SMART CARD KEYBOARD
USB Keyboard with Smart Card reader
USER MANUAL
XKKITASCR
www.hamletcom.com
2
Dear Customer,
thanks for choosing an Hamlet product. Please carefully
follow the instructions for its use and maintenance and,
once this item has run its life span, we kindly ask You to
dispose of it in an environmentally friendly way, by
putting it in the separate bins for electrical/electronic
waste, or to bring it back to your retailer who will collect it for free.
We inform You this product is manufactured with materials and
components in compliance with RoHS Directive 2002/95/CE,
2002/96/CE, 2003/108/CE; with WEEE Directive 2003/96/CE,
Italian Legislative Decree 2005/151 and EMC Directive
2004/108/EC for the following standards:
EN 55022: 2006+A1: 2007, Class B
EN 55024: 1998+A1: 2001+A2: 2003
CISPR 22: 2005+A1: 2005, Class B
AS/NZS CISPR 22: 2006, Class B
The complete CE declaration of conformity of the product can be
obtained by contacting Hamlet at info@hamletcom.com specifying
the product code and the documentation.
The information on the importer for your country are available in the
“About Us” section of the Hamlet website at www.hamletcom.com.
About this manual
This manual is for information only and may change without notice.
Hamlet reserves the right to modify or update the product and the
manual without reservation and without notice.
Trademarks
All trademarks and company names mentioned in this manual are
used for description purpose only and remain property of their
respective owners.
3
1. Introduction
Exagerate Smart Card Keyboard is a professional full-sized
keyboard designed for comfortable and long term use thanks to the
low-profile quiet keys and sturdy tilt legs which allows lock up
position and right inclination.
The integrated Smart Card reader allows to take advantage of
digital signature to perform transactions in a secure environment on
both public and private networks. The USB Smart Card Keyboard
works with all smart cards that comply with ISO standard 7816.
Features
• Interface: USB compatible; USB Type A Plug connector
• Operating (Input) Voltage: 4.75~5.25 VDC
• Supports all ISO 7816 smart cards
• Card insertion/removal detection
• Quiet low-profile keys
• Plug & Play, USB powered
• High quality membrane standard keyboard
• Compatible with 3V and 5V smart cards
• Short circuit detection, protects the smart card and reader
• Cable length: 2.0 meter
• Weight: 650 g
• Product dimension (HxDxW): 467 x 36.57 x 162.71 mm
Package Contents
• USB Keyboard
• User manual
• CD driver
System Requirements
• Windows 2000/XP/Vista/7 or Linux
• One free USB port
• CD/DVD drive
4
2. Installation and usage
To install the smart card reader driver for the Microsoft Windows
operating systems, do the following:
1. Insert the CD driver that comes with the product into the CD or
DVD drive.
2. Open the CD content and double click the Setup.exe file to
start the installation.
3. Follow the instructions on the screen to install the driver.
4. Once the installation is complete, click Finish.
5. Restart your computer if necessary.
6. After the computer restart, connect the keyboard cable to the
USB port on your computer.
7. The operating system will identify the keyboard and the smart
card reader, and the keyboard will be ready for use
Inserting a Smart Card
To insert a smart card in the Exagerate Smart Card Keyboard make
sure that the side of the smart card including the metallic part with
the contacts are at the front of you.
If the keyboard is installed properly and the smart card is inserted
correctly, the smart card LED indicator must be on.
Important notice
The Exagerate Smart Card Keyboard is a hardware device only.
You will need to install user provided application software* as well
to use the smart card as a security device of for other function.
* Not included
