Excel G-Evolution User Manual

User manual
Excel G-Evolution
User manual | Excel G-Evolution
Content
2. General information 7
2.1 Components and structure of your wheelchair 7
2.2 General explanation of your wheelchair 7
3. Safety regulations 8
3.1 General safety regulations 8
3.2 Warnings for safe use 8
4. User instructions 10
4.1 Balance 10
4.1.1 Getting in and out of the wheelchair 10
4.2 Bending and/or reaching 10
4.2.1 Bending and/or reaching forwards 10
4.2.2 Bending and/or reaching to the side 11
4.2.3 Bending and/or reaching backwards 11
4.3 Going in and o increases 11
4.3.1 Going on an increase 11
4.3.2 Going o an increase 12
4.4 Going on and o inclines 12
4.4.1 Going on an incline 12
4.4.2 Going o an incline 13
4.5 Going on and of stairs 13
4.5.1 Going on a stair 13
4.5.2 Going o a stair 14
5. Specications 15
6. Components of the Excel G-Basic 16
6.1 Fold and unfold the wheelchair 16
6.1.1 Folding the wheelchair 16
6.1.2 Unfolding the wheelchair 17
6.2 The push handles 17
6.3 The armrests 18
6.4 The backrest 19
6.5 The brake 19
2
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
6.6 The legrests 20
6.7 The footplates 21
6.7.1 Folding the footplates upwards 21
6.7.2 Adjust the height of the footplates 21
6.8 The frame 21
6.9 The stepper 22
6.10 The wheels 22
6.10.1 The front wheels 22
6.10.2 The rear wheels 22
6.11 The seat 23
7. Transport of the wheelchair 24
7.1 Folding the wheelchair 24
7.2 Unfolding the wheelchair 25
8. Maintenance 26
8.1 Tires 26
8.1.1 Air tires 26
8.1.2 PU tires 26
8.2 Brakes 26
8.3 Cross brace 27
8.4 Rear wheels 27
8.5 Castors and the front fork 27
8.6 Upholstery 28
8.7 Cleaning of the wheelchair 28
8.8 Periodical maintenance to your wheelchair 28
8.9 Service checklist 29
9. Problem analysis and solutions 30
10. Warrantie 31
10.1 Warranty application 31
10.2 Warranty conditions 31
3
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
General introduction
Before you are going to use your new Excel G-Evolution, you and your attendant must fully read and understand this user manual. Also, if you have this user manual, you agree to the conditions mentiond in this user manual.
At the moment we introduce you a quality product of Van Os Medical. We want to thank you for the condence in
our Excel ® products. The Excel G-Evolution is a real quality product. The policy of Van Os Medical is focussed on to continuously improving the quality and reliability of our products. Therefore, we resere ourself the right to, without further notice, make any changed to this user manual
It is important you read this user manual very carefully, before you are going to use your wheelchair. This user manual contains important information about the safe use and maintenance of your wheelchair. We recommend you to keep this user manual, because it is also your proof of warranty.
The safety instructions in this user manual are general guidlines which must be seen as overall guidlines. It is possible you develop your own ways for many common movements. However, we advise you to consult a
professional for assistance in developing safe use and eective techniques, regarding to your daily activities and
your physical capabilities.
Your new wheelchair requires frequent maintenance, much of which you can do yourself. We advise you to take
your wheelchair at least once a year to a professional for a check. You will nd a maintenance schedule later in this
user manual.
Attention!
In this user manual you will nd tips and warnings. These are clearly identied by the symbols and display of the
text, like you can see below.
Tip
The tips mentioned in this user manual are meant to make even better use of your Excel G-Evolution wheelchair.
Warning
The warnings mentioned in this user manual must always be followed, in order to prevent damage to the Excel G-Evolution wheelchair or injury to yourself.
4
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
Fill in the information of your authorised dealer below:
Company: ……………………………………………………………………………………………………………………………………
Address: ……………………………………………………………………………………………………………………………………
Phone number: ……………………………………………………………………………………………………………………………………
Fax number: ……………………………………………………………………………………………………………………………………
E-mail address: ……………………………………………………………………………………………………………………………………
Website: ……………………………………………………………………………………………………………………………………
5
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
1. Identication
Your wheelchair is equipped with a unique serial number. You will nd this number on the frame of your wheelchair. Below, you see an example of the framelabel, where you can nd the identication number. Furthermore, you will nd the explanation of the various data stored on the framelabel listed below.
2
3
5
6
4
1
7
1. Production date
The date which on your wheelchair was manufractured.
2. Serial number
Every wheelchair has its own unique serial number. You need this number when you have any technical questions or you want to order any parts of the wheelchair.
3. Maximum weight
The maximun weight allowed on the wheelchair.
4. Type number
This number indicates which model of wheelchair you have. You need this number when you have any technical questions or you want to order any parts of the wheelchair.
5. Model name
The model name of your wheelchair starts with the brand name Excel. The brand name Excel, followed by the de additional model description forms the model name of the wheelchair. You need the model name when you have any technical questions or you want to order any parts of the wheelchair, in this case the Excel G-Evolution.
6. Description
The intended use of your wheelchair is described here.
7. Warranty
Here, the warranty period of your wheelchair is reected. Chapter 10 describes the warranty conditions in further
detail.
6
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
2. General information
2.1. Components and structure of your wheelchair
1
1. Ergonomic push handles
2. Height adjustment of the push handles
3. Backrest
4. Armrests
5. 24” rear wheels
6. Seat
7. Legrests
8. Brake
9. Steppers
10. Footplates
11. 7” front wheels
2
3
5
4
6
8
7
9
10
11
Your wheelchair is equipped with a number of components and parts. You should know these before continue
reading this user manual. The design and specications may change without further notice.
2.2 General explanation of your wheelchair
Your new Excel G-Evolution wheelchair is a lightweight wheelchair. The wheelchair is equipped with ergonomic handles, so your attendant can push the wheelchair easily. Besides, the push handles are height adjustable. Also, the armrests of the wheelchair can be folded away backwards. The legrests of the Excel G-Evolution can be swung away to the side and are also removable. To fold the wheelchair, the footplates are foldable upwards. In addition, the footplates are adjustable in height. This can only be done with the an allen key. Finally, the wheelchair is equipped with 7“ front wheels and 24” rear wheels. The 24“ rear wheels are removable using the quick-release
system. This means you can simply take o the rear wheels in order to transport the wheelchair easier.
7
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
3. Safety regulations
Van Os Medical B.V. specically disclaims responsibility for any body injuries or property damage, which may occur
during any use when the recommendations and warnings discribed in this user manual are not followed. The Excel G-Evolution is, if the wheelchair is used correctly, a very safe and stable product. However, it is possible if you use wheelchair not correctly, dangerous situations may occur.
3.1 General safety regulations
Protect your wheelchair by checking it regularly. When a part of your Excel G-Evolution doesn’t function correctly, a dangerous situation could occur. Therefore, you must keep your wheelchair in perfect condition, to ensure safety in use. Periodical inspection, a correct adjustment and in time replacement of broken or worn parts will result in use
for years without any problems. A qualied Excel dealer, who will only use Excel replacement parts, will take care of
your wheelchair and make sure you can use your wheelchair for years without problems.
3.2. Warnings for safe use
To prevent any damage to your property, the wheelchair or the user of the wheelchair, you must observe the following warnings. Van Os Medical B.V. is not responsible for any damage, provided that the warnings be respected. After reading the warnings, you agree with the regulations, mentioned in this user manual.
When you get your wheelchair, always check if all components of the wheelchair are present and if there are any damages. If components are missing or there are any damages, you must immediatly contact your supplier;
Do not use your wheelchair on streets or roads, only on the pavements;
Do not use your wheelchair in sand, rough area, wet and glade surfaces or surfaces with little grip;
Do not lean concerning the back of the wheelchair. This can result in rolling over the wheelchair;
Do not try to ascend ramps without installed anti tippers, never ascend a hill without anti tippers;
Never go on or o an increase without help of your attendant;
Before leaning or reaching forward, sit back into the wheelchair to prevent falling out of the wheelchair;
Before getting on or o the wheelchair, sit back into the wheelhair and face the castors forward;
Do not stand on the footrest, because this will cause the wheelchair to tip and injure the user;
Place the wheelchair on a stable, at surface before you get on or o the wheelchair;
For suitable protection of potential obstruction the lowest point of the footrests serves minimum 7 cm free of
the ground;
A wheelie (the tilting angle of the wheelchair until it is in balance) is extremely dangerous to the user and will cause serious damage to the wheelchair;
Attach the brakes when you use the wheelchair in a lift or on a wheelchair lift and when you want to get o;
The transport of your wheelchair is in all vehicles, including vehicles which are adapted developed especially
and/or for the transport of your wheelchair, is at your own risk. We accept absolutely no liability for this;
We recommend you, if you want nevertheless to transport your wheelchair, to contact a recognised manufacturer of taxi xations to take with the carrier, your supplier and/or systems to choose an appropriate
system for your wheelchair and situation;
During the transport of the wheelchair, the wheelchair may not be used as a seat in a vehicle;
Never use your wheelchair when something is broken;
Never stand on your wheelchair;
Never connect anything to the wheels, this may cause damage to the chair and also eect the balance of the
chair and may injure the user;
Do not push the wheelchair If you attach the brakes of the wheelchair. This may cause damage at the wheelchair and may occur a dangerous situation;
8
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
The maximum user weight capacity has been indicated on your framelabel. Do not exceed this maximum user weight;
The wheelchair is suitable for one person at the time. Also, do not take anybody on your lap while using the wheelchair;
A sudden change of direction may cause the wheelchair to fall over. You should avoid this by keeping the same direction when you use the wheelchair;
Never independently increase a slope that is steeper than 10°. You should go on an increase or slope that is steeper than 10° with your attendant;
Unauthorized modication and or use of no Van Os Medical parts will void the warranty of this chair and may
lead to injury to the user and damage to the chair.
Warning
The implementation of changes to the Excel G-Basic wheelchair, which are structural changes, is at all times at the expense of the guarantee.
9
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
4. User instructions
It is very important you teach yourself the right and safe user instructions. Therefore, you need to know all the components of the wheelchair, described in this user manual. Always check an expert for support by developing the right and safe methods regarding to your physical possibilities to use your wheelchair.
4.1 Balance
Daily operations such as getting on and o the wheelchair, reaching and bending in wheelchair will cause change
the weight distribution and the centre of gravity of you and your wheelchair. You will need to perform these movements and techniques as shown below.
4.1.1 Getting in and out of the wheelchair
Getting in and out of the wheelchair is a common operation. The diculties of entering and exiting depend on your
physical capabilities. In this user manual, we describe the actions that must be followed when you want to get in or out the wheelchair without help. When you can’t do it no longer independently, we recommend that you comply
with an occupational therapist to discuss your options and determine how you can get the best on and o the
wheelchair.
Get in the wheelchair
Before you get in your wheelchair, you must make sure the wheelchair is on a at surface. Also, the wheelchair must be put on the brakes and the legrests need to ip sidewards. Make sure you are as close as possible to the
wheelchair en put the castors in forward direction. Now you can, leaning on the armrests, make the transfer to the wheelchair.
Get out of the wheelchair
When you want to get out of the wheelchair, you must follow the same instructions for getting in to the wheelchair. Make sure you are as close as possible to the wheelchair en put the castors in forward direction. Also, the
wheelchair must be put on the brakes and the legrests need to ip sidewards. Now you can, leaning on the armrests, make the transfer out o the wheelchair.
4.2 Bending and/or reaching
It may occur you are in your wheelchair and you need te get someting. This can be next to you, but also in front of or behind you. To avoid tilting your wheelchair or your wheelchair falls backwards, below we describe how you can bend and / or reach out the best in your wheelchair.
4.2.1 Bending and/or reaching forwards
If you want to get something that is in front of your wheelchair, please follow the steps below.
Make sure that you are as close as possible to the object;
Make sure the front wheels are turned forward. If not, go forwards and then backwards to turn the wheels
fully to the front;
Make sure the wheelchair is put on the brakes on both sides;
You can now move towards the target with caution to keep the wheelchair from falling.
10
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
4.2.2 Bending and/or reaching to the side
If you want to get something that is next to you or your wheelchair, please follow the steps below.
Make sure you are as close to the object with your wheelchair. Use the rear wheels of the wheelchair as a target;
Make sure the front wheels are turned forward. If not, go forwards and then backwards to turn the wheels fully to the front;
Make sure the wheelchair is put on the brakes on both sides;
You can now move to the side without the risk of losing the balance. Make sure you move along the
wheelchair as close as possible while lifting.
4.2.3 Bending and/or reaching backwards
If you want to get something that is behind you or your wheelchair, please follow the steps below.
Make sure you are as close to the object with your wheelchair. Make use of your rear wheels of the wheelchair. For example, place it against a closet;
Do not put the wheelchair on the brakes. If you lose your balance you better drive backwards then ip
backwards;
You can now bend backwards without having to risk losing the balance. But do not bend too far backwards. Then the wheelchair will tilt as well.
4.3 Going on and of increases
It may happen that you have to go on or o an increase with your wheelchair. In addition, we describe in this user manual rst how to do this independently and then how you can do this with an attendant.
4.3.1 Going on an increase
If you want to go on an increase you have to do it in a forward motion. Make sure your weight is, as far as it is possible, brought forward by bending over. By now making a so-called “wheely” , the casters are lifted at the front. This way you can get over an increase in your wheelchair.
Warning
You should only go on an increase after you discussed with a specialist, such as an occupational therapist, how to do this best.
You can also go on an increase with your supervisor. This can be done in two ways.
1. Your attendant should place the wheelchair in forward motion for going on the increase. By pressing the on
the handles, the casters at the front wheel will go o the ground. Simultaneously, your attendant should put his foot on the so-called stepper. There will now create a leverage eect and so the wheelchair can be driven
on the increase.
2. Your attendant should put the wheelchair in the backward movement for going on the increase. By sitting as far as possible in the wheelchair and slightly tilt the wheelchair backwards, your attendant can pull the chair on the increase. Your attendant should not lower the wheelchair until the casters are on the increase.
11
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
4.3.2 Going o an increase
If you want to go o an increase yourself, you should always do this backwards. When you do this forward, there is a
risk of falling over with your wheelchair. However, you should practice with an occupational therapist before you go
o an increase with your wheelchair yourself.
We advise you to go o an increase with your attendant. Your attendant drives your wheelchair to the edge of the
increase. Now the user has to sit back and attendant has to tilt the wheelchair backwards. When the wheelchair is
balanced your attendant can slowly set the wheelchair o the increase. The wheelchair should only be further used
if the casters touch the ground again.
4.4 Going on and o inclines
Most people can climb a short and not too steep incline itself. This depends on your physical capabilities and the degree of the incline. Most people also develop methods to go on and of an incline. If it is necessary you should
stop during going on or o the incline, do not make sudden movements that can cause you to fall over.
Tip
Make sure the incline is inspected to climb up and down. That way you will know what to expect and you can safely go upwards or downwards.
4.4.1 Going on an incline
When you go on an incline yourself, we advise you to bend your upper body forwards. This allows you to transfer the heaviest point forward and it is easier to get on an incline. We also recommend you to attach the anti-tip to the wheelchair when going up an incline. This will increase the safety during going on an incline. It is also important you don’t care extra weight as bags on your wheelchair. This allows the center of gravity is behind the wheelchair and the chance of tipping increases.
If your attendant push you up, he or she must be aware that sucient strength is required.
Warning
Always be careful when getting on and o an incline. An incline steeper than 5° is already dangerous to go on or o
with your wheelchair.
12
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
4.4.2 Going o an incline
Make sure that the feetrests of the wheelchair is at least seven centimeters from the ground. You will always keep
your face forward as you go o an incline. However, never lean forward when you go o an incline. This may result
in a forward tilt of the wheelchair. In order to increase the stability you can better slightly lean backwards.
To maintain control over your wheelchair, it is important you do not go down to quickly. You can controle the speed by the amount of grip that you apply to the hoops of the wheelchair. In this action the hoops slide through your hands and will cause friction. To avoid burning your hands, we recommend that you wear gloves. Do not use
the wheel brakes during going o the incline. These brakes are only suitable for use when stationary. Avoid also suddenly change of direction during going o an incline. This increases the chance that you fall over.
If your attendant supports you when going o an incline, he or she must be aware that a considerable traction
should be exercised.
4.5 Going on and o stairs
Stairs are one of the largest obstacles for people who use a wheelchair. However, it is possible to, together with two
attendants, go on and o a stairs with your wheelchair. You and your attendants must be aware of the rather heavy
weight which has te be moved.
4.5.1 Going on a stair
When you want to go on a stairs, you need to go up backwards. We advise if you want to climb the stairs with a wheelchair you will do this with the help of a minimum of two attendants. One attendant on the front of the wheelchair and one attendant on the back of wheelchair. The attendant at the back of the wheelchair grabs the push handles and let the wheelchairtip backwards until it in balance. When the wheel is in balance the attendant at the front of the wheelchair needs to grab the side frames. You are now in position to climb the stairs. The attendant
on the front pushes the side frames up until they are above the rst step and the attendant on the back makes the rst step on the stairs. Repeat this technique until the last step of the stair. You can let the front castors down when
the attendant on the front has taken the last step.
Warning
If you go on a stairway with your wheelchair, you should take a maximum of one step at a time. This prevents the risk of falling down the stairs in your wheelchair.
13
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
4.5.2 Going o a stair
To go down a stairs you follow basically the same operations as going on the stairs. One attendant on the front of the wheelchair and one attendant on the back of wheelchair. The attendant at the back of the wheelchair grabs the push handles and let the wheelchairtip backwards until it in balance. When the wheel is in balance the attendant at the front of the wheelchair needs to grab the side frames. You are now in position to climb the stairs.
Now, the attendant on the front lifts the side frames until they are above the rst step and the attendant on the back makes the rst step on the stairs. Repeat this technique until the last step of the stair. You can let the front
castors down when the attendant on the front has taken the last step.
Warning
If your attendant grabs the wheelchair to go on or o a stair, then your attendant should never do this on the
legrests. The legrests are not strong enough for this.
14
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
5. Specications
Below, you will nd the specications of the Excel G-Evolution.
Technical specications of the Excel G-Evolution
Total length 101 cm (incl. footrests) Total width 63 cm Total height 93 101 cm Total weight 15 kg User weight Max. 135 kg Seat width 45 cm Seat depth 42½ cm Seat height 53 cm Backrest height 39 cm
15
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
6. Components of the Excel G-Evolution
In this chapter the dierent components of the Excel G-Evolution are described. On the wheelchair are a number of components present which are adjustable. If you want to add or remove any of its components, make any adjustments of replace components, you should always follow the instructions described in this user manual.
6.1 Fold and unfold the wheelchair
To fold or unfold the wheelchair, there are some steps you should follow. When folding and unfolding the wheelchair you should always be careful so that the wheelchair does not get damaged.
6.1.1 Folding the wheelchair
If you want to fold the wheelchair, please follow the following steps.
Before you can fold the wheelchair, the footrests should be raised. On photo 1 you can see how the footrests are like when the wheelchair is unfolded. By folding the foot rests upwards (photo 2), you can fold the wheelchair. On photo 3 you see the wheelchair when the footrests are folded upwards;
To fold the wheelchair, you need to follow the operation as you can see on photo 4. You pull at the front and at the back of the seat, at the middle of the seat of the wheelchair;
Now you can pull the middle of the seat, on both the front and the back, as shown in photo 5;
After the seat is completely pulled up, the chair looks like shown on photo 6.
EXCEL G-EVOLUTION | PHOTO 1
EXCEL G-EVOLUTION | PHOTO 5
EXCEL G-EVOLUTION | PHOTO 2
EXCEL G-EVOLUTION | PHOTO 6
EXCEL G-EVOLUTION | PHOTO 3 EXCEL G-EVOLUTION | PHOTO 4
16
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
6.1.2 Unfolding the wheelchair
To unfold the wheelchair, please follow the following steps.
To unfold the wheelchair, you rst have to stand next to or in front of the wheelchair;
Now, press on the seat tubes (photo 7) to expand the wheelchair;
To make sure the wheelchair is folded correctly, go stand next to or in front of the wheelchair and push the
seat tube as far as it will go (photo 8);
Now you can put the foot rests down again (photo 9).
EXCEL G-EVOLUTION | PHOTO 7
EXCEL G-EVOLUTION | PHOTO 8 EXCEL G-EVOLUTION | PHOTO 9
Warning
When you are unfolding the wheelchair, you must make sure it is completely unfolded. The proceeding described at photo 8 is very important.
6.2 The push handles
The push handles of your Excel G-Evolution are ergonomically designed (photo 10). This means your attendant has a good grip on the push handles. As a result, pushing the wheelchair by your attendant is not only more comfortable, but the wheelchair can also be pushed safer. In addition, the lever that is visible under the push handle, is intended to adjust the height of the push handles..
EXCEL G-EVOLUTION | PHOTO 10
17
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
6.3 The armrests
The armrests of the Excel G-Evolution are foldable backwards. To fold the armrests, you must follow the following steps.
On photo 11 the wheelchair is shown with the armrests;
To fold the armrests away, you need to push the black lever (photo 12) down, as shown on photo 13;
You can now fold the armrests backwards (photo 14);
The armrests can not be folded further back than shown in photo 15;
To place the armrest back again, push the armrests into the xing point. You are certain the armrests are
mounted well, when you hear a click.
EXCEL G-EVOLUTION | PHOTO 11
EXCEL G-EVOLUTION | PHOTO 15
EXCEL G-EVOLUTION | PHOTO 12 EXCEL G-EVOLUTION | PHOTO 13 EXCEL G-EVOLUTION | PHOTO 14
18
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
6.4 The backrest
The backrest (photo 16) of the Excel G-Evolution is attached to the tubes of the push handles. The backrest is not adjustable and not removable. However, the material is comfortable to sit with your back against it.
EXCEL G-EVOLUTION | PHOTO 16
6.5 The brake
You can put your Excel G-Evolution on the brakes. This is recommended when going in and / or going out of the wheelchair, but also when you left parked, you can put the wheelchair on the brake. If you want to put the brakes on the wheelchair, please follow the following steps.
When sitting in the wheelchair and the wheelchair is not on the brake, you will see the situation as it is at photo 17;
You can use the brake lever to put the wheelchair on the brake. By pushing the lever forward (away from you) (photo 18), the wheelchair is put on the brake (photo 19);
If you are standing next to the wheelchair and you want to put the wheelchair on the brake, you should perform the same actions.
EXCEL G-EVOLUTION | PHOTO 17 EXCEL G-EVOLUTION | PHOTO 18 EXCEL G-EVOLUTION | PHOTO 19
19
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
6.6 The legrests
The legrests of the Excel G-Evolution are both foldable and removable. To swing the legrests away and take them
o, you should follow the steps described below.
The legrests of the wheelchair are shown on photo 20;
By pulling the black lever (photo 21) up (picture 22), the leg supports can come in motion;
In photo 23 you can see the legrests can be turned away;
If you want to take o the leg rests, you can pull up the leg rests. This can be done when the legrests can not
be further folded;
The legrest is released when it is past the elevations which sit on the side of the frame;
To place the legrests you put the legrests over the increases who are on the side of the frame and then turn the legrests in place until you hear a click. This click conrms that the legrests are mounted properly.
EXCEL G-EVOLUTION | PHOTO 20 EXCEL G-EVOLUTION | PHOTO 21 EXCEL G-EVOLUTION | PHOTO 22 EXCEL G-EVOLUTION | PHOTO 23
20
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
6.7 The footplates
At the legrests are also footplates attached. These are both foldable and adjustable in height.
6.7.1 Folding the footplates upwards
You can fold the footplates by following the following steps.
At photo 24 you see how the wheelchair looks like when the footplates are not folded;
You can fold the footrests by pushing the footplates simply upwards, as shown in photo 25;
In photo 26 you can see how the footplates look like when the they are folded.
EXCEL G-EVOLUTION | PHOTO 24 EXCEL G-EVOLUTION | PHOTO 25 EXCEL G-EVOLUTION | PHOTO 26 EXCEL G-EVOLUTION | PHOTO 27
6.7.2 Adjust the height of the footplates
It is also possible to adjust the height of the footplates. As you can see on picture 27, the footplates are adjustable
in ve dierent heights. To adjust the height, you need an allen key.
6.8 The frame
The frame of the Excel G-Evolution is based on the coating principle. This means the frame is extra rm.
Furthermore, the wheelchair is provided with a cross-frame. This also provides additional rigidity to the wheelchair. The cross frame is shown on to photo 28.
EXCEL G-EVOLUTION | PHOTO 28
21
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
6.9 The stepper
The Excel G-Evolution is equipped with two steppers (photo 29). These can be used by the attendant to put extra force when an increase should be undertaken with the wheelchair. However, you should be careful with the steppers when you use them.
EXCEL G-EVOLUTION | PHOTO 29
6.10 The wheels
At your wheelchair there are front and rear wheels mounted. These should be checked regularly for wear.
6.10.1 The front wheels
The front wheels of the wheelchair are 7“ and fastened by means of a front fork to the frame of the wheelchair (photo 30). The front wheels are important when you want to steer the wheelchair in the right direction. When the steering is not going smoothly or the front wheels vibrate, the front wheels are not properly set and / or adjusted.
EXCEL G-EVOLUTION | PHOTO 30 EXCEL G-EVOLUTION | PHOTO 32EXCEL G-EVOLUTION | PHOTO 31 EXCEL G-EVOLUTION | PHOTO 33
6.10.2 The rear wheels
The rear wheels of the wheelchair are 24“ PU tires (photo 31). These tires are less prone to leak. On the rear
wheels are also hoops conrmed. These hoops enables you to propel the wheelchair. In addition, the rear wheel is
equipped with solid spokes. The rear wheels are removable by the quick-release system. This makes them easy to
take o. By pressing the black button (picture 32), you can remove the rear wheel (photo 33).
22
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
6.11 The seat
The seat (photo 34) of the wheelchair is equipped with comfortable material. This allows you to sit comfortably for long periods in the wheelchair. The wheelchair is delivered as standard without a cushion on the seat. A seat cushion is, however, possible to the wheelchair. Check with your dealer if you want a seat cushion.
EXCEL G-EVOLUTION | PHOTO 34
23
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
7 Transport of the wheelchair
Your Excel G-Evolution wheelchair is designed to be easily transported by car. Your wheelchair is foldable so the total width is limited to an average measure of 30-35 cm. Further your wheelchair is equipped with swing away and detachable footrests. Besides, some of the components of the wheelchair reducable. The rear wheels are detachable, based on a quick-release system.
7.1 Folding the wheelchair
To fold the wheelchair, please follow the following operations:
Before you are going to fold the wheelchair, remove the seat cushion if your wheelchair is equipped with one;
Then both legrests should be removed (see section 6.6);
On photo 35 you see the wheelchair with the legrests in the way you can use them. To fold them upwards
(photo 36) you will create the situation shown on photo 37;
To fold the wheelchair you have to stand next to the wheelchair. Get a hold of the seat in the middle of the rear and front of the seat(photo 38) and pull it straight up. To fold the chair completely, pull the seat like shown on photo 40;
To make wheelchair even smaller so that it can be easaly transported, you can take wheels of the wheelchair o.by the Quick-release system (see section 6.10.1). In picture 41 you can see that by meaning of pressing the
black button, you can release the rear wheels of the wheelchair (photo 42).
EXCEL G-EVOLUTION | PHOTO 35
EXCEL G-EVOLUTION | PHOTO 39
EXCEL G-EVOLUTION | PHOTO 36
EXCEL G-EVOLUTION | PHOTO 40
EXCEL G-EVOLUTION | PHOTO 37 EXCEL G-EVOLUTION | PHOTO 38
EXCEL G-EVOLUTION | PHOTO 41 EXCEL G-EVOLUTION | PHOTO 42
24
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
7.2 Unfolding the wheelchair
To unfold the wheelchair, please follow the following operations:
Attach the rear wheels of the wheelchair to frame by the quick-release system. By meaning of pressing the black button (photo 43), you can attach the rear wheels to the wheelchair (photo 44);
Go stand next to the wheelchair and push on the two seat tubes down to fold the wheelchair;
To make sure the wheelchair is folded correctly, push both of the seat tubes as far as possible outside (photo
46). You can also see if the wheelchair is folded correctly, by the upholstery;
You can now place the legrests back on the wheelchair. You can do this by placing the leg supports to the side (photo 47) and then push in the correct position by turning inward. The legrests will then engage himself. This
click you will hear is the conrmation that the legrests are placed on the correct way (see photo 48);
Finally, place the seat cushion if your wheelchair is equipped with one. The wheelchair is now ready for use.
If the wheelchair is folded in your car, you should make sure that the wheelchair remains in place. You can do this
by attaching the wheelchair. This include taxi xation points available on the wheelchair.
EXCEL G-EVOLUTION | PHOTO 43
EXCEL G-EVOLUTION | PHOTO 47
EXCEL G-EVOLUTION | PHOTO 44
EXCEL G-EVOLUTION | PHOTO 48
EXCEL G-EVOLUTION | PHOTO 45 EXCEL G-EVOLUTION | PHOTO 46
25
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
8 Maintenance
Your Excel G-Evolution wheelchair needs periodical maintenance. This is necessary for long and optimum comfort
for the user of the wheelchair. A badly maintained wheelchair will give more technical problems, turn less exible
and it won’t be covered by the warranty. Preventive maintenance is very important. We advise you to check, at least
once a year, your wheelchair by a qualied Van Os Medical dealer. This dealer will, where necessary, using only
Excel replacement parts. These annual inspection will make sure your wheelchair will work perfect for years.
There are a lot of things you can do yourself to keep your wheelchair in optimum condition. If you regularly check the wheelchair and perform (small) maintenance, this will extend the lifetime and increase the ease of use.In the following paragraphs this little maintenance is further described.
8.1 Tires
You need to check the tires of the wheelchair regularly, because the tires will wear out. If the wear is at an advanced stage, then you should replace the tires.
8.1.1 Air tires
Air tyres should be checked weekly for correct tyre pressure. You will nd the recommended tyre pressure on the
rear wheels and you can check it with a standard car or bicycle tyre pressure gauge. If the tyres of the wheelchair
not have the correct pressure it will lean to the side where the minimum pressure is. It will also inuence the driving comfort and it will mean you have to exert more eort to move the wheelchair.
8.1.2 PU tires
More and more we use PU tyres (polyurethane or puncture-free tyres) on the wheelchair. You can recognise these tyres because they do not have a valve. These tyres have the advantage that they do not need to be pumped up and can not be punctured. This PU tyre can just as an air tyre wear out. Check periodically to see if the tread is still deep enough.
8.2 Brakes
Before you can check the brakes, you need to make sure the tyre pressure is correct, see chapter 7.1. Inspect both brakes for sharp rims. If there are sharp rims on the brakes we advise you to replace them. Ensure that all the parts of the brake are in the right position and fastened secure;
Make sure that the mechanism is functioning smoothly. If it is not functioning smoothly put some oil at turning
points with one or two drips of WD40 oil or Teon. Remove surplus oil and dirt. Also, make sure the brakes do not
come into contact with the wheels as you are moving.
26
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
8.3 Cross brace
The cross brace of your wheelchair is the basis of your wheelchair. Therefore, the cross brace should be in good condition. Check the cross brace in the following points:
Make sure the wheelchair can easily be fold and unfold;
Make sure the wheelchair travels in a straight line while moving;
Make sure the cross frame is not bent and shows no wear signs.
When any of the above points show abnormalities, please contact the dealer where you bought the wheelchair. Only your dealer may make any repairs to the cross brace.
8.4 Rear wheels
You can also check the rear wheels of your wheelchair yourself. Proper adjustment of the rear wheels increases the
stability of the wheelchair. Also, it ensures that you have to make less eort to move the wheelchair. Check the rear
wheels on the following points:
Make sure that the wheels can move freely without touching anything;
Make sure there is no margin on the rear wheels. If this is the case, this is often that the housing of the rear
wheels is loose.
When any of the above points show abnormalities, please contact the dealer where you bought the wheelchair. Only your dealer may make any repairs to the rear wheels.
8.5 Castors and front fork
The castors at the front of the wheelchair and the front fork which these casters must be attached to, must move smoothly to steer with your wheelchair. Check the castors and the front fork therefore the following points:
Make sure the nut of the front fork is nor to loose or to tight. When the nut is too loose, the wheels will rotate but the ride will be uncomfortable. If the nut is too tight, the chair will be dicult to steer because of the
bearings getting pushed so the balls can not move freely. When the nut is correct in place the front wheel will stop slowly;
Make sure the front castor shows no wear signs.
When any of the above points show abnormalities, please contact the dealer where you bought the wheelchair. Only your dealer may make any repairs to the castors or the fron fork.
Tip
Make sure the screw-nut is securely fastened to the caster. You can check this by turning the caster. The caster must stop slowly.
27
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
8.6 Upholstery
The upholstery of your wheelchair is also an important component. Torn or worn upholstery can not take human
weight anymore and this can be dangerous. Regular monitoring of your upholstery is very important. Check the
upholstery of your wheelchair therefore onthe following points:
Check the textile coating for holes, cracks and worn spots;
Check the upholstery-mounting grommets to make sure that they are all correctly aligned and secure.
When any of the above points show abnormalities, please contact the dealer where you bought the wheelchair. Only your dealer may make any repairs to the upholstery.
8.7 Cleaning of the wheelchair
Cleaning your wheelchair is important and should be done regularly. You can get your wheelchair best cleaned as described below.
Clean the upholstery, chassis and plastic components on the wheelchair regularly with a mild soap and water. Never use abrasive cleaners, they can damage the varnish. Also never use steam or high pressure cleaners;
Wax the varnish of the chassis regularly. Never use solvents, abrasive waxes, caustic chemicals or spray silicone;
Dry the wheelchair after cleaning. Also dry you wheelchair after you have been, for example, in a rainstorm.
8.8 Periodical maitenance to your wheelchair
Preventive maintenance is very important and many of these things you can easily do yourself (or your attendant). We highlight below the maintenance you can do yourself.
Every week
Check tyre pressure.
Every month
Check the fold ability of the wheelchair;
Check if the quick release rear wheels work properly;
Check upholstery for wear;
Check wheel movement front and rear and check turn ability of the wheels;
Check if the brakes are working correct.
Every three months
Check all bolts, screws and nuts and tighten if necessary;
Check all spokes for tension;
Check tyre tread for wear.
28
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
8.9 Service checklist
To maximize the liteme of your wheelchair, we recommend you to get your wheelchair checked,at least once
a year, by an authorized Van Os Medical dealer. The form below can be used for this check. The intensity of the wheelchair users can vary greatly from person to person. Therefore, it may be that your wheelchair needs a check several times a year. Furthermore, maintenance is not covered under warranty.
Service interval:
Service schedule
Service number 1 2 3 4 5 6 7 8 9
Wheels: backlash on the wheels, wear
bearings, adjustments, quick release, tires
Hoop: wear and brambles, check for swipes
Voorvorken: check fot backlash, adjust- ment of the ball head axle
Rims: adjustment, readjustment, check for backlash
Footrests: adjustment, line out
Frame: fracture, welding seams, plastic
components
Armrests: xation, rigid arms
Sealing was / Coating / Chrome
Bekleding: adjust straps, check for wear
Fixation material on all the components.
Teon treatment for al moving
parts.
Seat cushion
Checked by (paraph)
Inspection date
29
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
9. Problem analysis and solutions
It could be there are problems when using your Excel wheelchair. The potential problems that may occur are
described below in the table. You will also nd the solutions. If you have problems with your Excel wheelchair that
can not be found in the table below, we recommend you to contact an authorized Van Os Medical dealer.
Problems Solutions
1 2 3 4 5
There is backlash on the wheelchair X X
The wheelchair squeaks of rattles X
The castors utters X X X
The wheelchair moves heavy X X
The wheelchair is turning slowly X X X X
The wheelchairs deviates to the left X X X
The wheelchairs deviates to the right X X X
Check if the tyre pressure is correct. Make sure the pressure is equal in both wheels.
1
Check if all nuts and bolts are stuck tightly.
2
The rear wheels and/or castors may be adjusted improperly. Make sure that both rear wheels and
3
castor are mounted in identical positions.
Check if the bearings are not worn.
4
The front fork of the castors may be adjusted improperly. Make sure they are adjusted properly.
5
30
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
10. Warranty
Your user manual is also the warranty form. Enter the relevant data on page ve and keep this user manual
carefully.
10.1 Warranty application
On your wheelchair is factory warranty applicable. It could also be possible that your dealer oers an additional
warranty. However, in this user manual we are assuming the only warranty is the one given by Van Os Medical.
This warranty is only granted to you as the consumer. It is not intended to be used commercially (like hiring or institutional use). The warranty is limited to defects to materials and possible hidden shortages. Van Os Medical guarantees the following components on your Excel G-Evolution wheelchair:
Warranty period on side- and crossframe: 10 years;
Warranty period wheels, hand brakes, front forks, arm rests, footrests and all components not stated here
under: 2 years;
No warranty on: upholstered components like seat and back upholstery and rigid arms, plastic parts as foot plates, coating and rubber parts, tyres and inner tubes.
10.2 Warranty conditions
The warranty period starts upon the date of purchase of your wheelchair. If within the warranty period, your wheelchair will be defect, it will be repaired or replaced. However you do need to provide to Van Os Medical
a complete lled in warranty registration form or a copy of the bill with date of purchase. Without a warranty
registration form or a proof of the purchase date the warranty will start at the date when Van Os Medical sent the invoice to the dealer.
Repairs and replacement must be performed by an authorized Van Os Medical service agent. To qualify for the
warranty, your wheelchair must require the care standards. Furthermore, if a problem occurs, you need to fully inform the Van Os Medical service agent immediately. If you use the wheelchair outside the designated area of the Van Os Medical service agent, you can repair your wheelchair by any other, by the factory approved, service agent.
When parts of the wheelchair, within 24 months after the commence date, needs reparation or replacement, as a
result of a manufactory or material error and the wheelchair is with its rst owner, the part or parts will be
repaired or replaced free of charge.
This warranty does not include any labour charges incurred by replacements. Replaced or repaired parts fall under
the same warranty conditions as the original wheelchair. Worn parts are normally not guaranteed, unless these parts are worn as a direct result of an original manufacturer defect. These parts are for example upholstery, tyres, inner tubes and similar kinds of parts. The warranty conditions above describe all wheelchair parts, and are applied for the models bought at the normal price.
31
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
User manual | Excel G-Evolution
Under normal circumstances no responsibility is accepted when the wheelchair needs replacement or repairs as a direct result from:
Not maintaining the wheelchair and parts according to the recommendations of the manufacturer, or not using the specic original parts;
Damaging the wheelchair or parts by inattentive use, accident or wrong use;
Adjusting the wheelchair or parts, dierent from the specications of the manufacturer, or reparations done
before the service agent is warned.
If the product is not equipped with an original factory frame number and identication label as described in
the manual, see chapter 1.
The wheelchair which is described and showed in this user manual can dier from your own model in details. However, all instructions are relevant, independent of slightly dierent details. We reserve the right to change the
product in this user manual without further notice. All drawings, measures and capacities showed in this manual,
are approximations and may be slightly dierent to your wheelchairs specications.
Warning
Van Os Medical B.V. cannot be liable for any consequent or individual damage whatsoever. While this manual is created with care it is not exclusive. If your wheelchair does not comply with the rules contained in this user manual,
you will rst go to an authorized Van Os Medical dealer to discuss the problem. The warranty is only valid during
the indicated period. If adjustments are made to the Excel G-Evolution wheelchair, which have structural impact on the product, the warranty will expire completely. You can visit www.vanosmedical.com for an enlarged warranty and supply conditions and an address list of service agents.
For warranty service, contact your authorised dealer from where you bought your wheelchair. If it occurs that you are not helped to your satisfaction concerning the warranty service, please contact Van Os Medical in writing. You
can nd the address on back of this user manual.
Tip
Maintenance is not covered under warranty. Your dealer may deviate from the maintenance interval.
32
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
Product identication
Product: Medical aid Brand: Excel Model/type: G-Evolution Version:
Manufacturer: Name Van Os Medical B.V. Address Koperslagerij 3 4651 SK Steenbergen
Country The Netherlands
EU Representative: Name W. van Os Address Koperslagerij 3 4651 SK Steenbergen
Country The Netherlands
Function Director
Technical constructed le
Prepared by: Name J.M.J. Brouwer BBA Function: Research and Development Issue date: 01-08-2015 TCF date: 01-08-2015
Recertication date:
Means of conformity
The product is in conformity with Directive 93/42/EEC based on the use of a Technical construction le in
accordance with Article 9 (Class I products) of the Directive
Signature of EU representative:
Place : Steenbergen
Date : 01-08-2015
Number : VOS.TCF.EC.0117
33
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
© 2015 Excel, part of Van Os Medical B.V.
Van Os Medical B.V.
Koperslagerij 3
4651 SK, Steenbergen (NB)
Nederland
T: +31 (0) 167 57 30 20
F: +31 (0) 167 57 33 81
E: info@vanosmedical.nl
W: www.vanosmedical.nl
Van Os Medical UK Ltd.
Excel House
Ashbrooke Park
Sherburn in Elmet
North Yorkshire, England
LS25 6 PJ
T: +44 (0) 1904 720170
F: +44 (0) 1904 720398
E: sales@vanosmedical.com
W: www.vanosmedical.com
Loading...
