evoheat JBOX User Manual

JBOX
MANUAL

SAVING YOU MONEY ON WATER PUMPS & RUNNING COSTS

JBOX INSTALL GUIDE

EVOHEAT JBOX SCHEMATIC

NOTES:

CONNECT ACTIVE TO UNIT ACTIVE
CONNECT PUMP TO PUMP TERMINAL 1
CONNECT NEUTRAL TO PUMP TERMINAL 2

NOTE: heat pump, Jbox and water pump all on the same circuit

EVOHEAT ELECTRICAL CONNECTION

IMPORTANT: A licensed electrician must read the information in this manual before commencing

• Ensure power is disconnected from all equipment during installation or service

• Always comply with the national and local electrical codes and standards

• IMPORTANT: Ensure electrical cable size is adequate for requirements at the installation location. The

Heat pump may come supplied with a 10amp or 15 amp plug. When wiring up the J-Box to the heater you

will need to take into account the total draw from the heat pump and water pump. You may need to

remove the 10/15amp plug and hardwire into a larger circuit for the heat pump and water pump.

EVOHEAT JBOX WIRING CONNECTIONS

Wire up heat pump to mains power at L,N, and Earth on the Mains input terminals on heat pump as per image below.

Wire up EvoHeat JBox connections as per JBox image below. L terminal on the heat pump should have 2 cables

connected (1 to power supply and 1 to the JBox).

Connect 1 (water pump active) to the location on JBox shown below (right hand side of small terminal block)

Connect 2 (water pump neutral) on the heat pump terminal block to the blue terminal strip on the JBox

Connect earth terminals from both units

EVO INDUSTRIES AUSTRALIA PTY LTD

P: 1300 859 933 FAX: [phone]
E: [e-mail]
www.evoheat.com.au

JBOX WARRANTY

For further peace of mind the EvoHeat JBox comes with a 1 year warranty.
