Page 1
• 2 SATA III 6.0Gb/s Ports, 6 SATA II 3.0Gb/s Ports with Support
for RAID 0, RAID 1, RAID 0+1, RAID 5 JBOD
• 2 Gigabit Ethernet Ports (10/100/1000)
• 8 Channel High Definition Audio
• 2 USB 3.0/2.0 Ports, 12 USB 2.0 Ports (8 I/0, 4 Internal
)
• Supports Intel
®
CoreTM i7 1366 Processors
• Intel® X58/ICH10R Chipset
• 6 DIMM Triple-Channel DDR3 1600MHz+ (up to 24GB)
• Supports 2-way SLI® and 3-way SLI
®
or CrossFireXTM
KEY SPECS
8
V
EVGA Vdroop Control -
Improves overclocking
stability
EVGA Dummy OC -
Overclocking at the touch
of a button
EVGA E-LEET Tuning Utility -
Enthusiast software for adjusting
overclocking in O.S.
EVGA EZ Voltage Read Points -
Easily read voltage levels with
dedicated read points
Onboard Clear CMOS, Power,
and Reset Buttons -
System essentials
at the touch of a button
Passive Chipset Heatsink -
No fans, lower noise,
longer lifespan
EVGA EVBot Support -
Next generation handheld
overclocking device from EVGA
100%
100% Solid State Capacitors -
Higher quality, longer lifespan
• EVGA Driver Installation CD with
EVGA E-LEET
• Rear Case I/O Panel
• 6 SATA Data Cables
• 3 SATA Power Cables
• 2-way and 3-way SLI Bridge
• 2 Port USB/1394a Fi• 2 Port USB/1394a Firewire Bracket
• Visual Installation Guide
• Manual
ACCESSORIES
DIMENSIONS
• Width: 9.6in – 243.8mm
• Length: 12in – 304.8mm
• Form Factor: ATX
• Weight: 4.75 lbs.
This EVGA product has a 3 year limited warranty upon product registration.
For more information please visit: www.evga.com/warranty
PRODUCT WARRANTY
The EVGA X58 FTW3 Motherboard brings all the performance from the award-winning EVGA X58
lineup and now includes USB 3.0 and SATA III 6Gb/s!
The EVGA enthusiast board layout makes sure 2-way and 3-way SLI® configurations are compatible
with all chassis, and award winning overclocking features make this board the perfect choice for any
performance enthusiast. With all these features and much more, it's no wonder why EVGA products
are for those who demand no less than the ultimate in performance!
Part Number:
132-GT-E768-KR
X58 FTW3
