e-GeForce 6800 Ultra
256MB DDR3 TV-Out PCI-E
AT A GLANCE
• 256-bit GeForce 6800 Ultra (400MHz clock)
• 256MB 256-bit 1.6ns (8x32) DDR3 Memory
(550MHz clock - 1.1GHz effective)
• PCI Express x16 Compatibility
(PCI Express Compliant)
• Integrated NVIDIA TV Encoder (S-Video)
• Dual DVI-I Connectors
• 35.2 GB per second memory bandwidth
3D FEATURES
256-P2-N377
www.evga.com - The Definitive VGA Online Community
e-GeForce 6800 Ultra 256MB DDR3 TV-Out PCI-E
• Superscaler 16-pipe architecture
• CineFX 3.0 Engine
• UltraShadowII T echnology
• 64-bit texture filtering and blending
• Intellisample 3.0 T echnology
• SLI Multi-GPU Ready
• 128-bit Studio precision computation
• Full speed 32-bit color precision
RESOLUTION CHART
8-Bit 16-Bit 32-Bit
640 x 480 240Hz 240Hz 240Hz
800 x 600 240Hz 240Hz 240Hz
1024 x 768 240Hz 240Hz 200Hz
1152 x 864 200Hz 200Hz 170Hz
1280 x 960 170Hz 170Hz 150Hz
1280 x 1024 170Hz 170Hz 150Hz
1600 x 1024 120Hz 120Hz 100Hz
1600 x 1200 120Hz 120Hz 100Hz
1920 x 1080 100Hz 100Hz 85Hz
1920 x 1200 100Hz 100Hz 85Hz
1920 x 1440 85Hz 85Hz 75Hz
2048 x 1536 75Hz 75Hz 60Hz
Refresh rates shown are the highest obtainable and are
monitor dependent. Resolutions, pixel depths and refresh
rates are driver dependent and may not be available in
all applications or operating system.
*Patent Pending. Property of eVGA.com Corp.
2900 Saturn Street, Suite B Brea, CA 92821
Phone: (888) 881-eVGA Fax: (714) 528-4501
OTHER FEATURES
• NVIDIA nView™ multi-display technology
• NVIDIA Video Processing Engine (VPE)
• Integrated Dual 400MHz RAMDACs
• Advanced Adaptive De-Interlacing
• NVIDIA Digital Vibrance Control™ (DVC) 3.0
• 64-phase Video Scaler
• T rue color 64x64 hardware cursor with alpha
• Optimized for 32, 24, 16, 15 and 8-bpp modes
• Dual Single-Link DVI Support
• Integrated Full-Hardware MPEG Support
DRIVER SUPPORT
• AutoInstaller with ADM* T echnology
• ResChanger©
• NVIDIA Unified Driver Architecture (UDA)
(Windows 98/ME/NT 4.0/2000/XP)
• Direct Draw • Direct3D
• DirectVideo • DirectX
• Full OpenGL ICD for All Supported Operating
Systems
DIMENSIONS
• height: 3.88in - 88.4mm
• length: 8.5in - 215.9mm
