Exmark NAV27KC, NAV20KC User Manual

For Serial Nos.

510,000 & Higher

Part No. 103-8573 Rev. B

WARNING

POTENTIAL HAZARD
♦ This product is a piece of power equipment.
WHAT CAN HAPPEN
♦ Failure to follow safe operating pr actices can result in serious

operator injury or even death.
HOW TO AVOID THE HAZARD
♦ Keep all shields, guards, and safety devices (especially the grass

discharge system) in place and in proper working condit ion.
♦ Stop engine and wait for all moving parts to stop. Remove spark

plug wire(s) or remove key before adjust ing, servicing, or

performing maint enance.
♦ If mower deck becomes clogged, stop engine and wait for all

moving parts to stop. Remove spark plug wire(s) or r em ove k ey

before cleaning blockage.

♦ Keep hands, feet, and clothing away from power driven parts .
♦ Keep off mower unless seat platf o r m is pr ovided.
♦ Keep others off mower.

WARNING

POTENTIAL HAZARD
♦ Gasoline is harmful or f at a l if swallowed. Long-term exposure to

vapors has caused cancer in laboratory animals.
WHAT CAN HAPPEN
♦ Failure to use caution may cause serious injury or illness.
HOW TO AVOID THE HAZARD

♦ Avoid prolonged breathing of vapors.
♦ Keep face away from nozzle and gas tank/container opening.
♦ Keep away from eyes and skin.
♦ Never siphon by mouth.

IMPORTANT

When the mower is used or oper ated on any California forest, brush or grass covered land, a working
spark arrester must be at t ached t o the muffler. If not, the operator is violating stat e law, Section 4442
Public Resource Code. To acquire a spark ar r ester for your unit, see your Engine Service Dealer.

This spark ignition system complies with Canadian ICES-002
Ce système d’allumage par ètincelle de vèhicule est conform e à la norme NMB-002 du Canada

The enclosed Engine Owner’s Manual is supplied for information regarding The U.S.
Environmental Protection Agency (EPA) and the California Emission Control Regulation of
emission systems, maintenance and warranty.

Keep this engine Owner’s M anual with your unit. Should this engine Owner’s Manual become
damaged or illegible, replace immediately. Replacements may be ordered through the engine
manufacturer.

- i -

EXMARK PARTS PLUS® PROGRAM

EFFECTIVE DATE: September 1, 1995
Program

If your Exmark dealer does not have the Exmark part in stock,
Exmark will get the parts to the dealer the next business day or
the part will be FREE* Guaranteed!!

How the Program Works

1. If dealer does not have part in stock for a "down" unit at

2. Distributor ships part(s) to dealer or customer, as

3. If distributor does not have the part(s) in stock to satisfy Exmark Parts Plus

4. If order is received by 3:00 p.m. central time, Exmark ships part(s) direct to dealer or customer, as requested by

5. The customer pays for the part

6. Who pays for the part
A. Under any circumstance the customer does not pay.
B. If the part does not arrive overnight due to:

2. The Distributor being unable to ship the part the same day or not submitting the Exmark Parts Plus

3. Exmark being unable to ship the part and the Exmark parts order is received by 3:00 p.m., central time,

4. If the part does not arrive overnight due to the shipper (UPS), the shipper pays for the freight and Exmark

the time of request by customer, the dealer contacts his
distributor by 1:00 p.m., local time, and requests Exmark
Parts Plus

®

shipment of six (6) line items or less.

requested by dealer, same day, overnight UPS
Distributor bills dealer for part and freight charges where
applicable.

®

order, he contacts Exmark by 3:00 p.m.,

central time, with an Exmark Parts Plus

®

order of six (6) line items or less.

distributor, same day, overnight UPS, Exmark bills the distributor for parts and shipping charges, where applicable.

and freight if it is shipped under the Exmark Parts Plus® and if it arrives in

accordance to the program.

and freight if it fails to arrive overnight in accordance to the program?

1. The dealer not submitting the Exmark Parts Plus

®

order to his Exmark distributor by 1:00 p.m., the dealer

pays for the part and freight.

®

order

to Exmark by 3:00 p.m., central time, the Distributor pays for the part and freight.

Exmark pays for the part and freight.

pays for the part.

The following restrictions apply

-- The Exmark Parts Plus® Program is available only through participating Exmark
Dealers and applies only to orders submitted on this program Monday through Thursday. Parts Plus service is available
only in the 48 contiguous United States. UPS has initiated a Saturday delivery program to many areas of the continental
United States and can be requested for an overnight shipment on Friday to be delivered Saturday. The next day air
charge, plus the Saturday delivery fee will be the responsibility of the purchaser. Exmark Mfg. will assume no
responsibility for Saturday delivery shipments. To qualify, all Exmark Parts Plus® orders must be received by Exmark by
3:00 p.m., central time. Orders must be six (6) line items or less. Exclusions from the Exmark Parts Plus

®

Program are:
Any wholegood or accessory in its entirety, engines and engine replacement parts, 5-speed Peerless transmissions and
5-speed transaxles, hydraulic or hydrostatic wheel motors, cutter decks and engine decks or any item exceeding United
Parcel Service size and weight restrictions.

Due to UPS restrictions, aerosol spray paint is considered a hazardous material and cannot be shipped via UPS next day
or Second Day Air.

Exmark Manufacturing stocks a limited supply of parts for transaxles, pumps and wheel motors. These parts can be
ordered for Next Day Air shipment but will not be guaranteed per the Parts Plus Program.

- ii -

CONGRATULATIONS on the purchase of your Exmark mower. This product has
been carefully designed and manufactured to give you a maximum amount of
dependability and years of trouble-free oper at ion.

OPERATOR'S MANUAL

This manual contains assembly, operating, maintenance, adjustment, and safety
instructions for your Exmark mower.

BEFORE OPERATING YOUR MOWER,

CAREFULLY READ THIS MANUAL IN ITS ENTIRETY.

By following the operating, maint enance, and safety instructions, you will prolong
the life of your mower, mainta in it s m aximum efficiency, and promote safe oper ation.

If additional information is needed, or should you require trained mechanic
service, contact your authorized Exmark equipment dealer or distributor.

All Exmark equipment dealers and distribut or s are kept informed of the latest
methods of servicing and are equipped t o pr ovide prom pt and efficient service in the
field or at their service stations. T hey carr y ample stock of service parts or can
secure them promptly for you fr om the factory.

All Exmark parts are thoroug hly test ed and inspect ed before leaving the factory,
however, attention is required on your part if you are t o obt ain the fullest measure of
satisfaction and performance.

-iii-

TABLE OF CONTENTS

1. SAFETY PAGE

1.1 Safety Alert Symbol....................................................................................... 1

1.2 Training.........................................................................................................1

1.3 Preparation.................................................................................................1-3

1.4 Operation ...................................................................................................4-6

1.5 Maintenance & Storage..............................................................................6-7

1.6 Safety Signs............................................................................................. 8-10

2. SPECIFICATIONS

2.1 Model Number............................................................................................. 10

2.2 Engine......................................................................................................... 10

2.3 Fuel System ................................................................................................ 10

2.4 Electrical System....................................................................................10-11

2.5 Operator Controls........................................................................................ 11

2.6 Seat............................................................................................................. 11

2.7 Hydrostatic Ground Drive System ...............................................................11

2.8 Tires............................................................................................................12

2.9 Mower Deck ................................................................................................ 12

2.10 Dimensions.................................................................................................. 12

2.11 Torque Requirements..................................................................................12

3. ASSEMBLY INSTRUCTIONS

3.1 Uncrate Mower............................................................................................12

3.2 Service Battery.......................................................................................12-13

3.3 Install Drive Wheels..................................................................................... 13

3.4 Check Tire Pressure....................................................................................13

3.5 Service Engine............................................................................................ 13

3.6 Service Hydraulic Oil................................................................................... 14

4. OPERATION INSTRUCTIONS

4.1 Controls.................................................................................................. 14-16

4.2 Pre-Start...................................................................................................... 16

4.3 Operating Instructions ............................................................................ 16-18

4.4 Transporting........................................................................................... 18-19

5. MAINTENANCE & ADJUSTMENTS

5.1 Periodic Maintenance.............................................................................20-27

5.2 Adjustments ...........................................................................................27-35

6. WASTE DISPOSAL

6.1 Motor Oil Disposal.......................................................................................35

6.2 Mercury Switch Disposal ............................................................................. 36

6.3 Battery Disposal.......................................................................................... 36

7. TROUBLESHOOTING ..................................................................................37-38

8. ELECTRICAL DIAGRAM ................................................................................... 39

9. HYDRAULIC DIAGRAM ....................................................................................40

10. WARRANTY ..................................................................................................... 41

- iv -

1. SAFETY

1.1 SAFETY ALERT SYMBOL

This SAFETY ALERT SYMBOL is used both in this manual and on the machine to

identify important safety messages which must be followed to avoid accidents. This
symbol means:

ATTENTION! BECOME ALERT!

YOUR SAFETY IS INVOLVED!

The safety alert symbol appears above information which alerts you to unsafe actions or

situations and will be followed by the word DANGER, WARNING, or CAUTION.

DANGER: White lettering / Red background. I ndicates an imminently hazardous situation

which, if not avoided, WILL result in death or serious injur y.

WARNING: Black lettering / O r ange background. Indicates a pot ent ially hazardous

situation which, if not avoided, COULD result in deat h or serious injury.

CAUTION: Black lettering / Yellow background. Indicates a potentially hazardous

situation which, if not avoided, MAY result in minor or moderate injury.

1.2 TRAINING

1.2.1 Regard the Exmark mower as a piece of power equipment and teach this regard
to all who operate this unit.

1.2.2 Read the instructions carefully. Familiarize yourself with the controls and the
proper use of the equipment. If the operator(s) or mechanic(s) can not read
English, it is the owner’s responsibility to explain this mater ial t o them.

1.2.3 Do not allow operation of this machine by untrained personnel. Never allow
children, teenagers, or people unfamiliar with these instructions to use the
mower. Local regulations may restrict the age of the operator.

1.2.4 Avoid mowing while people, especially children, or pets, are nearby. Keep in
mind that the operator or user is responsible for accidents or hazards occurring
to other people or their property.

1.3 PREPARATION

1.3.1 Evaluate the terrain to determine what accessories and attachments are needed
to properly and safely perform the job. Only use accessories and attachments
approved by Exmark.

1.3.2 The use of per sonal pr ot ective equipment, such as (but not limited to) pr otection
for the eyes, ears, feet , and head is r ecom m ended.

CAUTION

POTENTIAL HAZARD
♦ This machine produces sound levels in excess of 85

dBA at the operator’s ear when in operation.

WHAT CAN HAPPEN
♦ Exposure to sound levels of 85 dBA or above for

extended periods of time can cause hearing loss.

HOW TO AVOID THE HAZARD
♦ Wear hearing protection when operating this machine.

1.3.3 While mowing, always wear substantial footwear and long trousers. Do not
operate equipment when barefoot or when wearing open sandals.

- 1 -

1.3.4 Thoroughly inspect the area where the equipment is to be used and remove all
stones, sticks, wires, bones, and other foreign objects which may damage the
equipment or cause personal injury to the operat or or bystanders.

WARNING

POTENTIAL HAZARD
♦ Engine exhaust contains carbon monoxide, which is

an odorless deadly poison.

WHAT CAN HAPPEN
♦ Carbon monoxide can kill you.

HOW TO AVOID THE HAZARD
♦ Do not run engine indoors or in a small confined area

where dangerous carbon monoxide fumes can collect.

DANGER

POTENTIAL HAZARD
♦ In certain conditions gasoline is extremely flamm able

and highly explosive.

WHAT CAN HAPPEN
♦ A fire or explosion from gasoline can bur n you, ot hers,

and cause property damage.

HOW TO AVOID THE HAZARD
♦ DO NOT smoke while refueling , and stay away from

an open flame or where gasoline fumes m ay be ignited
by spark.

♦ Refuel only outdoors.
♦ Store gasoline in an approved container and keep it

out of the reach of children.

♦ Add fuel before start ing the engine. Never remove the

cap of the fuel tank or add fuel when engine is running
or when the engine is hot.

♦ Never fill the fuel tank so t hat the gasoline level rises

above a level that is 1/2” below the bottom of the filler
neck to allow for gasoline expansion and prevent fuel
spillage.

♦ If fuel is spilled, DO NOT attempt to start the engine.

Move away from the area of the spill and avoid
creating any source of ignition unt il fuel vapors have
dissipated.

♦ Do not operate without entire exhaust system in place

and in proper working condition.

- 2 -

DANGER

POTENTIAL HAZARD
♦ In certain conditions gasoline is extremely flamm able

and highly explosive.

WHAT CAN HAPPEN
♦ A static charge can ignite g asoline vapors. A fire or

explosion from gasoline can burn you, others, and
cause property damage.

HOW TO AVOID THE HAZARD
♦ Purchase and store gasoline only in an approved

container.

♦ Always place gasoline containers on the ground away

from your vehicle before f illing.

♦ Do not fill gasoline containers inside a vehicle or on a

truck or trailer bed because interior car pets or plastic
truck bed liners may insulate the container and slow
the loss of any static charge.

♦ When practical, r emove gas-powered equipment from

the truck or trailer and r efuel the equipment with its
wheels on the ground.

♦ If this is not possible, then refuel such equipment on a

truck or trailer from a portable container, rather than
from a gasoline dispenser nozzle.

♦ If a gasoline dispenser nozzle must be used, keep the

nozzle in contact with the rim of the fuel tank or
container opening at all times until fueling is complete.

WARNING

POTENTIAL HAZARD
♦ Gasoline vapor can collect inside enclosed trailers and

may be ignited by electrical sparks or hot
engine/exhaust components.

WHAT CAN HAPPEN
♦ Explosion and fire may occur, resulting in proper t y

damage, personal injury, and/or death.

HOW TO AVOID THE HAZARD
♦ Provide adequate ventilation of any enclosed trailer to

prevent build up of gasoline vapors, especially at floor
level.

♦ Refuel only outdoors, never inside an enclosed trailer.
♦ Be sure all fuel tanks and gasoline st or age containers

have proper caps installed to prevent spillage and
minimize vapor escaping into the trailer.

♦ Do not place any equipment that is leaking gasoline in

an enclosed trailer.

- 3 -

1.4 OPERATION

Although hazard control and accident prevention are partially dependent upon the

design and configuration of the equipment, these factors are also dependent upon
the awareness, concern, prudence, and proper training of t he personnel i nvolved in
the operation, transport, maintenance, and st orage of t he equipment. It is essential
that all Operator Safety Mechanisms be connect ed and i n operat i ng condition prior
to use for mowing.

WARNING

POTENTIAL HAZARD
♦ Operating engine parts, especially the m uffler, become

extremely hot.

WHAT CAN HAPPEN

♦ Severe burns can occur on contact.
♦ Debris, such as leaves, grass, brush, etc. can cat ch fire.

HOW TO AVOID THE HAZARD
♦ Allow engine parts, especially the muff ler , to cool before

touching.

♦ Remove accumulated debris from muffler and engine area.
♦ Install and maintain in working order a spar k arrester before

using equipment on forest - covered, grass-covered, or
brush-covered unimproved land.

WARNING

POTENTIAL HAZARD
♦ Hands, feet, hair, clothing, or accessories can become

entangled in rotating part s.

WHAT CAN HAPPEN
♦ Contact with rotating parts can cause traum at ic am putation

or severe lacerations.

HOW TO AVOID THE HAZARD
♦ Do not operate the machine without guards, shields, and

safety devices in place and working.

♦ Keep hands, feet, hair, je welry, or clothing away from

rotating parts.

1.4.1 Give complete, undivided attention to the job at hand.

1.4.2 Mow only in daylight or good artif icial light, keeping away from holes and hidden
hazards. NEVER carry passengers.

DO NOT operate the mower when children or others are in the area.

1.4.3 When feasible, avoid operating the equipment in wet grass.

1.4.4 Use EXTREME caution when mowing and/or turning on slopes as loss of tr action
and/or tip-over could occur. The operator is r esponsible for safe operation on
slopes.

- 4 -

DANGER

POTENTIAL HAZARD
♦ Mowing on wet grass or steep slopes can cause sliding and

loss of control.

WHAT CAN HAPPEN
♦ Wheels dropping over edges, ditches, steep banks, or

water can cause rollovers, which may result in serious
injury, death or drowning.

HOW TO AVOID THE HAZARD

♦ Do not mow slopes when grass is wet.
♦ Do not mow near drop-offs or near water.
♦ Do not mow slopes greater than 15 degrees.
♦ Reduce speed and use extreme caution on slopes.
♦ Avoid sudden turns or rapid speed changes.

• See inside the back cover to determine the approximate slope angle of the

area to be mowed.

• Use a walk behind mower and/or a hand trimmer near drop- offs, ditches, steep

banks or water. This area can be dangerous, see Figure 1.

Figure 1

SAFE ZONE FOR MOWING

• Progressively greater care is needed as the slope increases.

• Always avoid sudden starting or stopping on a slope. If tir es lose t r action,

disengage the blades and proceed slowly off the slope.

• Avoid sudden stops when mowing downhill. Mower may tip forwards.

• Be aware that loss of traction may occur going uphill. Weight transfer to the

rear wheel may cause drive wheels to slip and cause loss of braking and
steering.

• Watch for ditches, holes, rocks, dips, and r ises t hat change the operating

angle, as rough terrain could overtur n the machine.

• Remove or mark obstacles such as rocks, t r ee lim bs, etc. from the mowing

area. Tall grass can hide obstacles.

• Use extreme care with attachments. These can change t he stability of the

machine and cause loss of control.

• Follow the manufacturer’s recommendations for wheel weights or

counterweights to improve stability.

1.4.5 Use EXTREME caut ion when backing up. LOOK BEHIND YOU!

1.4.6 Stop the blades when crossing surfaces other than gr ass and when transporting
the mower to and from the area to be m owed.

- 5 -

1.4.7 Never operate the mower with damaged guards, shields, or covers. Always
have safety shields, guards, switches, and other devices in place and in proper
working condition.

1.4.8 DO NOT change the engine g overnor set tings or overspeed the engine. Operating
an engine at excessive speed may increase the hazard of personal injury.

1.4.9 Disengage PTO befor e starting engine.

1.4.10 Start

the engine carefully with feet well away from the blades.

1.4.11 Keep hands, feet, and clothing away from r o t at ing parts while the mower is being
operated.

1.4.12 Stop engine, wait for all moving parts to stop, and remove key:

• Before checking, cleaning or work ing on the mower.

• After striking a foreign object (inspect the m ower for damage and make

repairs before restart ing and operating the mower).

• Before clearing blockages.

• Whenever you leave the mower.

Stop the engine and wait for all moving part s t o st op:

• Before refueling.

• Before dumping the gr ass cat c her .

1.4.13 Before stopping the engine, place the throt t le cont r ol midway between the “slow”
and “fast” positions. Allow the engine t o r un a m inim um of 15 seconds; then stop
the engine.

1.4.14 The fuel system is provided with a shut-off valve. Shut off the fuel:

• When the machine will not be used for a few days.

• During transport to and from the job.

• When parked inside a building.

1.4.15 This mower was designed for one operator only. Keep all others away fr om
mower during operation.

1.4.16 Do Not mow with the grass catcher door or the grass cat cher r aised, removed or
altered.

1.4.17 Do Not operate mower under the influence of alcohol or dr ugs.

1.4.18 Use extra care when approaching blind corners, shrubs, trees, or other objects
that may obscure vision.

1.4.19 If jump starting is required:

a) connect the positive (+) power cable from the positive post on the booster

battery to the positive terminal post on the star ter solenoid switch (this post
has the positive battery cable attached to it).

b) connect the negative or ground cable (-) from the negative post on the

booster battery to the engine block as far away from the battery as possible.

c) disconnect battery cables in the reverse order after starting.

1.5 MAINTENANCE AND STORAGE

1.5.1 For engine maintenance, follow the engine manufacturer’s recommendations
precisely as stated in the engine manual.

1.5.2 Disconnect the battery cable from the negative battery post when the unit will be
allowed to sit for more than 30 days without use.

- 6 -

1.5.3 Allowing batteries to stand for an extended period of time without recharging
them will result in reduced performance and ser vice life. To preserve optimum
battery performance and lif e, recharge batteries in storage when the open
circuit voltage drops to 12.4 volts.

Note: To prevent damage due to freezing, bat t er y should be fully charged

before putting away for winter storag e.

1.5.4 Keep engine, engine area, and pump drive belt compartment free from
accumulation of grass, leaves, excessive grease or oil, and ot her debris which
can accumulate in these areas. These materials can become com bustible and
may result in a fire.

1.5.5 Store fuel in a container specifically designed for this purpose in a cool, dry place.

1.5.6 Keep the m ower and fuel container in locked storage to pr event childr en from
playing or tampering with them.

1.5.7 Gasoline powered eq uipm ent or fuel containers should not be stored in a basement
or any enclosed area where open pilot lights or heat appliances are present.

1.5.8 Maximum mowing results and safety can only be achieved if the mower is
properly maintained and operated correctly.

1.5.9 Check all bolts frequently to maint ain proper tightness.

1.5.10 Keep all guards, shields, and all safety devices in place and in safe working condition.

1.5.11 Frequently check for worn or deteriorating com ponent s t hat could create a hazard.

1.5.12 All replacement parts must be the same as or equivalent to the par t s supplied as
original equipment.

WARNING

POTENTIAL HAZARD
♦ Hydraulic fluid escaping under pressure can penetrat e

skin and cause injury.

WHAT CAN HAPPEN
♦ Fluid accidentally injected into the skin must be

surgically removed within a few hours by a doctor
familiar with this form of injury or gangrene ma y result .

HOW TO AVOID THE HAZARD
♦ Make sure all hydraulic fluid hoses and lines are in

good condition an all hydraulic connections and fittings
are tight before applying pressure to hydraulic system.

♦ Keep body and hands away from pinhole leaks or

nozzles that eject high pressure hydraulic fluid.

♦ Use cardboard or paper, not your hands, to f ind

hydraulic leaks.

♦ Safely relieve all pressure in the hydraulic system, by

placing the motion control levers in neutral and
shutting off t he engine, before perfor m ing any work on
the hydraulic system.

- 7 -

1.6 SAFETY SIGNS

1.6.1 Keep all saf et y sig ns legible. Remove all grease, dirt and debris from safety
signs and instructional labels.

1.6.2 Saf et y sig ns m ust be replaced if they are missing or illegible.

1.6.3 When new components are installed, be sure that cur r ent safety signs are
affixed to the replaced components.

1.6.4 New safety signs m ay be obtained from Exmark Mfg. Co. I nc.

1.6.5 Saf et y signs may be affixed by peeling off the backing to expose the adhesive
surface. Apply only to a clean, dry surface. Smooth to remove any air bubbles.

1.6.6 Familiarize yourself with the following safety signs and inst r uct ion labels. They
are critical to the safe operation of your Exmark commercial mo wer.

LOCATION: Molded in LH Console

PART NO. 79-0360
LOCATION: On Front of Blower

Discharge Chute

PART NO. 1-643401
LOCATION: On Frame, Next to Mercury Switch

or On Mercury Switch

PART NO. 98-4361
LOCATION: - On Top of Pump Mounting Plate

- On PTO Shield

PART NO. 98-5954
LOCATION: - On Gear Box Cover, Under Rubber Cover

- On Top of Deck, Under Gear Box Cover

- On LH Frame, Under PTO Shield

- On RH Lower Frame, behind fuel tank

PART NO. 103-8451
LOCATION: On RH Console

PART NO. 1-523552
LOCATION: On Top of Oil Reservoir

- 8 -

PART NO. 103-8611
LOCATION: On Pump Plate,

Above Relays

WARNING

HOT

SURFACE

PART NO. 65-2690
LOCATION: - On Frame LH side in Front

- On Frame RH side behind

PART NO. 103-8444
LOCATION: On Hopper Door Hinge, Each Side

PART NO. 103-8495
LOCATION: On Top of Mainframe, Under Hopper

PART NO. 1-513747
LOCATION: On Battery Cover

65-2690

of Exhaust Cutout
Exhaust Cutout

PART NO. 103-8812
LOCATION: On RH Console

LOCATION: Molded into front of hopper

PART NO. 103-8416
LOCATION: On Top of Seat Console, Under Seat

- 9 -

PART NO. 103-9724
LOCATION: On PTO Guard

PART NO. 103-8425
LOCATION: - On front console,

- On driveshaft

Under Seat

PART NO. 103-9032
LOCATION: On Back of Seat

PART NO. 103-9034
LOCATION: On Rear of LH Drive

Wheel Fender

2. SPECIFICATIONS

2.1 MODEL NUMBER: NAV20KC, NAV27KC

2.2 ENGINE:

2.2.1 Engine Specifications: See your Engine Owner’s Manual

2.2.2 RPM: Full Speed: 3600 RPM (No Load) Idle: 1500 RPM

2.3 FUEL SYSTEM

2.3.1 Capacity: 7.5 gal (28 L)

2.3.2 Type of Fuel: Regular unleaded g asoline, 87 oct ane or higher

2.3.3 Fuel Filter: Kohler units: In-line 15 Micron Kohler P/ N 2405002.

2.3.4 Fuel Shut-Off Valve: 1/4 turn “in-line” valve by fuel filter.

2.4 ELECTRICAL SYSTEM

2.4.1 Charging System: Flywheel Alternator

2.4.2 Charging Capacity: 15 amps

2.4.3 Battery Type: BCI Group U1

2.4.4 Battery Voltage: 12 Volt

2.4.5 Polarity: Negative Ground

- 10 -
