Page 1
MADE IN ITALY
UK
design & production
PELLET STOvES USER MANUAL
INSERTO COMFORT P85 - P85 PLUS
004277958 - Rev 000
Page 2
2 ENGLISH
Page 3
attENtIoN
SurfacES caN bEcoME VEry Hot!
During combustion, thermal energy is released that signicantly increases the heat of surfaces, doors, handles, controls, glass, exhaust
pipes, and even the front of the appliance. Avoid contact with those elements if not wearing protective clothing (protective gloves
included). Make sure children are aware of the danger and keep them away from the stove during operation.
ENGLISH ............................................................................................................................................................................................................ 4
WarNINGS ........................................................................................................................................................................................................ 4
SafEty .............................................................................................................................................................................................................. 4
routINE MaINtENaNcE ................................................................................................................................................................................ 6
INStaLLatIoN .................................................................................................................................................................................................. 7
MINIMUM DISTANCES .............................................................................................................................................................................................................................. 7
PREPARATIONS FOR MAINTENANCE ..................................................................................................................................................................................................7
DEtaILS of coMfort P85 INSErt................................................................................................................................................................ 9
DEtaILS of coMfort P85 PLuS INSErt .................................................................................................................................................... 10
INStaLLatIoN of coMfort P85 - P85 PLuS INSErt ............................................................................................................................... 11
GENERAl ......................................................................................................................................................................................................................................................11
MINIMUM ClEARANCE ..........................................................................................................................................................................................................................11
INSTAllATION ...........................................................................................................................................................................................................................................12
frESH aIr DuctS .......................................................................................................................................................................................... 14
EXISTING INSTAllATION .......................................................................................................................................................................................................................14
NEw INSTAllATION ................................................................................................................................................................................................................................15
SafEty LatcH ................................................................................................................................................................................................ 16
ExtractIoN of INSErt aND PELLEt LoaDING ....................................................................................................................................... 17
PELLEtS aND fEEDING ................................................................................................................................................................................. 17
oPtIoNaL LoaDING accESSorIES ............................................................................................................................................................ 18
FRONT PEllET lOADING kIT ...............................................................................................................................................................................................................18
UPPER/SIDE PEllET lOADING kIT ....................................................................................................................................................................................................18
buLb tHErMoStat rEarM .......................................................................................................................................................................... 18
fuSE ................................................................................................................................................................................................................ 18
aIr DuctING fEaturES INSErt P85 PLuS ................................................................................................................................................19
FACTORy DEFAUlT OPERATION IN AIR DUCTING MODE .........................................................................................................................................................19
OPERATION IN AIR DUCTING wITh ThERMOSTAT OR PRObE (OPTIONAl)......................................................................................................................19
ta aDDItIoNaL tHErMoStat (oPtIoNaL) ...............................................................................................................................................20
EMErGENcy MoDuLE ................................................................................................................................................................................... 21
raDIo coNtroL ............................................................................................................................................................................................ 22
CONFIGURATION ......................................................................................................................................................................................................................................22
RADIO CONTROl ROOM PRObE CAlIbRATION ...........................................................................................................................................................................22
bATTERy TyPE AND REPlACEMENT .................................................................................................................................................................................................22
raDIo coNtroL fEaturES ......................................................................................................................................................................... 23
DISPLay .......................................................................................................................................................................................................... 24
GENEraL MENu ............................................................................................................................................................................................. 25
bASIC INSTRUCTIONS ............................................................................................................................................................................................................................26
fIrSt IGNItIoN SEttINGS ............................................................................................................................................................................ 26
DATE/TIME ..................................................................................................................................................................................................................................................26
lANGUAGE ..................................................................................................................................................................................................................................................26
DEGREES ......................................................................................................................................................................................................................................................26
oPEratIoN aND LoGIc ................................................................................................................................................................................ 27
froNt aIr ...................................................................................................................................................................................................... 28
aIr DuctING 1 ............................................................................................................................................................................................... 28
aIr DuctING 2 ............................................................................................................................................................................................... 28
EaSy SEtuP .................................................................................................................................................................................................... 28
cHroNo .......................................................................................................................................................................................................... 28
ENAblING ....................................................................................................................................................................................................................................................29
PRG 1-4 .........................................................................................................................................................................................................................................................29
SEttINGS ........................................................................................................................................................................................................ 31
UPDATE .........................................................................................................................................................................................................................................................31
STAND by .....................................................................................................................................................................................................................................................31
OPERATION wITh ADDITIONAl ThERMOSTAT (OPTIONAl) .................................................................................................................................................31
FIRST lOAD .................................................................................................................................................................................................................................................32
DElTA-T ........................................................................................................................................................................................................................................................32
RESET .............................................................................................................................................................................................................................................................32
aDDItIoNaL fuNctIoNS ............................................................................................................................................................................. 32
DElAy SwITCh-OFF.................................................................................................................................................................................................................................32
cLEaNING aND MaINtENaNcE ...................................................................................................................................................................33
MaINtENaNcE ............................................................................................................................................................................................... 33
PERIODIC ClEANING UNDER USER'S RESPONSIbIlITy .............................................................................................................................................................33
routINE MaINtENaNcE PErforMED by quaLIfIED tEcHNIcIaNS ....................................................................................................35
ShUT-DOwN (END OF SEASON) ........................................................................................................................................................................................................35
DISPLayS ........................................................................................................................................................................................................ 37
aLarMS .......................................................................................................................................................................................................... 37
GuaraNtEE tErMS ...................................................................................................................................................................................... 38
DISPoSaL........................................................................................................................................................................................................ 39
aLWayS uSE ProtEctIVE GLoVES!
3ENGLISH
Page 4
We thank you for having chosen our company; our product is a great heating solution developed from the
most advanced technology with top quality machining and modern design, aimed at making you enjoy the
fantastic sensation that the heat of a ame gives, in complete safety.
Warnings
This instructions manual is an integral part of the product: make sure that
it always accompanies the appliance, even if transferred to another owner
or user, or if transferred to another place. If it is damaged or lost, request
another copy from the area technician. This product is intended for the
use for which it has been expressly designed. The manufacturer is exempt
from any liability, contractual and extracontractual, for injury/damage
caused to persons/animals and objects, due to installation, adjustment
and maintenance errors and improper use.
Installation must be performed by qualied sta, which assumes complete responsibility for the denitive installation and consequent good
functioning of the product installed. One must also bear in mind all
laws and national, regional, provincial and town council Standards present in the country in which the appliance has been installed, as well as
the instructions contained in this manual.
The Manufacturer cannot be held responsible for the failure to comply
with such precautions.
After removing the packaging, ensure that the content is intact and
complete. Otherwise, contact the dealer where the appliance was purchased.
All electric components that make up the product must be replaced with
original spare parts exclusively by an authorised after-sales centre, thus
guaranteeing correct functioning.
safety
THE APPLIANCE MAY BE USED BY CHILDREN 8 YEARS OF AGE OR
OLDER AND INDIVIDUALS WITH REDUCED PHYSICAL, SENSORY, OR
MENTAL CAPACITIES OR WITHOUT EXPERIENCE OR THE NECESSARY
KNOWLEDGE, PROVIDED THAT THEY ARE SUPERVISED OR HAVE
RECEIVED INSTRUCTIONS ON SAFE USE OF THE APPLIANCE AND
THAT THEY UNDERSTAND THE INHERENT DANGERS.
4 ENGLISH
Page 5
THE GENERATOR MUST NOT BE USED BY PERSONS INCLUDING
CHILDREN WITH REDUCED PHYSICAL, SENSORY AND MENTAL
CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE
SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY
A PERSON RESPONSIBLE FOR THEIR SAFETY.
THE CLEANING AND MAINTENANCE REQUIRED BY THE USER MUST
NOT BE PERFORMED BY CHILDREN WITHOUT SUPERVISION.
CHILDREN MUST BE CHECKED TO ENSURE THAT THEY DO NOT PLAY
WITH THE APPLIANCE.
DO NOT TOUCH THE GENERATOR WHEN YOU ARE BAREFOOT OR
WHEN PARTS OF THE BODY ARE WET OR DAMP.
THE SAFETY AND ADJUSTMENT DEVICES MUST NOT BE
MODIFIED WITHOUT THE AUTHORISATION OR INDICATIONS OF THE
MANUFACTURER.
DO NOT PULL, REMOVE, TWIST THE ELECTRICAL CABLES COMING
OUT OF THE PRODUCT EVEN IF IT IS DISCONNECTED FROM THE
MAINS.
IT IS ADVISED TO POSITION THE POWER SUPPLY CABLE SO THAT IT
DOES NOT COME INTO CONTACT WITH HOT PARTS OF THE APPLIANCE.
THE POWER SUPPLY PLUG MUST BE ACCESSIBLE AFTER
INSTALLATION.
DO NOT CLOSE OR REDUCE THE DIMENSIONS OF THE AIRING VENTS
IN THE PLACE OF INSTALLATION. THE AIRING VENTS ARE ESSENTIAL
FOR CORRECT COMBUSTION.
DO NOT LEAVE THE PACKAGING ELEMENTS WITHIN REACH OF
CHILDREN OR UNASSISTED DISABLED PERSONS.
THE HEARTH DOOR MUST ALWAYS BE CLOSED DURING NORMAL
FUNCTIONING OF THE PRODUCT.
WHEN THE APPLIANCE IS FUNCTIONING AND HOT TO THE TOUCH,
ESPECIALLY ALL EXTERNAL SURFACES, ATTENTION MUST BE PAID
CHECK FOR THE PRESENCE OF ANY OBSTRUCTIONS BEFORE
SWITCHING THE APPLIANCE ON FOLLOWING A PROLONGED PERIOD
OF INACTIVITY.
THE GENERATOR HAS BEEN DESIGNED TO FUNCTION IN ANY
CLIMATIC CONDITION. IN PARTICULARLY ADVERSE CONDITIONS
STRONG WIND, FREEZING SAFETY SYSTEMS MAY INTERVENE
5ENGLISH
Page 6
THAT SWITCH THE GENERATOR OFF. IF THIS OCCURS, CONTACT THE
TECHNICAL AFTERSALES SERVICE AND ALWAYS DISABLE THE SAFETY
SYSTEMS.
IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS
FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE
BRIGADE.
THIS APPLIANCE MUST NOT BE USED TO BURN WASTE
DO NOT USE ANY FLAMMABLE LIQUIDS FOR IGNITION
DURING THE FILLING PHASE DO NOT PUT THE BAG OF PELLETS TO
INTO CONTACT WITH THE PRODUCT
THE MAJOLICAS ARE TOP QUALITY ARTISAN PRODUCTS AND
AS SUCH CAN HAVE MICRODOTS, CRACKLES AND CHROMATIC
IMPERFECTIONS. THESE FEATURES HIGHLIGHT THEIR VALUABLE
NATURE. DUE TO THEIR DIFFERENT DILATION COEFFICIENT, THEY
PRODUCE CRACKLING, WHICH DEMONSTRATE THEIR EFFECTIVE
AUTHENTICITY. TO CLEAN THE MAJOLICAS, IT IS RECOMMENDED TO
USE A SOFT, DRY CLOTH. IF A DETERGENT OR LIQUID IS USED, THE
LATTER COULD PENETRATE INSIDE THE CRACKLES, HIGHLIGHTING
THEM.
SINCE THE PRODUCT CAN TURN ON AUTOMATICALLY THANKS TO
THE TIMER, OR REMOTELY USING THE DEDICATED APPLICATIONS, IT IS
STRICTLY FORBIDDEN TO LEAVE ANY COMBUSTIBLE OBJECT WITHIN
THE SAFETY DISTANCES INDICATED ON THE TECHNICAL DATA PLATE.
routine Maintenance
Based on Decree 22 January 2008 n°37 art.2, routine maintenance means
interventions aimed at reducing degradation due to normal use, as well
as dealing with accidental events entailing the need of rst interventions,
which however do not modify the structure of the system upon which
one is intervening or its intended use according to the requirements laid
down by the technical standards in force and by the manufacturer's use
and maintenance manual.
6 ENGLISH
Page 7
INSTALLATION
GENERAL
The ue gas exhaust and hydraulic connections must be carried out by qualied personnel who must issue installation conformity
documentation compliant with national standards.
The installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity,
supplied with:
1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);
2) photocopy or photograph of the chimney plaque;
3) system booklet (where applicable).
The installer must ask to be issued with a receipt stating that the documentation has been provided, and must keep it with a copy of the technical
documentation relating to the installation.
For installation in a condominium, prior approval from the condominium's administrator must be requested.
Where required, check the exhaust gas emissions after installation. Should a sampling point be installed, it must be airtight.
COMPATIBILITY
Do not install in rooms with a re hazard. It is also forbidden to install it in living areas with the following characteristics:
1. where there are liquid fuel appliances with continuous or discontinuous operation that draw the combustion air into the room in which they
are installed.
2. where there are type B gas appliances intended for heating, with or without domestic hot water production and in adjacent and communicating
rooms.
3. where the depression measured in situ between the external and internal environment is greater than 4 Pa.
N.B.: Watertight appliances can also be installed in the cases indicated in points 1, 2 and 3 of this paragraph.
INSTALLATIONS IN BATHROOMS, BEDROOMS AND STUDIO FLATS
Installation in bathrooms, bedrooms and studio ats is only allowed for sealed or closed hearth appliances with ducted combustion air taken
from the outside.
POSITIONING AND SAFETY DISTANCES
The support surfaces and/or points must have a suitable capacity to bear the overall weight
of the appliance, accessories and coverings. If the oor is made of a combustible material,
we recommend using a non-combustible material to protect the front part from any burnt
material which might fall during routine cleaning operations. The generator must be level
to function properly. The side walls, the rear walls and the oor support surface should be
made of non-combustible material.
MINIMUM DISTANCES
Installation next to ammable or heat-sensitive materials is permitted only if the special
safety distances specied on the label at the beginning of the manual (pag.2) are
observed. If the materials are not ammable, you must keep a side and rear distance of at
least 100 mm (without the inserts). For products equipped with rear spacers, wall-mounting
installation is permitted exclusively for the rear side.
PREPARATIONS FOR MAINTENANCE
To carry out extraordinary maintenance operations on the product, it may be necessary to move it away from the adjacent walls. This must be
done by a technician authorised to disconnect the combustion product evacuation ducts and then reconnect them. For heaters connected to the
hydraulic system, the connection between the system itself and the product must be made in such a way that, when an authorised technician is
about to carry out extraordinary maintenance operations, it is possible to move the heater at least 1 metre away from the adjacent walls.
INSTALLING INSERTS
When installing inserts, access must be prevented to the internal parts of the appliance and it must not be possible to access live parts during
extraction operations.
Any wiring, for example the power cable or room probe, must be positioned so as not to be damaged during movement of the insert and must
not come into contact with hot parts. If a cavity made of combustible material is installed, we recommend taking all the safety precautions
indicated by the installation standards.
One must also bear in mind all laws and national,
regional, provincial and town council regulations in force
in the country in which the appliance has been installed,
as well as the instructions contained in this manual.
oor protection
Air inlet
VENTILATION AND AERATION OF INSTALLATION ROOMS
In case of non-airtight heater and/or installation, the ventilation must respect the minimum area indicated below (considering the highest value
among those provided):
Appliance categories Reference standard
Pellet stoves UNI EN 14785 - 80 cm²
Boilers UNI EN 303-5 50% 100 cm²
Under any condition, including in the presence of extractor hoods and/or of controlled forced ventilation systems, the pressure dierence
between the generator installation rooms and the outside must always be equal to or less than 4 Pa.
net opening section with respect to the
Percentage of the
appliance fumes outlet section
Minimum net opening value of the
ventilation duct
7ENGLISH
Page 8
In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or
ventilation opening.
The air inlets must meet the following requirements:
they must be protected with grids, metal mesh, etc., but without reducing the net useful section;
they must be made so as to make the maintenance operations possible;
positioned so that they cannot be obstructed;
The clean and non-contaminated air ow can also be obtained from a room adjacent to that of installation (indirect aeration and
ventilation), as long as the ow takes place freely through permanent openings communicating with the outside.
The adjacent room cannot be used as a garage, or to store combustible material or for any other activity with a re hazard, bathroom,
bedroom or common room of the building.
FLUE GAS EXHAUST
The heat generator works in depression and is equipped with an outlet fan for ue gas extraction. There must be a single exhaust system for
the generator. Using a ue that is shared with other devices is not allowed.
The components of the ue gas exhaust system must be chosen in relation to the type of appliance to be installed in compliance with:
UNI/ TS 11278 in the event of metal chimneys, with particular attention to that stated in the specication;
UNI EN 13063-1 and UNI EN 13063-2, UNI EN 1457, UNI EN 1806 in the event of non-metallic chimneys.
The length of the horizontal section must be minimal and, in any case, no longer than 3 metres, with a minimum upward slope of 3%
There must not be more than 4 direction changes including the one due to the use of the "T" element.
A “T” tting with a condensation collection cap must be provided at the base of the vertical section.
If the exhaust is not inserted in an existing ue, a vertical section with a windproof end piece is required (UNI 10683).
The vertical duct can be inside or outside the building. If the smoke duct is inserted in an existing ue, it must be certied for solid fuel.
If the smoke duct is outside the building, it must always be insulated.
The smoke ducts must have at least one airtight inlet for ue gas sampling.
All the sections of the ue gas duct must be accessible to inspection.
Inspection openings must be provided for cleaning.
If the generator has a fume temperature lower than 160°C+ ambient temperature caused by the high yield (contact technicians) it
MUST be resistant to humidity.
A ue system that does not respect the previous points or, in general, that does not comply with the regulations, may cause condensation
phenomena inside it.
CHIMNEY CAP
The chimney caps must meet the following requirements:
they must have a useful outlet section no less than double that of the chimney/ducted system on which it is installed;
they must be adapted in order to prevent the penetration of rain and snow in the chimney/ducted system;
they must be built so that, in the event of winds coming from all directions and from any angle, the expulsion of combustion products
is in any case ensured;
EXAMPLES OF CORRECT CONNECTION TO THE CHIMNEY
Protection from rain
and wind
Insulated ue
Condensation-proof
"T" tting with
inspection plug
Protection from rain and wind
Max 3 mt
3 - 5%
"T" tting with
inspection
plug
Insulated "T"
tting with
inspection plug
CONNECTION TO THE MAINS ELECTRIC SUPPLY
The generator is supplied with an electric power cable to be plugged into a 230V 50 Hz socket, possibly with a circuit breaker switch. The
socket must be easily accessible.
The electrical system must be compliant with standards. The eciency of the earthing circuit must be checked. Unsuitable earthing of the
system can cause malfunctioning for which the manufacturer will not be held liable.
Power supply variations beyond 10% can cause faulty operation of the product.
8 ENGLISH
Page 9
DETAILS OF COMFORT P85 INSERT
A
F
B C
D E
G H
I
J
K D
Ambient air outlet
A
Access to combustion chamber
B
and ash drawer
Emergency module
C
Fumes outlet
D
Pellet hopper
E
Fuse
F
Rail
G
Bulb thermostat rearm
H
TA inlet
I
230V power supply
J
Combustion air inlet
K
9ENGLISH
Page 10
DETAILS OF COMFORT P85 PLUS INSERT
A
H
B C
D F
E G DG
I J
K
L
M E
Ambient air outlet
A
Access to combustion chamber
B
and ash drawer
Emergency module
C
Air ducting Z1 outlet
D
Fumes outlet
E
10 ENGLISH
Pellet hopper
F
Air ducting Z2 outlet
G
Fuse
H
Rail
I
Bulb thermostat rearm
J
TA inlet
K
Thermostat connection inlet
230V power supply
L
Combustion air inlet
M
Page 11
INSTALLATION OF COMFORT P85 P85 PLUS INSERT
ASSEMBLY MUST BE CARRIED OUT BY QUALIFIED PERSONNEL!
GENERAL
The insert is supplied with a sliding base in iron that allows it to be
installed in a pre-existing chimney.
This sliding base allows the insert to be removed easily to load the
pellets inside the hopper and for any maintenance or cleaning at the
end of the season.
If there is no pre-existing chimney, one can be built using an insertholder pedestal (optional kit). In fact, the latter xes the insert to the
ground.
ASSEMBLY: place the base in the chosen point and adjust the feet to
the desired height. Install a socket on the rear of the pedestal in a way
that the plug is accessible once installation has been performed. Fix
the pedestal to the oor using have-duty steel plugs with diameter
of 8mm. Take the sliding base and x it to the pedestal.
MINIMUM CLEARANCE
Please note: If our pedestal is used, a slot must be created in the ue
pipe to allow the pellet hopper level to be checked, thus avoiding
spillage when it is being topped up.
gure 1 gure 2
For the insert to operate correctly, a minimum side and rear space
With front loading kit H= 635mm
must be guaranteed, as shown in gure 2; the coatings must be
made of non-ammable material.
11ENGLISH
Page 12
INSTALLATION
1
2
Open the door and release the latch using the poker supplied.
Remove the 6 screws and remove the ue pipe from the base.
3a
Fix the base to the existing ue pipe.
ATTENTION! RESPECT THE 50MM HEIGHT FOR OPENING AND CLOSING THE INSERT CORRECTLY!
12 ENGLISH
Page 13
3b
4
Fix the base to the kit if it is a new installation (optional kit).
5
Block the rails with two screwdrivers and secure the ue pipe to the base with 6 screws.
Close the insert and block the latch.
13ENGLISH
Page 14
FRESH AIR DUCTS
For correct operation, air must be allowed to recirculate inside the structure that covers the insert in order to prevent the appliance from
overheating.
To guarantee this, just realise one or more openings in the lower and upper part of the covering.
The following measurements must be respected:
LOWER PART COLD AIR INLET WITH TOTAL MINIMUM SURFACE 240 CM².
UPPER PART HOT AIR OUTLET WITH TOTAL MINIMUM SURFACE 240 CM².
The possible set-ups which must be respected are indicated below.
EXISTING INSTALLATION
FOR INSTALLATION ON AN EXISTING FLUE PIPE EXAMPLES 2 AND 3, A HOLE
MUST BE MADE ON THE SUPPORT BASE TO GUARANTEE THE CORRECT AIR FLOW.
EXAMPLE 1 EXAMPLE 2 EXAMPLE 3
A
A
C
A
A
B
B
B
B
D
A: Air convection outlet. Minimum section 120cm2.
B: air inlet from room. Minimum section 120cm2.
14 ENGLISH
C: Air convection outlet.
Minimum section 240cm2.
D: air inlet from room.
Minimum section 240cm2.
Page 15
NEW INSTALLATION
A
B
EXAMPLE 1 EXAMPLE 2
C
A
B
A: Air convection outlet. Minimum section 120cm2.
B: air inlet from room. Minimum section 120cm2.
D
C: Air convection outlet. Minimum section 240cm2.
D: air inlet from room. Minimum section 240cm2.
For the insert to operate correctly, a minimum side and rear space of 35 mm must be guaranteed; the coatings must be made of nonammable material.
IMPORTANT: ALL THE OPENINGS CREATED FOR THE CORRECT AIR CIRCULATION MUST PREVENT THE ENTRY OF
HAZARDOUS PARTS BY USING SPECIFIC GRILLES, BUT STILL GUARANTEEING THE MINIMUM AIR FLOW REQUIRED.
THE PIPE FOR FUMES OUTLET MUST ALWAYS MAINTAIN A MINIMUM DISTANCE OF 50 MM FROM INFLAMMABLE PARTS.
J
TO SAFEGUARD FROM ANY OVERHEATING, THE INSERT IS SUPPLIED WITH A PROBE THAT ANALYSES THE
TEMPERATURE INSIDE THE STRUCTURE
AND INTERVENES BY REDUCING THE FUNCTIONING POWER.
15ENGLISH
Page 16
SAFETY LATCH
Use the poker supplied to perform the release/block operation.
(Turn clockwise to release and anti-clockwise to block).
Holes present on two sides for the extraction of the insert via pokers.
Extraction of the insert allows both the pellets to be loaded inside the hopper and routine maintenance (cleaning the ash pipe at year
end) or unscheduled maintenance (replacement of mechanical parts if the product should break) to be performed.
16 ENGLISH
Page 17
EXTRACTION OF INSERT AND PELLET LOADING
Extraction of the insert allows both the pellets to be loaded inside the hopper and routine maintenance (cleaning the ash pipe at year end) or
unscheduled maintenance (replacement of mechanical parts if the product should break) to be performed.
To extract the insert, follow the procedure below:
Open the re door and turn the latch clockwise (using the poker supplied).
Turn the stove towards you using the pokers supplied until it blocks automatically.
THE INSERT MUST ONLY BE PULLED OUT WHEN THE STOVE IS SWITCHED OFF AND COMPLETELY COLD!
THE SURFACES MAY BE VERY HOT! ALWAYS USE SAFETY GLOVES!
PELLETS AND FEEDING
Pellets are made by subjecting wood shavings i.e. the rejects of pure wood (without paint) sawmill, carpenter products and products from
other activities connected to working and transforming wood, to very high pressures.
This type of fuel is fully ecological as no glues are used to hold it together. Indeed, the pellets remain compact over time due to a natural
substance found in wood: lignin.
As well as being an ecological fuel, as wood residues are made the most of, the pellet also has technical advantages.
While wood has a caloric value of 4.4 kWh/kg. (with 15% humidity, thus after 18 months of seasoning), the caloric value of the pellet is 5
kWh/kg.
Pellet density is about 650 kg/m3 and water content is equal to 8% of its weight. For this reason, the pellets do not need to be seasoned in
order to obtain a suciently adequate heat yield.
The pellet used must comply with the features described by Standards:
EN PLUS class A1, ISO 17225-2 class A1
and
UNI EN 303-5 with the following characteristics: Water content ≤ 12%, ash content ≤ 0.5% and heating value less than >17 MJ/kg (for boilers).
The manufacturer recommends using pellets with a diameter of 6 mm with its products.
PELLET STORAGE
To guarantee combustion without problems, the pellets must be kept in a dry place.
Open the hopper lid and load the pellets using a scoop.
DO NOT PLACE THE BAG DIRECTLY ON THE STOVE WHEN LOADING THE HOPPER!
ALWAYS USE A SCOOP TO LOAD THE HOPPER.
THE USE OF POOR QUALITY PELLETS OR ANY OTHER MATERIAL DAMAGES THE FUNCTIONS OF YOUR STOVE AND CAN
VOID THE WARRANTY AND THE RELEVANT RESPONSIBILITY OF THE MANUFACTURER.
TO GUARANTEE COMBUSTION WITHOUT PROBLEMS, THE PELLETS MUST BE KEPT IN A DRY PLACE.
17ENGLISH
Page 18
OPTIONAL LOADING ACCESSORIES
FRONT PELLET LOADING KIT
The optional pellet loading kit allows to load the pellets into the
hopper from the front without having to remove the insert (which
would require the machine to be switched o).
UPPER/SIDE PELLET LOADING KIT
The optional pellet loading kit allows to load the pellets into the
hopper without removing the insert from the installation opening
(which would require the machine to be switched o).
The kit can be assembled at a later time too.
DO NOT LOAD A GREATER NUMBER OF PELLETS THAN THE CAPACITY OF THE HOPPER AND DO NOT DROP PELLETS
INSIDE THE PRODUCT.
J
IN CASE OF INSTALLATION WITH LOADING KIT OPTIONAL THE MACHINE MUST NOT BE REMOVED.
Further information on accessories is available on the website under the category "accessories".
BULB THERMOSTAT REARM
The gure below shows the hopper rearm position. It is
recommended to contact the qualied technician if one of the
rearms should be triggered, so as to verify the cause.
FUSE
If the stove has no power supply, check the status of the fuse,
positioned laterally (right) with respect to the machine, located on
the circuit board support.
18 ENGLISH
Page 19
AiR dUCTing FeATURes inseRT p85 plUs
The model is tted with two independent air ducting outlets. The pipe used for ducting the hot air must have an internal diameter of 80 mm
and it must also be insulated or at least be protected against heat dispersion.
Air ducting 1 - 2 are enabled by factory default.
Features:
z2 I z1
diameter of air ducting outlet: 2x80 mm
maximum recommended air ducting length 8 m
temperature controlled air ducting
Speed regulation can be set in 2 modes: AUTO, COMFORT
FACTORy deFAUlT OpeRATiOn in AiR dUCTing MOde
Air ducting 1 and 2 are always in request by factory default (jumpers on Z1 and Z2 present), and follow the stove settings.
- No settings necessary.
OpeRATiOn in AiR dUCTing wiTh TheRMOsTAT OR pRObe (OpTiOnAl)
The stove is tted with two independent motors for air ducting. The connection of an external thermostat or temperature probe (NTC 10K)
in inputs 1 and 2, located in the rear part of the stove, makes it possible to control the air ducting motor independently of the stove.
Suce it to connect the thermostat/temperature probe and set the desired temperature.
For information on air ducting settings see chapter:" Menu - Air ducting"
WITH AMBIENT THERMOSTAT OPTIONAL
Remove the jumper on 1 and connect the ambient thermostat in the room that needs to be temperature-controlled through air ducting 1.
2 control modes:
OPERATION IN AIR DUCTING WITH AMBIENT THERMOSTAT OPTIONAL
Once the specic activation threshold has been reached and exceeded, at temperature
seT congured to AUTO
(the temperature setting is not visible)
seT congured to COMFORT
(the temperature setting is not visible)
to be satised (CLOSED CONTACT) the air ducting motor will follow the stove settings.
When the temperature set on the thermostat is reached (OPEN CONTACT), the air
ducting motor will switch to minimum and then follow the stove settings again when
there is a new request.
Once the specic activation threshold has been reached and exceeded, at temperature
to be satised (CLOSED CONTACT) the air ducting motor will follow the stove settings
but at a lower speed than in SET AUTO for increased acoustic/ambient comfort.
When the temperature set on the thermostat is reached (OPEN CONTACT), the air
ducting motor will switch to minimum and then follow the stove settings again, but
at a lower speed when there is a new request.
SAMe OPerAting SettingS FOr Air ducting 2 MOtOr
19ENGLISH
Page 20
WITH PROBE NTC 10K
Remove the jumper on 1 and connect the NTC probe in the room that needs to be temperature-controlled through air ducting 1.
2 control modes:
OPERATION IN AIR DUCTING WITH NTC PROBE 10K OPTIONAL
Once the specic activation threshold has been reached and exceeded, at temperature
seT congured to AUTO
Set the desired temperature ( from 7 to 37 °C)
seT congured to COMFORT
Set the desired temperature ( from 7 to 37 °C)
to be satised the air ducting motor will follow the stove settings.
When the temperature set on the set TEMPERATURE is reached, the air ducting motor
will switch to minimum and then follow the stove settings again when there is a new
request.
Once the specic activation threshold has been reached and exceeded, at temperature
to be satised the air ducting motor will follow the stove settings but at a lower speed
than in SET AUTO for increased acoustic/ambient comfort.
When the temperature set on the set TEMPERATURE is reached, the air ducting motor
will switch to minimum and then follow the stove settings again, but at a lower speed
when there is a new request.
SAMe OPerAting SettingS FOr Air ducting 2 MOtOr
TA AddiTiOnAl TheRMOsTAT (OpTiOnAl)
The appliance is able to control the room temperature through an additional thermostat (optional).
After ignition (by pressing key 1 or in chrono mode), the stove will work to reach the set value on the thermostat, displaying wORk (closed
contact) on the screen. The room sensor incorporated into the handheld device is automatically ignored,
TO INSTALL AND ACTIVATE:
A mechanical or digital thermostat is required.
Remove the plug from the socket.
Using the image to the side as a guide, connect the two thermostat wires (clean contact - no 230 V!) to
the respective terminals at the back of the machine, one red and the other black.
Connect the power to the stove again.
Press the key (
The stove is now correctly congured.
It will work by checking the external additional thermostat based on the TA function.
insTAllATiOn MUsT be peRFORMed by qUAliFied sTAFF And/OR The MAnUFACTUReR's seRviCe TeChniCiAns
), until the set temperature is set to lOw-TA.
TA
20 ENGLISH
Page 21
emergency mODULe
The stove is tted with an emergency module located at the side, allowing the basic operation of the stove in the event the handheld remote
is damaged or malfunctions.
The functions that can be managed from the emergency module are:
Key P1 Stove ignition/switch-o
L1: Blue LED o: The stove is o.
L1: Blue LED on: The stove is operating
L1: Blue LED ashing: The stove is in ALARM state
L1
P1
21ENGLISH
Page 22
OK
RADIO CONTROL
OK
CONFIGURATION
RADIO CONTROL CODING PROCEDURE:
1. Disconnect the power supply to the stove.
and
and
2. Press the keys
3. Using keys
4. Power the stove. Conrm the selected unit within 10 seconds (the LED will ash on the radio/emergency card) by pressing the OK key
on the remote control.
5. The LED on the radio/emergency card will remain on for 5 seconds to conrm the new conguration.
6. If the conguration was unsuccessful, the display will read "DEVICE NOT FOUND". In this case, repeat the procedure.
at the same time until the screen to choose RADIO ID appears.
select the new RADIO ID.
J
THE RADIO CONTROL IS ALREADY CONFIGURED WITH "RADIO ID" 0". IF THERE IS ANOTHER STOVE, TO AVOID
INTERFERENCES, A NEW CONFIGURATION MUST BE PERFORMED, MODIFYING ONE OF THE TWO STOVES.
SOME RADIO FREQUENCY DEVICES E.G. MOBILE PHONES, ETC. MAY CAUSE INTERFERENCE WITH
COMMUNICATION BETWEEN THE RADIO CONTROL AND THE STOVE.
RADIO CONTROL ROOM PROBE
CALIBRATION
This mode allows calibration of the room temperature detected
by the radio control (with ventilation active only). For correct
calibration, it is recommended to position the radio control in a
room with constant temperature and wait for at least two hours.
The procedure for calibration is the following:
Access the menu and reach “TECH MENU”.
Set the access key "F4". - "ADJ REMOTE PROBE"
Using the keys
calibration.
Save and exit with the key
or
adjust the desired ambient
.
BATTERY TYPE AND REPLACEMENT
To insert/replace the batteries, suce it to remove the battery
protection cover at the back of the radio control device (gure 1).
Insert the batteries in accordance with the symbols imprinted on
the radio control device and on the battery itself.
Three AAA batteries are required for the radio control to
function.
Respect the environment!
22 ENGLISH
Used batteries contain metals that are harmful to the environment, and therefore must be disposed of separately in
special containers.
(gure 1)
Page 23
RADIO CONTROL FEATURES
The radio control is tted with an LCD backlit display. The display remains lit for 5 seconds. After a certain period of time, in order to minimise
battery consumption, the display turns o (sleep mode).
It turns on again after pressing the ON/OFF key (6).
CAUTION!
Do not place the radio control device in direct or indirect contact with water. The radio control device may not work properly in the presence
of humidity or if exposed to water.
1
2
3
4
5
7
8
6
1
2
3
4
5
6
7
8
UPDATE
SET POWER/ scroll across in menus / increase - select a setting
SET THERMOSTAT room/ scroll across in menus / decrease - deselect a setting
Back key
Key to access MENU and CONFIRM
On/o stove or restore from sleep mode.
Serial cable input
Battery compartment
FREQUENCY BANDS MAXIMUM POWER TRANSMITTED
868.3 MHz 4 mW ERP
869.85MHz 4 mW ERP
23ENGLISH
Page 24
DISPLAY
Battery low
SCREEN IN OPERATION
STAND BY
active
Chrono active
Power 1-5^
Tangential fan active
Display text
Tangential fan active in COMFORT mode
Hour
Temperature detected in room
Set ambient temperature
SCREEN WITH EXTERNAL THERMOSTAT CONNECTED TO THE TERMINAL “TA”
Indicates contact of
the external additional
thermostat
display text
24 ENGLISH
Time
Page 25
GENERAL MENU
KEY FUNCTION
Scroll parameters
FRONT AIR SET
*AIR DUCTING 1
*AIR DUCTING 2
EASY SETUP
Modify settings
Ignition - switch-o key
SET
TEMPERATURE**
SET
KEY FUNCTION
Back - exit key
Access menu key
SET
TEMPERATURE**
CHRONO
SETTINGS
STOVE STATUS
TECH MENU***
ENABLING
PRG1
DATE/TIME PRG2
LANGUAGE PRG3
DISPLAY PRG4
STAND BY
FIRST LOAD
DELTAT
DEGREES
RESET
DEPRESSURE
NOTICE
***
* WHERE PRESENT
**IF A TEMPERATURE PROBE IS CONNECTED
*** TECHNICIANS ONLY
25ENGLISH
Page 26
BASIC INSTRUCTIONS
The following recommendations must be followed the rst few
times the stove is lit:
Slight odours may be produced due to the drying of the paints
and silicone used. Do not remain in the room for long periods.
Do not touch the surfaces as they may still be unstable.
Properly air out the room several times.
The hardening of surfaces will stop after several heating cycles.
This appliance must not be used to burn waste.
Before lighting the stove, the following points must be checked:
The hopper must be loaded with pellets
The combustion chamber must be clean
The burn pot must be completely free and clean
Check the hermetic closure of the hoper, re door and ash
drawer
Check that the power cord is properly connected
The bipolar switch in the rear must be positioned on 1.
FIRST IGNITION SETTINGS
Once the power cable at the back of the generator has been connected, move the switch, also located on the back, to (I).
The switch at the back of the generator powers the generator board.
The generator remains o and an initial screen appears on the panel, displaying OFF.
MAINS POWER FREQUENCY 50/ 60HZ
If the generator is installed in a country with a frequency of 60Hz, the generator will display “POWER FREQUENCY ERROR”. In this case, adjust
the frequency to 60Hz.
DATE/TIME
This menu allows the date and time to be set.
To set: OK > SETTINGS > DATE/TIME.
LANGUAGE
This menu allows the preferred language to be selected.
The languages available are: Italian - English - German - French - Spanish - Portuguese.
To set: OK > SETTINGS > LANGUAGE.
DEGREES
This menu allows you to set the desired unit of measurement.
To set: OK > SETTINGS > DEGREES
IT IS FORBIDDEN TO USE THE DEVICE WITHOUT A PARTITION A AND FLAME
GUARD B.
REMOVAL WILL COMPROMISE THE SAFETY OF THE PRODUCT AND RESULT IN
THE IMMEDIATE NULLIFICATION OF THE WARRANTY PERIOD.
IN THE EVENT OF WEAR OR DETERIORATION, REQUEST THE PART'S
REPLACEMENT FROM THE AFTERSALES SERVICE
REPLACEMENT DOES NOT FALL WITHIN THE PRODUCT WARRANTY AS THE
PART IS SUBJECT TO WEAR.
A
B
26 ENGLISH
Page 27
OK
OPERATION AND LOGIC
IGNITION
Once the previously listed points have been checked, press key
for a ame for a period of 15 minutes. Once the control temperature has been reached, the
stove interrupts the ignition phase and switches to PREPARATION.
PREPARATION
During the preparation phase, the stove stabilises combustion, increasing it progressively, to then start ventilation and switch to WORK
WORK
In the work phase, the stove operates at the POWER dened by the user, heating the room until SET THERMOSTAT is achieved. See next
heading.
ADJUSTING SET THERMOSTAT
The ambient SET THERMOSTAT can be set using keys 2 and 3, from LOWTA 7 - 37 °C - HOT. If the value is between 7 - 37 °C, the stove checks
the ambient temperature by means of the radio control probe. Once the set temperature has been reached, the stove automatically reduces
the power, guaranteeing best comfort and reducing pellet consumption: this process is called “modulation”.
LOWTA HOT
If the SET THERMOSTAT is “LOWTA” (set under the 7° threshold), temperature checking is entrusted to the additional thermostat contact,
thus bypassing the radio control temperature probe.
If the contact is open (fullled), the stove works at minimum power.
If the contact is closed (request), the stove works at the set power.
If the setting is on “HOT” (set above 37°C), the stove only works at the set power, thus bypassing the external contact and the temperature
probe.
for three seconds to ignite the stove. During ignition, the stove will check
ADJUSTING SET POWER
The power has 5 operating levels, when key
Power 1 = minimum level - Power 5 = maximum level.
The change must be conrmed by pressing the key
AUTO BLOW
During the work phase, the stove cleans the burn pot at regular intervals with an "AUTO BLOW".
When this procedure starts, a message is displayed. During the "AUTO BLOW" procedure, the pellet feed slow down and the fumes motor
increases.
After cleaning, the stove resumes operation in normal conditions.
SWITCHOFF
Press the key
Once this operation has been performed, the appliance automatically enters the switch-o phase, blocking the supply of pellets.
The ue gas exhaust motor and the hot air ow motor will remain on until the stove temperature has dropped below the safety settings.
REIGNITION
The stove can only be re-ignited if the temperature of the exhaust fumes is lower than the preset threshold and the minimum safety time has
passed.
for three seconds.
DO NOT USE ANY TYPE OF FLAMMABLE LIQUIDS FOR IGNITION!
DO NOT ALLOW THE BAG OF PELLETS TO COME INTO CONTACT WITH THE BOILING HOT STOVE DURING THE
FILLING PHASE!
IN THE EVENT OF CONTINUED FAILURE TO LIGHT, CONTACT AN AUTHORISED TECHNICIAN.
is pressed, the set power is displayed; it can be changed using keys
.
or
.
J
NO IGNITION
THE APPLIANCE MAY FAIL TO LIGHT BECAUSE THE AUGER IS EMPTY AND NOT ALWAYS ABLE TO LOAD THE BURN POT
FAST ENOUGH WITH THE PELLETS NEEDED FOR NORMAL IGNITION.
IF THE PROBLEM OCCURS AFTER ONLY A FEW MONTHS OF OPERATION, CHECK THAT THE ROUTINE CLEANING
DESCRIBED IN THE STOVE HANDBOOK HAS BEEN CARRIED OUT CORRECTLY
27ENGLISH
Page 28
FRONT AIR
This menu allows the front ventilation motor speed to be set. Range: (comfort, auto).
If comfort mode is selected, the front air speed is reduced.
To guarantee ecient combustion, front air is excluded when the appliance is running at minimum power.
To set: OK > FRONT AIR >SET
AIR DUCTING 1
This menu allows a choice of two operating modes for air ducting 1, and the regulation of the set temperature if an NTC probe is connected
in input: AUTO - COMFORT
To set: OK > AIR DUCTING 1 > SET
To adjust the temperature: OK > AIR DUCTING 1 > TEMPERATURE
AIR DUCTING 2
This menu allows a choice of two operating modes for air ducting 2, and the regulation of the set temperature if an NTC probe is connected
in input: AUTO - COMFORT
To set: OK > AIR DUCTING 2 > SET
To adjust the temperature: OK > AIR DUCTING 2 > TEMPERATURE
EASY SETUP
The volumetric weight of the pellet is the ratio between the weight and the volume of the pellet. This ratio may change without altering
pellet quality. By using the EASY SETUP function, it is possible to change the calibration of the volumetric weight by increasing or decreasing
the preset values.
In the stove program, the available values range from “– 3” to “+ 3”; all stoves are calibrated during production with the optimal value which
is 0
If you notice an excessive deposit on the burning pot, access the EASY SETUP program and lower the value by one unit to “- 1”; then wait
until the next day and if there is no improvement, decrease again, to a maximum of “- 3”. Instead, if it is necessary to increase the calibration
of the volumetric weight of the pellet, change the factory value from “0” to “+ 1, + 2, + 3” as required.
To set: OK > EASY SETUP
EXCESSIVE PELLET DEPOSIT IN BURN POT NORMAL OPERATION MINIMUM PELLET DEPOSIT IN BURN POT
-3 -2 -1 0 +1 +2 +3
THIRD DECREASE
RANGE IF THE
FIRST TWO ARE
INSUFFICIENT
N.B.: If these adjustments do not solve the problem of pellet deposits in the burn pot, please contact your local service centre.
SECOND
DECREASE
RANGE IF
THE FIRST IS
INSUFFICIENT
FIRST DECREASE
RANGE (TEST FOR
1 DAY )
OPTIMAL FACTORY
VALUE
FIRST INCREASE
RANGE
SECOND
INCREASE RANGE
IF THE FIRST IS
INSUFFICIENT
THIRD INCREASE
RANGE IF THE
FIRST TWO ARE
INSUFFICIENT
CHRONO
This function allows stove ignition and switch-o to be automatically programmed.
The factory setting for CHRONO is o.
The chrono allows the programming of 4 time slots per day, which can be used every day of the week.
set ignition and switch-o times, specic days of application, desired temperature and set power. Current day and time settings
are essential for the correct operation of the Chrono.
Recommendations
Before using the chrono function, it is necessary to set the current day and time. Therefore, check that the points in the sub-section
“DATETIME” have been followed. To use the chrono function correctly, it must not only be programmed, but also enabled. The 4 time
slots can be overlapped using the ignition and switch-o time settings. In this way, it is possible to create a combination of time slots
with dierent temperatures and power levels, without changing the status of the stove.
N.B.: in the case of overlapping time slots, the stove will remain on until the last switch-o time.
For each time slot, it is possible to
28 ENGLISH
Page 29
ENABLING
Allows the chrono and the dierent stove time slots to be enabled/disabled.
To set: OK > CHRONO > ABILITAZIONE.
PRG 14
Prg x allows you to set the on/o time, the days of use of the scheduled time slot and the temperature (LOW-TA - 07 - 37 °C - HOT), plus the
required power. Current day and time settings are essential for the correct operation of the Chrono.
To set: OK > CHRONO > PRGX
CHRONO > ENABLING > PRG1
>
>
>
>
PRG1 > START PRG1
>
>
>
>
>
PRG2 > START PRG2
>
>
>
>
>
PRG2
PRG3
PRG4
STOP PRG1
MONDAY...SUNDAY
SET PRG1
POWER PRG1
STOP PRG2
MONDAY...SUNDAY
SET PRG2
POWER PRG2
On/o Enable/disable PRG 1
On/o Enable/disable PRG 2
On/o Enable/disable PRG 3
On/o Enable/disable PRG 4
OFF-00:00-23:50 PRG1 ignition time
OFF-00:00-23:50 PRG1 switch-o time
On/o Enable/disable days PRG1
LOW-TA - 07- 37 °C - HOT Set thermostat PRG1
1-5 Set power PRG1
OFF-00:00-23:50 Ignition time PRG2
OFF-00:00-23:50 Switch-o time PRG2
On/o Enable/disable days PRG2
LOW-TA - 07- 37 °C - HOT Set thermostat PRG2
1-5 Set power PRG2
J
PRG3 > START PRG3
>
>
>
>
>
PRG4 > START PRG4
WHEN THE WEEKLY PROGRAMMER IS ACTIVE, THE RELATIVE ICON WILL BE SHOWN ON THE RADIO
CONTROL DISPLAY.
STOP PRG3
MONDAY...SUNDAY
SET PRG3
POWER PRG3
STOP PRG4
MONDAY...SUNDAY
SET PRG4
POWER PRG4
OFF-00:00-23:50 Ignition time PRG13
OFF-00:00-23:50 Switch-o time PRG3
On/o Enable/disable days PRG3
LOW-TA - 07- 37 °C - HOT Set thermostat PRG3
1-5 Set power PRG3
OFF-00:00-23:50 Ignition time PRG4
OFF-00:00-23:50 Switch-o time PRG4
On/o Enable/disable days PRG4
LOW-TA - 07- 37 °C - HOT Set thermostat PRG4
1-5 Set power PRG4
29ENGLISH
Page 30
02:00 23:0008:00 16:30
t
02:00 23:0008:00 16:30
t
3
1
02:00 23:0008:00 16:30
t
22°
18°
2
1
EXAMPLE OF CHRONO OVERLAPPING TIMES/SLOTS
Time slot
Set Power
Set Temperature
Time slot 1
start 02:00
stop 23:00
Set Power 3 - Set Temp 22°C
Time slot 2
stove operation
30 ENGLISH
start 08:00
stop 16:30
Set Power 1 - Set Temp 18°C
Page 31
SETTINGS
DATE/TIME
LANGUAGE
DEGREES
UPDATE
The "DISPLAY" menu allows:
SEE CHAPTER: COMMISSIONING SETTINGS.
Adjustment of the DISPLAY contrast
Activation/Deactivation of backlight.
Enabling/disabling of acoustic signal.
To set: OK > SETTINGS > DISPLAY.
Setting of the timer to turn o the Display backlight.
Setting of the timer to turn o the Display (sleep mode).
STAND BY
The STAND BY function is used if the stove needs to be turned o immediately instead of a power modulation.
To set: OK > SETTINGS> STAND BY.
STAND BY FUNCTION SET TO ON
If the STAND BY function is enabled (ON) and the ambient temperature exceeds the SET THERMOSTAT + DELTA-T OFF value, then the stove
switches o after a preset factory delay, and STAND BY will be displayed on the screen.
When the ambient temperature is less than SET THERMOSTAT - DELTA-T ON and after a certain cooling time, the stove ignites again.
STAND BY FUNCTION SET TO OFF FACTORY SETTING
When the STAND BY function is not enabled (OFF), if the stove exceeds the set ambient temperature, it will switch to the minimum power
level, modulating and displaying MODULATION on the screen. When the room temperature is lower than the SET THERMOSTAT the stove
will restart at the set power and WORK will be displayed on the screen.
OPERATION WITH ADDITIONAL THERMOSTAT OPTIONAL
STAND BY FUNCTION SET TO OFF FACTORY SETTING
When the STAND BY function is not activated (OFF), if the stove exceeds the room temperature set on the supplementary thermostat (open
contact), it switches to the minimum power level and displays MODULATION on the screen. When the ambient temperature is lower than the
set value on the additional thermostat (closed contact), the stove will resume operation at the set power, and WORK will be displayed on the
screen.
STAND BY FUNCTION SET TO ON
If the STAND BY function is activated (ON), when the room temperature set on the supplementary thermostat is reached (open contact), the
stove will switch o after a pre-set default delay period, and STAND BY will be displayed on the screen.
When the ambient temperature is less than the set temperature on the additional thermostat (closed contact), and after a certain cooling time,
the stove ignites again.
J
FOR CORRECT OPERATION, THE SET THERMOSTAT MUST BE SET TO LOWTA.
> SEE THE INSTALLATION CHAPTER SUPPLEMENTARY THERMOSTAT
31ENGLISH
Page 32
FIRST LOAD
This function allows you to activate the gearmotor for loading pellets continuously.
Before starting the function, make sure the stove is cold and “OFF”.
To set: OK > SETTINGS > FIRST LOAD
To stop continuous loading, just press and hold key 6 for 2 seconds.
Quick access:
Before starting the function, make sure the stove is cold and “OFF”.
Press keys 6 + 4 at the same time for two seconds until the message “FIRST LOAD” is displayed.
To stop continuous loading, just press and hold key 6 for 2 seconds.
DELTAT
This function allows the hysteresis thresholds to be set for stove ignition (DELTA-T ON) and switch-o (DELTA-T OFF), used as an ambient
temperature adjustment interval if not managed by an external thermostat.
The possible values of DELTA-T vary between 0.5 - 5 °C
To set: OK > SETTINGS > DELTAT
RESET
Allows the user to reset all editable values to the default values.
To set: OK > SETTINGS > RESET.
DEPRESSURE NOTICE
Allows the radio control buzzer to be activated for an acoustic warning if the door is opened.
Please note: Activation can reduce battery life by 30%.
The battery life depends on the usage
To set: OK > SETTINGS > DEPRESSURE NOTICE.
ADDITIONAL FUNCTIONS
DELAY SWITCHOFF
You can program a delayed switch-o for the stove. For example, if it is 8 pm and the delayed switch-o is set to 1h, the stove will automatically
switch o at 9 pm.
If you press and hold keys 6 + 2 at the same time, the screen “DELAY SWITCHOFF” will appear, (this setting can only be congured if the
stove is in the PREPARATION or WORK phase.
Use keys 2 and 3 to increase/decrease the number of hours after which the stove will automatically start the nal cleaning phase.
The number of hours range from OFF, 1 to 9.
Press P6 to conrm and return to the home page.
One hour after the set switch-o time, the remaining operating time is indicated by displaying at one-minute intervals “switch o in” and
the time “HOURS xx:xx”.
32 ENGLISH
Page 33
to find out where your nearest service centre is, contact your dealer or visit the
website: www.lanordica-extraflaMe.coM
CLEANING AND MAINTENANCE
ALWAYS FOLLOW THE INSTRUCTIONS IN COMPLETE SAFETY!
Make sure that the power cord is unplugged because the generator May have been prograMMed to switch on.
that the generator is cold all over.
the ashes are coMpletely cold.
ensure efficient air exchange in the rooM during product cleaning operations.
poor cleaning will coMproMise correct operation and safety!
MAINTENANCE
For correct operation, the generator must undergo routine maintenance by a qualied technician, at least once a year.
The periodic inspection and maintenance operations must always be performed by specialised, qualied technicians, who operate in
accordance with the laws in force and the instructions given in this use and maintenance manual.
EVERY YEAR, HAVE THE FUME EXTRACTION SYSTEM, FLUE PIPES AND "T" FITTINGS, INCLUDING THE INSPECTION
CAPS CLEANED. IF PRESENT, ALSO CLEAN THE ELBOWS AND HORIZONTAL SECTIONS!
THE GENERATOR CLEANING FREQUENCY IS INDICATIVE! IT DEPENDS ON THE QUALITY OF THE PELLETS AND
FREQUENCY OF USE.
THESE OPERATIONS MAY SOMETIMES NEED TO BE PERFORMED MORE OFTEN
PERIODIC CLEANING UNDER USER'S RESPONSIBILITY
The periodic cleaning operations, as indicated in this use and maintenance manual, must be performed with the utmost care after reading the
instructions, procedures and frequency described in this use and maintenance manual.
CLEANING THE SURFACES AND COVERING
Never use abrasive or chemically aggressive detergents for cleaning!
The surfaces must be cleaned when the generator and covering are completely cold. For the maintenance of the surfaces and metal parts,
simply use a cloth dampened with water or water and neutral soap.
Failure to comply with these instructions may damage the surfaces of the generator and cause the invalidation of the warranty.
CLEANING THE CERAMIC GLASS
Never use abrasive or chemically aggressive detergents for cleaning!
The ceramic glass must be cleaned when the glass is completely cold.
To clean the ceramic glass, simply use a dry brush and some damp newspaper dipped in ash. If the glass is very dirty, use a specic cleaning
agent for ceramic glass. Spray a small amount on a cloth and use it on the ceramic glass. Do not spray the cleaning agent or any other liquid
directly on the glass or seals!
Failure to comply with these instructions may damage the surfaces of the ceramic glass and cause the invalidation of the warranty.
CLEANING THE PELLET HOPPER
When the hopper is completely empty, disconnect the power cord of the generator, remove the residue (dust, chippings, etc.) from the empty
hopper and then ll it up.
THE PELLET HOPPER GASKETS, BURN POT AND FIRE DOOR GUARANTEE CORRECT STOVE OPERATION. THESE NEED
TO BE PERIODICALLY CHECKED BY THE USER. IF THEY ARE WORN OR DAMAGED, IMMEDIATELY REPLACE THEM.
THESE OPERATIONS MUST BE CARRIED OUT BY A QUALIFIED TECHNICIAN.
IF THE POWER CORD IS DAMAGED, IT MUST BE REPLACED BY THE SERVICE CENTRE OR BY A SIMILARLY QUALIFIED
PERSON, SO AS TO AVOID ALL RISKS.
33ENGLISH
Page 34
BURN POT AND COMBUSTION
CHAMBER:
Remove the burn pot completely from the
relevant compartment.
Once the ame guard (A) has been removed,
vacuum the residue in the burn pot.
Unblock all the holes in the burn pot using the
supplied poker.
Suck up the ash from the burn pot seat and
combustion chamber.
Re-position the burn pot in its slot and push it
towards the re wall and reposition the ame guard
(A)
Suck up the ash deposit from the ash collection
trays;
NOTE: Use a suitable ash vacuum cleaner with a
specic container for separation of the ash collected.
THE FOLLOWING IMAGES ARE FOR ILLUSTRATION PURPOSES
ASH DRAWER:
Remove the two ash drawers and empty them
into a dedicated container.
Vacuum the ash deposit in the combustion
chamber compartment.
Put the two ash drawers back.
34 ENGLISH
Page 35
A CLEAN BURN POT GUARANTEES CORRECT OPERATION!
J
burn pot
coMbustion chaMber
shell and tube heat exchanger
ash drawer
t-shaped fitting/ flue pipe
BY KEEPING THE BURN POT AND ITS HOLES CONSTANTLY CLEAN AND FREE OF
COMBUSTION RESIDUE, EXCELLENT COMBUSTION IS GUARANTEED OVER TIME,
THUS PREVENTING ANY GENERATOR MALFUNCTIONS THAT MAY REQUIRE
TECHNICAL ASSISTANCE.
THE "EASY SETUP" FUNCTION IN THE USER MENU CAN BE USED TO ADAPT
COMBUSTION ON THE BASIS OF THE NEEDS DESCRIBED.
parts/freQuency every day every 3-4 days every year
BURN POT HOLES
X
X
X
X
X
to find out where your nearest service centre is, contact your dealer or visit the website:
www.lanordica-extraflaMe.coM
ROUTINE MAINTENANCE PERFORMED BY QUALIFIED TECHNICIANS
Routine maintenance must be performed at least once a year.
Given the generator uses pellets as solid fuel, it requires annual routine maintenance, which must be performed by a Qualied technician,
using only original spare parts.
Failure to comply may jeopardise safety of the appliance and invalidate the warranty conditions.
By observing the cleaning schedule reserved to the user described in the use and maintenance manual, the generator will be guaranteed
correct combustion over time, thus preventing any faults and/or malfunctions which may require subsequent technical assistance. Requests
for routine maintenance are not covered by the warranty.
GASKETS: PELLET HOPPER LID, DOOR, ASH DRAWER AND BURN POT
The gaskets ensure the proper sealing of the stove and therefore its proper operation.
They must be periodically checked and immediately replaced if worn or damaged.
These operations must be carried out by a qualied technician.
CONNECTION TO THE FLUE
Annually, or in any case each time the ue pipe needs to be vacuumed and cleaned. If there are horizontal sections, the residue must be
removed to prevent it from obstructing the ow of fumes.
SHUTDOWN END OF SEASON
At the end of each season, before turning the stove o, it is advisable to completely empty the pellet hopper, removing any pellet residue and
dust with a vacuum cleaner.
Routine maintenance must be performed at least once a year.
35ENGLISH
Page 36
ROUTINE MAINTENANCE
THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES.
d
f
b
c
b
b
f
f
f
b
a
e
a
A
B
C
D
E
F
36 ENGLISH
Fumes motor (dismantling and cleaning, ue pipe and "T” tting).
Gaskets, inspections, door (replace if necessary), burn pot and heat exchanger
Combustion chamber and heat exchanger (full cleaning) including ignition plug pipe
Hopper (complete emptying and cleaning).
Check air intake pipe.
Dismantling of ambient air fan and removal of dust and pellet residue.
Page 37
Displays
upDate Reason
OFF
START
PELLET LOADING
IGNITION
PREPARATION
WORK
MODULATION
FINAL CLEANING
STAND-BY
COOLING STAND BY
BLACK OUT
STAND BY
AUTO BLOW
EMPTY HOPPER
Generator o
The START phase is in progress
Continuous pellet feeding is in progress during the ignition state
The phase dedicated to ignition is in progress
The ame stabilisation phase is in progress
The generator has reached operating capacity and is working on user settings
The generator is working at minimum capacity
The cleaning cycle is in progress which is required to cool the machine before it is switched o
Generator o but in stand-by to reignite autonomously if required by operating requests
The generator is requested to turn on during the shut-down phase. If activated, the generator will automatically
turn on again as soon as safety conditions permit it to do so
The generator is cooling after a power cut. Once cooling is completed, it will re-start automatically
The auto blow is in progress to keep the burn pot
clean and maximise combustion eciency
The pellet hopper is empty.
Check for the presence of pellets in the hopper.
Contact the after-sales centre.
CLOSE
HOPPER-STOVE
DOOR
This indication means that you have 60 seconds to close the hatch/door and the pellet lid.
After 60 seconds have passed, the stove will enter “DEPR ALARM” during the ignition phase while during
normal operation, the stove will enter “COOLING STAND BY” and then, restart automatically when the conditions
are right (clod stove, etc.).
alaRMs
upDate eXplanation solution
FUMES MOTOR
FAULT
FUMES PROBE
HOT FUMES
NO
IGNITION
NO
IGNITION
BLACK OUT
NO FLAME
Fumes motor fault Contact the after-sales centre
Fumes probe fault Contact the after-sales centre
High fumes temperature
The pellet hopper is empty
Pellet feed calibration inadequate
No current during the ignition phase
The pellet hopper is empty
No pellet load
The auger motor is not loading the pellets
Check the pellet ow (see “Pellet load adjustment”). If the problem
is not solve, contact a qualied technician
Make sure there are pellets in the hopper.
Adjust the pellet ow (see “Pellet load adjustment”).
Check the procedures described in the “Ignition” chapter.
Take the stove to o conditions using key 1 and repeat the
procedure described in the "Ignition" chapter.
Make sure there are pellets in the hopper.
Adjust the pellet ow (see “Pellet feed adjustment”).
DEPR ALARM
AUGER CONTROL
ALARM
The door is not closed correctly
The combustion chamber is dirty
The fumes exhaust pipe is blocked/dirty
Abnormal pellet loading Contact after-sales centre
Check hermetic door closure.
Check cleanliness of the fumes pipe and the combustion chamber.
37ENGLISH
Page 38
GUARANTEE TERMS
1. Extraame S.p.A. products are guaranteed, within the European community, for 24 months from the date of purchase.
Purchase has to be proved by means of a valid scal document issued by the seller (receipt, invoice or shipment document) identifying the
purchased product and its purchase and/or delivery date.
WARNING: This conventional guarantee does not replace the guarantee regulated by the European legislation on consumer rights.
The conventional guarantee is only applicable to the Italian region and to those areas, within the European Community, where the Authorised
Technical Assistance Centres are active (see the www.lanordica-extraame.com website)
It is also limited to the state of residence of the consumer, which must coincide with the premises and/or registered oce of the seller of the
Extraame S.p.A. product
These regulations do not apply if the product is purchased within commercial, entrepreneurial, or professional circumstances. In these cases
the product guarantee will be limited to a period of 12 months from the date of purchase.
ITALIAN GUARANTEE
What must be done if there is a product malfunction:
Consult the instructions manual to make sure the malfunction cannot be solved by using the product correctly. Make sure the malfunction is
included in those covered by the guarantee; otherwise the cost of the intervention will be borne entirely by the consumer. When requesting
the intervention of the Assistance service at the Authorised Assistance Centre, always specify: - type of malfunction - model of the appliance
- complete address - phone number
EUROPEAN GUARANTEE
What must be done if there is a product malfunction:
Consult the instructions manual to make sure the malfunction cannot be solved by using the product correctly. Make sure the malfunction
is included in those covered by the guarantee; otherwise the cost of the intervention will be borne entirely by the consumer. Request the
intervention of the Assistance service or the address of the Authorised Technical Assistance Centre to the seller; always specify: type of
malfunction, model of the appliance, complete address and phone number
If the malfunction arises in the rst 6 months of the product's life, the consumer has the right to have the product repaired with no expense.
From the seventh to the twenty-fourth month, if a malfunction arises, the consumer will bear the cost of the call, while the seller will pay for the
manpower and for any spare parts used.
2. If the malfunction is linked to external events and/or conditions such as, including but not limited to, insucient capacity of the systems;
wrong installation and/or maintenance by the personnel which hasn't got the skills prescribed by the laws of the country of residence of
the consumer; negligence; inability to use the product and wrong maintenance by the consumer, with respect to what is reported and
recommended by the instructions manual of the product, which is part of the sales contract, this guarantee will be void.
Damage to the product that cannot be related to manufacturing defects are also not included in this guarantee. Similarly are excluded defects
related to incorrect operation of the ue, according to the legislation in force in the country at the moment of purchase. Other exclusions
include all product defects due to carelessness, accidental breakdown, tampering and/or damage during transport (scratches, dents, etc.),
interventions carried out by unauthorised personnel and further damage caused by incorrect interventions by the consumer trying to arrange
the initial malfunction.
The following consumables are excluded by the guarantee: gaskets, ceramic or tempered glasses, cast iron grilles or coatings, refractory
materials (e.g. Nordiker or others), painted, chrome-plated or golden parts, majolica ware, handles, the brazier and its related components.
For Idro products the heat exchanger is not covered by the guarantee if a suitable condensation-proof circuit is not set up to ensure a return
temperature of the device of at least 55°C. The guarantee excludes all the external components on which the consumer can directly operate
during use and/or maintenance or that can be subject to wear and/or rust and stains on steel due to aggressive detergents.
If malfunctions are signalled which are not later conrmed during check by an authorised technician, the cost of the intervention will be borne
entirely by the consumer.
3. If it is not possible to restore product conformity by repairing it, the product/component will be replaced, the guarantee expiration date and
conditions will remain the same established when the product/component to be replaced has been purchased.
4. Extraame S.p.A. cannot be held liable for injury or damage which may - either directly or indirectly - be caused to persons, animals
and property ensuing from failure to observe all the instructions provided in the relevant instruction manual and the warnings regarding
installation, use and maintenance of the product, that can also be downloaded on the website.
5. Interventions for adjusting and/or regulating the product for the type of fuel or other reasons are excluded by the guarantee.
6. If the product is repaired in one of the Authorised Technical Assistance Centres indicated by Extraame S.p.A. and if the product is replaced,
transport will be free of charge. If the technician can repair the product at the user's place of residence and they refuse, transport to the
workshop and redelivery will be paid by the consumer.
7. After the 24 months of the guarantee have elapsed any repair intervention cost will be completely borne by the consumer.
8. In the case of disputes the only competent court is that of the Extraame S.p.A. registered oce - (Vicenza-Italy)
38 ENGLISH
Page 39
AddITIONAL wARNINGs
Only use the fuel recommended by the manufacturer. The product must not be used as an incinerator.
Do not use the product as a ladder or supporting structure.
Do not place laundry on the product to dry it. Any clothes-horse or similar objects must be kept at due distance from the product.
Danger of re or damage to the coating.
The user is fully liable for any incorrect use of the product. The manufacturer bears no civil or criminal liability for incorrect use.
Unauthorised tampering of any nature or replacement of spare parts of the product with non-original parts may endanger the operator
and the manufacturer bears no civil or criminal liability for this.
Large parts of the surface of the product can get very hot (door, handle, glass, smoke outlet pipes, etc.). Please therefore avoid coming
into contact with these parts without wearing suitable protective clothing or using appropriate measures, such as heat protective gloves.
DO NOT use the product with the door open or if the glass is broken.
The product must be electrically connected to a system equipped with an operational earthing system.
Turn o the product in the event of a failure or malfunctioning.
Unburned pellets that build up in the burner following each failed start-up must be removed before attempting to start up the product
again. Make sure that the burner is clean and correctly positioned before starting it up again.
Do not wash the product with water. Water may penetrate into the unit and cause faults in the electrical insulation. This can cause
electric shocks.
Installations not complying with the regulations in force, as well as incorrect use and failure to comply with the maintenance scheduled
by the manufacturer, will invalidate the guarantee.
DiSpoSAl
INfORmATION fOR mANAGEmENT Of ELEcTRIc ANd ELEcTRONIc APPLIANcE wAsTE cONTAINING bATTERIEs OR
AccUmULATORs
This symbol, which is used on the product, batteries, accumulators or on the packaging or documents, means that at the end of its useful
life, this product, the batteries and the accumulators included must not be collected, recycled or disposed of together with domestic waste.
Improper management of electric or electronic waste or batteries or accumulators can lead to the leakage of hazardous substances contained
in the product. For the purpose of preventing damage to health or the environment, users are kindly asked to separate this equipment and/
or batteries or accumulators included from other types of waste and to arrange for disposal by the municipal waste service It is possible to ask
your local dealer to collect the waste electric or electronic appliance under the conditions and following the methods provided by national
laws transposing the Directive 2012/19/EU.
Separate waste collection and recycling of unused electric and electronic equipment, batteries and accumulators helps to save natural
resources and to guarantee that this waste is processed in a manner that is safe for health and the environment.
For more information about how to collect electric and electronic equipment and appliances, batteries and accumulators, please contact your
local Council or Public Authority competent to issue the relevant permits.
39ENGLISH
Page 40
Extraame S.p.A. Via Dell’Artigianato, 12 36030 - MONTECCHIO PRECALCINO (VI) - ITALY
+39.0445.865911 - +39.0445.865912 - info@extraame.it - www.lanordica-extraame.com
MADE IN ITALY
design & production
TO FIND THE SERVICE CENTRE NEAREST TO YOU
CONTACT YOUR DEALER OR CONSULT
THE SITE WWW.LANORDICA-EXTRAFLAME.COM
The manufacturer reserves the right to vary the characteristics and the data reported in this pamphlet at any
moment and without notice, in order to improve its products.
This manual, therefore, cannot be regarded as a contract towards other parties.
02/05/2019
004277958-000 MAN.UT.COMFORT P85-P85 PLUS [EXT]
Loading...
