Extech Instruments 42275, 42265, SW276 User Manual

User Guide

Model 42265 Temperature Datalogger Kit
Model 42275 Temperature and Humidity Datalogger Kit
Model SW276 Datalogging Software

SW276

Introduction

gg

Congratulations on your purchase of Extech Instrument’s Datalogging instrumentation and
software. This User Guide serves three purposes, refer to the list below:

1. This User Guide covers the following products entirely with regard to hardware and
software operation:

Model 42275: Temperature and Humidity Datalogging Module with docking station and SW276 WindowsTM

Model 42265: Temperature Datalogging Module with docking station & SW276 Windows
Model SW276: Windows

2. This User Guide covers the following products with regard to software and some
hardware operation. A separate manual is supplied with your instrument that covers all
of the hardware operation.

Model 42276: Temperature & Humidity Datalogging Module plus printing/docking station & Optional

Model 42266: Temperature-only Datalogging Module plus printing/docking station & Optional SW276

Model 42270: Temperature and Humidity Datalogging Module
Model 42260: Temperature-only Datalogging Module

3. This User Guide covers the following products with regard to software only; all other
information regarding hardware is covered in a separate, dedicated manual supplied
with the instrument.

Model 42280: Temperature and Humidity Datalogger (Software instructions only)

Applications

The Datalogging modules models 42270 and 42260 can be used to monitor the
temperature of greenhouses, warehouses, food transports, aircraft cabins, refrigerated
trucks, containers, museums, and HVAC equipment. The Model 42270 records Relative
Humidity readings in addition to temperature readings. Modules can store 16,000 (8000
temperature and 8000 %RH for 42270) readings that can later be transferred to PC or
directly printed using the Model 42276 Programmer/Printer.

Software

TM

Software

TM

Datalogging Software

TM

TM

Software

Software

SW276 Windows

Windows

The datalogger module display will not switch

on until activated through the software

The datalogger module display will not switch on until it is activated by the

software in the LOGGER SET menu as described later in this manual. In

LOGGER SET the user selects the type of recording activation. When the

er begins to log data, the display and status LEDs will switch on.

lo

Important note on the Model 42280 Temperature/Humidity Datalogger

Note that the Model 42280 has its own User Guide. Please refer to
the separate User Guide supplied with the Model 42280 for details
on the meter’s operation. This manual covers only the Datalogging
software with regard to the 42280. Install the supplied Software as
described on the program CD’s label and then skip to page 5 of this
manual for software instructions.

Model 42280

2

V7.1 1/08

Description

1. LCD display

2. Mounting hole

3. Docking station

4. Interface Cable

5. Status LEDs

6. Software CD

Displays

LCD Display

REC: Displayed while logging readings. Read the ‘Recording
Status’ section for further details.

HI and LOW: Displayed when the High or Low Alarm limit is
exceeded. See ‘Alarm Status’ below for further information.

RH%: Relative Humidity (42270 and 42275 only)
C or F: Temperature units.
COMM: Appears when Datalogger is communicating with a PC.

Recording Status Indication

Both the RED status LED and the display indicator ‘REC’ will flash every 5 seconds if the
sampling rate is set to 5 seconds or higher. If the sampling rate is set lower than 5
seconds, the indicators will flash every 1, 2, 3, or 4 seconds as programmed.

ALARM Status Indication

Both the YELLOW status LED and the display indicator ‘ALM’ will flash when the recorded
value is higher than the user programmed High Alarm value or lower than the Low Alarm
value. The Alarm status LED and the ‘ALM’ display indicator flash every 5 seconds if the
sampling rate is programmed for 5 seconds or higher. If the sampling rate is set lower than
5 seconds, the indicators will flash every 1, 2, 3, or 4 seconds as programmed.

Low Battery Indication

When the lithium battery’s voltage nears the critical operating level the LCD displays ‘LO’.
To replace the battery, refer to the Battery Replacement section of this manual.

REC HI LOW COMM

RH%

°C
°F

3

V7.1 1/08

Software Installation

Installation instructions for models 42266 and 42276

Note: The software program and USB driver must both be
installed in order for the printer/meter to communicate with
the software. Please follow the installation instructions below.

1. Place the supplied software CD in the PC CD-ROM. The Data Acquisition Setup
Menu will appear (see below).

2. Click on “Install Software” to start the installation of the software.

3. Click “Finish” to install the program to the default location or click on “Change” to
enter the directory in which to install the program.

4. Follow the on-screen instructions to complete the program installation.

5. Click “Install USB” and follow the on screen instructions to complete the USB driver
installation.

LNK PC Link Screen

The printer must be set to PC communication on the Link
screen before communication can occur.

1. Turn the printer on

2. Press the Menu button until the LNK screen
appears.

3. Press the Up or Down button to select the logger or
the printer memory.

4. Press Enter when the selection is complete

Installation Instructions for models 42265 and 42275

Place the supplied software CD in the PC CD-ROM drive.

1. Click on “Install Software” to start the installation of the software.

2. Click “Finish” to install the program to the default location or click
on “Change” to enter the directory in which to install the program.

3. Follow the on-screen instructions to complete the program
installation.

Setup menu description

1. Install USB driver

2. Exit: Close the Setup Menu

3. Software Version number

4. Software installation

5. Open the English manual

6. Open the Spanish manual

7. Visit the Extech website

8. View all items on the CD-ROM

1

3
4

5, 6

7

8

2

4

V7.1 1/08

Software Operation

Main Screen

Diagram A: Main Screen

Cursor 1 and 2 Control

Click on a cursor line to select it. When the red cursor line is clicked, it turns bold red.
When you click the green cursor, it turns bold green (colors may vary). The CURSOR
STATUS field (lower left) shows the cursor positions. As the Arrow keys are used to select
the last record or the next record, the cursor location numbers change to reflect their new
position.

Left arrow key: Moves to previous point on the current plot.
Right arrow key: Moves to next point on the current plot.
<Shift>-left arrow key: Moves back 10 points on the current plot.
<Shift>-right arrow key: Moves forward 10 points on the current plot.
<Home>: Moves to first visible point on the current plot.
<End>: Moves to last visible point on the current plot.

The user can also click and drag the cursor with the mouse. The cursor tracks the mouse
until the mouse button is released. When the mouse button is released, the cursor snaps
to the nearest data point.

Offset Knob

Use the Offset control in the DISPLAY CONTROL field (lower right) to optimize the data
viewing area. Press the up or down arrow key to increment or decrement the record
number (with corresponding date) in the graph.

5

V7.1 1/08

Zoom and Pan on Graphs

To zoom in, press the <Ctrl> key and click the left mouse button over the desired point;
release the <Ctrl> key after the mouse button is pressed. The view resolution increases
until the mouse button is released. To zoom out, click the right mouse button.

To pan, press the <Ctrl-Shift> keys and click the left mouse button over the desired point,
and then drag the mouse to another point. The graph view scrolls so that the original point
now appears under the new mouse cursor location. Drag the mouse anywhere on the
screen.

To restore the view to its original state (after zooming or panning), press and hold the left
mouse button and drag the line on the Offset or Range knob (located in the DISPLAY
CONTROLS section).

Horizontal Axis select switch

Use the mouse to control the switch and select Record number or Time (HH:MM:SS) label
for the horizontal axis of the graph.

Warning message

A warning message will appear on the lower left if the Datalogger is disconnected from the
PC.

<< WARNING: Data Logger not plugged into interface module! >>

Display Control

After downloading or retrieving a record, the numbers on the "Offset" and "Range" knobs
will change to:

Offset: 0000/5000/10000/15000
Range: 50/250/500/1K/2K/4K/8K/12K/16K

Save File

To save a transferred data file

Click on SAVE FILE, select a folder, and name the data file.

6

V7.1 1/08

Retrieve File

Click on RETRIEVE FILE to retrieve a previously saved file.

To aid in reading a graph, a grid can be drawn on the graph. A dialogue box at the bottom
left hand corner shows the grid (CONTROL LOCATION Cursor 1 and 2)

After retrieving a file containing Humidity records, the labels "Temperature" and "Humidity"
will appear at the beginning of the curves. If no Humidity data is transferred, only the
Temperature curve will appear.

The date and time of the first point appears on the left hand corner. The last point’s date
and time appears on the right hand corner.

MAIN SCREEN WITH SAMPLE DATA

7
