XP SERIES POWER INVERTERS
Made in America, EXELTECH XP SERIES INVERTERS are the most
XP 125
XP 250
affordable, reliable, lightweight and best regulated, true sine wave inverters available. The XP SERIES inverter will operate any AC load anywhere. Ultra lightweight, yet rugged enough for the most extreme mobile enviroments, the XP SERIES is available in 100Vac, 120Vac, or 230Vac in 50Hz, 60Hz or 400Hz for land, marine or military applications, worldwide.
XP 600
XP 1100
XP 2000
2000
XP SERIES PART NUMBERING SYSTEM
EXELTECH XP SERIES
XP __ - __ - __ - __ - 1 - __ __
MODEL NUMBER
Step 1: Model number always starts
with XP.
Step 2: To designate wattage enter the single character code
1 for 125, 2 for 250, 6 for 600, K for 1100, X for 2000
Step 3: To designate output voltage enter the single character
code from the Vac chart
Step 4: To designate input voltage enter the single character code from the Vdc chart
Step 5: Output frequency is designated by using the first number of the frequency
5 for 50Hz, 6 for 60Hz and 4 for 400 Hz
Vac OUTPUT VOLTAGE CHART
AC Volts 100 120
Designation
*Not available in 125watt models
DC Volts 12 24 32
Designation 1 2 B
0
Vdc INPUT VOLTAGE CHART
230*
1
3
48 66 108
4 E
I
Step 6: This designates revision level (For EXELTECH use only). Step 7: To designate option, enter the code from the option chart below. If no option is required please leave it blank.
OPTION CHART
CodeOption
Conformal coating Low idle current drain Circuit board with heat sink only 50MS transfer relay
* available thru a distributor only(only on XP1100W) **available for OEM’s only ***available on XP600 and XP1100 only
07 02*
04** 20***
EXAMPLE: XP600 with
117Vac output, 12Vdc input, 60Hz with the conformal coating option would require the following model number:
XP6-1-1-6-1-07
XP SERIES POWER INVERTER SPECIFICATIONS
OUTPUT POWER
CONTINUOUS
POWER
125W 125W 250W** 250W** 250W** 600W** 600W**
600W** 1100W** 1100W** 1100W**
2000W 2000W 2000W
*10W with X2 option , **remote switchable
SURGE
POWER
150W 150W 300W 6W 300W 300W
1100W 117 +/-6% 5.1 6.5 1100W 230 +/-6% 2.7 6.5 2200W 2200W 2200W
4000W 4000W 4000W
NO LOAD
POWER
5W 5W
6W 7W 8W 8W
9W 20W* 100 +/-6% 20W* 20W*
12W 12W 12W
OUTPUT
VOLTAGE
100 +/-6% 117 +/-6% 2 100 +/-6% 117 +/-6% 230 +/-6% 100 +/-6% 6.0
117 +/-6% 230 +/-6% 10
100 +/-2% 120 +/-2%
230 +/-2%
OUTPUT
CURRENT
1.2
1.1
2.5
2.1
1.1
11.0
9.5
4.8
20.0
16.7
8.7
INPUT POWER
MODEL
VOLTAGE
**12V
24V 32V 48V 66V
108V
*Indicates typical cut-off voltage/warning buzzer voltage
1
+/- 3%
MINIMUM
(TYPICAL)
10.4/10.6* 13.8V 16.5V 85% 87%
26.5/28V* 36.8V 44V 88% 90%
41.5/42.5V 55.2V 62V 87% 89%
57.5/58.5V* 75.9V 91V 88% 90%
** Output Power derated for XPX
1 1
SYSTEM
(TYPICAL)
19/21V* 27.6V 33V 87% 89%
94/95V* 125V 149V 87% 90%
MAXIMUM (TYPICAL)
TYPICAL
EFFICIENCY
@ FULL POWER
EFFICIENCY
GENERAL
CONDITIONS
WAVEFORM VOLTAGE OUTPUT LINE REGULATION
LOAD REGULATION
DISTORTION
FREQUENCY
See www.exeltech.com for more data regarding XP Series inverters.
MINIMUM
-
-5%
-
-
-
-0.1%
TYPICAL
SINUSOIDAL
NOMINAL
0.1%
0.5%
1.5%
NOMINAL
WEIGHT
LBS.
2
5 5 5
6.51100W
10 10
15 15 15
PEAK @ 1/3
POWER
MAXIMUM
-
+5%
0.5% 1% 2%
+0.1%
MECHANICAL
Case size (HxWxD) 125W case size= 2.16" X 4.93" X 7.90"
(2 lbs) 250W case size= 2.77" X 5.23" X 12.03" (5 lbs) 600W case size= 3.57" X 7.69" X 12.10" (6.5 lbs) 1100W case size= 3.57" X 7.69" X 15.05" (10 lbs) 2000W case size= 4” X 9” X 18” (15 lbs)
OPTIONS
XP Options:
- conformal coating (07 option)
- low idle current drain (02 option)*
- circuit board with heat sink only (04 option) many other options available for OEM applications, consult factory.
*1100 watt only
PROTECTION CIRCUITRY
*Over Voltage: Shut off at maximum input voltage, per input conditions. Automatic reset upon fault correction.
*Under Voltage: Shut off at minimum input voltage, per input conditions
*Thermal: 105 C internal temperature. Warning buzz 5 C before shut off
Output Short: Unit shuts off (manual reset)
*Automatically reset
ENVIRONMENTAL
Temperature: -25 to 30 C full power derated 20% per 10 C, above 30 C. Humidity: 5 to 95% non condensing
Altitude: -200 to 10k feet full power, derated above 10k
Audible Noise: Less than 45dbA Cooling: 600W/1100W Thermo-
statically controlled forced air. 125W/250W convection cooled.
Finish: Painted aluminum Warranty: Full year parts labor
COMPANY PROFILE
931- * * * C0- 00P
EXELTECH was founded in 1990, based on the philosophy that efficiencies in the manufacturing process through product design, coordinated with facility layout, was paramount to productivity and the key to a quality product. Our mission is to provide leadership electronics and superior customer service through the merging of innovative designs with advanced Manufacturing technology.
Quality through design for manufactureability is a primary goal. Utilizing surface mount technology, all design and manufacturing is performed in our facility, located in FORT WORTH, TEXAS. "Pick and place" machines are set up with parts that are standard to all models, allowing for zero setup time and eliminating errors created when reloading or setting up machines. Only large capacitors and magnetics are placed by hand, in an effort to minimize human error through automation. Hand soldering is eliminated through the use of vapor phase reflow. Point to point wiring is eliminated with extensive use of PCB's to perform interconnectivity functions. The use of extruded aluminum for mechanics has reduced the number of nut/bolt and screw points to one­fourth that of previous products, while increasing heat dissipation efficiency and lending a functional form factor to the product.
While design of the products to comply with automated manufacturing processes continues, our people remain the most important part of the quality equation. All employees go through a six month internship before becoming full-time staff members. All employees are cross trained for multi-task capability. Using a PULL system, each station performs a quality check on the performance of the previous station. Data for first time yield and DPU is recorded and analyzed by each station and test bench in an ongoing effort to yield a zero defect process. Upon final assembly, all products then proceed to A.L.T. for "accelerated life testing" to minimize "infant mortality". Packaging and shipping procedures are constantly evaluated to reduce damage.
.
.
.
All repairs are performed at the factory for quality feedback and input for future design. The net result of these philosophies is a line of products that demonstrates an MTBF(mean time between failure) in excess of 20 years and offers the most competitively priced true sine wave inverters available anywhere.
.
Our commitment to quality and total customer satisfaction has allowed EXELTECH to become innovators in the DC to AC power product market. A few of our "firsts" include; The smallest, lightest high frequency PWM sine wave inverter. The first "N+1" redundant inverter systems, "hot" swapable capability and "modular" design. Our many satisfied customers include AT&T, BROOKHAVEN NATIONAL LABS, DIGITAL EQUIPMENT CORPORATION, MOTOROLA, MCI, GTE GOVERNMENT SYSTEMS and numerous federal and state agencies. We are found quite literally, around the world. We also provide back up power for the communications room in every U.S. Embassy worldwide.
7317 Jack Newell Blvd North Fort Worth, Texas 76118-7100 817.595.4969 817.595.1290 800.886.4683voice- fax- toll free-
.
Document subject to change without notice. 931-***C0-00P March 2008
