Page 1
Read instructions before use
User Manual
Excel
Excite 4 ‘Galaxy’
Version 1.3 (updated 5/03/2010) See www.vanosmedical.nl/eng for latest manuals
Page 2
Welcome aboard your new Excel Excite Galaxy Galaxy scooter!
We wish to thank you for letting us improve your freedom and independence. This model has been
designed with your practical needs in mind. It is equipped with modern high tech electronics and special
features for a more comfortable ride.
Its safety and performance will provide you with years of excellent service and pleasure!
It is from the utmost importance to read this manual very well before using the Excel Excite Galaxy
scooter. The manual contains important information concerning the use and small maintenance of the
Excite Galaxy.
Safe use of the Excite Galaxy is a following issue. This manual should be stored very well. It contains
information that might come in handy later!
The italic printed parts in this manual are from extra importance. They supply important information
concerning safe use of you mobility scooter.
The intended use of the Excel Excite Galaxy is for people of all ages, who have trouble with walking far
distances or walking for a longer time.
The Excite Galaxy is an outdoor use scooter. The seat can be adjusted by the user. The seat height can
also be adjusted to lower leg length. The seat is able to turn and the flip backward armrests can be used
for an easy transfer.
The maximum speed of the Excite Galaxy is about 15 km/h and at a normal daily use the range is up to
50 km (in combination with 73Ah batteries). The Excite Galaxy can be loaded up to about 220 kg. The
electric engine is controlled by a control unit with micro processor. The electronic driving characteristics
can be adjusted to your wishes within certain limits. Please contact your dealer in this case.
ATTENTION! INDIVIDUAL ADJUSTMENTS TO THIS PRODUCT NEED TO BE DONE WITH THE MANUFACTURERS
WRITTEN APPROVAL.
Page 3
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 2
Contents
Introduction 1
General safety precautions 2
Driving inclines 2
Transport 3
Freewheel mode 3
Electro Magnetic Compatibility 3
Fixation belt (optional) 4
Responsibility 4
First use 4
Learning the scooter 5
Control units 10
The control lever (gas lever) 10
Battery indicator 10
Warning lights 11
Indicators 11
Horn 11
Speed adjustment 11
Statusindicator 11
Charging plug 12
Making a transfer 12
Driving 12
Driving on an incline 13
Obstacles and thresholds 13
Brakes 14
Battery safety 14
Freewheel 14
The Excite Galaxy chair 15
Adjust backrest angle 15
Armrest adjustment 16
Adjust head rest (option) 16
Removing the Excite Galaxy chair 16
Adjust tiller 16
Moving the Excite Galaxy manually 17
Fault by engaged freewheel 17
Charging the batteries 17
Battery charger specifications 18
Opening battery space 19
Storage 19
Upholstery 19
Chassis and plastic parts 19
Tires 19
Other maintenance 19
Replacement parts 20
Maintenance frequency 20
Faults 21
Range 21
Standard programmed driving parameters 22
Warranty precautions 22
Technical information 23
Page 4
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 3
General safety precautions
The Excite Galaxy is designed to be safe in use. This can be noticed on the scooter directly in the below
features:
• When charging the scooter it cannot be driven electrically
• At too high engine and controller unit (Dynamic Rhino) the Excite Galaxy will drive at half power
• With the freewheel function engaged the scooter cannot be driven electrically
• If the control lever is in neutral position the scooter cannot be driven.
• Scooter parts where might be body parts clamped between are fully covered
The Excite Galaxy is meant to be used by one person. Placing a second person on the scooter is not
allowed. The driving characteristics will be influenced badly by this and the Excite Galaxy will
damage.
Inside the control unit (Dynamic Rhino) is a function build who prevents deep de-charge of the
batteries. The control unit reduces the speed eminently.
Please make sure when driving the scooter and performing small maintenance to the Excite Galaxy
there can be no fingers injured in the space between the covers and the wheels.
Driving inclines
A very safe control feature when driving inclines is the following: if the Excite Galaxy is able to drive an
incline, the incline can also be descent with reduced speed. Always drive a steep incline up first and
make sure the Excite Galaxy is not too heavily loaded.
Turning the Excite Galaxy on an incline is not recommended. The scooter can easily tip over.
Never drive from a pavement or incline diagonal. The scooter may tip over. Always drive off a
pavement or incline at low speed.
In areas with pedestrians it is recommended to adjust the maximum speed to a lower standard for your
and other persons safety.
Transport
Transporting the Excite Galaxy inside a vehicle can be done by making the scooter as small as possible.
In this case, you dismount the chair and fold the tiller down. Always check if the scooter is not in
freewheel mode and fixate it firmly to the floor.
It is recommended to not sit in the scooter during transport. The scooter should always be lifted by two
persons, one at the front (front bumper) and one at the back of the scooter (rear bumper). Van Os
Medical accepts no responsibility for any eventual consequences.
Freewheel mode
On freewheel engagement the brakes of the Excite Galaxy are not working. By disengaging the
freewheel lever the brakes will be in work again. Look at page 17 for further freewheel explanation.
Never use the freewheel mode when standing on an incline. This may cause the scooter drive by itself.
Electro Magnetic Compatibility
A couple of European standards have been set in the field of electro magnetic interference on electric
devices. The Excite Galaxy complies to these demands. In an extreme case the Excite Galaxy might be
sensitive to very powerful transmitters. This may cause unexplainable faults. In this case you best turn
to your dealer.
Page 5
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 4
When using transmitters nearby the Excite Galaxy, we recommend to first shut down the scooter
before using a device.
Examples of transmitters can be mobile phones, walkie talkies or a 27 MC transmitter. The Excite
Galaxy itself also transmits electric waves. These are within the applying standards. There might be,
however, certain unintended events, like a shop alarm going off.
Fixation belt
An optional fixtion belt can be mounted to fix the seat position (picture 1). The two parts of the belt can
be mounted below the seat with screws. The screws fixate the belt to the ground plate of the seat. By
use of a click buckle the belt can be fixated.
Picture 1
The fixation belt can only be used on the chair. During transport in a wheelchair taxi the fixation belt
may not be used as a safety belt.
Responsibility
Van Os Medical B.V. can not be held responsible for unsafe situations, accidents or damages, as a result
from:
• use for other purposes or under other circumstances than indicated in this manual. This also
contains applying other than the original replacement parts and changing the programming
adjustments of the Rhino controller
• ignoring warnings or precautions noted in this manual
• improper or insufficient maintenance
First use
Find an open area such as a park and make sure you have an assistant to help you excersize with the
scooter (picture 2).
Picture 2
Not
following these safety guidelines may result in damage to the scooter or personal injury
Page 6
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 5
Make sure the scooter is off before getting in or out of it. Set the speed control knob according to your
driving ability.
We recommend that you keep the speed at the slowest position (fully counter-clockwise) until you are
familiar with the driving characteristics of this vehicle.
Picture 3
Learning the scooter
Now, practice moving forward by pulling the right lever. Be sure to set the speed to the lowest setting
(1).
Picture 4
After becoming familiar with moving forward, practice making ‘S’ turns (picure 4).
Picture 5
Once you are familiar with ‘S’ turns, practice moving in reverse. When driving backward the scooter
already drives slower than forward, but for your safety we recommend to put the setting to the lowest
level (1).
Page 7
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 6
Picture 6 Picture 7
Do not carry any passengers (picture 6)! Do not drive across a slope (picture 7)
Picture 8 Picture 9
Never drink and drive (picture 8)! Do not tow a trailer (picture 9)
Picture 10
Do not turn on or use hand-held personal communications devices such as citizens band (CB) radios and
cellular phones.
Pay attention to the following warnings!
Page 8
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 7
Picture 11 Picture 12
Do not drive in heavy traffic (picture 11) Do not drive beside a river, port or lake without a
fence or railing (picture 12)
Picture 13 Picture 14
Do not drive during the rain Do not drive during or on snow
(picture 13) (picture 14)
Picture 15 Picture 16
Do not drive off-road or on any Be sure to use headlights when
Uneven surfaced roads (picture 15) driving at night (picture 16)
When driving on the road, pay attention to the following:
Page 9
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 8
Picture 17 Picture 18
Make sure that there are no obstacles Do not make sudden stops, weave
behind you when driving in reverse erratically, or make sharp turns (picture 18)
We recommend to set the speed
knob at the lowest speed (1) when
driving back (picture 17)
Picture 19 Picture 20
Keep your hands on or inside the Do not attempt to climb curbs greater
armrests and foots on the footplate than 5 cm (picture 20)
(picture 19)
Picture 21 Picture 22
Do not attempt to cross over a gap Do not attempt to climb a hill greater
greater than 10 cm (picture 21) than 10° (picture 22)
Page 10
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 9
Picture 23 Picture 24
Do not reverse while driving up a hill Use caution when driving over soft,
Forward only. If you reverse while moving uneven or unprotected surfaces
Uphill, it may cause the vehicle to tip over such as grass, gravel and decks
(picture 23) (picture 24)
Picture 25 Picture 26
Use low speed while driving downhill. Do not get in and out on a hill
When going downhill, the tiller will Always stop on the level surface to
become harder to reach and handle. get in and out of the vehicle (picture 26)
When braking while moving downhill
the scooter will take longer to come to
a complete stop (picture 25)
Picture 27 Picture 28
Always climb or descend gradients Do not load or carry heavy items in
perpendicular to the slope or ramp the basket while driving downhill
(picture 27) (picture 28)
Page 11
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 10
Control units
The control units of the Excite Galaxy are very clearly arranged on the dashboard (picture 29). The
charging plug is located on the tiller, the freewheel lever on the rear right side of the scooter. The
status indicator is located on the dashboard. See the below picture for a survey of all control units.
Picture 29
1. Seat control
2. Battery indicator
3. Warning signal
4. Claxon
5. Indicator control right
6. Speed control
7. Control lever
8. Battery charger
9. Driving mode limited speed
10. Indicator control left
11. Illumination
The control lever (number 7, picture 29)
- Pull the left lever to drive backwards
- Pull the right lever to drive forwards
Page 12
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 11
Battery indicator
This indicates the battery charging amount (number 2, picture 29). This also affects the range at the
time. The indication is divided as below:
When the lights on the battery indicator are green: Full range (90% - 100% capacity available)
When the lights on the battery indicator are oranje: Decreasing range (60-70% capacity available)
When the lights on the battery indicator red: Limited range (20-30% capacity available)
Warning lights
Warning lights can be powered by pushing the button. By pressing it again, the warning lights will go off.
Indicators
The switches can be pushed to engage the indicators. They can be operated both left and right handed.
Horn
Pressing the button engages the horn.
Speed adjustment
This knob adjusts desired maximum speed. You turn the knov right for a higher maximum speed and left
for a lower. Speed can be adjusted in 6 steps.
Driving mode limited speed (number 9, picture 29)
With this button you adjust the speed of the scooter till it’s minimum. When you press this button the
scooter will drive very slowly.
Page 13
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 12
Seat control Up and Down (Optional number 1, picture 29)
You need to push the seat control button to activate its function. The light above the button will be on
when it is activated.
When it is activated you can bring the seat up or down by using the lever control.
To deactivate the seat control function you need to push the button again. The light above the button
will go out. When the light is out you can drive with the scooter by using the lever controls.
Number of blinks Fault Scooter condition Remarks
1 Charge battery DRIVING POSSIBLE
BATTERY VOLTAGE LOWERED TO LESS
THAN 23.3 V, CHARGE BATTERIES SOON
2 Battery voltage too low DRIVING NOT POSSIBLE
BATTERY VOLTAGE LOWERED TO LESS
THAN 16.5 V, CHARGE BATTERIES
IMMEDIATELY
3 Battery voltage too high DRIVING NOT POSSIBLE
BATTERY VOLTAGE INCREASED TO HIGHER
THAN 32 V. PROBABLY DEFECT CHARGER
4 Current limit time out DRIVING NOT POSSIBLE
DETECTOR DETECTED SHORTCUT IN THE
MOTOR. WARN DEALER
5 Brake fault DRIVING NOT POSSIBLE CHECK IF FREEWHEEL IS DISCONNECTED
6 Gas pot not in neutral at power up DRIVING NOT POSSIBLE CONTACT DEALER
7 Speed pot error DRIVING NOT POSSIBLE CONTACT DEALER
8 Motor volts error DRIVING NOT POSSIBLE CONTACT DEALER
9 Other internal error DRIVING NOT POSSIBLE CONTACT DEALER
10 Push too fast fault DRIVING NOT POSSIBLE TURN OFF SCOOTER AND RESTART
Charging plug
To charge the batteries use a charger which guards the process and is convenient to charge the fitted
batteries. Your battery charger should be equipped with a 3-pole plug which fits into the charging plug
in the tiller.
Making a transfer
Make sure the Excite Galaxy is always turned off and in freewheel position before making a transfer.
• move the rotion lever upwards to unlock the chair (picture 32)
• next, turn the chair 90º left or right. The chair will automatically lock on every 45º if you release
the rotation lever (picture 32)
• take place on the chair and turn it back to the starting position. The chair is fitted with flip-
backward armrests. These can be flipped away to be able to make an easy side transfer. Always
make sure to flip the armrests back in the original position when seated.
Picture 32
Page 14
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 13
Driving
The Naviagor can be powered up with the ignition key on the right side of the tiller. After a brief selftest the Excite Galaxy is ready to drive. By pulling the right side of the gas lever (at thumb control
pushing), the Excite Galaxy moves forward. The closer you pull the lever towards you, the faster the
scooter will drive. If you release the lever the Excite Galaxy will stop. For reversing please stop the
scooter first. Now pull the left side of the gas lever (a thumb control push). The Excite Galaxy now will
drive backwards, with reduced speed.
• Before you drive, first check if the chair is properly fixated.
• Make sure the tires are always on the right pressure (see technical specifications).
• Make sure the batteries are always sufficiently charged. The pointer of the battery indicator
should be in the green area.
• Should the gas lever not be in neutral position when the Excite Galaxy is powered up, it will
not drive. Only after the control lever has been placed in neutral position, the Excite Galaxy is
ready to drive. The neutral position is when the gas lever is not operated.
• Never take sharp turns while driving at full speed. We recommend to slow down before making
a sharp turn. We strongly recommend to avoid dangerous driving in corners.
• Always think of your own safety if you drive from the even road with the Excite Galaxy. Adjust
your speed. Never drive through deep holes, water etc.
• The ideal stability and weight balance can be achieved when taking the following points into
consideration: always sit straight on the chair and place your feet as far to the front as
possible. Do not lean left or right while driving.
Driving on an incline
A very safe control feature when driving inclines is the following: if the Excite Galaxy is able to drive an
incline, the incline can also be descent with reduced speed. Always drive a steep incline up first and
make sure the Excite Galaxy is not too heavily loaded.
Picture 33
Driving up a hill: lean a little forward and drive as constant as possible in a straight line up (picture 33).
To stop and restart driving costs extra energy.
Driving off a hill: lean a littly backward and drive carefully with low speed down the hill.
A will which is difficult to climb for the Excite Galaxy needs to be avoided. When climbing very steep
inclines (over 12°) is dangerous. At sudden braking the scooter might tip over to the front or the back.
Page 15
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 14
Obstacles and thresholds
Driving obstacles should be done very carefully. When driving an obstacle which is too high the Excite
Galaxy might get stuck. For maximum ground clearance please see the chapter ‘Technical data’.
Picture 34
Driving up thresholds: drive towards the threshold until the front wheel is approximately 20-50 cm
before the threshold. Now carefully drive forward and approach the threshold. As soon as the front
wheel is on the threshold you can slowly drive further until the rear wheels are also on or over the
threshold (picture 34). If this does not succeed or very difficult, please choose another route.
Driving off thresholds: drive to the threshold until the front wheel is before it. Drive off the threshold
carefully and with low speed. Please always make sure that the anti-tip device never interferes with a
threshold or kerb when mounting or dismounting.
Brakes
Braking can be done in different ways:
• you can slowly move the gas lever into the neutral position, to make the Excite Galaxy slow
down easily
• you can just let the gas lever go, so the Excite Galaxy will come to a full stop
• the Excite Galaxy is also fitted with a disk brake rear with the lever on the tiller. This may be
used on eventual emergency stops
If driving down a hill the Excite Galaxy might drive faster than the maximum speed possible. In this case
the control unit will slow the Excite Galaxy down to reach the programmed maximum speed.
If the gas lever of the Excite Galaxy is in neutral position the scooter is braked. The motor brake power
is enough to stop the scooter and keep on its place on the maximum possible incline angle (12 degrees).
At rain, snow or other slippery road conditions, please brake gently to provide sliding danger.
Battery safety
When driving on low or empty batteries, to be seen on your battery indicator, the battery safety feature
will be engaged. This provides battery damage through deep decharge. The engagement of this feature
can be noticed by the decreasing maximum speed. Drive as little as possible in this condition. After thy
system being engaged the batteries should be charged as soon as possible.
Page 16
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 15
Freewheel
The Excite Galaxy is equipped with a so-called freewheel function. This allows the Excite Galaxy to be
moved without using the engine. Push the backrest to move the scooter. In this freewheel position the
scootercan not be driven electrically. You can engage the freewheel function by the freewheel lever on
the rear side of the scooter, just below the cover (picture 35).
Picture 35
It is important to first fully turn off the power before engaging the freewheel lever. The power needed
to push the scooter is mimimal. The brakes of the Excite Galaxy are not in use during freewheel
engagement. This can be reversed by turning the freewheel function off.
Fault by engaged freewheel
If the Excite Galaxy is powered when you engage the freewheel lever, the status indicator will indicate
fault code 5. To erase the fault code and drive electrically please proceed as follows:
• first disengage the freewheel function (push te freewheel lever down)
• then, power off the system (this erases the fault)
• when the system is powered up the scooter is able to drive again
The Excite Galaxy chair
The chair of the Excite Galaxy is equipped with a number of adjustment possibilities which improves
your seat and driving comfort considerably. The entire chair can be height adjusted in a range of 10 cm
in 4 teps of 2,5 cm. This adjustment can be done by your dealer.
Adjust backrest angle
The backrest angle is stepless adjustable in a sitting position up to standard 105 degrees (picture 36). By
replacing the hex bolt on the turning point this can be increased up to 135 degrees. The backrest can
also be fully flipped forward to ease transport. On the right side of the chair (left shown on picture 36) is
a lever. Pull it up and lean forward or rearward to adjust the desired backrest angle (picture 36). As
soon as you reached it you release the lever> The backrest will fixate in your position.
Picture 36
Page 17
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 16
Never operate the lever when you are not in the chair. The backrest will come forward with strength.
Armrest adjustment
The armrests can be fully flipped up (picture 37). Also the angle and the armrest height are adjustable.
The armrests are fully flipped up by moving them up. he armrest angle is adjustable by the bolt on the
inner side of the armrest. You can turn this bolt further out by hand (the arm rest angle will go down) or
further in (the arm rest angle will go up). On the rear side of the arm rest tube is a turning knob. Turn it
loose and adjust the arm rest to the desired height. Fasten the knob securely.
Picture 37
Adjust head rest (option)
The head rest is adjustable in three height positions.
Removing the Excite Galaxy chair
Unlock the turning system of the chair as shown on the picture below (picture 38). You can pull the chair
straight up and eventually move it around a little. Flipping back the armrests and folding down the
backrest eases the removal. The chair can be handled on the lower side, symmetrical to the seat post.
Picture 38
The chair of the Excite Galaxy weights around 16 kg. Please remember this when removing the chair.
The chair can be lifted by putting your one arm around the backrest and grip firmly and the other arm
under the seat. Folding the armrests and the backrest can ease the lifting.
Page 18
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 17
Adjust tiller
You can adjust the tiller angle as follows (picture 39):
1. pull the small lever on the left side of the tiller
2. you can adjust the tiller with two hands by lowering or lifting it in the desired position
3. when you release the lever the tiller will fixate in the current position
4. the tiller can be fully folded down to ease transport
Picture 39
Moving the Excite Galaxy manually
Manual movement of the Excite Galaxy can be done by first engaging the freewheel mode and the
power off. If this is not done the Excite Galaxy can only be moved with great strength.
• put the freewheel lever in the up position. This engages the freewheel mode
• the Excite Galaxy can now be moved freely by pushing the backrest
• after returning the freewheel lever and powering up the control unit the Excite Galaxy is able to
drive again.
The brakes of the Excite Galaxy are not in use during freewheel engagement. This can be reversed by
turning the freewheel function off.
Fault by engaged freewheel
If the Excite Galaxy is powered when you engage the freewheel lever, the status indicator will indicate
fault code 5. To erase the fault code and drive electrically please proceed as follows:
• first disengage the freewheel function (push te freewheel lever down)
• then, power off the system (this erases the fault)
• when the system is powered up the scooter is able to drive again
Charging the batteries
The Excite Galaxy can be equipped with two dry 12 Volt batteries of maximum 73Ah (50Ah as standard).
At daily use the dry batteries need no other maintenance than regular charge. The scooter is equipped
with 2 50Ah batteries. The battery connector type on the cable is Alex PVC, dimensions 40 x 20 mm.
Because the batteries are probably empty or partly charged when they arrive, it is of great importance
to first fully charge the batteries. The scooter is fitted with a charger, standard delivered. If the
batteries are charged using the below procedure, you will gain maximum lifetime, power and reach of
the batteries.
Page 19
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 18
1. Turn off the power of your scooter
2. Put the power support cable in a wall socket
3. Put the battery charge cable into the tiller (turn away the round cover) (picture 40).
4. When the battery charger is turned on the scooter will be charged. During charge the progress
indicator will blink. A RED light means the charger is in use, a WHITE light means the scooter is being
charged and a GREEN light means the scooter is fully charged.
The Excite Galaxy can not be driven electrically with a plug in the charge socket. If the range of the
Excite Galaxy is strongly decreasing, the batteries need replacement. In this case you need to contact
your dealer. It is not allowed to replace the batteries yourself. When a battery is leaking contact dealer
immediately! Please consider the following when changing batteries: see that the connectors do not
contact with each other. Make sure when connecting the batteries the connectors are correctly poled
(++ and --). The Excite Galaxy comes with a battery charger. If any problems occur please contact your
dealer. It is not allowed to open the charger. The charge socket is indicated with a symbol on the tiller
(picture 40a). The charger connection is indicated on the charger with a symbol (picture 40b):
Picture 40 Picture 40a Picture 40b
Picture 40c
Battery charger specifications:
• appropriate for the fitted batteries
• maximum nominal charge current: 24 Volt
• maximum nominal charge power: 6 Ampère
• suitable for unguarded use
Black
Red
Picture 40c
shows 70A
h
batteries (optional extra)
Scooter fitted with 50Ah as
standard
Page 20
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 19
Opening battery space and removing batteries
The batteries of the Excite Galaxy can be reached by removing the rear cover. First remove the chair as
described on page 16. The rear cover can be removed. Replacement in reverse order. The batteries
should be lifted on the lower side.
Storage
If the Excite Galaxy is not be used for longer time, please consider the below remarks. The Excite
Galaxy needs to be stored with fully charged batteries in a dry and freeze free environment, in regard to
freezing danger of the batteries. Always turn the Excite Galaxy off during storage.
The charge condition of the batteries should be checked regularly when the Excite Galaxy is not used
for a long time. If necessary the batteries must be recharged.
The Excite Galaxy should never be left unnecessary in the bright sunlight. Parts like the upholstery or
metal parts might get very hot. This also might shorten the tyres lifetime.
Upholstery
The scooters upholstery should be cleaned with a mild cleanser. Weep the upholstery should with a
moist cloth after cleaning.
Chassis and plastic parts
The chassis and the plastic parts, including the control panel, should only be cleaned with a light moist
cloth. Dry the parts after that with a dry cloth.
It is not allowed to clean the Excite Galaxy with a high pressure hose or otherwise using too much
water.
All the maintenance that can be done by the user is described in this chapter. If the Excite Galaxy
needs additional maintenance or repair you need to contact your dealer. It is not allowed to perform
any other than the herein described tasks on the Excite Galaxy.
Charging the batteries
Always charge the batteries regularly and on time. This preserves the maximum charge capacity and
increases the lifetime of the batteries. For charging instructions see page 17.
Tires
It is very important to check the tire pressure or tire damage regularly. When any damage might occur
(for instance caused by a nail or glass), contact your dealer immediately.
The scooter tires should always be on the prescribed pressure (see chapter technical data). Driving with
low pressure tires causes bad driving and steering characteristics.
The tires should never be inflated over the maximum tire pressure. The tire might get off the rim or
explode.
Other maintenance
Please leave any other maintenance to your dealer. Adapt the needed maintenance to your scooter
together with your dealer.
If any lubricant should leak, for instance from the gear box, please contact your dealer immediately and
don’t drive the scooter again.
Page 21
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 20
Replacement parts
All Excite Galaxy parts, including electronic components, are securely adapted to each other and
tested. This results in a quality scooter with a long lifetime. This quality, safety and lifetime can only be
preserved by using only original replacement parts.
Not using original parts could result in decreased liability from the Excite Galaxy and reduced safety.
Also due of the warranty.
All replacement parts can be ordered by your dealer at Van Os Medical B.V..
Maintenance frequency
This schedule has been made to give you a survey of the maintenance that should be done to the Excite
Galaxy. The yearly maintenance should be done by your dealer.
Check Weekly Monthly Yearly By whom
Battery charger connection Dealer
Bolts and nuts Dealer
Tire wear User
Tire pressure User
Wiring and connections Dealer
Clean upholstery User
Illumination and indicators User
Bearings Dealer
Engine Dealer
Battery poles Dealer
Clean chassis parts and covers User
Driving program Dealer
Suspension Dealer
Freewheel and parking brake Dealer
Faults
The dashboard contains a status indicator. If this lights up green without blinking the Excite Galaxy is
ignited and there are no problems. In case of a fault the status indicator indicates a fault by blinking
codes. If the status indicator shows a fault, the first thing to do is turn off the power of the Excite
Galaxy and ignite again.
If the indicator shows another fault, please count the blinks. These show a code which indicates a fault.
The flash code list below shows all the meanings of the flashes. The list also containt possible causes and
an eventual solution of the problem. If you are unable to solve the problem with help of this list, please
contact your dealer.
Page 22
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 21
Number of blinks Fault Scooter condition Remarks
1 Charge battery DRIVING POSSIBLE
BATTERY VOLTAGE LOWERED TO LESS THAN 23.3 V,
CHARGE BATTERIES SOON
2 Battery voltage too low
DRIVING NOT
POSSIBLE
BATTERY VOLTAGE LOWERED TO LESS THAN 16.5 V,
CHARGE BATTERIES IMMEDIATELY
3 Battery voltage too high
DRIVING NOT
POSSIBLE
BATTERY VOLTAGE INCREASED TO HIGHER THAN 32 V.
PROBABLY DEFECT CHARGER
4 Current limit time out
DRIVING NOT
POSSIBLE
DETECTOR DETECTED SHORTCUT IN THE MOTOR.
WARN DEALER
5 Brake fault
DRIVING NOT
POSSIBLE
CHECK IF FREEWHEEL IS DISCONNECTED
6 Gas pot not in neutral at power up
DRIVING NOT
POSSIBLE
CONTACT DEALER
7 Speed pot error
DRIVING NOT
POSSIBLE
CONTACT DEALER
8 Motor volts error
DRIVING NOT
POSSIBLE
CONTACT DEALER
9 Other internal error
DRIVING NOT
POSSIBLE
CONTACT DEALER
10 Push too fast fault
DRIVING NOT
POSSIBLE
TURN OFF SCOOTER AND RESTART
All Van Os Medical products are built for a long and durable lifetime. However, during time reparation
and maintenance to your Excite Galaxy will not be renumerative any more. Your dealer will contact you
in time for this. When recycling the Excite Galaxy your should consided the below points:
• at scooter recycling the current or local precautions should always be followed
• the Excite Galaxy only contains known materials. A couple of this materials, if collected
separately, can be recyled
• at development and build of the Excite Galaxy for all used materials were known waste disposal
possibilities and no risks were known for recycling persons, not containing the batteries
Make sure during recycle of the Excite Galaxy the batteries do not get damaged. They should be
offered to a certified instance or company for further disposal. When dealing with batteries always
take the needed precautions for protection of yourself and the environment.
Range
The range of the Excite Galaxy (± 60 km) depends on the following factors:
• condition of the batteries
• weight on the chair (user, luggage etc)
• average driving speed
• driving style
• surface
• environment temperature
• driving conditions (hilly or flat, gravel or smoot asfalt)
Standard programmed driving parameters
The Excite Galaxy controller is equipped with a microprocessor. This can be indicated as the ‘brain’ of
the scooter. Inside this microprocessor a number of parameters can be adjusted. Some of these
parameters have consequences for the driving characteristics of the Excite Galaxy. Van Os Medical B.V.
equipped the Excite Galaxy with a standard program. If this program does not satisfy you, it can be
adjusted by use of a programmer box to adjust all parameters to your desires.
The values of the parameters have been carefully chosen. Extreme altering of the parameter data could
result in unstable driving habit. Small changes of the parameters are allowed.
Page 23
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 22
Warranty precautions
These warranty precautions are in accordance with all other product specific warranties and are just
applicable to the first owner. If a none specified, to the product belonging warranty claim will appear,
this claim will judged by Van Os Medical B.V. during the warranty period. During the warranty period the
replacement parts can only be guaranteed until the end of the regular warranty period. All appearing
warranty will be limited to the replacement or reparation of the defect parts. Van Os Medical B.V. can
never be held responsible for any consequence such as damage or incidental damage, in what way ever.
Van Os Medical B.V. only guarantees replacement parts.
This warranty gives you specific lawful rights. You must be aware of the fact that these rights can
change from country to country. Some lands do not accept a limited warranty concerning incidental or
consequential damage, or the time limit of the warranty. In that case the warranty period and / or the
exception of the warranty will be adjusted.
For warranty and service you need to contact the authorised Travelux® dealer, who supplied the
Travelux®. If during a warranty period reparations are done by another company than Van Os Medical
B.V. or a not by Van Os Medical B.V. approved company, every right on warranty comes to an end. In
case of service and warranty is not given to satisfaction by your dealer, please contact Van Os Medical
B.V. We will try to get to a satisfying solution for both parties.
Page 24
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 23
Technical Information
Electrical system
Description 3 Wheel Version 4 Wheel Version
Motor (10 Km/h) 400W 400W
Motor (12.8 Km/h, 8MPH, UK) 400W 400W
Motor (15Km/h) 400W 400W
Batteries 2 x 50 AH
2 x 60 AH
2 x 73 AH
2 x 50 AH
2 x 60 AH
2 x 73 AH
Main fuses (10 km/h) 60A 60A
Weight
Description 3 Wheel Version 4 Wheel Version
Without batteries and seat 60 kg* 65kg*
Without batteries 80 kg 85kg
With 73 Ah batteries 127 kg 132 kg
Weight of heaviest part 21.4 kg 25 kg
Maximum load
(operating load)
175 kg 200 kg
Dimensions
Description 3 Wheel Version 4 Wheel Version
Height 123 cm* 123 cm*
Width 65.5 cm* 65.5 cm*
Length (inc anti-tip and
bumper)
141cm* 146 cm*
Seat Height (From chassis /
floor
46 / 64 cm*
48 / 66 cm*
49 / 68 cm*
51 / 71 cm*
46 / 64 cm*
48 / 66 cm*
49 / 68 cm*
51 / 71 cm*
Backrest height (No headrest) 44 cm* 44 cm*
Backrest height (Inc Headrest) 63 cm* 63 cm*
Backrest angle 0°, 10°, 15°, 30° 0°, 10°, 15°, 30°
Seat Width 44-55 cm* 44-55cm*
Seat Depth 44 cm* 44 cm*
Armrest height 24-30 cm* 24-30 cm*
Tyres
Description 3 Wheel Version 4 Wheel Version
Tyre pressure 2.5 bar (40psi) 2.5 bar (40psi)
Page 25
User manual
Excel Excite Galaxy Galaxy
Version 1.3 – updated 5/03/2010. See www.vanosmedical.nl/eng/ for latest manuals
Page 24
Travelling Performance
Description 3 Wheel Version 4 Wheel Version
Speed 10 km/h
12.8 km/h (8 MPH, UK)
15km/h
10 km/h
12.8 km/h (8 MPH, UK)
15km/h
Safe climbing of inclines n/a n/a
10 km/h version Up to 175 kg operating load: 15°
(21%)
up to 200 kg operating load:
15° (26%)
12.8 km/h (8 MPH, UK) and
15 km/h versions
• up to 150 kg operating load:
12° (21%)
• up to 175 kg operating load:
10° (17%)
• up to 150 kg operating load:
12° (21%)
• up to 200 kg operating load:
10° (17%)
Maximum obstacle height 11 cm 11 cm
Tightest turning radius 130 cm 161 cm
Drive range in
accordance with ISO
7176**
n/a n/a
10 km/h version n/a n/a
50 Ah batteries 30 km 30 km
60 Ah batteries 35 km 35 km
73 Ah batteries 40 km 40 km
12.8 (8 MPH, UK) and 15
km/h versions
n/a n/a
50 Ah batteries 35 km 35 km
60 Ah batteries 45 km 45 km
73 Ah batteries 50 km 50 km
* Approximate values
Page 26
Van Os Medical B.V.
The Netherlands
Koperslagerij 9
4651 SK Steenbergen NB
Tel: +31 (0) 167 57 3020
Fax: +31 (0) 167 57 3381
info@vanosmedical.nl
www.vanosmedical.com
Dealer:
Page 27
www.vanosmedical.com
Loading...
