Extech MA610 User guide

USER MANUAL
600A AC Clamp Meter + NCV Model MA610
EXTECH INSTRUMENTS
2 MA610-en-GB_V1.0 12/16
Introduction
Thank you for selecting the Extech MA610 Clamp Meter. This meter measures AC Current, AC/DC Voltage, Resistance, Capacitance, Frequency, Diode Test, Duty Cycle, Continuity and Non­Contact Voltage detection. This device is shipped fully tested and calibrated and, with proper use, will provide years of reliable service. Please visit our website (www.extech.com) to check for the latest version and translations of this User Manual, Product Updates, Product Registration, and Customer Support.
Features
Large backlit LED display 30mm (1.2") jaw size fits conductors up to 500MCM Relative and Zero mode functionality Auto Power OFF (APO) Non-Contact Voltage Detector Visual and audible continuity measurement alert Low battery indicator CAT III 600V
Safety
To ensure the safe operation and service of the meter, follow these instructions closely. Failure to observe warnings can result in severe injury.
WARNINGS
WARNINGS identify hazardous conditions and actions that could cause BODILY HARM or DEATH.
When handling test leads or probes, keep hands and fingers behind the finger guards at all times. Remove test leads from the meter before opening the battery compartment or meter housing. Use the meter only as specified in this User Manual or accompanying Quick Start to avoid compromising
the protections provided by the meter.
Be sure to use the proper terminals, switch positions, and ranges when taking measurements. Verify the meter’s operation by measuring a known voltage. Have the meter serviced if the meter
responds unusually or if there are questions regarding the meter’s functional integrity.
Do not apply more than the rated voltage, as marked on the meter, between terminals or between any
terminal and earth ground.
Use caution working with voltages above 30 VAC RMS, 42 VAC peak, or 60 VDC. These voltages pose a
shock hazard.
To avoid misleading readings that could lead to electric shock and injury, replace the batteries as soon as
the low battery indicator is displayed.
Disconnect power to the circuit under test and discharge all high-voltage capacitors before testing
resistance, continuity, diodes, or capacitance.
EXTECH INSTRUMENTS
3 MA610-en-GB_V1.0 12/16
Do not use the meter in the presence of explosive gas or vapor. To reduce risk of fire or electric shock, do not use the meter if it is wet and do not expose the meter to
moisture.
Individual protective equipment should be used if HAZARDOUS LIVE parts in the installation where
measurements are to be carried out could be accessible.
CAUTIONS
CAUTIONS identify conditions and actions that could cause DAMAGE to the meter or equipment under test. Do not expose the meter to extremes in temperature or high humidity.
Disconnect the test leads from the test points before changing the position of the function (rotary)
switch.
Do not expose the meter to extremes in temperature or to high humidity. Never set the meter to the resistance, diode, capacitance, or amp functions when measuring the
voltage of a power supply circuit; this could result in meter damage and damage to the equipment under test.
Safety Symbols
This symbol, adjacent to another symbol, indicates the user must refer to the manual for further information.
Risk of electrical shock
Equipment protected by double or reinforced insulation
Diode symbol
Capacitance
Battery symbol
Conforms to EU directives
Complies with USA and Canada requirements AC measurement
DC measurement
Earth ground
EXTECH INSTRUMENTS
4 MA610-en-GB_V1.0 12/16
PER IEC1010 OVERVOLTAGE INSTALLATION CATEGORY
OVERVOLTAGE CATEGORY I
Equipment of OVERVOLT AGE CATEGORY I is equipment for connection to circuits in which measures are taken to limit the transient over-voltages to an appropriate low level.
Note – Examples include protected electronic circuits.
OVERVOLTAGE CATEGORY II
Equipment of OVERVOLTAGE CATEGORY II is energy-consuming equipment to be supplied from the fixed installation.
Note – Examples include household, office, and laboratory appliances.
OVERVOLTAGE CATEGORY III
Equipment of OVERVOLTAGE CATEGORY III is equipment in fixed installations.
Note – Examples include switches in the fixed installation and some equipment for industrial use with permanent connection to the fixed installation.
OVERVOLTAGE CATEGORY IV
Equipment of OVERVOLTAGE CATEGORY IV is for use at the origin of the installation. Note – Examples include electricity meters and primary over-current protection equipment
Description
Meter Description
1. Transformer current jaws
2. Jaw opening trigger
3. M (Mode) button
4. Backlit LCD
5. Control buttons (see descriptions below)
6. COM negative input terminal
7. Positive input terminal
8. Function selector
9. NCV alert lamp
10. Backlight button
11. NCV sensor
Note: Battery compartment is located on back of meter
Fig. 1 – Meter Description
EXTECH INSTRUMENTS
5 MA610-en-GB_V1.0 12/16
Display Description
Relative mode icon
Units of Frequency
AC
Alternating Current
Units of Voltage
DC
Direct Current
Units of Capacitance
Negative readings
NCV
Non-contact AC Voltage Detect
Diode mode
Automatic range mode
Continuity mode
Low Battery icon
Display Hold
Duty Cycle
Units of resistance
Measurement overload
Control Buttons
Mode button: Short press to step through the mode options for the selected
measurement function
HOLD button: Short press to freeze/unfreeze reading
Backlight button: Short press to turn backlight ON or OFF. Note that the backlight
button is on the upper right side of the meter.
For AC/DC voltage, AC current and Resistance modes: Short press to store the
displayed reading as a reference value. Subsequent measurements will be displayed as ‘measurement minus reference value’. Short press to exit. For Capacitance mode, short press to zero the display; the LCD will show the delta symbol. Short press to exit this mode.
Short press to step through frequency (Hz) and duty cycle (%) measurements for the
Voltage and Hz switch positions.
EXTECH INSTRUMENTS
6 MA610-en-GB_V1.0 12/16
Operation
CAUTION: Read and understand all of the Safety statements listed in the safety section of this manual prior to use.
Powering the Meter
1. Move the function switch to any position to power the meter. Check the batteries if the unit
fails to power ON.
2. Move the function switch to the OFF position to remove power to the meter.
3. The meter has an Auto Power OFF feature (APO) where the meter switches OFF after 30
minutes of inactivity. Press any button to recover from an APO condition.
Low battery indication
When the icon appears in the display, the battery should be replaced. Refer to the battery replacement procedure in the maintenance section.
