IIEEEEEE 11339944 CCDD--RRWW
IINNSSTTAALLLLAATTIIOONN GGUUIIDDEE
- 1 -
USING CD
USING CD----RW WITH IEE
USING CDUSING CD
Connect the IEEE 1394 CD-RW to computer
♦ Windows 98SE/Me/2000 and Macintosh:
1. Connect the of IEEE 1394 cable to the IEEE 1394 interface connector
of the CD-RW drive.
RW WITH IEEE 1394 INTERFACE
RW WITH IEERW WITH IEE
E 1394 INTERFACE
E 1394 INTERFACEE 1394 INTERFACE
Plug the AC adapter into the DC IN Jack of CD-RW, and attach the AC
adapter to the AC power outlet.
Plug the port connector of IEEE 1394 cable into the IEEE 1394 port of
computer, the Portable CD-RW is ready for use immediately.
PC Connection Macintosh Connection
- 2 -
SOFTWARE INSTALLATION FOR WINDOWS 98 SE
NOTE: The IEEE1394 interface only works under Win98 Second
Edition or above version.
1. Boot-up your computer into Window s 98S E, m ake su re the ‘IEEE 1394
Host Controller’ device driver has installed and available in Win98SE.
Please ri ght -click ‘My Computer’, click ‘Properties’ ‘Device
Manager’ to open the ‘Device Manager’ windo w, refer to the below
picture to check whether the ‘IEEE 1394 Host Controller’ is installed.
2. Microsoft has provided the ‘1394 Storage Supplement’ on ‘Windows
Update web site’, this patch file can let IEEE1394 devices be removed
safely, please go to ‘Windows Update’ to download this patch file,
otherwise, the IEEE 1394 device won’t work stable.
3. To download the patch file, please click Start ‘Windows Update’ to
link to the web site.
4. On the web site, click ‘Product Updates’ to open the download list,
under the ‘Recommended Updates’ area, check ‘Windows 98 Second
Edition 1394 Storage Supplement’, then click ‘Download’ button to
download the patch and install it.
5. After the update is complete, restart computer.
6. Connect the AC adapter plugs into the DC IN Jack at the rear panel of
the CD-RW, attach the AC adapter to the AC power outlet. Plug the port
connector of the IEEE 1394 cable into the IEEE 1394 port of computer.
- 3 -
7. Windows 98SE will install its built-in device driver automatically. After
the installation, this Portable CD-RW will appear in ‘My Computer’.
8. If this Portable CD-RW doesn’t appear in ‘My Computer’ or doesn’t
work properly, please go into ‘Device Manager’ to check whether the
devices are installed as below (the name under the CD-ROM drive list in
the picture below may be different from your CD-RW drive).
- 4 -
SOFTWARE INSTALLATION FOR WINDOWS ME
SOFTWARE INSTALLATION FOR WINDOWS ME
SOFTWARE INSTALLATION FOR WINDOWS MESOFTWARE INSTALLATION FOR WINDOWS ME
1. Boot-up your computer into Windows Me, make sure the ‘IEEE 1394
Host Controller’ device driver has installed and available in Windows
Me. Pleas e right-click ‘My Computer’, click ‘Properties’ ‘Device
Manager’ to open the ‘Device Manager’ windo w, refer to the below
picture to check whether the ‘IEEE 1394 Host Controller’ is installed.
2. Connect the AC adapter plugs into the DC IN Jack at the rear panel of
the CD-RW, attach the AC adapter to the AC power outlet. Plug the port
connector of the IEEE 1394 cable into the IEEE 1394 port of computer.
3. Windows Me will install its built-in device driver automatically. After
the installation, this Portable CD-RW will appear in ‘My Computer’.
- 5 -
4. If this Portable CD-RW doesn’t appear in ‘My Computer’ or doesn’t
work properly, please go into ‘Device Manager’ to check whether the
devices are installed as below (the name under the CD-ROM drive list in
the picture below may be different from your CD-RW drive).
- 6 -
SOFTWARE INSTALLATIO
SOFTWARE INSTALLATION FOR WINDO WS 2000
SOFTWARE INSTALLATIOSOFTWARE INSTALLATIO
1. Boot-up your computer into Windows 2000, make sure the ‘IEEE 1394
Host Controller’ device driver has installed and available in Windows
2000. Please right-click ‘My Computer’, click ‘Properties’
‘Hardware’ ‘Device Manager’ to open the ‘Device Manager’
window, refer to the below picture to check whether the ‘IEEE 1394
Host Controller’ is installed.
N FOR WINDOWS 2000
N FOR WINDOWS 2000N FOR WINDOWS 2000
2. Connect the AC adapter plugs into the DC IN Jack at the rear panel of
the CD-RW, attach the AC adapter to the AC power outlet. Plug the port
connector of the IEEE 1394 cable into the IEEE 1394 port of computer.
3. Windows 2000 will install its built-i n device driv er automatically . After
the installation, this Portable CD-RW will appear in ‘My Computer’.
- 7 -
4. If this Portable CD-RW doesn’t appear in ‘My Computer’ or doesn’t
work properly, please go into ‘Device Manager’ to check whether the
devices are installed as below.
- 8 -
SOFTWARE INSTALLATIO
SOFTWARE INSTALLATION FOR MACINTOSH
SOFTWARE INSTALLATIOSOFTWARE INSTALLATIO
1. Before install the Portable CD-RW, please check the version of your
FireWire driver in system, the version higher than 2.5 is recommended.
Follow the below procedures to check the version.
A. Double-click ‘Macintosh HD’ on desktop.
B. Double-click ‘System Folder’ in the opened window.
C. Double-click ‘Extensions’ folder.
N FOR MACINTOSH
N FOR MACINTOSHN FOR MACINTOSH
D. Click on ‘FireWire Support’ in the list.
E. Click ‘File’ ‘Get Info’ ‘General Information’ to open the
information window.
F. Check the ‘Version’, if the number is lower than 2.5 (it could be
version 2.2 .2), we suggest you upgra de it to version 2.5 or hi gher.
Please go to the homepage of Apple Computer Inc. –
http://www.apple.com
‘Download’, and download the ‘FireWire Update’ to upg rade your
FireWire driver.
2. After check the FireWire driver and upgrade it, connect the AC adapter
plugs into the DC IN Jack at the rear panel of th e CD-RW, attach the AC
adapter to the AC power outlet. Plug the port connector of the IEEE
1394 cable into the IEEE 1394 port of computer.
3. Now you can use the Portable CD-RW as a CD-ROM drive, it can read
disc but still can’t write data to disc.
4. You must install the CD Recording Software that came with the drive
before you can perform the write and rewrite functions on the CD-RW
drive
, after link to the homepage, go into ‘Support’
- 9 -
USING CD
USING CD----RW WITH IEE
USING CDUSING CD
Connect the IEEE 1394 CD-RW to computer
♦ Windows 98SE/Me/2000 and Macintosh:
1. Connect the 36-pins connector to the interface connector of the CD-RW.
2. Plug the AC adapter into the DC IN Jack of CD-RW, and attach the AC
adapter to the AC power outlet.
3. Plug the port connector of IEEE 1394 cable into the IEEE 1394 port of
computer, the Portable CD-RW is ready for use immediately.
RW WITH IEEE 1394 INTERFACE
RW WITH IEERW WITH IEE
E 1394 INTERFACE
E 1394 INTERFACEE 1394 INTERFACE
Disconnect the IEEE 1394 CD-RW from computer
♦ Windows 98SE:
Note: If you didn’t download and install the ‘1394 Storage
Supplement’ from ‘Windows Update’ web site, plug out the
1394 cable directly during Windows 98SE running may causes
the Windows 98SE halted. If you experienced this situation, the
best solution is install the above patch file, please follow the
procedure in ‘Software Installation for Windows 98SE’ to
complete the update.
1. Double-click on the icon
Hardware’ dialog box appears.
2. Highlight the ‘1394/USB CD-ROM’ in the dialog box, click on Stop,
then click on OK on next screen.
3. Wait for few seconds, the system prompts ‘The 1394/USB CD-ROM
can now be safely removed f rom the syst em’, click on OK, and then plug
out the IEEE 1394 cable from the IEEE 1394 port of computer.
in system tray, the ‘Unplug or Eject
- 10 -
♦ Windows Me:
1. Double-click on the icon
Hardware’ dialog box appears.
2. Highlight the ‘IEEE 1394 CD-ROM’ in the dialog box, click on Stop,
then click on OK on next screen.
3. Wait for few seconds, the system prompts ‘The IEEE 1394 CD-ROM
can now be safely removed f rom the syst em’, click on OK, and then plug
out the IEEE 1394 cable from the IEEE 1394 port of computer.
♦ Windows 2000:
1. Double-click on the icon
Hardware’ dialog box appears.
2. Highlight the ‘IEEE 1394 / Firewire IDE device IEEE 1394 SBP2
Device’ in the dialog box, click on Stop, then click on OK on next
screen.
3. Wait for few seconds, the system prompts ‘The IEEE 1394 / Firewire
IDE device IEEE 1394 SBP2 Device can now be safely removed from
the system’, click on OK, and then plug out the IEEE 1394 cable from
the IEEE 1394 port of computer.
in system tray, the ‘Unplug or Eject
in system tray, the ‘Unplug or Eject
♦ Macintosh:
1. If there is a disc in the Portable CD-RW, you must take out the disc first:
click on the icon of disc, press
CD-RW, take the disc out and then reload the disc tray, the icon will
disappear.
2. Plug out the IEEE 1394 cable from the IEEE 1394 port of computer.
- 11 -
to eject the disc tray of
CD
CD----R/CD
R/CD----RW MEDIA
CDCD
R/CDR/CD
When you are using the Portable CD-RW to record your own CDs, you can
use both CD-R disc and CD-RW discs. The CD-R/CD-RW discs must
comply with the Orange Book Part II standard.
Media Compatibility
CD-R disc is readable by CD-ROM, CD-R and CD-RW drives. CD-RW
disc is only readable by MultiRead CD-ROM and CD-RW drives, some
CD-R drives may read CD-RW disc too. The readability of data discs on
various systems will also be affected by the filenames/file system selected,
and the operating system(s) under which the disc is written and read.
RW MEDIA
RW MEDIARW MEDIA
Disc Handling
For best result of recording and also the care of the CD Discs, read the
following notes cautiously before using the Portable CD-RW.
Keep your CD-R/CD-RW discs clean by wiping the disc w ith a soft, d ry
cloth radially, i.e. from the center straight out to the edge.
Dry the disc thoroughly before inser ting it in the drive.
Never write on either side of a disc with a ballpoint pen or pencil. To
label CD-R/CD-RW discs, use only markers or label specifically
designed for CD-R/CD-RW media.
Avoid exposing discs to direct sunlight, and avoid storing them in areas
subject to hi gh temperature or high humidity.
Store discs in cases to avoid dust, dirt, scratches, and bending.
- 12 -
