version D esCriPtion PArt #

MDA 3SVA 1x3 S-Video w/Stereo Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-444-20

MDA 5SV

Five Output S-Video Mini Distribution Amplifier

uni que feAt ure s

•

Accepts and distributes S-video on female 4-pin mini DIN connectors

•

Input loop-through

•

270 MHz (-3 dB) video bandwidth, fully loaded

moDeL version D esCriPtion PArt #

MDA 5SV 1x5 S-Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-447-01

Continued

515

www.extron.com

© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.

USA West

+1.714.491.1500 / +80 0.633.9876
+1.714.491.1517 FAX

USA East

+1.919.86 3.1794 / +80 0.633.9876
+1.919.86 3.1797 FA X

China

+ 86.21.3760.1568 / +4 00.883.1568
+ 86.21.3760.1566 FAX

Japan

+81.3. 3511.7655
+81.3. 3511.7656 FAX

Europe

+31.33 .453.4 040 / +800. 3987.6673
+31.33 .453.4 050 FA X

Dubai

+97 1.4.299 1800
+97 1.4.299 1880 FAX

Asia

+65.6 383.440 0 / +800.7339. 8766
+65.6 383.4664 FAX

A u D i o / vi De o D i s t r i b u t i o n A mp li f i e r s

MDA Series

Stereo Audio Models

MDA 3A

Three Output Stereo Audio Mini Distribution Amplifier

uni que feAt ure s

•

Accepts and distributes balanced or unbalanced line level stereo audio

•

Audio output gain dip switch to maintain unity gain between balanced and

unbalanced signals

moDeL version D esCriPtion PArt #

MDA 3A 1x3 Stereo Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-440-01

MDA 5A RCA

Five Output Stereo Audio Mini Distribution Amplifier

uni que feAt ure s

•

Accepts and distributes unbalanced audio on RCA jacks

moDeL version D esCriPtion PArt #

MDA 5A RCA 1x5 Stereo Audio on RCAs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-441-01

MDA Series Accessories

oPtionAL ACCessories moDeL Des CriPtion PAGe PArt #

RSU 129 1U 9.5" Deep Universal Rack Shelf Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 819 60-190-01

RSF 123 1U 3.5" Deep VersaTools® Rack Shelf Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 818 60-190-20

RSB 129 1U 9.5" Deep Basic Rack Shelf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 820 60-604-01

PMK 100 One VersaTools®, 1/4 Rack Width Mini Projector Mounting Kit . . . . . . . . . . . . . . . . . . . page 813 70-217-01

516

Continued

China

+ 86.21.3760.1568 / +4 00.883.1568
+ 86.21.3760.1566 FAX

Japan

+81.3. 3511.7655
+81.3. 3511.7656 FAX

Europe

+31.33 .453.4 040 / +800. 3987.6673
+31.33 .453.4 050 FA X

Dubai

+97 1.4.299 1800
+97 1.4.299 1880 FAX

Asia

+65.6 383.440 0 / +800.7339. 8766
+65.6 383.4664 FAX

China

+ 86.21.3760.1568 / +4 00.883.1568
+ 86.21.3760.1566 FAX

Japan

+81.3. 3511.7655
+81.3. 3511.7656 FAX

Europe

+31.33 .453.4 040 / +800. 3987.6673
+31.33 .453.4 050 FA X

Dubai

+97 1.4.299 1800
+97 1.4.299 1880 FAX

Asia

+65.6 383.440 0 / +800.7339. 8766
+65.6 383.4664 FAX

MDA Series

A u D i o / vi De o D i s t r i b u t i o n A mp li f i e r s

sPeCi fiCAtions

viD eo

Gain .. .. . .. .. .. . .. .. . .. .. . .. .. . .. .. . Unity

Bandwidth

MDA 3SV/3SVA,

. .. . .. .. . .. .. . .. .. .. . .. .. . 270 MHz (-3 dB)

MDA 5SV
MDA 3V/3AV/3V Dual,

.. .. . .. .. . .. .. . .. .. .. . .. .. . . 435 MHz (-3 dB)

MDA 5V

viD eo i nPu t

Number / Signal type

MDA 3SV/3SVA, MDA 5SV
MDA 3V/3AV, MDA 5V
MDA 3V Dual

Connectors

MDA 3SV/3SVA, MDA 5SV
MDA 3V/3AV, MDA 5V
MDA 3V Dual

Nominal level . .. . .. .. . .. .. . .. .. . . 1 Vp-p for Y of S-video and for composite video

Minimum / Maximum levels .. . 0.4 V to 2.0 Vp-p for composite video or Y of S-video with no offset

Impedance .. .. . .. .. . .. .. . .. .. . .. .. 75 ohms

Return loss

MDA 3SV/3SVA, MDA 5SV,
All other models

DC offset (max. allowable) .. .. .. . 5.0 V

Input coupling .. .. . .. .. . .. .. . .. .. . AC

viD eo o utP ut

Number / Signal type

MDA 3SV/3SVA

. .. . .. .. . .. .. . .. .. .. . .. .. . 6 S-video: 5 buffered for distribution, 1 passive loop-through

MDA 5SV

. .. . .. .. . .. .. . .. .. .. . . 3 buffered composite video

MDA 3V/3AV
MDA 3V Dual

.. .. . .. .. . .. .. . .. .. .. . .. .. . . 6 composite video: 5 buffered for distribution, 1 passive loop-through

MDA 5V

Connectors

MDA 3SV/3SVA

. .. . .. .. . .. .. . .. .. .. . .. .. . (6) 4-pin mini DIN female

MDA 5SV

. .. . .. .. . .. .. . .. .. .. . . 3 BNC female

MDA 3V/3AV
MDA 3V Dual

.. .. . .. .. . .. .. . .. .. .. . .. .. . . 6 BNC female

MDA 5V

Nominal level . .. . .. .. . .. .. . .. .. . . 1 Vp-p for Y of S-video and for composite video

Minimum / Maximum levels .. . 0.4 V to 2.0 Vp-p, follows input

Impedance .. .. . .. .. . .. .. . .. .. . .. .. 75 ohms

Return loss . .. .. . .. .. . .. .. . .. .. .. . <-30 dB @ 5 MHz

DC offset .. .. . .. .. . .. .. . .. .. . .. .. . . ±50 mV with input at 0 offset

syn C

Standards .. . .. .. . .. .. .. . .. .. . .. .. . NTSC 3.58, NTSC 4.43, PAL, SECAM

AuD io ( MDA 3AV, MD A 3SVA , MD A 3A, MDA 5A R CA)

Gain

DIP switch set to match

. .. .. . .. .. . .. .. .. . .. .. . .. Unity (0 dB)

output type
DIP switch not matched
to output type

Frequency response .. .. . .. .. . .. 20 Hz to 20 kHz, ±0.05 dB

THD + Noise .. . .. .. . .. .. . .. .. . .. .. 0.03% @ 1 kHz at nominal level

S/N

.. . .. .. .. . .. .. . .. .. . .. >90 dB, unbalanced, at maximum output

MDA 5A RCA
All other models w/audio

Stereo channel separation . .. . >80 dB @ 1 kHz; >60 dB @ 20 kHz

CMRR .. .. .. . .. .. . .. .. . .. .. . .. .. . .. . >75 dB @ 20 Hz to 20 kHz

AuD io i nPu t (M DA 3A V, MDA 3SVA, MDA 3A, MDA 5 A RC A)

Number / Signal type

.. . .. .. .. . .. .. . .. .. . .. 1 stereo unbalanced

MDA 5A RCA
MDA 3AV, MDA 3SVA,

. .. .. . .. .. . .. .. . .. .. .. . .. .. . 1 stereo balanced/unbalanced

MDA 3A

Connectors

.. . .. .. .. . .. .. . .. .. . .. 2 RCA connectors

MDA 5A RCA
MDA 3AV, MDA 3SVA,

. .. .. . .. .. . .. .. . .. .. .. . .. .. . (1) 3.5 mm captive screw connector, 5 pole

MDA 3A

.. .. .. 1 S-video

.. . .. .. . .. .. 1 composite video

.. .. . .. .. . .. .. .. . .. .. . 2 composite video

.. . .. .. (1) 4-pin mini DIN female

.. . .. .. . .. .. 1 BNC female

.. .. . .. .. . .. .. .. . .. .. . 2 BNC female

0.3 Vp-p for C of S-video

.. . .. .. . .. .. . .. .. . . <-27 dB @ 5 MHz

. .. .. . .. .. . .. .. . .. . 3 buffered S-video

.. .. . .. .. . .. .. .. . .. .. . 2 x 3 buffered composite video

. .. .. . .. .. . .. .. . .. . (3) 4-pin mini DIN female

.. .. . .. .. . .. .. .. . .. .. . 6 BNC female

0.3 Vp-p for C of S-video

. .. .. . .. .. . .. .. .. . .. .. See the table below.

DIP Switch Setting

Balanced 0 dB -6 dB

Unbalanced +6 dB 0 dB

Unbalanced Balanced

.. . .. .. . . >90 dB, balanced at maximum output

Output Wiring

Impedance

.. . .. .. .. . .. .. . .. .. . .. >10k ohms unbalanced, DC coupled

MDA 5A RCA
MDA 3AV, MDA 3SVA,

. .. .. . .. .. . .. .. . .. .. .. . .. .. . >50k ohms unbalanced, >25k ohms balanced, DC coupled

MDA 3A

Nominal level . .. . .. .. . .. .. . .. .. . . +4 dBu (1.23V), 0 dBu (0.775 V), -10 dBV (316 mV), -20 dBV (100 mV)

Maximum level

.. . .. .. .. . .. .. . .. .. . .. +17 dBu (unbalanced) at 1%THD+N

MDA 5A RCA
All other models w/audio

NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu

AuD io o utP ut ( MDA 3AV, MDA 3SVA , MDA 3A, MDA 5A R CA)

Number / Signal type

.. . .. .. .. . .. .. . .. .. . .. 5 stereo, unbalanced

MDA 5A RCA
MDA 3AV, MDA 3SVA,

. .. .. . .. .. . .. .. . .. .. .. . .. .. . 3 stereo, balanced/unbalanced

MDA 3A

Connectors

.. . .. .. .. . .. .. . .. .. . .. 10 RCA connectors

MDA 5A RCA
MDA 3AV, MDA 3SVA,

. .. .. . .. .. . .. .. . .. .. .. . .. .. . (3) 3.5 mm captive screw connectors, 5 pole

MDA 3A

Impedance

.. . .. .. .. . .. .. . .. .. . .. 50 ohms unbalanced

MDA 5A RCA
MDA 3AV, MDA 3SVA,

. .. .. . .. .. . .. .. . .. .. .. . .. .. . 50 ohms unbalanced, 100 ohms balanced

MDA 3A

Gain error .. .. . .. .. . .. .. . .. .. .. . .. . ±0.1 dB channel to channel

Maximum level (Hi-Z)

.. . .. .. .. . .. .. . .. .. . .. +15 dBV, unbalanced, at 1%THD+N

MDA 5A RCA
All other models w/audio
Maximum level (600 ohm)
MDA 3A/5A RCA
All other models w/audio

Gen erAL

.. .. . .. .. .. . .. .. . . >+14 dBm, unbalanced, at 1%THD+N

External power supply . .. . .. .. . 100 VAC to 240 VAC, 50/60 Hz, 5 watts, external, universal; to 12 VDC,

Power input requirements

MDA 3V/3SV/5V/5SV
MDA 3AV/3SVA
All other models

Temperature / Humidity .. .. . .. . Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

. .. .. . .. .. . .. .. . .. . 12 VDC, 0.3 A (max.)

.. . .. .. . .. .. . .. .. . . 12 VDC, 0.2 A (max.)

Rack mount . .. . .. .. . .. .. . .. .. . .. . Yes, with optional 1U rack shelf, part #60-190-01, or 60-604-01; or the

Enclosure type .. .. .. . .. .. . .. .. . .. Metal

Enclosure dimensions . .. .. . .. .. 1.7" H x 4.3" W x 3.0" D (1U high, quarter rack wide)

Product weight

MDA 3V, MDA 3SVA

. .. . .. .. . .. .. . .. .. . .. .. .. . 0.6 lbs (0.3 kg)

MDA 3AV
MDA 5V, MDA 5SV
MDA 3SV
MDA 3A
MDA 5A RCA

Shipping weight

MDA 3V, MDA 3V Dual
MDA 3AV, MDA 5V
MDA 3SV
MDA 3SVA, MDA 5SV
MDA 5A RCA

Vibration . .. .. . .. .. . .. .. . .. .. . .. .. . ISTA 1A in carton (International Safe Transit Association)

Listings .. . .. .. . .. .. . .. .. . .. .. . .. .. . UL, CUL

Compliances . .. .. . .. .. . .. .. . .. .. . CE, FCC Class A, VCCI, AS/NZS, ICES

MTBF . .. .. . .. .. . .. .. . .. .. . .. .. . .. .. 30,000 hours

Warranty .. . .. .. .. . .. .. . .. .. . .. .. . . 3 years parts and labor

NOTE: All nominal levels are at ±10%. Specifications are subject to change without notice.

.. . .. .. . .. .. . .. . 0.5 lbs (0.2 kg)

. .. . .. .. . .. .. . .. .. .. . .. .. . 0.4 lbs (0.2 kg)

. .. .. . .. .. . .. .. . .. .. .. . .. .. . 0.5 lbs (0.2 kg)

.. . .. .. .. . .. .. . .. .. . .. 0.4 lbs (0.2 kg)

.. . .. .. . .. .. . .. . 3 lbs (2 kg)

. .. . .. .. . .. .. . .. .. .. . .. .. . 2 lbs (1 kg)

.. . .. .. .. . .. .. . .. .. . .. 2 lbs (1 kg)

compatible

.. . .. .. . . +24 dBu (balanced) at 1%THD+N

.. . .. .. . . >+24 dBu, balanced at 1%THD+N

.. . .. .. . . >+15 dBm, balanced or unbalanced, at 1%THD+N

1 A (max.), regulated

. .. .. .. . .. .. . 12 VDC, 0.1 A (max.)

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

VersaTools® rack shelf, part #60-190-20, or 60-604-20

4.2 cm H x 11.0 cm W x 7.6 cm D (Depth excludes connectors and knobs.)

.. . .. .. . .. .. . . 0.4 lbs (0.2 kg)

. .. .. . .. .. . 3 lbs (2 kg)

. .. .. . .. .. . . 2 lbs (1 kg)

517
