EXCURSION PXA 45 Owner's Manual

P PLUG & PLAY UPGRADE SERIESXA

...is all you need

CONGRATULATIONS !

Dealer's Name____________________________

Date of Purchase__________________________

Installaon Shop__________________________

Installaon Date __________________________

CAUTION !

Connous exposure to sound pressure levels in excess of 100dB can cause permanent hearing loss. EXCURSION Products are capable
of producing sound pressure levels well over 170dB. Please observe all local sound ordinances while listening to your EXCURSION System.
EXCU RSION Intl. acceptss no liability for hearing loss, bodily injury, or property damage due to the result of use or missuse of this product.

CONGRATULATIONS !

Dealer's Name____________________________

Date of Purchase__________________________

Installaon Shop__________________________

Installaon Date __________________________

CAUTION !

1

EXCURSION

You now own an EXCURSION PXA Plug & Play Series Amplifier, the product of an
uncompromising design and german engineering philosophy. A product made
from Car Audio fanacs who truely believe in the relentless pursuit of perfecon.

EXCURSION amplifiers are the result of several decades of product improvements,
compeon, innovaon and highest quality parts and control standards in industry.
When properly installed these amplifiers will provide you with many years of
listening pleasure and are the perfect balance between high fidelity, extreme
performance and long-lasng reliabilty.

Should your amplifier ever need a service, Please record your informaon on
the following lines to refer to in the event that you may need it later.

At EXCURSION Intl. we are confident you will have many years of outstanding
enjoyment from your high performance investment. For maximum performance
we recommend that you have your new EXCURSION PXA Amplifier installed by
an exclusive Authorizied EXCURSION Dealer

To learn more about EXCURSION, please visit us on the World Wide Web at

hp://www.excursion.us

2

SPECIFICATIONS

FEATURES

l MINI D OEM PLUG & PLAY UPGRADE DESIGN SIZE
l DOUBLE SIDE PCB AND SMD COMPONENTS
l FULL RANGE CLASS D 2OHM STABLE
l H FRONT & REARPF CROSSOVER
l HIGH/LOW CONVERTING + RCA OUT

Model EXCURSION PXA 45

Output Power

50W RMS x 4

Input Sensitivity

Frequency Response

HPF

Auto Turn ON/OFF

Fuse Protection

Components & PCB

Height

Width

Length

180

110

@ Plug & Play Mode

20 A

SMD parts / double side pcb

D (mm)imension

45

2 Hz 5 Kh (-3dB)0 ~ 0 z

0 30~ 0Hz

0. ~ V5 10

50W RMS x 4

Input Impedance

100 Ohm

S/N Ratio (A)

FRD - Full Range Class D

l AUTO TURN ON/OFF + REM OUT
l UP to 8GA POWER CAP TERMINALS

30 A

Max Current Consumption

Source Voltage 14.4V (10V-16V)

Weight incl. accessoires 1.8 kg

l 1,8M 20 POL PLUG & PLAY HARNESS (opt.)
l HEAVY DUTY STACKABLE HEATSINK

0 30~ 0Hz

VARIABLE REAR

VARIABLE FRONT

75 dB

90 dB

@ 1W (CEA-2006)

@ RATED POWER

Amplifier Type

3

EXCURSION

FRONT PANEL LAYOUT

REAR PANEL LAYOUT

PLUG & PLAY CONNECTION POWER CAP

SPEAKER OUT HIGH LEVEL IN POWER

LOW LEVEL
& REM OUT

- -

50RMS x 4CH HIGH POWER PLUG & PLAY CAR AMP

(OPTIONAL)

1. Level Controls for Input Sensivity (GAIN)

The amplifier can receive High Level Audio Signal Input Range from 0.5V to 10V from the Audio
Source unit. Please adjust the GAIN Level of Front and Rear Channels separately to ensure they
match the Audio Source Output Level.

GAIN control is not to compare with the Volume control of the Audio Source Unit. The Note:
appropriate INPUT Signal Level to the PXA 45 amplifier is the guarantee of perfect audio quality.
A proper guide to adjust GAIN is to turn off the GAINs first step. Next turn up the Volume control
of the Audio Source aprox to 90%. Finally turn up the GAINs to your maximum choice of output
Level without distoraon. Asure mind damage of your Loudspeakers and your listening abilies.

Cauon: Excessive output Level can damage Loudspeaker and result in distorted sound.

4

2. High Pass Filter (HPF)

This knob controls the input frequency range for amplificaon. Therefor you can cut out the boom
Frequency with a range from 0Hz to 300Hz ahead of amplificaon for a limited Output Signal.

Note: The boom frequency range ever effect into most stress to the amplifier and loudspeaker.
Cung boom frequencies ahead amplificaon increase the energec balance and longlife of your
Equipment while the Distoraon of Sound get decreased and higher output Levels are possible.

EXCURSION SMART OEM Upgrade Concept recommend PXA 45 Amplifier with PXA B8
acve underseat Subwoofer for a perfect audio quality even of the boom frequency range.

3. Subwoofer RCA PRE Output and REM Output Signal

Via the included interface the EXCURSION PXA 45 provide a PRE Low Level Signal for the PXA B8
underseat Subwoofer or EXURSION SXA or H XA MONO Amplifiers as well other Power Amplifiers.
At same me it can provide a 12V REM TURN ON/OFF Signal for proper funcon of all Amplifiers.

Note: The most common way of installaon within our recommondaon will be, via the 1,8m
20 Pole ISO Harness, at the front underseat locaon of car. Therefor, for this short distance, is
only a RCA Male Adapter demanded to the EXCURSION PXA B8 underseat Subwoofer.

4. ALARM (Protecon Indicator)

The ALARM LED indicator will light up and flash if there is fault presented to the amplifier,
like short circuit, overheat or under voltage protecon and the amplifier will stop working.

5. POWER (Working Indicator)

The amplifier will go into normal working status aer complet self-check and light up LED indicator.

6. Connecon of EXCURSION PXA with the Car Audio Source (Picture see Page 5)
(Please use our professional EXCURSION 20 Pole Plug & Play Harness, which is oponal)

Male Connector will be plugged into the car Harness, which has been disconnected ahead.1.
Female Connector will be plugged into the Audio Source unit. 2.
20 Pole Connector will be plugged into the EXCURSION PXA 45 Amplifier3.

7. POWER CAP (acity)

Within EXCURSION SMART OEM Upgrade Concept we focus to the basic handicap of all kind of
Plug & Play installaon = limitaon of the Power and Ground cable wiring. Too small diameter
of the Power Cable effect into losses of voltage at higher consumpon demands. Less Voltage
effect direct into losses of Power and Sound Quality with much higher Distoraon of the Signal.
Especially in challenge with all kind of music material every amplifier need stable power supply
to perform at its best fine and rough dynamic according the origin recording without distoraon.

In order to perform at its best quality we recommend to hook up at all kind of Plug & Play installs
an extra Power Capacity. This local Energy Storage provide quick impulsiv discharge power supply
while connous stable recharging of the Capacity Storage via the Plug & Play harness is possible.
The Power Capacity Storage follow in size the total consumpon. Sure increase in case further
PXA B8 underseat subwoofer or Power Amplifiers get distribut connected via the CAP Terminal.

Note: Oponal Power Capacies are recommend in short distance with 12Volt Caps & AGM Baeries.

5

EXCURSION

Installaon:

A. Please prepare sufficiently to layout car space before installaon

B. The temperature of heatsink surface will reach up to 80°C with connuously
working status. Do make sure that there is enough space between amplifier
and other thermo sensive components in the car, like plasc and electronic parts.

C. Please take care insulated cables to avoid damages when cables pass trough
metal, rubber and plasc. Do not pull the cable too ght during installaon.

D. Avoid perforaons on gas tank, Fuel or hydraulic lines, as well electrical wiring ect.

E. Please use the fuses as required to avoid the damage of the amplifier.

Trouble Shoong

(RCA & REM OUT INTERFACE)

incl. for opt. PXA B8 or HXA MONO Amp

(opt. PXA ISO HARNESS)

EXCURSION LIMITED WARRANTY POLICY

EXCURSION Intl. offers limited warranty on EXCURSION products under normal use on the following terms:

.EXCURSION Amplifiers are to be free of defects in material and workmanship for a period of one year

This warranty applies only to EXCURSION products sold to consumers by Authorizied EXCURSION Dealers
in Germany. Products purchased by consumers from an EXCURSION dealer in another country are covered
only by that country´s Distributor and not by EXCURSION Intl.

This warranty covers only the original purchaser of EXCURSION product. In order to receive service, the
purchaser must provide EXCURSION with the receipt stang the consumer name, dealer, product and date
of purchase.

Products found to be defecve during the warranty period will be repaired or replaced (with a product
deemed to be equivalent) at Excursion`s discreon and will not be liable for incidental or consequenal
damages. EXCURSION will not warranty this product under the following situaons:

* Amplifiers received with apparent rust or corrosion
* Any evidence of liquid damage or exposure to excessive heat
* Aempted repairs or alteraons of any nature
* Product that has not been installed according to this owner manual

Any implied warranes including warranes of fitness for use and merchantability are limited in duraon
to the period of the express warranty set forth above. No person is authorizied to assume for E XCURSION
any other liability in connecon with the sale of this product.

Please call prior your authorizied EXCURSION dealer the product got purchased. In case they
are not accessible call 0961-416-0420 for EXCURSION Customer Service. You must obtain an RA#
(Return Authorizaon Number) to return any product to EXCURSION Intl. The RA number must
be prominently marked on the outside of the shipping carton or the delivery will be refused.
Please pack your return carefully! We are not responsibile for items damaged in shipping.
Return the defecve product along with a copy of the original dated retail sales receipt, plus 10,- EUR
for handling and diagnosc evaluaon to:

EXCURSION Intl. - A Division of CHPW

An: Returns (RA# ........................ )

Neustaedter Str. 20
D-92685 Floss / Germany
