EWM TROLLY 70-1, TROLLY 70-2, TROLLY 70-2 DF, TROLLY 70-3, TROLLY 70-3 DF Operating Instructions Manual

EWM HIGHTEC WELDING GmbH Dr. Günter - Henle - Straße 8; D-56271 Mündersbach, Germany Phone: +49 (0)2680.181-0; Fax: +49 (0)2680.181-244 Internet:

www.ewm.de ; E-mail: info@ewm.de

Operating instructions

Transport Vehicle

TROLLY 70-1 TROLLY 70-2; 70-2 DF TROLLY 70-3; 70-3 DF

These operating instructions must be read before commissioning. Failure to do so may be dangerous.

Machines may only be operated by personnel familiar with the appropriate safety regulations.

The equipment complies with

• EC Low Voltage Directive (73/23/EEC)

Table of contents Page

Safety instructions..............................................................................................................................S/1

For your safety............................................................................................................................S/1

Notes on the use of these operating instructions .......................................................................S/2

1 Technical data........................................................................................................................... 1/1

2 Description................................................................................................................................ 2/1

2.1 General............................................................................................................................. 2/1

2.2 Overview ..........................................................................................................................2/2

2.3 Equipment........................................................................................................................ 2/3

3 Assembly / fitting...................................................................................................................... 3/1

3.1 Individual parts ................................................................................................................. 3/2

3.2 Fitting................................................................................................................................ 3/2

4 Commissioning......................................................................................................................... 3/1

4.1 Area of applicat ion ............................................................................................................ 3/1

4.1.1 TROLLY 70-1......................................................................................................... 3/1

4.1.2 TROLLY 70-2 and TROLLY 70-2 DF..................................................................... 3/1

4.1.3 TROLLY 70-3 and TROLLY 70-3 DF..................................................................... 3/1

4.2 Transport/Set-up ..............................................................................................................3/2

4.2.1 Crane transport...................................................................................................... 3/2

4.2.2 Assembly................................................................................................................ 3/2

4.2.3 Installation..............................................................................................................3/3

4.2.4 Procedure............................................................................................................... 3/3

4.3 Fitting units onto the transport vehicle ............................................................................. 3/4

4.4 Fitting wire feed units ....................................................................................................... 3/5

4.4.1 Fitting WELDON DRIVE 4L or PHOENIX DRIVE 4L............................................. 3/5

4.4.2 Fitting WELDON DRIVE 4 or PHOENIX DRIVE 4................................................. 3/5

4.5 Fixing and securing gas cylinders.................................................................................... 3/6

4.5.1 Transport vehicle with one gas bottle .................................................................... 3/6

4.5.2 Transport vehicle with two gas bottles................................................................... 3/6

5 Spare parts list.......................................................................................................................... 4/1

Contents/1

Safety instructions

For Your Safety:

Ignoring the following safety precautions can be fatal. Observe accident prevention regulations. These operating instructions are valid only in conjunction with the relevant safety regulations, especially with accident prevention regulations VBG 9 and operating instructions of one of the welding machines from our product range!

Proper usage

This machine has been manufactured according to the latest developments in technology and current regulations and standards. It is to be operated only for the use for which it was designed (see chapter Commiss ioning/ Ar ea of applic at io n) .

Improper usage

This machine may be a hazard to persons, animals and property, however, if it is

• not used as designed

• used by unskilled persons who have not been trained,

• modified or converted improperly

Our operating instructions will provide you with an introduction into the safe use of the machine. Therefore please read them carefully and only start work when you are familiar with them.

Any person involved in operation, maintenance and repair of this machine must read and follow these operating instructions, especially the safety precautions. Where appropriate, this must be confirmed by signature.

Furthermore, the

• relevant accident prevention regulations,

• generally recognised safety regulations,

• local regulations, etc. must be observed.

Secure gas cylinder

• Place shielding gas cylinders in the holders provided for them and secure with safety

chains or belts.

• Take care when handling cylinders; do not throw or heat, guard against them toppling

over.

• For transport vehicles which can be moved by crane, the gas bottle must be removed

before crane transport.

When moving and setting up the transport vehicle, it is only secure against falling to an angle of 10 additional danger results from obstacles on the floor as these can cause additional tilting moments.

Comprehensive and additional welding safety precautions can be found in the operating instructions for our welding machines. A list of the standards and specifications currently in force can also be found in these instructions.

Repair and modifications may only carried out by authorised, trained, specialist staff. The warranty becomes null and void in the event of unauthorised interference.

°°°°. Special attention should be paid to the fact that, when the machine is moved,

S / 1

Safety instructions

Notes on the use of these operating instructions

Our operating instructions will provide you with an introduction into the safe use of the machine. Therefore please read them carefully and only start work when you are familiar with them.

These operating instructions are arranged into chapters. To help you find your way around more quickly, in the margins you will occasionally see symbols

along with the sub-headings. These symbols refer to particularly important passages of text which are graded as follows depending on their importance:

(Note): Applies to technical peculiarities which must be observed by the user. (Warning): Applies to working and operating procedures which must be carefully

followed to avoid damaging or destroying the machine.

(Caution): Applies to working and operating procedures which must be carefully

followed to avoid endangering people and includes the "Warning" symbol.

Instructions and lists detailing step-by-step actions in given situations can be recognised by bullet points, e.g.:

• Insert plug of welding current lead into socket Meaning of the diagram descriptions:

e.g.

(C1) means: Item C / figure 1 in the relevant chapter

e.g.

(chap. 3, C1) means: in chapter 3 Item C / figure 1

(chap. 5, G2) and lock.

S / 2

1 Technical data

TROLLY 70-1 TROLLY 70-2 TROLLY 70-2DFTROLLY 70-3 TROLLY 70-3

Dimensions (LxWxH) in mm

Weight without accessories

Constructed to standards

1050x500x865 1050x500x1100 1050x500x1100 1050x500x1325 1050x500x1325

approx. 44kg approx. 46kg approx. 49kg approx. 47kg approx. 50kg

EN 60974 / IEC 60974 / VDE 0544 Chap. 14

1/1

2 Description

2.1 General

• Mobile, cranable

• Steady and stable design due to the welded construction

• Building site, assembly and workshop use

• Brackets for all the necessary components

Fig. 2/1 e.g. Trolly 70-2

complete with equipment

Fig. 2/2 e.g. Trolly 70-3 DF

complete with equipment

2/1

2 Description

2.2 Overview

TROLLY 70-1 70-2

70-2 DF

Brackets for the following welding machines, components, incl. torches, tube packages, accessories and filler metals

Welding machine/s

Module/s

Wire feed unit

Gas cylinder/s Option required Opt. PHOENIX 300 holding

plate Opt. TRITON 260 holding plate

Fully fitted; item no.

For fitting; item no.

1) Transport only permitted with one power source and one module; 2) Transport only permitted with one power source and two modules; 3) TRITON 260 without cooling moduel, no holding plate option required

TRITON

260

COOL

30 U20

WELDON/ PHOENIX

DRIVE 4/ DRIVE 4L

092-001651-00000 092-001651-00000 092-001651-00000 092-001651-00000 092-001651-00000

092-001652-00000

090-008103-00000 090-008089-00000 - - 090-008155-00000 090-008156-00000 090-008157-00000 090-008158-00000 090-008159-00000

TRITON,

SIRION:

400, 500;

PHOENIX: 300,

400, 500

- 1 module, e.g. COOL 70 U40 /41 2 modules, e.g. COOL 70 U40 /41 und MULTIVOLT 70-

WELDON/ PHOENIX

DRIVE 4/ DRIVE 4L

1 121 2

--- -

1 power source: E.g. TRITON 400, 500

SIRION 400, 500

PHOENIX 300, 400, 500

70-3

500

WELDON/ PHOENIX

DRIVE 4/ DRIVE 4L

70-3 DF

2/2

2 Description

2.3 Equipment

A1 B1

C1 A1

E1 F1

G1 H1

N1 M1

L1 K1

Fig. 2/3 e.g. Trolly 70-2

Item Description

A1 Fixing points for crane transportation B1 Brackets for wire feed units WELDON DRIVE 4 and PHOENIX DRIVE 4 C1 Hook for holding accessories, such as welding torches D1 Intermediate tube package strain relief E1 Exterior bores for housing the rubber feet, e.g. on the following units:

COOL 71U40/41; MULTIVOLT 70-50 0; TRITO N 400/50 0; SIRION 400 /50 0; PHO ENI X 300/400/500 (chap. 4.3)

F1 Interior bores for housing the rubber feet, e.g. on the following units:

COOL 30U20; TRITON 260 (chap. 4.3)

G1 Guide castors H1 Holding plate with brackets for fixing the units I1 Fixed castors J1 Carrier plate for gas cylinder K1 Securing chain fixing point for gas cylinder L1 Clamping plate for housing the welding machine handle M1 Press arbor retainer N1

Press arbor for housing the wire feed units WELDON DRIVE 4L or PHOENIX DRIVE 4L

2/3

3 Assembly / fitting

3.1 Indivi dual parts

234

Fig. 3/1 Trolly 70-2, disassembled

Fig.3/2 Trolly 70-2, fully fitted

3/1

3 Assembly / fitting

Please check that the parts are complete after unpacking the transport vehicle.

Item Qua

1 2 3 4 5

6, 9

7 8

13, 14

16 17

(not illustrated) (not illustrated) (not illustrated) (not illustrated)

Description

ntity

Star handle

Wire feed carrier plate

Press arbor socket

Press arbor

DV302 holder plate

M8X10 hexagonal socket screw, black galvanised

Standard clamping plate

Tube B high (TROLLY 70-1)

Tube B medium (TROLLY 70-2 / 70-2 DF) Tube B high (TROLLY 70-3 / 70-3 DF)

1 Cylinder holder

M8X15 self-locking hexagongal screw

Base assembly, fully fitted with wheels, holding plate, cylinder base

Tube A high (TROLLY 70-1)

Tube A medium (TROLLY 70-2 / 70-2 DF) Tube A high (TROLLY 70-3 / 70-3 DF) Rubber blank

Gas cylinder securing chain

1-2

Tube guide (TROLLY 70-2 DF / 70-3 DF only)

Cylinder guide (TROLLY 70-2 DF / 70-3 DF only)

3.2 Fitting TROLLY 70-1; 70-2; 70-3

• Loosely screw cylinder holder (11) to the base assembly (16) [(12) thread] using the M8X15 self-locking hexagonal screws (13).

• Insert one tube A (17) and B (8) through the tube guides (10) on the cylinder holder (11) into the holes (15) on the base assembly (16) and screw on loosely using the M8X15 self-locking hexagonal screws (14).

• Screw the wire feed carrier plate (2) using the M8X10 hexagonal screws (6) and the DV302 holder plates (5) onto the tubes already fitted. The position of the holder plates (5) (angle section up or down) depends on the wire feed case to be transported (chap. 4.4).

• Connect the second tube A (17) to the tube B (8) already fitted and the second tube B (8) to the tube A (17) already fitted and screwn on loosely to the base assembly (16). (Fig. 3/1).

• Tighten all loosely fastened screws.

• Screw the fitted tubes to the tube guides (10) using the M8X10 hexagonal screws (9) and

tighten.

• Affix the rubber blank (not illustrated) onto the wire feed carrier plate (2).

• Insert the press arbor socket (3) into the relevant hole in the wire feed carrier plate (2).

• Insert the press arbor (4) into the fitted socket (3).

• Screw the clamping plates (7) onto the wire feed carrier plate (2) using the star handles (1).

After assembly, check that all the screws and connections are tightly secured. Ensure that the correct clamping plates (7) for the equipment being fitted have been used (chap. 2.2 and chap. 4.3). The procedure for fitting the holder plates (5) depends on the wire feed case being transported (chap. 4.4)

3/2

4 Commissioning

4.1 Area of application

4.1.1 TROLLY 70-1

• Transport of TRITON 260 + COOL 30 U20 + WELDON DRIVE 4/4L or TRITON 400/500,

SIRION 400/500 and PHOENIX 300/400/500 + PHOENIX DRIVE 4/4L only

This produces the following possible combinations:

TRITON 260 XXXX COOL 30 U20 X X Opt. TRITON 260 holding plate X X WELDON DRIVE 4 / 4L X X

TRITON 400/500, SIRION 400/500, PHOENIX 400/500 X X WELDON or PHOENIX DRIVE 4 / 4L X PHOENIX 300 X Opt. PHOENIX 300 holding plate X

• Bracket for one gas cylinder (chap.2, J1 and chap. 4.5)

• Brackets for all the necessary additional components:

Welding torches, hose assemblies, accessories and filler metals

4.1.2 TROLLY 70-2 and TROLLY 70-2 DF

• Exclusive transport of:

TRITON 400/500; SIRION 400/500; PHOENIX 300/400/500 + COOL 71 U40/41 or MULTIVOLT 70-500 + WELDON or PHOENIX DRIVE 4 / 4L

This produces the following possible combinations:

TRITON 400/500; SIRION 400/500; PHOENIX 400/500 X X COOL 71 U40 / 41 or MULTIVOLT 70-500 X X X WELDON or PHOENIX DRIVE 4 / 4L X PHOENIX 300 X Opt. PHOENIX 300 holding plate X

• Bracket for one gas cylinder (TROLLY 70-2) (chap.2, J1 and chap. 4.5) or

for two gas cylinders (TROLLY 70-2 DF)

• Brackets for all the necessary additional components:

Welding torches, hose assemblies, accessories and filler metals

4.1.3 TROLLY 70-3 and TROLLY 70-3 DF

• Exclusive transport of:

TRITON 400/500; SIRION 400/500; PHOENIX 300/400/500 + COOL 71 U40/41 + MULTIVOLT 70-500 + WELDON or PHOENIX DRIVE 4 / 4L

This produces the following possible combinations:

TRITON 400/500; SIRION 400/500; PHOENIX 400/500 X X COOL 71 U40 / 41 X X X MULTIVOLT 70-500 X X X WELDON or PHOENIX DRIVE 4 / 4L X PHOENIX 300 X Opt. PHOENIX 300 holding plate X

• Bracket for one gas cylinder (TROLLY 70-3) (chap.2, J1 and chap. 4.5) or

for two gas cylinders (TROLLY 70-3 DF)

• Brackets for all the necessary additional components:

Welding torches, hose assemblies, accessories and filler metals

4/1

4 Commissioning

4.2 Transport/set-up

The points listed in chapters 4.2.1, 4.2.2, 4.2.3 und 4.2.4 are examples only. More detailed information can be found in the general and specific safety and accident

prevention regulations.

4.2.1 Crane transport

• The transport vehicles can be transported by crane by attaching the lifting lugs to the fixing

points (fig. 4/1).

Use only these fixing points for lifting by crane.

• Before crane transport remove the gas cylinder

from the transport vehicle.

• Before crane transport, remove wire feed unit

from transport vehicle.

• If the transport vehicle has to be moved with

the wire feed unit, ensure that the unit is sufficiently well attached and secured.

• The wire coil must always be removed when

moving the machine with a crane, with the wire feed unit attached.

• When moving the machine with a crane with

the wire feed units WELDON DRIVE 4L or PHOENIX DRIVE 4L attached, ensure that the press arbor (chap.2, N1) is removed from the bracket (chap.2, M1) before attaching and securing the unit.

Fig. 4/1

• During crane transport no-one should be standing under the suspended load.

• Before lifting it must be ensured that all the fixing points are securely assembled.

• Before and after lifting, check that the snap closures between the cooling unit and

welding machine are sitting properly.

• Before and after lifting, check that the holding plates for fixing the units to the transport

vehicle are correctly positioned.

• The clamping plates for housing the welding machine handle must be securely

attached.

• All loose parts such as accessories and welding torches are to be removed from the

transport vehicle before lifting.

•

Only use undamaged cables for lifting.

• Do not raise or lower the load suddenly.

4.2.2 Assembly

Risk of injury when assembling the machines on the transport vehicles.

• Avoid the risk of injury by careful, prudent and foresighted actions during assembly

onto the transport vehicle.

• First fit the cooling module, then the welding machine and lastly the wire feed case.

• For WELDON and PHOENIX DRIVE 4L wire feed units, the angle section of the A2 rail

should be fitted so that it points downwards (fig. 4/7). Otherwise there is a risk of injuries from crushing when the wire feed units are rotating.

• For housing WELDON and PHOENIX DRIVE 4 wire feed units, the angle section of the

A2 rail should be fitted so that it points upwards (fig. 4/9).

• Always use original accessories and spare parts.

4/2

4 Commissioning

4.2.3 Installation

The transport vehicle must be installed on a firm base.

4.2.4 Procedure

• Do not position on uneven surfaces.

• The floor must not be at an angle and must be level.

• When moving and setting up the transport vehicle, it is only secure against falling to an

angle of 10

• Caution is required on a sandy, loamy, soft, wet or slippery base.

• Avoid projecting parts such as accessories and torches. There is the risk of becoming

caught on the machine, e.g. people passing by.

• Do not place on glowing slag or caustic liquids, or the wheels could be damaged.

The following points must be noted when using the transport vehicle:

• When moving and setting up the transport vehicle, it is only secure against falling to an

angle of 10

• Prudent behavior is a necessity when using the transport vehicle.

• Before using the transport vehicle, ensure that all fixing points are securely attached.

• Before and after lifting, check that the snap closures between the cooling unit and

welding machine, and the holding plates for fixing the units to the transport vehicle, are correctly positioned.

• The clamping plates for housing the welding machine handle must be securely

attached.

• Caution: The centre of gravity of the loaded transport vehicle changes according to the

load, e.g. with different sizes of gas cylinders.

• Do not use sloping routes when pushing the transport vehicle.

• The base on which the transport vehicle is moved must be level, firm and dry. If the

base is uneven (e.g. ground beams) an additional securing device specific to the wire feed unit must be fitted. Caution is required on a sandy, loamy, soft, wet or slippery base.

• The route to be travelled by the transport vehicle should be checked for obstacles

beforehand. Sufficient space must be ensured, particularly in narrow passages, such as doors. When using the transport vehicle there is a risk from objects on the ground, because additional tilting moments may arise.

• Ensure that projecting parts such as accessories or welding torches do not become

caught when pushing past obstacles.

• If large gas cylinders in particular are assembled on the transport vehicle, the forces to

be applied when using should be estimated correctly.

• When pushing the transport vehicle keep both hands on the handles.

• Do not move over glowing slag or caustic liquids, or the wheels could be damaged.

• The chains for fixing the gas cylinders must always be hung correctly on the hooks

provided for them and must by lying firmly against the gas cylinders.

°°°°.

4/3

4 Commissioning

4.3 Fitting units onto the transport vehicle

For the combination options for assembling machines and modules (e.g. COOL 30 U20 or MULTIVOLT 70-500) in relation to the different transport vehicles, please see the tables in chap. 4.1

A1 B1

Fig. 4/2

D1 A1

A1 C1

Fig. 4/3

Assembling the welding machine or module

• Place the welding machine or module (e.g. COOL 30 U20 or COOL 71 U40/41) in the

corresponding holes using the rubber feet: Place the TRITON 260 or COOL 30 U20 into the inner holes B1. Place TRITON 400/500, SIRION 400/500 and PHOENIX 300/400/500 or COOL 71 U40/41 and MULTIVOLT 70-500 in the outer holes A1.

• Hook holding plate C1 into the relevant recesses on the machine

(fig. 4/3) and screw tight using the rotary handles D1.

• Fit the clamping plates (fig. 4/4; E1) using the relevant recesses on the welding machine

handle and tighten using the rotary handles (see fig. 4/4 and fig. 4/5)

Assemble the welding machine with module/s

• Place the module with the rubber feet into the corresponding holes (fig. 4/2)

Place COOL 30 U20 into the inner holes B1. Place COOL 71 U40/41 or MULTIVOLT 70-500 into the outer holes A1.

• Fit the welding machine onto the module using the snap closures located on the module.

• Fit the clamping plates (fig. 4/4; E1) using the relevant recesses on the welding machine

handle and tighten using the rotary handles (see fig. 4/4 and fig. 4/7; B2)

Before and after assembly work check the snap closures are properly located. For transport with the TROLLY 70-2 / 70-2 DF, one module and for the TROLLY 70-3 / 70-3 DF two modules must be assembled in addition to the welding machine. When transporting the TRITON 260 + COOL 30 U20 with the transport vehicle TROLLY 70-1 or PHOENIX 300 with the transport vehicles TROLLY 70-1; 70-2 / 70-2 DF (+1 module) or TROLLY 70-3 / 70-3 DF (+2 modules) special optional holding plates (clamping plates) are required. (chap. 2.2 and chap. 4.1)

Fig. 4/4

4/4

4 Commissioning

4.4 Fitting wire feed uni ts

For WELDON and PHOENIX DRIVE 4L wire feed units, the angle section of the A2 holder plate should be fitted so that it points downwards (fig. 4/7). Otherwise there is a risk of injuries from crushing when the wire feed units are rotating.

For housing WELDON and PHOENIX DRIVE 4 wire feed units, the angle section of the A2 holder plate should be fitted so that it points upwards (fig. 4/9).

• Insert the end of the tube package on the wire feed unit through the strain-relief (fig. 4/7) and

lock by turning to the right (fig. 4/8).

Fig. 4/5

4.4.1 Fitting WELDON DRIVE 4L or PHOENIX DRIVE 4L

Fig. 4/7

• The wire feed unit should be fitted with the retainer located on the base plate on the pin plug

C2 (fig. 4/7 and fig. 4/8).

4.4.2 Fitting WELDON DRIVE 4 or PHOENIX DRIVE 4

Fig. 4/6

Fig. 4/8

Fig. 4/9

• Position the wire feed unit on the relevant rails A2 (fig. 4/9 and fig. 4/10)

4/5

Fig. 4/10

4 Commissioning

4.5 Fixing and securing gas cylinders

• Position the gas cylinders on the carrier plate (chap.2; J1)

• Secure the gas cylinders with the chains (chap.2; K1)

• Ensure that the chains are positioned securely against the gas cylinders.

Large cylinders with 50 l and 300 bar are generally not permissible.

TROLLY 70-1

20L gas cylinder, max. 200bar

20L gas cylinder, max. 300bar

50L gas cylinder, max. 200bar

50L gas cylinder, max. 300bar Not normally permissible!

1x 1x 1x - 2x 1x 1x - 2x 1x 1x 1x - 2x 1x 1x - 2x 1x 1x 1x - 2x 1x 1x - 2x

TROLLY 70-2

TROLLY 70-2 DF

TROLLY 70-3

TROLLY 70-3 DF

4/6

5 Spare parts list

8 7

5/1

1420

Fig. 4/1 TROLLY 70-2

5 Spare parts list

Item Quan

tity

1 1 1 2 3 4 5 6 7 8 8 8

9 10 11 12 12 13 13

13 14 15 15 16 17 19 20

ohne

Abb.

ohne

Abb.

ohne

Abb.

ohne

Abb.

2 094-007608-00002 Tube A low 2 094-007523-00005 Tube A medium 2 094-007910-00000 Tube A high 1 094-007522-00002 Base plate 2 094-000327-00000 Guide castor

8 064-000562-00000 M8X15 self-locking hexagonal screw 10 094-001125-00 000 M8X16 loc k ing sc rew 10 064-000560-00000 M8 lock-tooth nut

2 094-007524-00000 Machine holder plate

2 094-007607-00002 Tube B low

2 094-007519-00005 Tube B medium

2 094-007911-00000 Tube B high

2 094-007598-00000 DV302 holder plate

8 094-007573-00001 Star handle

1 094-007520-00003 WF carrier plate

1 094-000141-00011 Cylinder base

1 094-007917-00000 Cylinder base (similar to diagram)

2 094-007597-00001 Standard clamping plate

2 094-007606-00001 Special clamping plate for TRITON 260 with

2 094-008104-00000 Special clamping plate for PHOENIX 300

2 094-000179-00000 Wheel

1 094-007521-00004 Bottle holder

1 094-007918-00000 Bottle holder (similar to diagram)

1 094-007483-00003 Press arbor

1 094-007371-00002 Press arbor socket 10 094-000724-00000 M8X10 black galvanised hexagonal screw

2 094-000213-00000 Wheel fastening

1 094-007600-00000 Rubber blank

1-2 094-000178-00000 Chain

2 094-007941-00000 Tube guide

2 094-007919-00000 Cylinder guide

Item No. Description

cooling module

TROLLY 70-1

TROLLY 70-2

TROLLY 70-2 DF

TROLLY 70-3

TROLLY 70-3 DF

XX XXXXX XXXXX XXXXX XXXXX XXXXX XXXXX X

XX XXXXX XXXXX XXXXX XX X

XX XXXXX X

XX XXXXX XX X

XX XXXXX XXXXX XXXXX XXXXX XXXXX

XXXXX

5/2

EWM TROLLY 70-1, TROLLY 70-2, TROLLY 70-2 DF, TROLLY 70-3, TROLLY 70-3 DF Operating Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of contents Page

Safety instructions

1 Technical data

2 Description

3 Assembly / fitting

4 Commissioning

5 Spare parts list
