HD300 CFM/CMM
Thermo-Anemometer +
IR Thermometer
Built-in IR Thermometer for quick
troubleshooting of ceiling vents,
duct work, and other remote
surfaces
• IR Thermometer has 30:1 distance
to target ratio and Laser pointer
• Simultaneous display of Air Flow
in CFM/CMM or Air Velocity
Plus Ambient Temperature
• Up to 8 easy to set Area
dimensions stored in memory
• Large backlit LCD
• Air Flow displayed in 2 modes
as an instantaneous value or
up to 20 point average
• USB port includes PC software
• Includes PC software, cable, vane
sensor on 3.9ft (120cm) cable, builtin stand, case, and 9V battery
407113 High
Temperature CFM Metal
Vane Anemometer
Withstands temperatures to 175°F
(80°C) and airspeed to 6890ft/min
• Display Air Flow (CFM) or Air
Velocity plus Temperature
• Air Flow displayed in 3 modes:
Instantaneous value, Up to 20
point average, or 2/3 flow value
• Record and Recall MIN/MAX
• Data Hold plus Auto power off
• Built-in PC Interface
• Optional Data Acquisition software
407001 - see details on
p. 114
• Includes metal vane sensor with 3.9ft
(120cm) cable, 9V battery, holster with
stand, and hard case; Optional 117V
(156119) or 220V (156221) AC adaptors
(see
p. 136 for ordering).
407119 Hot Wire CFM/
CMM Anemometer
Accurately measures Air Flow
(CFM/ CMM) or Air velocity plus
Temperature
• Air velocity measurements
as low as 40ft/min
• Telescoping probe extends
up to 3ft (940mm) long
• Measures air volume in CFM (ft
3
/
min) and CMM (m
3
/min) plus
Temperature simultaneously
• Air Flow displayed in 2 modes
as an instantaneous value or
up to 20 point average
• Record and Recall MIN/MAX
• Data Hold plus Auto power off
• Optional Data Acquisition software
407001 - see details on
p. 114
• Complete with telescoping
probe with 5.5ft (167.6cm)
cable, and four AA batteries
HD300 ÿ 407113 ÿ 407119 ÿ
80 to 5900 (1) 100 to 6890 (1) 40 to 3346 (1)
0.4 to 30.00 (0.01) 0.5 to 35 (0.1) 0.2 to 17 (0.1)
1.4 to 108.0 (0.1) 1.8 to 126.0 (0.1) 0.7 to 61.2 (0.1)
0.9 to 67 (0.1) 1.1 to 78.3 (0.1) 0.9 to 38.0 (0.1)
0.8 to 58.0 (0.1) 1.0 to 68.0 (0.1) 0.4 to 33.0 (0.1)
14 to 140°F/-10 to 60°C (0.1°) 32 to 175°F (0.1°)/ 0 to 80°C (0.1°) 32 to 122°F (0.1°)/ 0 to 50°C (0.1°)
-58to932°F/-50to500°C(0.1°/1°) — —
0 to 999,900CFM (0.001) 0 to 999,900CFM (0.001) 0 to 1,271,200CFM (0.001)
0 to 999,900CMM (0.001) 0 to 999,900CMM (0.001) 0 to 36,000CFM (0.001)
±3%rdg; ±4°F (2°C) ±2%rdg; ±1.5°F (±0.8˚C) ±2%rdg; ±1.5°F (±0.8˚C)
Yes Optional 407001 Software (see
p. 114) Optional 407001 Software (see p. 114)
Directly to PC using software — —
Ye s Ye s Ye s
8x3x1.9" (203x75x50mm)/12.2oz (350g) 7x2.9x1.3" (178x74x33mm)/1.35lbs (612g) 7x2.9x1.3" (178x74x32mm)/1.1lbs (482g)
3 years 3 years 3 years
Vane and Hot Wire CFM/CMM Thermo-Anemometers
