EX350 Series Professional MultiMeters
EX350 Series True RMS MultiMeters with LPF and LoZ
Professional meters loaded with advanced features and functions including
Low Pass Filter (LPF) and Low Impedance (LoZ)
• TrueRMSforaccurateACmeasurements
• 0.5% basic accuracy
• Low Pass Filter (LPF) for accurate measurement of variable frequency drive signals
• LoZ prevents false readings caused by ghost voltages
• Built-in Non-contact AC Voltage Detector (NCV) with LED indicator
• Data Hold freezes the reading on the display
• Min/Max/Max-Min captures highest and lowest
readings and the difference between them
• Relative Mode for Capacitance Zero and offset adjustment
• Continuity and Diode Test
• Auto Power Off conserves battery life
• CAT III-600V rating
Model EX350
• 4000 count backlit LCD display
• Complete with test leads and two AA batteries
Model EX355
• 6000 count backlit LCD display
• TypeKTemperature
• Complete with test leads, two AA batteries, and general
purpose bead wire temperature probe
SPECIFICATIONS
EX350 EX355
Display counts 4000 6000
Basic DCV Accuracy ±0.5% ±0.5%
NCV Detector Yes Yes
DC/AC Voltage 0.01mV to 600V 0.01mV to 600V
DC/AC Current 0.1µA to 10.00A 0.1µA to 10.00A
Resistance 0.1Ω to 40.00MΩ 0.1Ω to 60.00MΩ
Capacitance 1pF to 60.00mF 1pF to 60.00mF
Frequency 0.001Hz to 10MHz 0.001Hz to 10MHz
Temperature (Type K) — -40 to 1832°F (-40 to 1000°C)
Duty Cycle 0.1 to 99.9% 0.1 to 99.9%
Diode Test 3.2V 3.2V
Continuity Audible Audible
Dimensions/ Weight 6.7x3.2x1.9" (175x81x48.5mm)/ 13.1oz (370g)
Warranty 3 years 3 years
ORDERING
EX350 ÿ
True RMS MultiMeter + NCV
EX355
ÿ
True RMS MultiMeter + NCV + Temperature
TL810 Electrical Test Lead Kit
TL803 Standard Test Leads
TP200 Type K Clamp Probe (212°F/100°C)
EX355
with Temperature
EX350
Low Past Filter (LPF) ensures accurate
AC Voltage measurements on a variable
frequency drive.
Verify Temperature output on HVAC units
using Model EX355
Calibration Traceable to NIST
A NIST traceable certificate with data is
available when you order your meter with
Certificate Traceable to NIST. Look for this
symbol ÿ next to product part numbers.
