Extech Instruments 160273 User Manual

User’s Manual

Battery Operated Counting Scale

MODEL 160273

2

WARRANTY

EXTECH INSTRUMENTS CORPORATION warrants the basic instrument to be free of defects in
parts and workmanship for one year from date of shipment (a six month limited warranty applies
on sensors and cables). If it should become necessary to return the instrument for service during
or beyond the warranty period, contact the Customer Service Department at [phone] for
authorization. A Return Authorization (RA) number must be issued before any product is
returned to Extech. The sender is responsible for shipping charges, freight, insurance and proper
packaging to prevent damage in transit. This warranty does not apply to defects resulting from
action of the user such as misuse, improper wiring, operation outside of specification, improper
maintenance or repair, or unauthorized modification. Extech specifically disclaims any implied
warranties or merchantability or fitness for a specific purpose and will not be liable for any direct,
indirect, incidental or consequential damages. Extech's total liability is limited to repair or
replacement of the product. The warranty set forth above is inclusive and no other warranty,
whether written or oral, is expressed or implied.

CALIBRATION AND REPAIR SERVICES

Extech offers complete repair and calibration services for all of the products we sell. For periodic
calibration, NIST certification or repair of any Extech product, call customer service for details on
services available. Extech recommends that calibration be performed on an annual basis to insure
calibration integrity.

Copyright © 1999 Extech Instruments Corporation.

All rights reserved including the right of reproduction in whole or in part in any form.

Tech Support Hotlines

781-890-7440 ext. 200

[e-mail]

www.extech.com

(

160273 V1.1 2/00

3

Introduction

Congratulations on your purchase of Extech’s 160273 Counting Scale. This scale accurately weighs
and Counts components and parts up to 25 lbs. Zero and Tare functions are standard. The Scale is
battery operated and the internal battery is rechargeable using the supplied AC adapter. Proper use
and care of this meter will yield years of reliable service.

Specifications

Display Three LCD Displays for Weight, Piece Weight, and Quantity
Status LED Red: Battery drained; Green: fully charged; Amber: some charge
Status LCD arrows LCD status arrows for Zero, Net weight, Light samples, Add samples
Max. Weight 25 lbs.
Resolution 0.005 lbs.
Accuracy ±0.02%
Max. Piece Count 9,999
Power supply Internal rechargeable battery
Range selection Automatic ranging
Auto Power OFF Programmable for 5, 10, 20, or 30 minutes (can be deactivated)
Operating temp. 32 to 122oF (0 to 50oC)
Pan Size 9.4 x 11” (240 x 280mm)
Dimensions 11.3W x 13.5D x 4.3H” (287W x 344D x 110H mm)
Weight 15 lbs. (6.8 kg)
Accessories AC Adapter, Spider assembly installation kit
