Extron electronic 200, 300, PVS 400, 400 User Manual 3
PoleVault Systems
Installation Guide for the PVS 200, 300, and 400
68-1390-01
Rev. D
03 09
Precautions
Safety Instructions • English
This symbol is intended to alert the user of important operating and maintenance
(servicing) instructions in the literature provided with the equipment.
This symbol is intended to alert the user of the presence of uninsulated dangerous
voltage within the product’s enclosure that may present a risk of electric shock.
Caution
Read Instructions • Read and understand all safety and operating instructions before using the equipment.
Retain Instructions • The safety instructions should be kept for future reference.
Follow Warnings • Follow all warnings and instructions marked on the equipment or in the user
information.
Avoid Attachments • Do not use tools or attachments that are not recommended by the equipment
manufacturer because they may be hazardous.
Consignes de Sécurité • Français
Ce symbole sert à avertir l’utilisateur que la documentation fournie avec le matériel
contient des instructions importantes concernant l’exploitation et la maintenance
(réparation).
Ce symbole sert à avertir l’utilisateur de la présence dans le boîtier de l’appareil
de tensions dangereuses non isolées posant des risques d’électrocution.
Attention
Lire les instructions• Prendre connaissance de toutes les consignes de sécurité et d’exploitation avant
d’utiliser le matériel.
Conserver les instructions• Ranger les consignes de sécurité afin de pouvoir les consulter à l’avenir.
Respecter les avertissements • Observer tous les avertissements et consignes marqués sur le matériel ou
présentés dans la documentation utilisateur.
Eviter les pièces de xation • Ne pas utiliser de pièces de fixation ni d’outils non recommandés par le
fabricant du matériel car cela risquerait de poser certains dangers.
Sicherheitsanleitungen • Deutsch
Dies es Symbol soll dem Benut zer in der im Liefer umfang ent haltenen
Dokumentation besonders wichtige Hinweise zur Bedienung und Wartung
(Instandhaltung) geben.
Dieses Symbol soll den Benutzer darauf aufmerksam machen, daß im Inneren des
Gehäuses dieses Produktes gefährliche Spannungen, die nicht isoliert sind und
die einen elektrischen Schock verursachen können, herrschen.
Achtung
Lesen der Anleitungen • Bevor Sie das Gerät zum ersten Mal verwenden, sollten Sie alle Sicherheits-und
Bedienungsanleitungen genau durchlesen und verstehen.
Aufbewahren der Anleitungen • Die Hinweise zur elektrischen Sicherheit des Produktes sollten Sie
aufbewahren, damit Sie im Bedarfsfall darauf zurückgreifen können.
Befolgen der Warnhinweise • Befolgen Sie alle Warnhinweise und Anleitungen auf dem Gerät oder in der
Benutzerdokumentation.
Keine Zusatzgeräte • Verwenden Sie keine Werkzeuge oder Zusatzgeräte, die nicht ausdrücklich vom
Hersteller empfohlen wurden, da diese eine Gefahrenquelle darstellen können.
Warning
Power sources • This equipment should be operated only from the power source indicated on the product. This
equipment is intended to be used with a main power system with a grounded (neutral) conductor. The
third (grounding) pin is a safety feature, do not attempt to bypass or disable it.
Power disconnection • To remove power from the equipment safely, remove all power cords from the rear of
the equipment, or the desktop power module (if detachable), or from the power source receptacle (wall
plug).
Power cord protection • Power cords should be routed so that they are not likely to be stepped on or pinched by
items placed upon or against them.
Servicing • Refer all servicing to qualified service personnel. There are no user-serviceable parts inside. To
prevent the risk of shock, do not attempt to service this equipment yourself because opening or removing
covers may expose you to dangerous voltage or other hazards.
Slots and openings • If the equipment has slots or holes in the enclosure, these are provided to prevent
overheating of sensitive components inside. These openings must never be blocked by other objects.
Lithium battery • There is a danger of explosion if battery is incorrectly replaced. Replace it only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the
manufacturer’s instructions.
Avertissement
Alimentations• Ne faire fonctionner ce matériel qu’avec la source d’alimentation indiquée sur l’appareil. Ce
matériel doit être utilisé avec une alimentation principale comportant un fil de terre (neutre). Le troisième
contact (de mise à la terre) constitue un dispositif de sécurité : n’essayez pas de la contourner ni de la
désactiver.
Déconnexion de l’alimentation• Pour mettre le matériel hors tension sans danger, déconnectez tous les cordons
d’alimentation de l’arrière de l’appareil ou du module d’alimentation de bureau (s’il est amovible) ou
encore de la prise secteur.
Protection du cordon d’alimentation • Acheminer les cordons d’alimentation de manière à ce que personne ne
risque de marcher dessus et à ce qu’ils ne soient pas écrasés ou pincés par des objets.
Réparation-maintenance • Faire exécuter toutes les interventions de réparation-maintenance par un technicien
qualifié. Aucun des éléments internes ne peut être réparé par l’utilisateur. Afin d’éviter tout danger
d’électrocution, l’utilisateur ne doit pas essayer de procéder lui-même à ces opérations car l’ouverture ou le
retrait des couvercles risquent de l’exposer à de hautes tensions et autres dangers.
Fentes et orices • Si le boîtier de l’appareil comporte des fentes ou des orifices, ceux-ci servent à empêcher
les composants internes sensibles de surchauffer. Ces ouvertures ne doivent jamais être bloquées par des
objets.
Lithium Batterie • Il a danger d’explosion s’ll y a remplacment incorrect de la batterie. Remplacer uniquement
avec une batterie du meme type ou d’un ype equivalent recommande par le constructeur. Mettre au reut les
batteries usagees conformement aux instructions du fabricant.
Vorsicht
Stromquellen • Dieses Gerät sollte nur über die auf dem Produkt angegebene Stromquelle betrieben werden.
Dieses Gerät wurde für eine Verwendung mit einer Hauptstromleitung mit einem geerdeten (neutralen)
Leiter konzipiert. Der dritte Kontakt ist für einen Erdanschluß, und stellt eine Sicherheitsfunktion dar. Diese
sollte nicht umgangen oder außer Betrieb gesetzt werden.
Stromunterbrechung • Um das Gerät auf sichere Weise vom Netz zu trennen, sollten Sie alle Netzkabel
aus der Rückseite des Gerätes, aus der externen Stomversorgung (falls dies möglich ist) oder aus der
Wandsteckdose ziehen.
Schutz des Netzkabels • Netzkabel sollten stets so verlegt werden, daß sie nicht im Weg liegen und niemand
darauf treten kann oder Objekte darauf- oder unmittelbar dagegengestellt werden können.
Wartung • Alle Wartungsmaßnahmen sollten nur von qualiziertem Servicepersonal durchgeführt werden.
Die internen Komponenten des Gerätes sind wartungsfrei. Zur Vermeidung eines elektrischen Schocks
versuchen Sie in keinem Fall, dieses Gerät selbst öffnen, da beim Entfernen der Abdeckungen die Gefahr
eines elektrischen Schlags und/oder andere Gefahren bestehen.
Schlitze und Öffnungen • Wenn das Gerät Schlitze oder Löcher im Gehäuse aufweist, dienen diese zur
Vermeidung einer Überhitzung der empndlichen Teile im Inneren. Diese Öffnungen dürfen niemals von
anderen Objekten blockiert werden.
Litium-Batterie • Explosionsgefahr, falls die Batterie nicht richtig ersetzt wird. Ersetzen Sie verbrauchte
Batterien nur durch den gleichen oder einen vergleichbaren Batterietyp, der auch vom Hersteller
empfohlen wird. Entsorgen Sie verbrauchte Batterien bitte gemäß den Herstelleranweisungen.
Instrucciones de seguridad • Español
Este símbolo se utiliza para advertir al usuario sobre instrucciones importantes
de operación y mantenimiento (o cambio de partes) que se desean destacar en el
contenido de la documentación suministrada con los equipos.
Este símbolo se utiliza para advertir al usuario sobre la presencia de elementos con
voltaje peligroso sin protección aislante, que puedan encontrarse dentro de la caja
o alojamiento del producto, y que puedan representar riesgo de electrocución.
Precaucion
Leer las instrucciones • Leer y analizar todas las instrucciones de operación y seguridad, antes de usar el
equipo.
Conservar las instrucciones • Conservar las instrucciones de seguridad para futura consulta.
Obedecer las advertencias • Todas las advertencias e instrucciones marcadas en el equipo o en la
documentación del usuario, deben ser obedecidas.
Evitar el uso de accesorios • No usar herramientas o accesorios que no sean especificamente recomendados
por el fabricante, ya que podrian implicar riesgos.
安全须知 • 中文
这个符号提示用户该设备用户手册中有重要的操作和维护说明。
这个符号警告用户该设备机壳内有暴露的危险电 压，有触电危险。
注意
阅读说明书 • 用户使用该设备前必须阅读并理解所有安全和使用说明。
保存说明书 • 用户应保存安全 说明书以备将来使用。
遵守警告 • 用户应遵守产品和用户 指南上的所有安全和 操作说明。
避免追加 • 不要使用该产品厂商没有推荐的工具或追加设备，以避免危险。
Advertencia
Alimentación eléctrica • Este equipo debe conectarse únicamente a la fuente/tipo de alimentación eléctrica
indicada en el mismo. La alimentación eléctrica de este equipo debe provenir de un sistema de distribución
general con conductor neutro a tierra. La tercera pata (puesta a tierra) es una medida de seguridad, no
puentearia ni eliminaria.
Desconexión de alimentación eléctrica • Para desconectar con seguridad la acometida de alimentación eléctrica
al equipo, desenchufar todos los cables de alimentación en el panel trasero del equipo, o desenchufar el
módulo de alimentación (si fuera independiente), o desenchufar el cable del receptáculo de la pared.
Protección del cables de alimentación • Los cables de alimentación eléctrica se deben instalar en lugares donde
no sean pisados ni apretados por objetos que se puedan apoyar sobre ellos.
Reparaciones/mantenimiento • Solicitar siempre los servicios técnicos de personal calicado. En el interior no
hay partes a las que el usuario deba acceder. Para evitar riesgo de electrocución, no intentar personalmente
la reparación/mantenimiento de este equipo, ya que al abrir o extraer las tapas puede quedar expuesto a
voltajes peligrosos u otros riesgos.
Ranuras y aberturas • Si el equipo posee ranuras o orificios en su caja/alojamiento, es para evitar el
sobrecalientamiento de componentes internos sensibles. Estas aberturas nunca se deben obstruir con otros
objetos.
Batería de litio • Existe riesgo de explosión si esta batería se coloca en la posición incorrecta. Cambiar esta
batería únicamente con el mismo tipo (o su equivalente) recomendado por el fabricante. Desachar las
baterías usadas siguiendo las instrucciones del fabricante.
警告
电源 • 该设备只能使用产品上标明的电源。 设备必须使用有地线的供电系统供电。 第三条线
（地线）是安 全设 施，不能不用或跳过 。
拔掉电源 • 为安全地从设备拔掉电源，请拔掉所有设备后或桌面电源的电源线，或任何接到市
电系统的电 源线。
电源线保护 • 妥善布线， 避免被 踩踏，或重 物挤压。
维护 • 所有维修必须由认证的维修人员进行。 设备内部没有用户可以更换的零件。为避 免出现
触电危险不要自己试图打开设备盖子维修该设备。
通风孔 • 有些设备机壳 上有通风槽或孔，它们是用来防止机内敏感元件过 热。 不要用任何 东
西挡住通风 孔。
锂电池 • 不正确的更换电池会有爆炸的危险。必须使 用与厂家推荐的相同或相近 型号的电池。
按照生 产厂的建议处 理废弃电池。
Introduction
FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation. The Class A limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area
is likely to cause harmful interference, in which case the user will be required to correct
the interference at his own expense.
Overview
This manual covers the installation of the Extron PoleVault™ System in a drop ceiling room with a wood or concrete
structural ceiling above. If the location has a concrete or beam style ceiling and no drop ceiling, alternative ceiling
mounts can be obtained separately from Extron (see 2c, "Optional items", page 1-9). For those types of installation,
refer to the individual mounting hardware user's manuals for the method.
It is assumed that the installer has some knowledge and experience of A/V, electrical, or electronic device
installation. This manual guides the A/V installer through the steps for installation and connection of each of the
system’s component parts.
It may be that the locations for the devices (e.g., wall plates, projector, and screen) have been pre-determined.
However, some room installation examples are given to help in installations where nal location is yet to be
determined.
The PoleVault System
Extron PoleVault Systems are easy-to-use, network-enabled, all-inclusive packages, making them ideal for singleprojector K-12 classrooms. PoleVault Systems use economical twisted pair cables for transmitting signals and
include network connectivity for Web-based asset management, monitoring, and control.
N
The hardware and devices listed on the inventory pages have individual user manuals which have detailed safety
information, installation, set-up, and configuration instructions, and should be referred to as needed.
For operation and set up of the projector, screen, and input devices, refer to the relevant manufacturer's manuals
supplied with those devices.
PoleVault Systems Installation • Introduction
1-1
Introduction, cont'd
L
R
AUX/MIX IN
DO NOT GROUND
OR SHORT
SPEAKER OUTPUTS!
1B
1A
I
N
P
U
T
S
O
U
T
P
U
T
S
2B
2A
3B
3A
RS-232 MLC/IR
DC VOL
4/8 Ohms
AMPLIFIED OUTPUTS
VOL/MUTE
Tx
A
B
C
Rx
IR
12V
10V
POWER
12V
3A MAX
US
LISTED
17TT
AUDIO/VIDEO
APPARATUS
®
RGB
VIDEO
RGB
VIDEO
PMK 450
Multi-product Pole
Mount Kit
PVT CV D
1 Gang
PVT RGB D
1 Gang
PVT RGB D
1 Gang
AC for Projector
AC for PoleVault
System
Ceiling Mounted
AC Outlet
RGB and Audio Input
RGB and Audio Input
Video and Audio Input
(x2)
(x2)
MLC 104 IP Plus
Projector on/off control
Projector input switching
Projector volume control
2 Gang (depth: 1.78”)
PCM 240
Projector Drop Ceiling
Mount
PV SI 3C LP
Full Range
Single Driver
Ceiling Speakers
AUDIO IN
L
R
VIDEO IN
COMPUTER IN
AUDIO IN
COMPUTER IN
AUDIO IN
4
4
7
1
1
1
3
2
8
9
CONFIG
DISPLAY
VOLUME
1
2
3
4
ON
OFF
TCP/IP
Network
PVS 204SA
PoleVault Switcher
Extron PoleVault™ System
UPB 25
Universal Projector
Mounting Bracket
AC in
RS-232
PMP 6
Projector Mounting Pole
Comm Adapter
(depending on
projector type)
6
5
7
8
6
5
4
3
2
1
9
Video In
Video In
Video In
Video Out
Audio
Audio
Communication
Extron Cables & Notes
CAT 5 T568A cable - 50'
Projector control cable - 50'
MLC power and control cable - 50'
18 AWG Speaker cable - 25'
Composite Video cable - 3'
VGA Video cable - 3'
PoleVault Switcher power cable - 25'
Projector power cord - not included
UTP network cable - not included
PoleVault System installation and wiring overview
1-2
PoleVault Systems Installation • Introduction
CONFIG
DISPLAY
VOLUME
1
2
3
4
ON
OFFVCR
DVD
PC
Extron
MLC 104 IP Plus
PoleVault System
CONFIG
DISPLAY
VOLUME
1
2
3
4
ON
OFF
VCR
DVD
PC
Extron
MLC 104 IP Plus
Before you Begin Installation - Planning
Before installation is started, you must consider several major factors to ensure that the overall installation is as
smooth and trouble free as possible, and that the final finished project meets the needs of the customers, users,
audiences, and installer.
The installation consideration on the following pages, though not comprehensive, should be consulted to help ensure
that key aspects have been considered.
1. Room layout
a. The room
The application diagram below shows a typical classroom installation.
Typical classroom installation
Room factors to be considered should include, but are not confined to:
• Room size, orientation, and layout:
Audience factors (e.g. number, ADA requirements, seating arrangements)
Existing installed furniture (bookcases, racks, cabinets, workbenches, sinks, etc.)
Windows, doors, and support pillar locations in relationship to the proposed screen location
• Ceiling and wall type (important in assessing the installation hardware needed)
Ceiling type: dropped, spline, hard lid etc., structural type (wood, concrete, trusses), plenum or
non-plenum
Wall type: drywall, cement, brick etc.
W
Check the structural ceiling to ensure that it can handle a load four times the weight of the final setup.
PoleVault Systems Installation • Introduction — Planning
1-3
Introduction — Planning, cont’d
Student Desks
Teacher’s Desk
TV / VCR / DVD
Inputs
Screen/White Board
Location
Windows
MLC Controller
Location
PVT A/V Wallplate
Location
Projector/Switcher
Location
Speaker
Location
Greater than
27"
(68.5 cm)
80"
(203 cm)
Min
Walking Parallel to a Wall
4"
(10 cm)
Max
(ADA referenced figure 8a, redrawn)
• Lighting
Type and control (important for projector image viewing)
Ambient light from windows
Example of a classroom installation
b. Location of the screen and projector
• Proposed screen location
Normally located at the front center of the room (not covering fire alarm strobes when screen is lowered)
Dimensions and type of screen (maximum image size, motorized or hanging screen)
• Proposed projector location
Aligned with center of the screen. Not an obstruction to viewing
Projector's throw distance (maximum and minimum limits to screen) of the image
Horizontal offset (horizontal distance from the center of the lens to the center of the projector)
Vertical offset of the projected image (height relationship between the projector and the screen)
Projector angle (image projected up, down, or horizontal to screen)
Power source for the projector: existing and accessible or needing installation
Projector weight. The Universal Projector Bracket (UPB 25) supports a maximum weight of 25 lbs.
Overhead clearances (refer to a copy of the Americans with Disabilities Act document, "ADA Standards
for Accessible Design", "Section 4-4", "Head Room" for ADA requirements)
1-4
ADA overhead and side clearance requirements
PoleVault Systems Installation • Introduction — Planning
30"
(76 cm)
10"
(25.5 cm)
Max
54"
(137 cm)
Max
High / Low Side Reach Limits
9"
(23 cm)
Min
30"
(76 cm)
24"
(61 cm)
Max Side Reach over Obstruction Limits
46"
(117 cm)
Max
34"
(86.5 cm)
(ADA referenced figure 6c, redrawn)
(ADA referenced figure 6b, redrawn)
High Forward Reach Limits
48"
(122 cm)
Max
15"
(38 cm)
Min
(ADA referenced figure 5a, redrawn)
Student Desks
Teacher’s
Desk
TV / VCR / DVD
Inputs
Screen/White board
Location
Windows
MLC Controller
Location
PVT A/V Wallplate
Location
Projector/Switcher
Location
Speaker
Location
Each speaker covers
one-fourth of
listening area.
• Viewing obstructions
Pillars, furniture etc., window locations for glare reduction, obstructions between projector and screen
c. Location of MediaLink Controller and Wall Plates
• Forward and side reach (for full details refer to a copy of "ADA Standards for Accessible Design", "Section 4-2",
"Space Allowance and Reach Ranges")
ADA high/low forward, side and over obstruction reach limit requirements
• Location of source devices
Desk, table, or rack mounted, proximity to proposed transmitter location (wall, podium, or furniture)
• Cabling obstacles
Studs, utility pipes, power supply location (raceway installation needed?)
• Network drop for MediaLink Controller
Wall or floor cabled
d. Type and location of the speakers
• Speaker type based on room ceiling and wall type
• Total number and spacing of speakers
Based on ceiling height and room size
• Audience seating and room acoustics
Desired evenness of sound coverage and ambient noise level compensation
Example classroom with four speaker installation
PoleVault Systems Installation • Introduction — Planning
1-5
Introduction — Inventory Overview
UPB 25 White
60-773-03
UPB 25
Universal Projector Bracket
PCM 240
Projector Ceiling Mount
PCM 240 White
60-772-03
(4)Turnbuckles
(5) Lag eyes screws
(5) Concrete anchors
(2) Cable clamps, Gal Steel
(1) Safety wire (15 ft 1/8” dia)
(2) Tie wire (30 ft, 14 AWG)
(4) Locking Screws
(4) Adhesive pads
(1) Hex key
PoleVault System
42-108-03 (or 42-109-03, or 42-110-03*)
(4) M6 x 40 mm screws
(4) M5 x 40 mm screws
(4) M4 x 40 mm screws
(4) M3 x 40 mm screws
0.328 ID washers (4)
#10 washers (4)
#6 washers (4)
Adhesive pads (4)
Hex key (1)
PMK 450
Pole Mount Kit
PMK 450 White
70-618-03
(7) Replacement screws
(2) Velcro
™
pads
(1) Set screw Hex wrench
(1) Security screw Hex wrench
PoleVault System Devices and Hardware
PMP
Projector
Mounting Pole
PMP 6 White
70-511-13
PCM 240
UPB 25
PMK 450
PMP
CABLES
(1) SPK 18, 25’
(1) MLC, PW/RS232/VC, 50’
(1) IR SERIAL COMM, 50’
(1) MVGA M-M, 3’
(1) V RCA, 3’
CAT5 T568A Patch, 50’
Quantity varies depending on
PVS system ordered.
These may be boxed separately or
loose inside larger box.
2. Inventory
a. Included items
The PoleVault System (PVS xxx) ships in two boxes. The larger box (42-1xx-xx) contain the devices and
hardware, individually boxed and labeled. The smaller box (42-103-13) contains only the PV SI 3C LP speakers.
Each PVS system has the same quantities of speakers, hardware and devices, but differ in the number and type of
PoleVault A/V Source Input Wall Plates, and are shipped as follows:
• PVS 200 (part # 42-108-03) includes one PVT RGB D and one PVT CV D
• PVS 300 (part # 42-109-03) includes two PVT RGB D and one PVT CV D
• PVS 400 (part # 42-110-03) includes two PVT RGB D and two PVT CV D (see front cover of this manual)
Carefully check all the received items against the following lists.
1-6
PoleVault Systems Installation • Introduction — Inventory Overview
PVT CV D
Wallplate
PVT CV D White
60-819-13
(1) Mud ring
(2) Dog legs
(2) Dog leg screws
(2) PVT mounting screws
(1) Decora® Faceplate
(2) Faceplate screws
*Part #’s 42-109-03 and 42-110-03
contain 3 or 4 PoleVault Wallplates, according to
type ordered.
PoleVault System
42-108-03 (or 42-109-03, or 42-110-03*)
PoleVault System Devices and Hardware, cont’d
PVT CV D
PVT RGB D
Wallplate
PVT RGB D White
60-820-13
(1) Mud ring
(2) Dog legs
(2) Dog leg screws
(2) PVT mounting screws
(1) Decora® Faceplate
(2) Faceplate screws
PVT RGB D
MLC 104 IP Plus
MediaLink Controller
MLC 104 IP Plus White
60-818-03
(1) Mud ring
(8) Mud ring screws
(8) Replacement screws
MLC 104 IP Plus
PVS 204SA
60-800-01
PVS 204SA
PoleVault Switcher
(1) 2-pole connector (orange)
(2) 3-pole connector (blue)
(1) 5-pole connector (blue)
(1) Audio connector (black)
(2) Securing screws
(4) Tie wraps
(4) Adhesive foot pads
(2) Velcro
®
pads
PVS 204SA
(1) Power supply
(1) Power cord
PoleVault System Devices and Hardware, (cont'd)
PoleVault Systems Installation • Introduction — Inventory Overview
1-7
Introduction — Inventory Overview, cont’d
PV SI 3C LP
Speakers
PV SI 3C LP White
42-103-13
(2) C-rings
(8) C-ring attaching screws
(4) V-rails
(2) Speaker grills
(8 pcs) Grill putty
(1) Grill key
PV SI 3C LP
PoleVault System Ceiling Speakers
1-8
1-8
N
PoleVault Systems Installation • Introduction — Inventory Overview
If any items in the PoleVault System boxes are damaged or missing, contact the Extron Technical Hotline (see rear
cover for contact numbers).
b. Items not included
The following items are not included. However, input and display devices are essential parts of the system, and at
any installation they may vary depending on their use. This list suggests various devices that may be used.
• Projector (or display device)
• Screen (and mounting hardware)
• Input devices, such as:
DVD/CD/VCR combo player (and cables)
Document camera (and cables)
PC or Mac (with keyboard, mouse, local monitor, VGA cables, RJ-45 network cables, power cords, and,
where desired, a P/2 DA2 or DA for PC signal to local monitor and projector)
• Installation hardware needed (may vary per installation):
Bolts for concrete structural ceilings where needed
Toggles (used for screen mounting on dry wall)
S-hooks for hanging the screen
Spare ceiling tiles in case of accidental damage during installation
Electrical box, where installation of a box on the PCM 240 is desired
Safety wire, lag eye bolts, and strain reliefs for installation and securing ceiling speakers
Heat shrink, extension cord
c. Optional items
The optional items suggested below can be added to or substituted for items in the standard PoleVault System.
• Optional accessories:
MLP 101 D (mic to line pre-amplier)
Wall mount speakers (e.g., SI 26) or extra ceiling speakers
MLC 104 IP Plus DV+ controller (includes DVD/VCR IR control)
MLC 104 IP Plus L controller (with lectern faceplate)
MLC 104 IP Plus AAP controller (with AAP opening)
PPC 25 Priority Page Controller
P/2 DA2
• Optional installation hardware:
FCMP (flat ceiling mount)
ACMP (angled ceiling mount)
SMB (surface mount boxes for installing the MLC on a podium or desk)
EWB (external wall boxes to mount devices for a surface raceway system)
MLM-WB+ (lockable metal wall box with ip-down 4U rack space)
• Optional A/V source inputs:
PVT CV AAP (composite video architectural adapter plate model)
PVT RGB AAP (RGB architectural adapter plate model)
PVT RGB (RGB rack mount model)
PVT SW RGB (RGB rack mount model with switching capabilities)
PVT CV (composite video rack mount model)
PVT RGB CV (RGB and composite video rack mount model)
• Optional speakers:
SI 3 (Compact Full-Range Surface Mount Speakers)
SI 26X (Two-Way Open Back Ceiling Speakers)
SI 26W (Two-Way-In-Wall Speakers with 6.5" Woofer)
SI 28W (Two-Way-In-Wall Speakers with 8" Woofer)
SI 26CT (Two-Way Ceiling Speakers with 8" Back Can and Transformer)
SI 26 (Two-Way Surface Mount Speakers with 6.5" Woofer)
PoleVault Systems Installation • Introduction — Inventory Overview
1-9
1-9
Introduction — Inventory Overview, cont’d
d. Installation tools
To aid the professional installer, this checklist gives the tools recommended to complete the installation.
Tools should include, but are not confined to:
• Laser level, or two levels (large for screen installation, small for wall plates and projector mounts)
• Tape measure
• Stud nder
• Drill and drill bit set including a Unibit to cut through metal studs
• Extension drill bit (3/4" min. (1.9 cm), 4 to 8' length (122 to 244 cm), to drill through re-breaks)
• Socket set
• Pipe strap or wrapped pipe wrench
• Lineman’s pliers and wire strippers
• Standard screwdriver set and tweeker
• Cable cutters (to cut safety wire)
• Dry wall saw and hacksaw blade mounted on handle (for cutting ceiling tiles)
• Flashlight and safety goggles
• Razor knife
• 2" hole saw
• Painters tape (to mark up walls), pencil, and marker pen
• RJ-45 crimpers and RJ-45 connectors
• Voltage tester
• Fish tape, pull string, and electrical tape (for taping sh tape to pull string)
• Zip ties
• Vacuum cleaner
• Heat gun
1-10
PoleVault Systems Installation • Introduction — Inventory Overview
Installation OverviewInstallation Overview
This overview outlines the basic steps for installing the PoleVault System. Detailed description of these steps is given
in five sections, Stages One though Five.
N
Carefully check inventory of PoleVault system packages, input and output devices, any optional accessories, and
installation hardware before commencing.
Additional installation hardware is needed and should be supplied by the installer. See Introduction, “Items not
included” on page 1-9, for a list.
Optional accessories may be desired for this installation. See Introduction, “Optional items”, for a list on page 1-9,
or visit www.extron.com for details.
Refer to local building standards and codes to verify that the installation will meet all the regulatory requirements.
Observe all local and national building and safety codes, UL requirements, and ADA Accessibility Guidelines.
For details of the OSHPD approved method of installation (OPA-1782), consult the PCM 240 User’s Manual,
68-1180-01, Rev D.
Refer to the specifications on pages 2-34 and 2-35 for system hardware weights and dimensions.
Outline of installation steps
Stage One — Install the Screen and Projector.
c Mark the screen location (page 2-3).
c Install projector to verify location (page 2-3).
c Verify the image location (page 2-4).
c Cut the ceiling tile (page 2-5).
c Finish projector ceiling mount installation (page 2-5).
c Secure the projector ceiling mount to the ceiling (page 2-6).
c Install the screen (page 2-7).
Stage Two — Install the A/V Source Input Wall Plates and MLC 104 IP Plus.
c Install the mud rings (page 2-10).
c Pull cables (page 2-11).
c Install the wall plates (page 2-12).
c Install the MediaLink Controller (page 2-13).
Stage Three — Install the PV SI 3C LP Ceiling Speakers.
c Cut the ceiling tile (page 2-17).
c Install the speaker in the ceiling tile (page 2-17).
c Secure the speakers to the structural ceiling (page 2-18).
c Cable the speakers (page 2-18).
c Finish speaker installation (page 2-20).
Stage Four — Install the PMK 450 and the PVS 204SA.
c Pull the cables (page 2-22).
c Install the PMK 450 pole mount kit (page 2-22).
c Install the PVS 204SA switcher (page 2-23).
c Finish installing the pole mount kit (page 2-24).
Stage Five — Configuring the system.
c Congure the system (page 2-26).
c Test the system (page 2-28).
c Final installation (page 2-29).
Where possible in the following pages, line drawings and photos from an actual installation are used to clarify some
of the steps discussed in the text. Each image has a number corresponding to the particular step (e.g.,
) described.
Ñ
PoleVault Systems Installation • Installation Overview
2-1
Stage One — Install the Screen and Projector
Cable
Access
Cutout
(install this
end uppermost)
Threaded at both
ends
T-bar
Securing
Screws (4)
Pipe Adapter Plate
Lock Nuts (4)
Pipe
Adapter
Pipe
Adapter
Set Screws (2)
1-gang and 2-gang Accessory
Mounting Points (e.g. power sockets)
360° Movement
Projector Securing
Screw
Threaded
Barrels (4)
Arm Adjustment
Screws (4)
Adjuster Plate
Locking Screws (4)
Security Flange
(on rear)
Projector Bracket
(Bottom Section)
Adjuster Plate
(Top Section)
Pivot Point Screws (4)
Horizontal Angle
Adjustment Screws (4)
Set Screws (2)
Security Flange
(on rear)
Vertical Angle
Adjustment
Screws (4)
Pivot
Point
Screw
Stage 1
This stage involves installing the three pieces of hardware shown below.
PCM 240 Projector Ceiling Mount
Where it goes: Attaches to structural ceiling, rests on
suspended ceiling.
What it does: Holds PMP, pole mount kit
(see Stage 4), and projector.
UPB 25 Universal Projector Bracket (shown separated into the two sections)
PMP Projector Mounting Pole
Where it goes: Screws up into PCM 240.
What it does: Holds pole mount kit and
projector.
Where it goes: Adjuster plate screws onto base of PMP, and projector bracket attaches to projector.
What it does: Attaches projector to PMP. Allows projector orientation to be adjusted in three planes.
2-2
PoleVault Systems Installation • Installation — Stage 1
Adjuster Plate
Locking Screws (4)
Projector
Bracket
Adjuster
Plate
Loosen the four Adjuster Plate
Locking Screws and slide the
Adjuster Plate away from the
Projector Bracket
a
b
Set Screws (2)
Security flange
Minimum/Maximum
Throw Distance Marks
PCM
4
1a
PMP installed
onto PCM 240
2c
2d
1. Mark screen location
a. Mark the center line and the outer edges of screen.
When marking the location of screens, devices, or site
T
for installing transmitters and MediaLink control
devices, use painters tape to avoid wall surface damage.
When marking the center line of the screen,
where possible, keep it aligned with the center of the
ceiling tile. This makes the projector installation and
alignment easier.
b. Mark any structural studs, utility pipes, conduits,
or fire-breaks before drilling the hardware holes.
Do not drill the holes at this time.
2. Install projector to verify location
a. Remove the ceiling tiles, and mark the maximum and
minimum throw distances on the T-frame.
b. Place the PCM 240 over the T-frame, between the two
marks. Lightly tighten the frame screws.
Mark the screen location
c. Back out the set screws on the PCM 240 adapter plate
and screw the PMP into the pipe adapter, with the cable
access hole closest to the ceiling. Turn it so the cable
access hole faces away from the screen.
Tighten the set screws.
d. Back out the set screws on the top portion (the adjuster
plate, see
onto the base of the PMP. Align it so the security flange
is at the rear. Tighten the set screw.
below) of the UPB 25, and screw the plate
a
Place the PCM 240 on the T-bar
Install the PMP
Screw the adjuster plate onto the PMP
PoleVault Systems Installation • Installation — Stage 1
2-3
