ISW Series Managed Industrial Ethernet Switch Command Reference Guide
ISW 4-10/100P, 2-10/100T, 2-SFP ISW 4GbP, 2GbT, 2-SFP ISW 8-10/100P, 4-SFP ISW 8GbP, 4-SFP
9034963-01 Rev. 02
Copyright © 2017 Extreme Networks, Inc. All rights reserved.
Legal Notice
Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
The hardware, firmware, software or any specifications described or referred to in this document are subject to change without notice.
Trademarks
Extreme Networks and the Extreme Networks logo are trademarks or registered trademarks of Extreme Networks, Inc. in the United States and/or other countries.
All other names (including any product names) mentioned in this document are the property of their respective owners and may be trademarks or registered trademarks of their respective companies/owners.
For additional information on Extreme Networks trademarks, please see:
www.extremenetworks.com/company/legal/trademarks
Software Licensing
Some software files have been licensed under certain open source or third-party licenses. End­user license agreements and open source declarations can be found at:
www.extremenetworks.com/support/policies/software-licensing
Support
For product support, phone the Global Technical Assistance Center (GTAC) at 1-800-998-2408 (toll-free in U.S. and Canada) or +1-408-579-2826. For the support phone number in other countries, visit: http://www.extremenetworks.com/support/contact/
For product documentation online, visit: https://www.extremenetworks.com/documentation/

Table of Contents

Preface.........................................................................................................................................4
Text Conventions...................................................................................................................................................................4
Getting Help............................................................................................................................................................................ 4
Extreme Networks Publications.....................................................................................................................................5
Providing Feedback to Us.................................................................................................................................................5
Chapter 1: Introduction to the Industrial Switches Command Referene Guide................6
Chapter 2: Getting Started with the ISW Switch...................................................................7
Connecting to the ISW Interface................................................................................................................................... 7
Execution Modes...................................................................................................................................................................8
Using the CLI Help................................................................................................................................................................9
Terminal Key Function........................................................................................................................................................9
Syntax Conventions........................................................................................................................................................... 10
Chapter 3: ISW Commands......................................................................................................11
Initialize Mode Commands............................................................................................................................................... 11
Enable Mode Commands.................................................................................................................................................13
Configure Mode Commands.........................................................................................................................................47
VLAN Mode Commands................................................................................................................................................. 78
Interface VLAN Mode Commands.............................................................................................................................83
RingV2 Group Mode Commands................................................................................................................................88
Spanning Tree...................................................................................................................................................................... 90
sFlow Configure Command.......................................................................................................................................... 96
SNMP Configure Command..........................................................................................................................................99
QoS Function Command.............................................................................................................................................. 105
IGMP Functional Commands......................................................................................................................................... 111
MVR Functional Commands......................................................................................................................................... 115
MLD Functional Commands..........................................................................................................................................121
Authenticate Mode Commands.................................................................................................................................125
Loop-Protection Configure commands................................................................................................................. 133
LLDP Configure commands.........................................................................................................................................135
RFC2544 Testing Configure Commands...............................................................................................................138
GVRP Configure Commands...................................................................................................................................... 140
Voice VLAN Configure Commands...........................................................................................................................141
Profile Alarm Commands..............................................................................................................................................143
PoE Commands.................................................................................................................................................................144
Configuring ERPS from the CLI................................................................................................................................. 147
Appendix A: Regulatory and Compliance Information.................................................... 150
Glossary..........................................................................................................................................152
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 3

Preface

Text Conventions

The following tables list text conventions that are used throughout this guide.
Table 1: Notice Icons
Icon Notice Type Alerts you to...
General Notice Helpful tips and notices for using the product.
Note Important features or instructions.
Caution Risk of personal injury, system damage, or loss of data.
Warning Risk of severe personal injury.
New This command or section is new for this release.
Table 2: Text Conventions
Convention Description
Screen displays
The words enter and type
[Key] names Key names are written with brackets, such as [Return] or [Esc]. If you must press two
Words in italicized type Italics emphasize a point or denote new terms at the place where they are defined in
This typeface indicates command syntax, or represents information as it appears on the screen.
When you see the word “enter” in this guide, you must type something, and then press the Return or Enter key. Do not press the Return or Enter key when an instruction simply says “type.”
or more keys simultaneously, the key names are linked with a plus sign (+). Example: Press [Ctrl]+[Alt]+[Del]
the text. Italics are also used when referring to publication titles.

Getting Help

If you require assistance, contact Extreme Networks using one of the following methods:
GTAC (Global Technical Assistance Center) for Immediate Support
Phone: 1-800-998-2408 (toll-free in U.S. and Canada) or +1 408-579-2826. For the support
phone number in your country, visit: www.extremenetworks.com/support/contact
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 4
Email: support@extremenetworks.com. To expedite your message, enter the product name or
model number in the subject line.
GTAC Knowledge — Get on-demand and tested resolutions from the GTAC Knowledgebase, or
create a help case if you need more guidance.
The Hub — A forum for Extreme customers to connect with one another, get questions answered,
share ideas and feedback, and get problems solved. This community is monitored by Extreme Networks employees, but is not intended to replace specific guidance from GTAC.
Support Portal — Manage cases, downloads, service contracts, product licensing, and training and
certifications.
Before contacting Extreme Networks for technical support, have the following information ready:
Your Extreme Networks service contract number and/or serial numbers for all involved Extreme
Networks products A description of the failure
A description of any action(s) already taken to resolve the problem
A description of your network environment (such as layout, cable type, other relevant environmental
information) Network load at the time of trouble (if known)
The device history (for example, if you have returned the device before, or if this is a recurring
problem) Any related RMA (Return Material Authorization) numbers
Preface

Extreme Networks Publications

General
Product documentation is available at: http://documentation.extremenetworks.com. Release notes are available at: www.extremenetworks.com/support/release-notes
Open Source Declarations
Some software files have been licensed under certain open source licenses. More information is available at: www.extremenetworks.com/support/policies/software-licensing

Providing Feedback to Us

We are always striving to improve our documentation and help you work better, so we want to hear from you! We welcome all feedback but especially want to know about:
Content errors or confusing or conflicting information.
Ideas for improvements to our documentation so you can find the information you need faster.
Broken links or usability issues.
If you would like to provide feedback to the Extreme Networks Information Development team about this document, please contact us using our short online feedback form. You can also email us directly at
internalinfodev@extremenetworks.com.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 5
1 Introduction to the Industrial
Switches Command Referene Guide
Scope
This user guide describes the commands and parameters of the Command Line Interface (CLI) as implemented in the current version of Extreme Networks ISW Series Industrial Switches software. These commands are used to set up, administer, and maintain the system.
Audience
The guide is intended for Operating personnel.
Pre-required Knowledge
You must be familiar with the:
Basic operations of Industrial Switches.
Security and activity monitoring constraints that limit how a command is implemented.
Access to Hardware Interface
Access to the hardware interface is by a terminal (or computer with terminal emulation software). Requirements for the terminal are:
RS-232 ASCII port
Selectable transmission baud rate
Full alphanumeric capability
Selectable odd/even or no parity check
Connecting to ISW Ethernet port (RJ45 Ethernet port)
Key-in the command under Telnet: telnet 192.0.2.1
Login with default account and password:
Username: admin
Password: [none]
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 6
2 Getting Started with the ISW
Switch
Connecting to the ISW Interface Execution Modes Using the CLI Help Terminal Key Function Notation Conventions
Access to the switch is protected by a logon security system. You can log on to the switch with the user name and password. After three failed logon attempts, the system refuses further attempts.
After you log on, the system monitors the interface for periods of inactivity. If the interface is inactive for too long, you are automatically logged o.
The CLI initial user name is (admin) and no password. You should change the password as soon as possible, because the initial password is known to anyone who reads this manual. You can also change the user name or add additional user names. Use the account add command to enter a new user identification, password, and authorization level.

Connecting to the ISW Interface

Interface
Console Baud rate: 115200bps
Telnet Port 23
SSH Port 22 (In Windows, you can run terminal emulator such as PuTTY)
Connecting to ISW Ethernet port (RJ45 Ethernet port): 1 Key-in the command under Telnet: telnet 192.0.2.1
2 Log in with default account and password (admin / [none]).
Parameters
Data bit: 8 Parity: None. Stop bit: 1
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 7
Getting Started with the ISW Switch
Figure 1: Screen Description

Execution Modes

The CLI contains several execution modes. Users will see dierent set of commands under dierent execution modes. The following table lists all the execution modes and their purposes. When you enter a certain execution mode, the corresponding mode prompt will be displayed automatically on the screen. The mode prompts of all the execution modes are also listed in the following table.
Table 3: List of Execution Modes
Mode Access Level Prompt
Init Mode Guest
Enable Mode Guest
Config Mode Guest
Alarm Profile Config Mode Engineer
Gigabit Interface Config Mode Engineer
ACL (Access Control List) Profile Config Mode Engineer
scheduler Profile Config Mode Engineer
> # (conf)# (alarm-profile-conf)# (gigabit-intf-conf)# (acl-profile-conf)# (sch-profile-conf)#
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 8
Getting Started with the ISW Switch
Table 3: List of Execution Modes (continued)
Mode Access Level Prompt
VLAN (Virtual LAN) Interface Config Mode Engineer
IGMP (Internet Group Management Protocol)
MVR Profile Config Mode
IGMP ACL Profile Config Mode Engineer
RingV2 Group Config Mode Engineer
Trunk Group Config Mode Engineer
Engineer
(vlan-intf-conf)# (igmp-mvr-profile-conf)#
(igmp-acl-profile-conf)# (ring)# (trunk-group-conf)#

Using the CLI Help

You can get help by entering a question mark (?) at each position in the command. The displayed result depends on the execution mode and previous input.

Terminal Key Function

Following is the list of all the terminal keys and their function.
Table 4: List of Terminal Keys
[ENTER]
[CTRL] + [M]
Run a CLI config script
[TAB] Tab completion.
If [TAB] is pressed after a non-whitespace character, complete the word before the
[CTRL] +[I]
[?]
up arrow
[CTRL] + [P]
down arrow
[CTRL] + [N]
[Home]
[CTRL] + [A]
[End]
[CTRL] + [E]
left arrow
[CTRL] + [B]
right arrow Move the cursor forward
Tab. If [TAB] is pressed after a whitespace character, complete the next word.
Display available commands. If ? is pressed after a non-whitespace character, show possible choices for this word. If ? is pressed after a whitespace character, show possible choices for the next word.
Up history
Down history
Move the cursor to the beginning of the input line
Move the cursor to the end of the input line
Move the cursor backward
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 9
Table 4: List of Terminal Keys (continued)
[CTRL] + [F]
Getting Started with the ISW Switch
[Backspace]
[CTRL] + [H]
Erase the character before the cursor
Notation Conventions
The notation conventions for the parameter syntax of each CLI command are as follows:
{ }: Required parameters.
[ ]: Optional parameters.
|: Only one of the specified values can be used.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 10

3 ISW Commands

Initialize Mode Commands Enable Mode Commands Configure Mode Commands VLAN Mode Commands Interface VLAN Mode Commands RingV2 Group Mode Commands Spanning Tree sFlow Configure Command SNMP Configure Command QoS Function Command IGMP Functional Commands MVR Functional Commands MLD Functional Commands Authenticate Mode Commands Loop-Protection Configure commands LLDP Configure commands RFC2544 Testing Configure Commands GVRP Configure Commands Voice VLAN Configure Commands Profile Alarm Commands PoE Commands Configuring ERPS from the CLI

Initialize Mode Commands

The commands in this section (except the enable command) can be executed under all command modes. These are also global commands.

exit

Description
Exit current mode and quit CLI.
Syntax
exit
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 11
Parameters
None.
configure terminal
Description
Enter configuration mode.
Syntax

configure terminal

Parameters
None.

enable

ISW Commands
Description
Enter enable mode.
Syntax
enable
Parameters
None.

show terminal

Description
Show CLI environment variables.
Syntax
show terminal
Parameters
None.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 12

show history

Description
Show command history.
Syntax
show history
Parameters
None.

show clock

Description
ISW Commands
Note Commands issued in one execution mode only appear in history of that execution mode.
Show current time.
Syntax
show clock [detail]
Parameters
None.

Enable Mode Commands

All the show commands in this section can also be executed under any other command mode except Initialize Mode.
configure terminal
Description
Enter configuration mode.
Syntax

configure terminal

Parameters
None.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 13

disable

Description
Enter init mode.
Syntax
disable
Parameters
None.

show aaa

Description
Show AAA.
Syntax
ISW Commands
show aaa
Parameters
None.

show access management

Description
Access management configuration.
Syntax
show access managemnet [statistics | access_id_list]
Parameters
Name
statistics access_id_list
Description
Statistics data.
ID of access management entry.

show access-list

Description
Access list.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 14
ISW Commands
Syntax
show access-list [interface [(port_type [ v_port_type_list])]] [rate-
limiter [rate_limiter_list]] [ace statistics [ace_list]]
show access-list ace-status [static] [link-oam] [loop-protect] [dhcp]
[ptp] [upnp] [arp-inspection] [mep] [ipmc] [ip-source-guard] [ip-mgmt] [conflicts] [switch switch_list]
Parameters
Name Description
interface ace-status port_type v_port_type_
list rate-limiter rate_limiter
_list ace statistics ace_list static loop-protect ipmc ip-source-
guard dhcp
Select an interface to configure
The local ACEs status
GigabitEthernet,1 Gigabit Ethernet Port
Port list in 1/1 – 14
Rate limiter
Valid values are 1 – 16
Access list entry
Trac statistics
<AceId : 1–256> ACE ID
The ACEs that are configured by users manually
The ACEs that are configured by Loop Protect module
The ACEs that are configured by IPMC module
The ACEs that are configured by IP Source Guard module
The ACEs that are configured by DHCP module
conflicts arp-
The ACEs that did not get applied to the hardware due to hardware limitations
The ACEs that are configured by ARP Inspection module
inspection

show account

Description
Show user account list.
Syntax
show account
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 15
Parameters
None.

show aggregation

Description
Aggregation.
Syntax
show aggregation [mode]
Parameters
ISW Commands
mode
Trac distribution mode.

show aging time

Description
Show aging time for MAC learning table (system-wide).
Syntax
show aging time
Parameters
None.

show alarm

Description
Alarm information.
Syntax
show alarm [history | current]
Parameters
current history
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 16
Shows alarm current information.
Shows alarm history information.

show cpu-load

Description
CPU load.
Syntax
show cpu-load
Parameters
None.

show ddmi

Description
Show DDMI configuration.
Syntax
ISW Commands
show ddmi
Parameters
None.

show dot1x

Description
Show dot1x information.
Syntax
show dot1x
Parameters
None.

show dot1x status

Description
Show dot1x stats.
Syntax
show dot1x status [interface port_type [port_type_list]] [brief]
Parameters
None.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 17

show dot1x statistics

Description
Show dot1x statistics
Syntax
show dot1x statistics {eapol | radius | all} [interface (port_type [v_port_type_list])]
Parameters
Name Description
ISW Commands
eapol radius all port_type v_port_type_list

show ext-tpid

Description
Show TPID for the VLAN (Virtual LAN) Tag
Syntax
show ext-tpid
Parameters
None.
Show EAPOL statistics
Show Backend Server statistics
Show all dot1x statistics
GigabitEthernet, 1 Gigabit Ethernet Port
PORT_LIST, Port list in 1/1-14

show green-ethernet

Description
Green Ethernet.
Syntax
show green-ethernet [interface (port_type [port_list])] show green-ethernet eee [interface (port_type [port_list])] show green-ethernet energy-detect [interface (port_type [port_list])] show green-ethernet short-reach [interface (port_type [port_list])]
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 18
Parameters
Name Description
ISW Commands
eee energy-
Shows green ethernet EEE status for a specific port or ports.
Shows green ethernet energy-detect status for a specific port or ports.
detect short-reach interface port_type port_list
Shows green ethernet short-reach status for a specific port or ports.
Shows green ethernet status for a specific port or ports.
GigabitEthernet, 1 Gigabit Ethernet Port.
Port list in 1/1 – 14.

show interface gigabit <portNo>

Description
Show interface gigaport information
Syntax
show interface gigabit portNo
Parameters
Name
Description
portNo
Gigabit port. Valid values: 1 – 10 Type: Mandatory

show interface gigabit <portNo> port-isolation

Description
Show isolation information per gigabit port.
Syntax
show pvlan isolation [interface portNo [port_type_list]]
Parameters
Name
portNo
Description
Valid values: 1 – 10 Type: Mandatory
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 19

show interface gigabit <portNo> storm-control

Description
Show storm control information per gigabit port.
Syntax
show interface gigabit portNo storm-control
Parameters
Name Description
ISW Commands
port_type portNo
Port type in Fast, Giga or Tengiga Ethernet
Valid values: 1–10 Type: Mandatory

show interface gigabit <portNo> transceiver

Description
Show interface transceiver
Syntax
show interface GigabitEthernet interface port_type_list transceiver
Parameters
Name
portNo
Description
Valid values: 11 – 14 (for 14 port model) Type: Mandatory

show interface gigabit <portNo> vlan

Description
Show vlan information per port
Syntax
show interface gigabit portNo vlan
Parameters
Name
portNo
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 20
Description
Gigabit port. Valid values: 1 – 10 Type: Mandatory

show interface

Description
Show interface information per port.
Syntax
show interface port_type [port_type_list] status
Parameters
Name Description
ISW Commands
port_type portNo
Port type in Fast, Giga or Tengiga Ethernet
Valid values: 1 – 10 Type: Mandatory

show interface priority

Description
Show QoS (Quality of Service)
Syntax
show interface port_type [port_type_list] statistics {priority [0–7] }
Table 5: Parameters
Name Description
priority [0–7]
port_type portNo
Valid values:0 – 7 Type: Mandatory
Port type in Fast, Giga or Tengiga Ethernet
Valid values: 0 – 10 Type: Mandatory
per gigabit port.

show interface statistics

Description
Show Ethernet counter per gigabit port.
Syntax
show interface port_type [port_type_list] statistics
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 21
Parameters
Name Description
ISW Commands
port_type portNo
counter
Port type in Fast, Giga or Tengiga Ethernet
Valid values: 1 – 10 Type: Mandatory
Show Gigabit Ethernet counter

show interface vlan

Description
Show interface information of all or specific VLANs.
Syntax
show interface vlan {vlanid}
Parameters
Name Description
vlanid
VLAN ID. Valid values: 1 – 4094

show ip

Description
IP information.
Syntax
show ip
Parameters
Name
arp dhcp http igmp interface name-server route source
Description
Address Resolution Protocol
Dynamic Host Configuration Protocol
Hypertext Transfer Protocol
Internet Group Management Protocol
IP interface status and configuration
Domain Name System
Display the current ip routing table
source command
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 22
Name Description
ISW Commands
ssh statistics verify
Secure Shell
Trac statistics
verify command

show ipmc

Description
IPMC information.
Syntax
show ipmc profile [profile_name] [detail] show ipmc range [entry_name]
Parameters
Name Description
profile range profile_name
IPMC profile configuration.
A range of IPv4/IPv6 multicast addresses for the profile.
Profile name in 16 characters.
detail Detailed information of a profile.
entry_name

show ipv6

Description
IPv6 information.
Syntax
show ipv6
Parameters
Name
interface mld neighbor route
Range entry name in 16 characters.
Description
Select an interface to configure.
Multicasat Listener Discovery.
IPv6 neighbors.
IPv6 routes.
statistics
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 23
Trac statistics.

show lacp

Description
LACP information.
Syntax
show lacp {internal | statistics | system-id | neighbour}
Parameters
Name Description
internal Internal LACP configuration.
neighbour Neighbour LACP status.
statistics Internal LACP statistics.
system-id LACP system ID.
ISW Commands

show line

Description
Alive line information.
Syntax
show line [alive]
Parameters
Name
alive
Description
Display information about alive lines.

show logging

Description
Logging information.
Syntax
show logging log_id [ switch switch_list] show logging [info] [warning] [error] [switch switch_list]
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 24
Parameters
Name Description
ISW Commands
log_id error info warning
Valid values are 1 – 4294967295
Error
Infomation
Warning

show loop-protec

Description
Loop protect information.
Syntax
show loop-protect [interface (port_type [plist])]
Parameters
Name Description
interface Interface status and configuration.
port_type
GigabitEthernet, 1 Gigabit Ethernet Port.
plist
Port list in 1/1 – 14.

show system inventory

Description
Show system inventory.
Syntax
show system inventory
Parameters
None.

show mac address-table (learning)

Description
Show MAC learning table.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 25
Syntax
show mac address-table [conf | static | aging-time | {{learning | count} [interface port_type [port_type_list]]} | {address mac_addr [vlan vlan_id ]} | vlan vlan_id | interface port_type [port_type_list]]
Parameters
None.

show mac address table learning

Description
Learn/disable/secure stat.
Syntax
show mac address-table [conf | static | aging-time | {{learning | count} [interface (port_type [v_port_type_list])]} | {address v_mac_addr [vlan v_vlan_id]} | vlan v_vlan_id_1 | interface (port_type [v_port_type_list_1])]
ISW Commands
Parameters
None.

show mac-address-table (per gigabit port)

Description
Show static MAC forwarding table per gigabit port.
Syntax
show mac address-table {learning | count} [interface port_type [port_type_list]]
Parameters
Name
port_type portNo
Description
Port type in Fast, Giga or Tengiga Ethernet
Valid values: 1 – 10 Type: Mandatory

show mac address-table (per VLAN index)

Description
Show static MAC forwarding table per VLAN
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 26
index.
Syntax
show mac address-table {learning | count} vlan vlan_id
Parameters
Name Description
ISW Commands
vlan_id
Valid values: 1 – 4094 Type: Mandatory

show mac address-table conf

Description
User-added static MAC addresses.
Syntax
show mac address-table conf | static | aging-time | {{learning | count} [interface port_type [v_port_type_list]]} | {address v_mac_addr [vlan v_vlan_id ]} | vlan v_vlan_id | interface port_type [v_port_type_list]]
Parameters
None.

show mac address-table count

Description
Total number of MAC addresses.
Syntax
show mac address-table [conf | static | aging-time | {{learning | count} [interface (port_type [v_port_type_list])]} | {address v_mac_addr [vlan v_vlan_id]} | vlan v_vlan_id_1 | interface (port_type [v_port_type_list_1])]
Parameters
None.

show mac address-table interface

Description
Show MAC learning table per port.
Syntax
show mac address-table [interface (port_type [port_type_list]]
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 27
Parameters
Name Description
portNo Valid values: 1 – 10
Type: Mandatory

show mac address-table static

Description
Show all static MAC addresses.
Syntax
show mac address-table [conf | static | aging-time | {{learning | count} [interface (port_type [v_port_type_list])]} | {address v_mac_addr [vlan v_vlan_id]} | vlan v_vlan_id_1 | interface (port_type [v_port_type_list_1])]
ISW Commands
Parameters
None.

show mac address-table vlan <vlanid>

Description
Show MAC learning table per VLAN index.
Syntax
show mac address-table {learning | count} vlan [vlan_id]]
Parameters
Name
vlan_id
Description
Valid values: 1 – 4094 Type: Mandatory

show multicast-fdb

Description
Show IGMP (Internet Group Management Protocol) group membership table
Syntax
show multicast-fdb
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 28
None.

show mvr

Description
MVR information.
Syntax
show mvr vlan [v_vlan_list | name mvr_name] [group-database [interface (port_type [v_port_type_list])] [sfm-information]] [detail]
Parameters
Name Description
ISW Commands
vlan v_vlan_list
name Search by MVR name.
mvr_name group-database interface port_type v_port_type_list sfm-information detail
Search by VLAN.
MVR multicast VLAN list.
MVR multicast VLAN name.
Multicast group database from MVR.
Search by port.
GigabitEthernet, 1 Gigabit Ethernet Port.
PORT_LIST, Port list in 1/1 – 14
Including source filter multicast information from MVR.
Detail information/statistics of MVR group database.

show ntp

Description
Show SNTP (Simple Network Time Protocol)
Syntax
information.
show sntp
Parameters
None.

show platform phy

Description
PHYs information.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 29
ISW Commands
Syntax
show platform phy [interface (port_type [v_port_type_list])] show platform phy id [interface (port_type [v_port_type_list])] show platform phy instance show platform phy status [interface port_type [v_port_type_list])]
Parameters
Name Description
id instance status interface port_type v_port_type_list
ID
PHY Instance Information
Status
Interface
Gigabit Ethernet, 1 Gigabit Ethernet Port
Port list in 1/1 – 14

show poe

Description
Show PoE (Power over Ethernet) status and information for each port.
Syntax
show poe show poe [interface (port_type [v_port_type_list])]
Parameters
Name
poe port_type v_port_type_list
Description
Power over Ethernet
Gigabit Ethernet, 1 Gigabit Ethernet Port
Port list in 1/1 – 14

show port-mirror

Description
Show port mirror information.
Syntax
show port-mirror
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 30
None.

show port-security

Description
Port security.
Syntax
show port-security
Parameters
Name Description
ISW Commands
port switch interface port_type v_port_type_list

show port-shaper

Description
Show port shaper information.
Syntax
show port-shaper
Parameters
None.
Show MAC Addresses learned by Port Security
Show Port Security status
Interface
Gigabit Ethernet, 1 Gigabit Ethernet Port
Port list in 1/1 – 14
show profile alarm
Description
Profile alarm.
Syntax

show profile alarm

Parameters
None.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 31

show protocol-vlan

Description
Show protocol based VLAN information for all entries.
Syntax
show protocol-vlan
Parameters
None.

show pvlan isolation [interface <port_type> [<port_type_list>]]

Description
Show all port isolation information.
Syntax
ISW Commands
show pvlan isolation [interface port_type [port_type_list]]
Parameters
Name
port_type portNo
Description
Port type in Fast, Giga or Tengiga Ethernet
Valid values: 1 – 10 Type: Mandatory

show pvlan [<pvlan_list>]

Description
PVLAN ID
Syntax
show pvlan [pvlan_list]
Parameters
Name
Description
pvlan_list
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 32
PVLAN ID to show configuration for

show qos

Description
QoS interface information
Syntax
show qos [{interface [(port_type [port])]}
Parameters
Name Description
ISW Commands
interface port_type port
Interface
GigabitEthernet, 1 Gigabit Ethernet Port
PORT_LIST, Port list in 1/1-14

show qos maps

Description
MAPS
Syntax
show qos maps {maps [dscp-cos] [dscp-ingress-translation] [dscp-classify] [cos-dscp] [dscp-egress-translation]}
Parameters
Name
cos-dscp dscp-classify
Description
Map for cos to dscp
Map for dscp classify enable
dscp-cos dscp-egress-translation dscp-ingress-translation
Map for dscp to cos
Map for dscp egress translation
Map for dscp ingress translation

show qos maps (CoS queue mapping)

Description
Show CoS (Class of Service) queue mapping table.
Syntax
show qos maps
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 33
Parameters
None.

show qos qce

Description
QCE
Syntax
show qos {qce [qce]}
Parameters
Name Description
qce QCE ID. Valid values are 1 – 256.
ISW Commands

show qos storm

Description
Show storm control information by VLAN
Syntax
show vlan unknown-uc show vlan unknown-mc show vlan broadcast
Parameters
Name
unknown-uc
unknown-mc
broadcast
.
Description
Show unknown unicast storm control information by VLAN. Type: Mandatory
Show unknown multicast storm control information by VLAN. Type: Mandatory
Show broadcast storm control information by VLAN. Type: Mandatory
show que-scheduler profile
Description
Show scheduler profile table.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 34
Syntax
show queue-scheduler profile
Parameters
None.

show queue-shaper

Description
Show queue shaper information.
Syntax
show queue-shaper
Parameters
None.
ISW Commands

show radius-server [statistics]

Description
show radius-server statistics
Syntax
show radius-server [statistics]
Parameters
Name
statistics
Description
Count radius packet statistics
show rfc2544 profile
Description
Show rfc2544 profile name.
Syntax

show rfc2544 profile [word32]

Parameters
Name
word32
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 35
Description
rfc2544 profile name

show ringv2

Description
Show ring protect information
Syntax
show ring
Parameters
None.

show rmon

Description
Syntax
show rmon alarm [id_list] show rmon event [id_list] show rmon history [id_list] show rmon statistics [id_list]
ISW Commands
Parameters
Name
alarm event history statistics id_list

show running-cfg

Description
Show running configuration.
Syntax
show running-cfg
Parameters
Description
Display the RMON alarm table
Display the RMON event table
Display the RMON history table
Display the RMON statistics table
Statistics entry list. Valid values are 1 – 65535
None.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 36
show running-config interface Gigabit
Description
Show port configuration.
Syntax
show running-config interface (port_type [list]) [all-defaults]
Parameters
Name Description
ISW Commands
list all-defaults
Port list in 1/1 – 14.
Include most/all default values.
show running-config interface vlan
Description
Show default running configuration.
Syntax

show running-config interface vlan vlan_list [all-defaults]

Parameters
Name
vlan_list all-defaults
Description
List of VLAN numbers.
Include most/all default values.
show running-config all-defautls
Description
Show all default settings.
Syntax
show running-config [all-defaults]
Parameters
Name
all-defaults
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 37
Description
Include all default values.
show running-config feature
Description
Show running configuration feature.
Syntax

show running-config feature feature_name [all-defaults]

Parameters
Name Description
ISW Commands
all-defaults
feature_name
all-defaults Include most/all default values
Include all default values.
CWORD Valid values are : GVRP | access | access-list | aggregation | alm_profile | arp-inspection | auth | clock | dhcp | dhcp-snooping | dhcp_server | dns | dot1x | green-ethernet | http | icli | ip-igmp-snooping | ip-igmp-snooping-port | ip-igmp-snooping-vlan | ipmc-profile | ipmc-profile-range | ipv4 | ipv6 | ipv6-mld-snooping | ipv6-mld-snooping-port | ipv6­mld-snooping-vlan | lacp | lldp | logging | loop-protect | mac | monitor | mstp | mvr | mvr-port | ntp | phy | port | port-security | pvlan | qos | rmon | snmp | source-guard | ssh | tring_g1 | tring_g2 | tring_g3 | user | vlan | voice-vlan web-privilege-group-level
show running-config line
Description
Line information.
Syntax

show running-config line {console | vty} list [all-defaults]

Parameters
Name
list all-defaults
Description
List of console/VTYs.
Include most/all default values
show running-config vlan
Description
VLAN information.
Syntax

show running-config vlan list [all-defaults]

ISW Series Managed Industrial Ethernet Switch Command Reference Guide 38
Parameters
Name Description
ISW Commands
list all-defaults
List of VLAN numbers.
Include most/all default values.
show sflow
Description
Sflow information
Syntax
show sflow show sflow statistics {receiver [rcvr_idx_list] | samplers [interface
[samplers_list] (port_type [v_port_type_list])]}
Parameters
Name Description
receiver samplers interface
Show statistics for receiver
Show statistics for samplers
Interface
port_type v_port_type_list
Gigabit Ethernet, 1 Gigabit Ethernet Port
Port list in 1/1 – 14

show snmp

Description
SNMP (Simple Network Management Protocol)
Syntax
show snmp show snmp access [group_name {v1 | v2c | v3 | any} {auth | noauth | priv}] show snmp community v3 [community] show snmp host [conf_name] [system] [switch] [interface] [aaa] show snmp mib context show snmp mib ifmib ifIndex show snmp security-to-group {v1 | v2c | v3} security_name] show snmp user [username engineID] show snmp view [view_name oid_subtree]
information.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 39
Parameters
Name Description
ISW Commands
access group_name any v1 v2c v3 auth noauth priv community community host conf_name aaa interface switch
access configuration
Group name
any security model
v1 security model
v2c security model
v3 security model
authNoPriv Security Level
noAuthNoPriv Security Level
authPriv Security Level
Community
Specify community name
Set SNMP host's configurations
Name of the host configuration
AAA event group
Interface event group
Switch event group
system mib context ifmib ifIndex security-to-group security_name user username engineID view view_name oid_subtree
System event group
Management Information Base
MIB context
IF-MIB
The IfIndex that is defined in IF-MIB
security-to-group configuration
Security group name
User
Security user name
Security Engine ID
MIB view configuration
MIB view name
MIB view OID. Valid values are 1 – 255.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 40

show spanning-tree

Description
System-wide Spanning Tree setting/status.
Syntax
show spanning-tree [summary | active | {interface (port_type [v_port_type_list])} | {detailed [interface port_type [v_port_type_list_1])]} | {mst [configuration | {instance [interface (port_type [v_port_type_list_2])]}]}]
Parameters
Name Description
ISW Commands
active detailed interface mst summary
STP (Spanning Tree Protocol) active interfaces
STP statistics
Choose port
Configuration
STP summary

show switchport forbidden

Description
Lookup VLAN
Syntax
show switchport forbidden [{vlan vid} | {name name}]
Parameters
Name
vlan
Forbidden port entry
Description
Show forbidden access for specific VLAN id
vid name name
VLAN id
Show forbidden access for specific VLAN name
VLAN name

show tacacs-server

Description
TACACS+ configuration
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 41
Syntax
show tacacs server
Parameters
None.

show version

Description
Show firmware hardware and software status update status.
Syntax
show version
Parameters
None.
ISW Commands

show vlan

Description
Show bridge port memberset/status.
Syntax
show vlan
Parameters
None.

show vlan brief

Description
VLAN summary information
Syntax
show vlan [id vlan_list | name name | brief]
Parameters
Name
id vlan_list name
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 42
Description
VLAN status by VLAN ID.
VLAN ID. Valid values are 1 – 4095.
VLAN status by VLAN name.
Name Description
ISW Commands
name brief
A VLAN name up to 32 characters.
VLAN summary information.

show vlan id

Description
Show bridge port memberset/status per VLAN index.
Syntax
show vlan id vlan_id
Parameters
Name Description
vlan_id
Valid values: 1 – 4094 Type: Mandatory.

show vlan ip-subnet

Description
Show VLAN
ip-subnet entries
Syntax
show vlan ip-subnet [id subnet_id]
Parameters
Name
id subnet_id
Description
Show a specific IP-subnet entry
The specific IP-subnet to show. Valid values are 1 – 28.

show vlan mac

Description
Show VLAN MAC entries
Syntax
show vlan mac [address mac_addr]
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 43
Parameters
Name Description
ISW Commands
address mac_addr
Show a specific MAC entry
<mac_ucast> The specific MAC entry to show

show vlan name

Description
Show bridge port memberset/status per VLAN name.
Syntax
show vlan name vword32
Parameters
Name Description
vword32
Valid values: 32 words Type: Mandatory.

show vlan protocol

Description
Protocol-based VLAN
status
Syntax
show vlan protocol [eth2 {etype | arp | ip | ipx | at}] [snap {oui |
rfc-1042 | snap-8021h} pid] [llc dsap ssap]
Parameters
Name
eth2
etype <0x600-0x> Ether Type (Range: 0x600 - 0xFFFF)
arp ip ipx at llc
dsap <0x0-0x> DSAP (Range: 0x00 - 0xFF)
Description
Ethernet protocol based VLAN status
Ether Type is ARP
Ether Type is IP
Ether Type is IPX
Ether Type is AppleTalk
LLC-based VLAN status
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 44
Name Description
ssap <0x0-0x> SSAP (Range: 0x00 - 0xFF)
ISW Commands
snap
oui <0x0-0x> SNAP OUI (Range 0x000000 - 0XFFFFFF)
rfc-1042 SNAP OUI is rfc-1042
snap-8021h
SNAP-based VLAN status
SNAP OUI is 8021h

show vlan status

Description
Show the VLANs configured for each interface
Syntax
show vlan status [interface (port_type [plist])] [combined | admin | nas |
mvr | voice-vlan | mstp | erps | vcl | evc | gvrp | all | conflicts]
Parameters
Name
admin all
Description
Show the VLANs configured by administrator
Show all VLANs configured
combined conflicts gvrp interface mstp mvr nas vcl voice-vlan

show vlan-trans

Description
Show VLAN
Syntax
show vlan-trans
translation table for all
Show the VLANs configured by a combination
Show VLANs configurations that has conflicts
Show the VLANs configured by GVRP
Show the VLANs configured for a specific interface(s)
Show the VLANs configured by MSTP (Multiple Spanning Tree Protocol).
Show the VLANs configured by MVR
Show the VLANs configured by NAS
Show the VLANs configured by VCL
Show the VLANs configured by Voice VLAN
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 45
Parameters
None.

show voice

Description
Vlan for voice trac
Syntax
show voice vlan [oui oui | interface (port_type [port_list])]
Parameters
Name Description
ISW Commands
vlan
oui OUI configuration
oui OUI value
interface Select an interface to configure
port_type GigabitEthernet, 1 Gigabit Ethernet Port
port_list Port list in 1/1-14
VLAN for voice trac

show web

Description
Web privilege
Syntax
show web privilege group [group_name] level
Parameters
Name
privilege Web privilege
Description
group Web privilege grou
group_name CWORD
Valid words are: Aggregation | DHCP | Debug | Dhcp_Client | Diagnostics | EEE | Green_Ethernet | IP2 | IPMC_Snooping | LACP | LLDP (Link Layer Discovery Protocol) | Loop_Protect | MAC_Table | MVR | Maintenance | Mirroring | NTP | Ports | Private_VLANs | QoS | RPC | Security | Spanning_Tree | System | Timer | VCL | VLANs | Voice_VLAN | XXRP | sFlow
level Web privilege group level
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 46
Configure Mode Commands
Commands that can be executed under Configure Mode. To enter Configure Mode, type the command:
configure terminal. The prompt will now show (config)#.
aaa
Description
Authentication
Syntax
aaa authentication
Parameters
Name Description
ISW Commands
authentication

access

Description
Management configuration
Syntax
access management
Parameters
Name
management

access-list

Description
Authentication
Description
Access management configuration
Enter ACL (Access Control List)
Syntax
profile acl
Parameters
None.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 47
Profile Config Mode

account add <username>

Description
Add an account.
Syntax
username word31 privilege 0-15 password encrypted word4-44
Parameters
Name Description
ISW Commands
word31
0-15
word4-44

account delete <username>

Description
Delete an account.
Syntax
no username word31
Parameters
Name
word31
Description
Valid values: 1 – 31 characters Type: Mandatory
Valid values: 1 – 31 characters Type: Mandatory
Valid values: 0 – 15 Type: Mandatory
Valid values: 4-44 characters debug Type: Mandatory

aggregation mode

Description
Trac distribution mode
Syntax
aggregation mode {dmac | ip | port | smac}
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 48
Name Description
ISW Commands
dmac ip port smac

alarm history clear

Description
Clear alarm history
Syntax
alarm history clear
Parameters
None.

banner

Destination MAC aects the distribution
IP address aects the distribution
IP port aects the distribution
Source MAC aects the distribution
Description
Banner control
Syntax
banner {LINE | exec | login | motd}
Parameters
Name
LINE exec login motd
Description
c banner-text c, where 'c' is a delimiting character
Set EXEC process creation banner
Set login banner
Set Message of the Day banner

clear ip igmp snooping statistics

Description
clear IP IGMP
snooping statistics
Syntax
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 49
clear ip igmp snooping [vlan vlan_list] statistics
Parameters
Name Description
ISW Commands
vlan_list
VLAN list.

clear logging

Description
Clear logging
Syntax
clear logging [info] [warning] [error] [switch switch_list]
Parameters
Name Description
info warning error switch_list
Information
Warning
Error
List of switch ID, e.g., 1,3-5,6

clear mac address-table

Description
Clear MAC address-table
Syntax
clear mac address-table
Parameters

clock datetime

Description
Set device date and time.
Syntax
clock datetime 2000-2037 1-12 1-31 0-23 0-59 0-59
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 50
Name Description
ISW Commands
2000-2037 1-12 1-31 0-23 0-59 0-59
year
month
Date
Hour
minute
Second

clock summer-time set [start-time] [end-time]

Description
Set date/time.
Syntax
clock summer-time word16 date [1-12 1-31 2000-2097 hhmm 1-12 1-31 2000-2097 hhmm [1-1440]]
Parameters
Name
Description
word16
day
month
year
minute
second
Valid values: please see 'list timezone' Type: Mandatory
Valid values: 1 – 31 Type: Mandatory
Valid values: 1 – 12 Type: Mandatory
Valid values: 2000 – 2097 Type: Mandatory
Valid values: 0 – 59 Type: Mandatory
Valid values: 0 – 59 Type: Optional

clock timezone

Description
Set time zone.
Syntax
clock timezone word16 -23-23 [0-59]
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 51
Parameters
Name Description
ISW Commands
word16
Valid values: please see 'list timezone' Type: Mandatory
configuration save and replace
Description
Save and install configuration
Syntax
copy {startup-config | running-config | Filename} {startup-config |
running-config | Filename} [syntax-check]
Parameters
Name Description
running-config startup-config syntax-check Filename
Currently running configuration
Startup configuration
Perform syntax check on source configuration
File in FLASH or on TFTP server

ddmi

Description
Enable DDMI function
Syntax
ddmi
Parameters
None.

debug

Description
Set prompt for testing
Syntax
debug prompt word
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 52
Parameters
Name Description
ISW Commands
word
Word for prompt in 32 characters.

default access-list rate-limiter

Description
Rate limiter
Syntax
default access-list rate-limiter [rate_limiter_list]
Parameters
Name Description
RateLimiterId
Rate limiter ID. Valid values are 1 – 16.

delete

Description
Delete one file in flash: file system
Syntax
delete word
Parameters
Name
word
dir
Description
Directory of all files in flash: file system
Syntax
dir
Parameters
Description
Name of file to delete.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 53
do
Description
To run exec commands in config mode
Syntax
do line
Parameters
Name Description
ISW Commands
line
Exec Command

duplex

Description
Set duplex mode
Syntax
duplex {half | full | auto [half | full]}
Parameters
Name
half full auto half | full
Description
Forced half duplex.
Forced full duplex.
Auto negotiation of duplex mode.
Advertise half /full duplex.

editing

Description
Enable command line editing
Syntax
editing
Parameters
firmware
Description
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 54
Firmware swap and upgrade
Syntax
firmware {swap | upgrade}
Parameters
Name Description
ISW Commands
swap upgrade
Swap between Active and Alternate firmware image
Firmware upgrade
flowcontrol
Description
Enable/Disable flow control.
Syntax

flowcontrol {on | off}

Parameters
Name
on off
Description
Enable flow control.
Disable flow control.
flow-control {enable | disble}
Description
Enable/Disable flow-control.
Syntax

flow-control {enable | disble}

Parameters
Name
enable disable
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 55
Description
Enable flow-control.
Disable flow-control.

frame-sizes

Description
Select the frame sizes that the enabled tests will loop through
Syntax
frame-sizes {[64] [128] [256] [512] [1024] [1280] [1518] [2000] [9600]}
Parameters
Name Description
ISW Commands
64 128 256 512 1024 1280 1518 2000 9600
Enable testing with 64-byte TST PDUs
Enable testing with 128-byte TST PDUs
Enable testing with 256-byte TST PDUs
Enable testing with 512-byte TST PDUs
Enable testing with 1024-byte TST PDUs
Enable testing with 1280-byte TST PDUs
Enable testing with 1518-byte TST PDUs
Enable testing with 2000-byte TST PDUs
Enable testing with 9600-byte TST PDUs

green-etherneteee

Description
Powering down of PHYs when there is no trac.
Syntax
green-etherneteee
Parameters

green-etherneteee optimize-for-power

Description
Set if EEE shall be optimized for least power consumption (else optimized for least trac latency).
Syntax
green-etherneteee optimize-for-power
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 56

green-etherneteee urgent-queues

Description
Enables EEE urgent queue. An urgent queue means that latency is kept to a minimum for trac going to that queue. Note: EEE power savings will be reduced.
Syntax
green-etherneteee urgent-queues [range_list]
Parameters
Name Description
ISW Commands
range_list

help

Description
Description of the interactive help system
Syntax
help
Parameters

interface gigabit <portNo>

Description
Enter gigabit interface mode.
Syntax
interface gigabit portNo
EEE Interface.
Parameters
Name
portNo
Description
Valid values: 1 – 10 Type: Mandatory

interface vlan <vlanid>

Description
Enter mode of interface VLAN.
Syntax
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 57
interface vlan vlanid
Parameters
Name Description
ISW Commands
vlanid
Valid values: 1 – 4094 Type: Mandatory

iparp inspection

Description
IPARP inspection
Syntax
iparp inspection
Parameters

ip arp inspection translate

Description
IP ARP inspection entry interface configuration
Syntax
ip arp inspection translate [interface port_type port_type_id vlan_id mac_ucast ipv4_ucast]
Parameters
Name
port_type port_type_id vlan_id mac_ucast ipv4_ucast
Description
Port type in Fast, Giga or Tengigaethernet
Port ID in the format of switch-no/port-no
Select a VLAN id to configure
Select a MAC address to configure
Select an IP Address to configure

ip arp inspection entry

Description
ARP inspection entry interface configuration
Syntax
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 58
ip arp inspection entry interface port_type in_port_type_id vlan_var mac_var ipv4_var
Parameters
Name Description
port_type Port type in Fast, Giga or Tengigaethernet
in_port_type_id Port ID in the format of switch-no/port-no
vlan_var Select a VLAN id to configure
mac_var Select a MAC address to configure
ipv4_var Select an IP Address to configure

ip arp inspection vlan

Description
ISW Commands
IP ARP inspection vlan setting
Syntax
ip arp inspection vlan vlan_list
Parameters
Name
vlan_list

ip dns proxy

Description
IP DNS proxy service
Syntax
ipdns proxy
Parameters
Description
ARP inspection VLAN list

ip http secure-redirect

Description
IP http secure-redirect
Syntax
ip http secure-redirect
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 59
Parameters

ip http secure-server

Description
IP Secure HTTP web server
Syntax
ip http secure-server
Parameters

ip source binding interface

Description
IP source binding entry interface configuration
ISW Commands
Syntax
ip source binding interface port_type port_type_id vlan_id ipv4_ucast mac_ucast
Parameters
Name
port_type port_type_id vlan_id ipv4_ucast mac_ucast
Description
Port type in Fast, Giga or Tengigaethernet
Port ID in the format of switch-no/port-no
Select a VLAN id to configure
Select an IP Address to configure
Select a MAC address to configure

ip ssh

Description
IP Secure Shell
Syntax
ipssh
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 60

ip name-server

Description
IP name server
Syntax
ip name-server {v_ipv4_ucast | dhcp [interface vlan v_vlan_id]}
Parameters
Name Description
v_ipv4_ucast A valid IPv4 unicast address
dhcp Dynamic Host Configuration Protocol
v_vlan_id VLAN identifier(s): VID

ip route

ISW Commands
Description
IP Route
Syntax
ip route v_ipv4_addr v_ipv4_netmask v_ipv4_gw
Parameters
Name
v_ipv4_addr Network
v_ipv4_netmask Netmask
v_ipv4_gw Gateway
Description

ip routing

Description
IP routing
Syntax
ip routing
Parameters

ip verify

Description
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 61
IP verify
Syntax
ip verify [source] [translate]
Parameters
Name Description
source verify source
translate ip verify source translate all entries
ipmc profile
Description
IPMC profile configuration
ISW Commands
Syntax

ipmc profile

Parameters

ipmc range

Description
A range of IPv4/IPv6 multicast addresses for the profile
Syntax
ipmc range word16 {ipv4_mcast [ipv4_mcast] | ipv6_mcast [ipv6_mcast]}
Parameters
Name
word16 ipv4_mcast ipv4_mcast ipv6_mcast
Description
Range entry name in 16 char's
Valid IPv4 multicast address
Valid IPv4 multicast address that is not less than start address
Valid IPv6 multicast address
ipv6_mcast
Valid IPv6 multicast address that is not less than start address

lacp

Description
LACP system priority
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 62
Syntax
lacp system-priority v_1_to_65535
Parameters
Name Description
system-priority System priority
v_1_to_65535 Priority value, lower means higher priority

line

Description
Console terminal control
Syntax
line {0–16 | console 0 | vty 0–15}
ISW Commands
Parameters
Name Description
<0–16>
console Console terminal line
vty Virtual terminal
List of line numbers

login host

Description
Domain name and IP address
Syntax
logging hostname {v_ipv4_ucast | v_word45}
Parameters
Name
hostname
Description
Domain name of the log server
ipv4_ucast IP address of the log server

login level

Description
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 63
Log level
Syntax
logging level {info | warning | error}
Parameters
Name Description
ISW Commands
error
info Information
warning Warning

login on

Description
Log on
Syntax
logging on
Parameters

logout

Description
System logout
Error
Syntax
logout
Parameters

mac address-table aging-time

Description
MAC table entries/configuration
Syntax
mac address-table aging-time v_0_10_to_1000000
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 64
Name Description
ISW Commands
<v_0_10_to_1000000>
Aging time in seconds, 0 disables aging

mac address-table aging-time <time>

Description
Configure aging time for a bridge port.
Syntax
mac address-table aging-time time
Parameters
Name Description
time
Valid values: 10 – 1000000 (seconds), 0: disable aging Type: Mandatory

mac address-table static

Description
MAC table entries/configuration
Syntax
mac address-table static v_mac_addr vlan v_vlan_id interface (port_type [v_port_type_list])
Parameters
Name
v_mac_addr 48 bit MAC address
v_vlan_id VLAN IDs 1-4095
port_type Select an interface to configure
v_port_type_list Port list
Description

media-type

Description
Configure media-type
Syntax
media-type {rj45 | sfp | dual}
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 65
Parameters
Name Description
ISW Commands
rj45 sfp dual
rj45 interface (copper interface).
sfp interface (fiber interface).
Dual media interface (cu & fiber interface).

monitor destination interface

Description
The destination port. That is the port that tracked should be mirrored to.
Syntax
monitor destination interface port_type port_type_id
Parameters
Name Description
port_type Port type
port_type_id Port Number

monitor source cpu

Description
Mirror Interface trac
Syntax
monitor source {cpu [cpu_switch_range]}} {both | rx | tx}
Parameters
Name
both
rx Setting source port to rx will mirror ingress trac
tx Setting source port to tx will mirror egress trac
Description
Setting source port to both will mirror both ingress and egress trac

monitor source interface

Description
Mirror Interface trac
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 66
Syntax
monitor source {{interface (port_type [v_port_type_list])}
Parameters
Name Description
port_type 1 Gigabit Ethernet Port
v_port_type_lis Port list

more

Description
File in FLASH or on TFTP server
Syntax
more Path
ISW Commands
Parameters

mtu <value>

Description
MTU size.
Syntax
mtu value
Parameters
Name
value
no
Description
Description
Range. Valid values: 1536 – 9000 (bytes) Type: Mandatory
Function disable
Syntax
no {debug | port-securit | terminal}
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 67
Name Description
ISW Commands
debug port-securit terminal
Debugging functions
Port security (PSEC limit)
Set terminal line parameters

ntp server <1-5> ip-address <ip>

Description
Set NTP server address.
Syntax
ntp server 1-5 ip-address {ipv4_ucast | ipv6_ucast | hostname}
Parameters
Name Description
1-5 ipv4
<ipv6 > hostname
index number
Type: Mandatory
Server name

ping

Description
The ping function
Syntax
ping {ip | ipv6}
Parameters
Name
ip ipv6

port-security

Description
Port security
Description
IP (ICMP (Internet Control Message Protocol)) echo
IPv6 (ICMPv6) echo
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 68
Syntax
port-security [aging] [time v_10_to_10000000]
Parameters
Name Description
aging Enable/disable port security aging
ISW Commands
time v_10_to_10000000

port {enable/disable}

Description
Set interface gigabit port enable or disable.
Syntax
port {enable | disable}
Parameters
Name
enable Turn o gigabit port.
disable Turn o gigabit port.
Description

privilege

Time in seconds between check for activity on learned MAC addresses
10 – 10000000 seconds
Syntax
privilege {exec |configure|config-vlan |line |interface | if-vlan |ipmc-
profile |snmps-host |stp-aggr |dhcp-pool |rfc2544-profile} level privilege
cmd
Parameters
Name
config-vlan configure dhcp-pool exec if-vlan interface
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 69
Description
VLAN Configuration Mode
Global configuration mod
DHCP Pool Configuration Mode
Exec mode
VLAN Interface Mode
Port List Interface Mode
Name Description
ISW Commands
ipmc-profile line rfc2544-profile snmps-host stp-aggr
profile sch
Description
Enter Scheduling Profile Config Mode
Syntax

profile sch

Parameters
None.
IPMC Profile Mode
Line configuration mode
RFC2544 Profile Mode
SNMP Server Host Mode
STP Aggregation Mode

reload

Description
System or configuration reset
Syntax
reload {cold | default}
Parameters
Name
cold defaults

rmon

Description
RMON
Syntax
rmon {alarm | event}
Description
Reload cold
Reload defaults without rebooting
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 70
Parameters
Name Description
ISW Commands
alarm event
Configure an RMON alarm
Configure an RMON event

rmon alarm

Description
RMON Alarm
Syntax
rmon alarm id oid_str interval {absolute | delta} rising-threshold rising_threshold [rising_event_id] falling-threshold falling_threshold [falling_event_id] {[rising | falling | both ] }
Parameters
Name Description
id Alarm entry ID
interval Sample interval
absolute Test each sample directly
delta Test delta between samples
rising_threshold <-2147483648-2147483647> rising threshold value
rising_event_id <0-65535> Event to fire on rising threshold crossing
falling_threshold <-2147483648-2147483647> falling threshold value
falling_event_id <0-65535> Event to fire on falling threshold crossing
rising Trigger alarm when the first value is larger than the rising threshold
falling rigger alarm when the first value is less than the falling threshold
both
Trigger alarm when the first value is larger than the rising threshold or less than the falling threshold (default)

rmon event

Description
RMON Event
Syntax
rmon event id [log] [trap community] {[description description]}
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 71
Name Description
ISW Commands
description log trap
Specify a description of the event
Generate RMON log when the event fires
Generate SNMP trap when the event fires

speed (Ethernet)

Description
Configure gigabit Ethernet speed and Copper/SFP for gigabit port 7–8.
Note Ports 1–6 Only support copper. They do not support SFP. Ports 9 and 10 only support auto.
Syntax
speed {auto | full-l000mbps | full-100mbps | full-10mbps | half-100mbps |
half-10mbps}
Parameters
Name
Description
auto full-l000mbps full-100mbps full-10mbps half-100mbps half-10mbps
Auto negotiation.
Set 1000 Mbps full duplexing.
Set 100 Mbps full duplexing.
Set 10 Mbps full duplexing.
Set 100 Mbps half duplexing.
Set 10 Mbps half duplexing.

speed (interface)

Description
Configure interface speed. If you use 10, 100, or 1000 keywords with the auto keyword the port will only advertise the specified speeds.
Syntax
speed {10g | 2500 | 1000 | 100 | 10 | auto {[10] [100] [1000]}}
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 72
Parameters
Name Description
ISW Commands
10g 2500 1000 100 auto 10 100 1000
10 Gbps
25 Gbps
1 Gbps
100 Mbps
Auto-negotiation
10 Mbps
100 Mbps
1000 Mbps (1 Gbps)

syslog {enable | disable}

Description
Disable or enable Syslog service.
Syntax
logging on no logging on
Parameters
None.

tacacs-server host

Description
Configure TACACS+ server
Syntax
tacacs-server host word1-255 [ port 0-65535] [timeout 1-1000] [key line1-63]
Parameters
Name
word1-255 0-65535 1-1000 line1-63
Description
Hostname or IP address
TCP port number
Wait time in seconds
The shared key
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 73

tacacs-server key

Description
Configure TACACS+ encryption key
Syntax
tacacs-server key line1-63
Parameters
Name Description
ISW Commands
line1-63
The shared key

terminal

Description
Terminal control.
Syntax
terminal {editing |exec-timeout |help |history |length |width}
Parameters
Name
editing exec-timeout help history length
Description
Enable command line editing
Set the EXEC timeout
Description of the interactive help system
Control the command history function
Set number of lines on a screen
width
Set width of the display terminal

tacacs-server timeout

Description
Time to wait for a TACACS+ server to reply
Syntax
tacacs-server timeout <1-1000>
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 74
Name Description
ISW Commands
1-1000
Wait time in seconds

traps

Description
trap event configuration
Syntax
traps [aaa authentication ] [system [coldstart] [warmstart]] [switch [stp] [rmon]]
Parameters
Name Description
aaa authentication coldstart warmstart stp rmon
AAA authentication fail event
Cold start event
Warm start event
STP event
RMON event

upnp

Description
Set UPnP's configurations
Syntax
upnp
Parameters

upnp advertising-duration

Description
Set UPnP's advertising duration
Syntax
upnp advertising-duration 100-86400
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 75
Name Description
ISW Commands
100-86400

upnp ttl

Description
Set UPnP's TTL value
Syntax
upnp ttl 1-255
Parameters
Name Description
1-255

username

Description
advertising duration
TTL value
User account
Syntax
username username privilege priv password encrypted encry_password username username privilege priv password none username username privilege priv password unencrypted password
Parameters
Name
username <Username : word31> User name allows letters, numbers and underscores
privilege Set user privilege level
priv User privilege level
password Specify the password for the user
encrypted Specifies an ENCRYPTED password will follow
none NULL password
unencrypted Specifies an UNENCRYPTED password will follow
Description

vlan <vlanid>

Description
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 76
Configure VLAN.
Syntax
vlan vlanid
Parameters
Name Description
ISW Commands
vlanid

vlan <vlanid> <name>

Description
Configure VLAN
Syntax
vlan vlanid name
Parameters
Name
vlanid
name
’s name.
Create an empty VLAN index. Valid values: 1 – 4094 Type: Mandatory
Description
Create an empty VLAN index. Valid values: 1 – 4094 Type: Mandatory
VLAN Name (0–31) String Size:0–31 Type: Mandatory

vlan disable <vlanid>

Description
Delete VLAN memberset/setting.
Syntax
vlan disable vlanid
Parameters
Name
vlanid
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 77
Description
Valid values: 1 – 4094 Type: Mandatory
web
Description
Configure web privilege group names and levels.
Syntax
web privilege group group_namelevel {[crocro] [crwcrw] [srosro] [srwsrw]}*1
Parameters
Name Description
ISW Commands
privilege
group Web privilege group
group_name Valid words are Aggregation | DHCP | Debug | Dhcp_Client | Diagnostics | EEE |
level
cro Configuration Read-only level
crw Configuration Read-write level
sro Status/Statistics Read-only level
srw Status/Statistics Read-write level
cro <Cro : 0-15>
crw <Crw : 0-15>
sro <Sro : 0-15>
srw <Srw : 0-15>
Web privilege
Green_Ethernet | IP2 | IPMC_Snooping | LACP | LLDP | Loop_Protect | MAC_Table | MVR | Maintenance | Mirroring | NTP | Ports | Private_VLANs | QoS | RPC | Security | Spanning_Tree | System | Timer | VCL | VLANs | Voice_VLAN | XXRP | sFlow
Web privilege group level

VLAN Mode Commands

vlan

Description
VLAN commands
Syntax
vlan vlan_list
Parameters
Name
vlan_list
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 78
Description
ISL VLAN IDs 1–4095

vlan ethertype s-custom-port

Description
Vlan Ether type for custom S-ports configuration
Syntax
vlan ethertype s-custom-port 0x0600-0xffff
Parameters
Name Description
ISW Commands
0x0600-0xffff
Ethertype range

vlan protocol

Description
Syntax
Syntax
vlan protocol {{eth2 {0x600-0xffff | arp | ip | ipx | at}} | {snap {0x0-0xffffff | rfc_1042 | snap_8021h} 0x0-0xffff} | {llc 0x0-0xff 0x0-0xff}} group word16
Parameters
Name
0x600-0xffff arp ip ipx
Description
Ether Type range
Ether Type is ARP
Ether Type is IP
Ether Type is IPX
at 0x0-0xffffff rfc_1042 snap_8021h 0x0-0xffff 0x0-0xff 0x0-0xff word16
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 79
Ether Type is AppleTalk
SNAP OUI range
SNAP OUI is rfc_1042
SNAP OUI is 8021h
PID range
DSAP range
SSAP range
Group Name. Valid values are 1 – 16 characters

vlan-trunking

Description
Change whether trunking of unknown VLANs is enabled
Syntax
vlan-trunking
Parameters

switchport access vlan

Description
Set switch access mode of the interface
Syntax
switchport access vlan vlan_id
ISW Commands
Parameters
Name Description
vlan_id
VLAN ID of the VLAN when this port is in access mode

switchport forbidden vlan

Description
Adds or removes forbidden VLAN
Syntax
switchport forbidden vlan {add | remove} vlan_list
Parameters
Name
add remove vlan_list
s from the current list of forbidden VLANs
Description
Add to existing list.
Remove from existing list.
VLAN IDs

switchport hybrid acceptable-frame-type

Description
Set acceptable frame type on a port
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 80
ISW Commands
Syntax
switchport hybrid acceptable-frame-type {all | tagged | untagged}
Parameters
Name Description
all tagged untagged
Allow all frames
Allow only tagged frames
Allow only untagged frames

switchport hybrid allowed vlan

Description
Set allowed VLAN
Syntax
switchport hybrid allowed vlan {all | none | [add | remove | except]
vlan_list}
Parameters
Name
all none add
characteristics when interface is in hybrid mode
Description
All VLANs
No VLANs
Add VLANs to the current list
remove except vlan_list
Remove VLANs from the current list
All VLANs except the following
VLAN IDs of the allowed VLANs when this port is in hybrid mode

switchport hybrid egress-tag

Description
Egress VLAN tagging configuration
Syntax
switchport hybrid egress-tag {none | all [except-native]}
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 81
Name Description
ISW Commands
none all except-native
No egress tagging
Tag all frames
Tag all frames except frames classified to native VLAN of the hybrid port
switchport hybrid ingress-filtering
Description
VLAN Ingress filter configuration
Syntax

switchport hybrid ingress-filtering

Parameters

switchport mode

Description
Set switching mode
Syntax
switchport mode {access | trunk | hybrid}
Parameters
Name
access trunk hybrid
Description
Set mode to ACCESS unconditionally
Set mode to TRUNK unconditionally
Set mode to HYBRID unconditionall

switchport trunk allowed vlan

Description
Set allowed VLAN
Syntax
switchport trunk allowed vlan {all | none | [add | remove | except]
vlan_list}
characteristics when interface is in trunk mode
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 82
Name Description
ISW Commands
all none add remove except vlan_list
All VLANs
No VLANs
Add VLANs to the current list
Remove VLANs from the current list
All VLANs except the following
VLAN IDs of the allowed VLANs when this port is in trunk mode

switchport vlan protocol group

Description
Protocol-based VLAN group commands
Syntax
switchport vlan protocol group word16 vlan vlan_id
Parameters
Name
Description
word16 vlan_id
Group Name (Range: 1 - 16 characters)
VLAN ID required for the group to VLAN mapping (Range: 1-4095)

Interface VLAN Mode Commands

interface

Description
Interface configuration
Syntax
interface port_type [port_type_list]
Parameters
Name
port_type port_type_list
Description
Port type in Fast, Giga or Tengigaethernet
List of Port ID, ex, 1/1,3-5;2/2-4,6
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 83

interface vlan

Description
VLAN interface configurations
Syntax
interface vlan vlan_list
Parameters
Name Description
ISW Commands
vlan_list
List of VLAN interface numbers, range is 1 – 4095

ip address

Description
IPv4 address configurations
Syntax
ip address {{ipv4_addr ipv4_netmask} | {dhcp [fallback ipv4_addr ipv4_netmask [timeout uint]]}}
Parameters
Name
ipv4_addr ipv4_netmask dhcp fallback ipv4_addr
Description
IP address
IP netmask
Enable DHCP
DHCP fallback settings
DHCP fallback address
ipv4_netmask timeout uint
DHCP fallback netmask
DHCP fallback timeout
DHCP fallback timeout in seconds

ip name-server

Description
Interface Internet Protocol config commands Domain Name System
Syntax
ip name-server {ipv4_ucast | dhcp [interface vlan vlan_id]}
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 84
Parameters
Name Description
ISW Commands
ipv4_ucast vlan_id
A valid IPv4 unicast address
VLAN identifier(s): VID

ip dhcp excluded-address

Description
Prevent DHCP from assigning certain addresses
Syntax
ip dhcp excluded-address low_ip [high_ip]
Parameters
Name Description
low_ip Low IP address
high_ip High IP addres

ip dhcp pool

Description
Pool name in 32 characters
Syntax
ip dhcp pool <pool_name>
Parameters
None.

ip dhcp server

Description
DHCP Server
Syntax
ip dhcp server
Parameters
None.
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 85

ip dhcp relay

Description
DHCP relay agent configuration
Syntax
ipdhcp relay
Parameters
None.

ip dhcp relay information option

Description
IP DHCP relay information option(Option 82)
Syntax
ipdhcp relay information option
ISW Commands
Parameters
None.

ip dhcp retry interface vlan

Description
Restart the DHCP query process
Syntax
ipdhcp retry interface vlan vlan_id
Parameters
Name
vlan_id
Description
Vlan ID

ip dhcp snooping

Description
IP DHCP snooping
Syntax
ipdhcp snooping
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 86
Parameters
None.

ip helper-address

Description
DHCP relay server
Syntax
ip helper-address <v_ipv4_ucast>
Parameters
Name Description
ISW Commands
v_ipv4_ucast

ipv6 address

Description
Configure the IPv6 address of an interface
Syntax
ipv6 address ipv6_subnet
Parameters
Name
ipv6_subnet

ipv6mtu

Description
IP address of the DHCP relay server
Description
IPv6 prefix x:x::y/z
IPv6 Maximum transmission unit
Syntax
ipv6 mtu 1280-1500
Parameters
Name
1280-1500
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 87
Description
MTU value in bytes

RingV2 Group Mode Commands

ringv2 protect

Description
To configure ring protection.
Syntax
ring protect
Parameters
Name Description
group1 Configure ring protection v2 group1 (Ring)
group2 Configure ring protection v2 group2 (Ring)
group3 Configure ring protection v2 group3 (Chain)
ISW Commands

guard-time

Description
Set guard time
Syntax
guard-time {ringGuardTimerDef}
Parameters
Name
ringGuardTimerDef <10-3600>, unit: secound. Default is 10 seconds

mode

Description
Enable/Disable ring group
Syntax
mode {disable | enable}
Description
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 88
Name Description
ISW Commands
disable
enable Set the specified Ring group to Enabled
Set the specified Ring group to Disabled

node1 interface GigabitEthernet <portNo>}

Description
Set interface of ring protection node
Syntax
node1 interface GigabitEthernet portNo
Parameters
Name Description
portNo
Valid values: 1–max port index.

node2 interface GigabitEthernet <portNo>}

Description
Set interface of ring protection node
Syntax
Node2 interface GigabitEthernet portNo
Parameters
Name
portNo
Description
Valid values: 1–max port index.

role

Description
Set role for group
Syntax
role {ring-master | ring-slave | coupling-primary | coupling-backup | dual-homing | chain-head | chain-tail | chain-member | b-chain-terminal-1 | b-chain-terminal-2 | b-chain-central-block | b-chain-member}
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 89
Name Description
ISW Commands
ring-master ring-slave coupling-
primary coupling-
backup dual-homing chain-head chain-member chain-tail b-chain-
central-block b-chain-member b-chain-
terminal-1 b-chain-
terminal-2
Set role to ring master
Set role to ring slave
Set role to coupling primary
Set role to coupling backup
Set role to dual homing
Set role to chain head
Set role to chain member
Set role to chain tail
Set role to balancing chain central block
Set role to balancing chain member
Set role to balancing chain terminal 1
Set role to balancing chain terminal 2

Spanning Tree

spanning-tree

Description
Enabe/disable STP on this interface
Syntax
spanning-tree
Parameters
None.

spanning-tree aggregation

Description
Spanning Tree protocol
Syntax
spanning-tree aggregation
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 90
Parameters
None.

spanning-tree auto-edge

Description
Auto detect edge status
Syntax
spanning-tree auto-edge
Parameters

spanning-tree bpdu-guard

Description
ISW Commands
Enable/disable BPDU guard
Syntax
spanning-tree bpdu-guard
Parameters
None.

spanning-tree edge

Description
Edge port
spanning-tree
STP Bridge
Syntax
spanning-tree edge
Parameters
None.
spanning-tree edge bpdu-filter
Description
Enable BPDU filter (stop BPDU tx/rx)
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 91
Syntax
spanning-tree edge bpdu-filter
Parameters
None.

spanning-tree mode

Description
Spanning Tree mode
STP protocol mode
stp
802.1D Spanning Tree
ISW Commands
rstp
Rabid Spanning Tree (802.1w)
mstp
Multiple Spanning Tree (802.1s)
Syntax
spanning-tree mode {stp | rstp | mstp}
Parameters
Name
stp rstp mstp

spanning-tree mst cost

Description
Description
802.1D Spanning Tree
Rabid Spanning Tree (802.1w)
Multiple Spanning Tree (802.1s)
STP
bridge instance
STP Cost of this port
Syntax
spanning-tree mst 0-7 cost {1-200000000 | auto}
Parameters
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 92
Name Description
ISW Commands
0-7 1-200000000

spanning-tree mst port-priority

Description
port-priority
Syntax
spanning-tree mst 0-7 port-priority 0-240
Parameters
Name Description
0-7 0-240

spanning-tree mst priority

instance 0-7 (CIST=0, MST2=1...)
STP Cost of this port
instance 0-7 (CIST=0, MST2=1...)
STP priority of this port
Description
Priority of the instance. Range in seconds.
Syntax
spanning-tree mst 0-7 priority 0-61440
Parameters
Name
0-7 0-61440

spanning-tree mst vlan

Description
VLAN keyword
Syntax
spanning-tree mst 0-7 vlan vlan_list
Description
instance 0-7 (CIST=0, MST2=1...)
Priority of the instance
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 93
Parameters
Name Description
ISW Commands
0-7 vlan_list

spanning-tree mst forward-time

Description
forward-time
Delay between port states
Syntax
spanning-tree mst forward-time 4-30
Parameters
Name Description
4-30
instance 0-7 (CIST=0, MST2=1...)
Range of VLANs
Delay between port states

spanning-tree mst max-age

Description
Max bridge age before timeout.
Syntax
spanning-tree mst max-age 6-40 [forward-time 4-30 ]
Parameters
Name
6-40 4-30
Description
Max bridge age before timeout
forward-time

spanning-tree mst max-hops

Description
MSTP bridge max hop count
Syntax
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 94
spanning-tree mst max-hops 6-40
Parameters
Name Description
ISW Commands
6-40
MSTP bridge max hop count

spanning-tree mst name

Description
Name of the bridge
Revision
Revision keyword
Syntax
spanning-tree mst name word32 revision 0-65535
Parameters
Name
word32 0-65535
Description
Name of the bridge
Revision keyword

spanning-tree mst <instance>

Description
instance 0-7 (CIST=0, MST2=1...)
Syntax
spanning-tree mst instance priority prio spanning-tree mst instance vlan v_vlan_list
Parameters
Name
instance priority vlan prio v_vlan_list
Description
<Instance : 0-7> instance 0-7 (CIST=0, MST2=1...)
Priority of the instance
VLAN keyword
<Prio : 0-61440> Range in seconds
<vlan_list> Range of VLANs
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 95

spanning-tree recovery

Description
Recovery
Syntax
spanning-tree recovery interval interval
Parameters
Name Description
ISW Commands
interval interval;
The interval
Interval : 30-86400 seconds

spanning-tree transmit

Description
Transmit
Syntax
spanning-tree transmit hold-count holdcount
Parameters
Name
hold-count holdcount
Description
Max number of transmit BPDUs per sec
<Holdcount : 1-10> 1-10 per sec, 6 is default

sFlow Configure Command

sflow
Description
Enables/disables flow sampling on this port.
Syntax
sflow [range_list]
Parameters
Name
range_list
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 96
Description
Sampler instance
sflow agent-ip
Description
The agent IP address used as agent-address in UDP datagrams. Defaults to IPv4 loopback address.
Syntax
sflow agent-ip {ipv4 ipv4_addr | ipv6 ipv6_addr}
Parameters
Name Description
ISW Commands
ipv4_addr ipv6_addr
IPv4 address
IPv6 address
sflow collector-address
Description
Sflow runtime, see sflow_icli_functions
Syntax

sflow collector-address [receiver range_list] [word]

Parameters
Name
range_list
Description
Sampler instance
sflow max-datagram-size
Description
Statistics flow Maximum datagram size.
Syntax

sflow max-datagram-size [receiver range_list] 200-1468

Parameters
Name
range_list 200-1468
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 97
Description
receiver list
packet byte
sflow max-sampling-size
Description
Specifies the maximum number of bytes to transmit per flow sample.
Syntax

sflow max-sampling-size [sampler range_list] [14-200]

Parameters
Name Description
ISW Commands
range_list 200-1468
Sampler instance
packet byte
sflow collector-port
Description
Collector UDP port
Syntax

sflow collector-port [receiver rcvr_idx_list] collector_port

Parameters
Name
collector_port
Description
<Collector Port : 1-65535> Port number
sflow sampling-rate
Description
Specifies the statistical sampling rate. The sample rate is specified as N to sample 1/Nth of the packets n the monitored flows. There are no restrictions on the value, but the switch will adjust it to the closest possible sampling rate.
Syntax

sflow sampling-rate [sampler range_list] [1-4294967295]

Parameters
Name
range_list 1-4294967295
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 98
Description
Sampler instance
Sampling rate
sflow timeout
Description
Receiver timeout measured in seconds. The switch decrements the timeout once per second, and as long as it is non-zero, the receiver receives samples. Once the timeout reaches 0, the receiver and all its configuration is reset to defaults.
Syntax

sflow timeout [receiver range_list] 0-2147483647

Parameters
Name Description
ISW Commands
range_list 0-2147483647
SNMP Configure Command

snmp-server

Description
Enable SNMP
Syntax
snmp-server
Parameters
None.

snmp-server access

server
Sampler instance
Number of seconds.
Description
snmp-server access configuration
Syntax
snmp-server access group name model {v1 | v2c | v3 | any} level {auth |
noauth | priv} [read word255] [write word255]
Parameters
Name
group name v1 | v2c | v3 | any
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 99
Description
32 words
V1–v3 security model
Name Description
ISW Commands
level auth | noauth | priv
read word255
security level
authNoPriv Security Level noAuthNoPriv Security Level authPriv Security Level
specify a read view for the group
read view name

snmp-server community v2c

Description
Set the SNMP v2c community
Syntax
snmp-server community v2c word127 [ro | rw]
Parameters
Name Description
word127
Community word
ro rw
Read only
Read write

snmp-server community v3

Description
S Set the SNMP
Syntax
snmp-server community v3 word127 [ipv4_addr ipv4_netmask]
Parameters
Name
word127 ipv4_addr ipv4_netmask
v3 community
Description
Community word
IPv4 address
IPv4 netmask
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 100
Loading...
