Page 1
CV-LD 102
Vehicle Vacuum Cleaner
Read this operation instruction manual carefully before usage
and keep it for future reference
Page 2
Production Specifications
Type
Vehicle vacuum
cleaner
Model
CV-LD102
Voltage
DC 12V
Power
75W
Range of
operation
4m
Noise
≤75dB
Size
405*125*125mm
Weight
1.1KG
Product Feature
1. With standard water filter, wet and dry use.
2. Powerful motor and stronger suction.
3. Ultra silent design,more comfortable to use.
4. With useful attachments such as crevice tool,long
soft hose ans brush.
5. With fuse for 10 A current to protect car power.
6. Four meters power cord,allowed to extend to every
corner of the car.
7. Ergonomic design for fingers,easy to hold.
8. Nano waterproof technology to effectively solve
the clogging of the filter mesh.
Page 3
Product construction
Page 4
Circuit
1. Pick up the unit from the package.
2. Red light of the adapter is on when insert the
3. Press the switch , the vacuum cleaner is working
4. Handle the vacuum cleaner , with inlet aim at dust
5. After using , press the switch then turn off the
Using Instruction
adapter into the 12V cigar-lighter.
when the green lighter is on.
and dirt , start to clean.
vacuum cleaner.
Page 5
Usage and introduction
Cleaning
1. If the vacuum cleaner is working, press the switch
to close it.
2. Press the dust cup and take off it, hold the dust cup
and take out the filter component.
3. Hold the front of dust cup and pout the rubbish
inside the dust cup to the dustbin.And wash the filter
component.
4. After drying out the filter net,rotate clock wisely
into the dust cup,and buckle the dust cup into the
body to use it again.
5. All the accessories are washable.
Maintaining
1. Maintenance can be done when it is power off and
the switch is off.
2. Clean the dust inside the dust cup frequently in
case of malfunction.
3. Don’t use gasoline or other corrosive matter to
scrub the surface of unit.
Page 6
Cautious
1. Please keep the power cord intact without any
cut,damaged. Excessively pulled,twisted,knotted,bent or
close to some heating parts. Otherwise,the damaged
power cord will cause short circuit.
2. When power cord,plug and socket loosed,please do
not use it,otherwise,it will cause electric shock and short
circuit.
3. Do not remove it if you are not familiar with this.
4. Please don’t absorb the below things to avoid
damages:
a.Burning things such as cigarette butt.
b.Harmful things such as solvent etc.
c.Sharp parts such as glass.
Page 7
Trouble Shooting
Problem
Cause
Solution
Do not work
after press
on the
power switch
Cigarette lighter do
not connect
correctly
Connect the cigarette
lighter and car power
supply correctly
Car power supply
do not have enough
power
Check the car power
supply
Fuse was burn-out
Please contact customer
service center
Can’t absorb
dust
Too many dust on
the water-strainer
and filter
Clean the water-strainer
and filter in time
