Information provided by EXFO is believed to be accurate and reliable.
However, no responsibility is assumed by EXFO for its use nor for any
infringements of patents or other rights of third parties that may result from
its use. No license is granted by implication or otherwise under any patent
rights of EXFO.
EXFO’s Commerce And Government Entities (CAGE) code under the North
Atlantic Treaty Organization (NATO) is 0L8C3.
The information contained in this publication is subject to change without
notice.
Trademarks
EXFO’s trademarks have been identified as such. However, the presence
or absence of such identification does not affect the legal status of any
trademark.
Units of Measurement
Units of measurement in this publication conform to SI standards and
practices.
January 31, 2012
Version number: 7.0.0
iiRTU-310/310G
Contents
Contents
Certification Information ....................................................................................................... ix
1 Introducing the RTU-310/310G ..................................................................... 1
Features ..................................................................................................................................1
Data Capture Export ...........................................................................................................515
viiiRTU-310/310G
Certification Information
Certification Information
Federal Communications Commission (FCC) and
Industry Canada (IC) Information
Electronic test and measurement equipment is exempt from FCC Part 15
compliance in the United States and from IC ICES 003 compliance in
Canada. However, EXFO Inc. (EXFO) makes reasonable efforts to ensure
compliance to the applicable standards.
The limits set by these standards are designed to provide reasonable
protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
with the user guide, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
Ethernet Test Moduleix
Certification Information
European Union (CE) Information
Electronic test and measurement equipment is subject to the EMC
Directive in the European Union. The EN61326 standard prescribes both
emission and immunity requirements for laboratory, measurement, and
control equipment. For devices within the scope of information technology
equipment (ITE) and complying with applicable ITE EMC standards,
EN55022 and EN55024 can also be used for declaring conformance. This
unit has been tested and found to comply with the limits for a Class A
digital device. Please refer to the CE Declaration of Conformity on page xi.
Note: If the equipment described herein bears the CE symbol, the said equipment
complies with the applicable European Union Directive and Standards
mentioned in the Declaration of Conformity.
Laser
This product complies with 21 CFR 1040.10 and with EN 60825-1.
This product may employ a Class 1 or Class 1M laser SFP/XFP per IEC
60825-1. The laser classification is reproduced on the SFP/XFP.
xRTU-310/310G
CE Declaration of Conformity
Application of Council Directives: 2006/95/EC - The Low Voltage Directive
2004/108/EC - The EMC Directive
2006/66/EC - The Battery Directive
93/68/EEC - CE Marking
and their amendments
Manufacturer’s Name: EXFO Inc.
Manufacturer’s Address: 400 Godin Avenue
Quebec, Quebec
Canada, G1M 2K2
Equipment Type/Environment: Test & Measurement / Industrial
Trade Name/Model No.: IP Services Test Head / RTU-310/310G
Standard(s) to which Conformity is Declared:
EN 55022: 2006 + A1: 2007 Information technology equipment - Radio disturbance
characteristics - Limits and methods of measurement
EN 60950-1 :2001 +A11 :2004
First Edition
Information technology equipment
Safety Part 1: General requirements
EN 61326-1 :2006 Electrical Equipment for Measurement, Control and Laboratory Use
EMC Requirements Part 1: General Requirements.
EN 61000 3-2 :2006 Electromagnetic compatibility (EMC)
Part 3-2: Limits - Limits for harmonic current emissions (equipment
input current 16 A per phase)
EN 61000 3-3 :1995 +A1 :2001
+A2 :2005
Electromagnetic compatibility (EMC)
Part 3-3: Limits - Limitation of voltage changes, voltage fluctuations
and flicker in public low-voltage supply systems, for equipment with
rated current 16 A per phase and not subject to conditional
connection
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directives and Standards.
Manufacturer
Signature:
Full Name: Stephen Bull, E. Eng
Position:Vice-President Research and
Development
Address:400 Godin Avenue, Quebec (Quebec),
Canada, G1M 2K2
Date:May 29, 2009
DECLARATION OF CONFORMITY
Certification Information
Ethernet Test Modulexi
1Introducing the RTU-310/310G
The RTU-310/310G is a powerful 24/7 network testing solution for IPTV and
Ethernet services.
Features
High-performance probe hardware supporting hundreds of
simultaneous services
Real-time measurement of over 35 IPTV metrics
Detailed Ethernet statistics and error reporting
Alarm reporting
Complete EtherSAM™ (ITU-T Y.1564) test suite. EtherSAM is the new
standard for testing Ethernet mobile backhaul and commercial
services
Throughput, back-to-back, latency and frame loss measurements as
per RFC 2544 (bidirectional results)
EtherBERT™ test functionality for assessing the integrity of Ethernet
services running on WDM networks
Multistream generation and analysis, allowing quality of service (QoS)
verification through VLAN and TOS/DSCP prioritization testing
True wire-speed, stateful TCP throughput test for undisputable SLA
Interoperable with the FTB-8510B Packet Blazer Ethernet Test Module,
FTB-8510G, and the AXS-200/850 Ethernet Test Set
Full remote control capability through the EX-Vu software and VNC
service
Ethernet Test Module1
Introducing the RTU-310/310G
Feature s
Boot using USB drive
RTU health diagnostics
Remote restart
NTP server support with daylight saving option
Fully compliant with IEEE 802.3ae standard
Pluggable XFP base optical module
Capability to perform full-line-rate data capture and decode
Capability to scan incoming live traffic and auto-discover all
VLANID/Priority and MPLS ID/COS flows
2RTU-310/310G
Introducing the RTU-310/310G
Models
The RTU-310 is equipped with two electrical 10/1000/1000 Mbps Ethernet
port and two optical 100/1000 Mbps Ethernet port. The RTU-310G is
equipped with one optical 10 Gbps Ethernet port. The RTU-310/310G unit is
available either with AC or DC power connector.
RTU-310
AC version
DC version
Models
Note: The 100 Mbps optical interface is available through a software option. Refer
to Software Options on page 347 for more information.
Note: A LAN transceiver is required for the 100/1000 Mbps optical port. See Optical
Transceivers (SFP) on page 5 for more information.
Ethernet Test Module3
Introducing the RTU-310/310G
Models
RTU-310G
AC version
DC version
4RTU-310/310G
Introducing the RTU-310/310G
Option
OptionDescription
RTU-8580Software key that enables the 1000 Mbps electrical
and optical interfaces on the RTU-310 model.
100M OpticalSoftware key that enables the 100 Mbps optical
FTB-85910100Base-FX (1310 nm, MMF, 2 Km) LC connectors
optical SFP transceiver module.
FTB-85911100Base-LX10 (1310 nm, SMF, 15 Km) LC connectors
optical SFP transceiver module.
Ethernet Test Module5
Introducing the RTU-310/310G
Optical Transceivers (XFP)
Optical Transceivers (XFP)
OptionDescription
FTB-85900850 nm short-wave optics (10GBASE-SR/SW)
FTB-859011310 nm long-wave optics (10GBASE-LR/LW)
FTB-859021550 nm long-wave optics (10GBASE-ER/EW)
6RTU-310/310G
Introducing the RTU-310/310G
Conventions
Conventions
Before using the product described in this manual, you should understand
the following conventions:
WARNING
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury. Do not proceed unless you
understand and meet the required conditions.
CAUTION
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury. Do not proceed unless you
understand and meet the required conditions.
CAUTION
Indicates a potentially hazardous situation which, if not avoided,
may result in component damage. Do not proceed unless you
understand and meet the required conditions.
IMPORTANT
Refers to information about this product you should not overlook.
Ethernet Test Module7
2Safety Information
Laser Safety Warnings
WARNING
Do not install or terminate fibres while a laser source is active.
Never look directly into a live fibre, and ensure that your eyes are
protected at all times.
WARNING
Use of optical instruments with this product will increase eye
hazard.
WARNING
This product may employ a Class 1 or Class 1M SFP/XFP.
WARNING
When the LASER LED is on, the RTU-310/310G is receiving/emitting
an optical signal.
Ethernet Test Module9
Safety Information
Installation Instruction Warnings
Installation Instruction Warnings
No user serviceable parts are contained inside. Contact the
manufacturer regarding service of this equipment.
Keep all ventilation openings clear and unobstructed.
All wiring and installation must be in accordance with local building
and electrical codes acceptable to the authorities in the countries
where the equipment is installed and used.
CAUTION
CAUTION
IMPORTANT
CAUTION
Electrostatic Discharge (ESD) Sensitive Equipment: Electronic
equipment can be damaged by static electrical discharge. To
minimize the risk of damage, dissipate static electricity by touching
a grounded unpainted metal object before handling (or
removing/inserting) an SFP/XFP.
CAUTION
All telecom (electrical) interfaces are SELV (Safety Extra Low
Voltage) circuitry for intra-building use only.
10RTU-310/310G
Safety Information
Installation Instruction Warnings
IMPORTANT
Unauthorized modifications to this equipment shall void the user’s
authority to operate this equipment.
CAUTION
For DC version:
The RTU-310/310G must be installed in Restricted Access Locations.
Ethernet Test Module11
3Getting Started
4 USB ports
Optical 100/1000 Mbps
AC Power Plug
10/100 Mbps Ethernet CRAFT Port
10/100 Mbps Ethernet LAN Port
Electrical 10/100/1000 Mbps
LEDs
SHUT DOWN/RESTART button
VGA port
Console Port
(future use)
4 USB ports
Optical 10 Gbps
AC Power Plug
10/100 Mbps Ethernet CRAFT Port
10/100 Mbps Ethernet LAN Port
LEDs
SHUT DOWN/RESTART button
Console Port
(future use)
VGA port
REF OUT
EXT. CLK
This chapter covers the description of the RTU-310/310G unit, the physical
installation, all connections, LEDs, and the initial setup of the
RTU-310/310G.
Front Panel Description
The following figure indicates the location of all connectors, ports, and
LEDs available on the front panel of the RTU-310/310G unit.
For RTU-310 AC version
For RTU-310G AC version
Ethernet Test Module13
Getting Started
SHUT DOWN / RESTART Button
SHUT DOWN / RESTART Button
The SHUT DOWN/RESTART button is used to either shut down or restart
(shut down and restart) the unit.
To shut down the RTU-310/310G unit:
Press the SHUT DOWN / RESTART button once. The RTU-310/310G unit
closes all applications and once done, the POWER/STANDBY LED will
flash to indicate that it is safe to disconnect the AC or DC power.
To wake up the RTU-310/310G unit:
Press the SHUT DOWN / RESTART button once while in standby mode.
The RTU-310/310G unit will restart. An LED sequence is displayed on
the RTU-310/310G front panel indicating the booting process. Once
powered up, the POWER/STANDBY LED turns on indicating that the
RTU-310/310G is ready to be used.
To reset the RTU-310/310G unit:
Press the SHUT DOWN / RESTART button for 5 seconds. The
RTU-310/310G unit will shut down without closing applications. Press
the SHUT DOWN / RESTART once again, an LED sequence is displayed
on the RTU-310/310G front panel indicating the booting process. Once
powered up, the POWER/STANDBY LED turns on indicating that the
RTU-310/310G is ready to be used.
14RTU-310/310G
Getting Started
RTU-310/310G LEDs
RTU-310/310G LEDs
LEDStatusDescription
POWER/STANDBY OnIndicates that the RTU-310/310G unit is on
and ready to be used.
Flashing Indicates that the RTU-310/310G unit is in
standby mode. It is safe to turn the unit off.
CRITICAL
MAJOR
MINOR
a.Alarm severity is configurable for certain alarms.
a
a
a
OnIndicates current critical severity alarm.
OffIndicates no critical severity alarm.
OnIndicates current major severity alarm.
OffIndicates no major severity alarm.
OnIndicates current minor severity alarm.
OffIndicates no minor severity alarm.
VGA Port
The VGA port is used to connect a monitor to access the EX-Vu application
on the RTU-310/310G platform.
Console Port
The Console port is provided for future use.
USB Ports
The RTU-310/310G provides four USB ports. These ports are used to
connect keyboard, mouse, or to boot from a USB drive.
Ethernet Test Module15
Getting Started
Installing the RTU-310/310G in a Rack
Installing the RTU-310/310G in a Rack
To install the RTU-310/310G in a rack:
1. Fix the supplied brackets on the RTU-310/310G with the supplied
8-32 x 5/16 in. screws.
Bracket kits are available for 19 and 23 inch rack mount applications
but only one kit is supplied with the unit.
Note: The brackets allow the RTU-310/310G to be installed with its front panel
flush or offset with the front of the rack.
16RTU-310/310G
Getting Started
Installing the RTU-310/310G in a Rack
2. Place the unit in the rack at the desired height.
3. Fix the unit in place using four 10-32 x 1/2 in. screws and lock washers.
Ethernet Test Module17
Getting Started
AC Power Plug
AC Power Plug
Connecting the Power
Connecting the Power
The RTU-310/310G is available with either an AC or DC integrated power
supply.
Note: The RTU-310/310G automatically powers up once connected to a live AC or
DC power source.
To connect the RTU-310/310G to an AC power source:
1. Connect the supplied AC power cord to the RTU-310/310G front panel.
2. Connect the other end to an AC power source.
For RTU-310
For RTU-310G
18RTU-310/310G
Loading...
+ 517 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
