Everten 685305 User manual

ICY ICE MAKER 12KG

Owner’s Manual

IMPORTANT

Read and follow all warnings and instructions before

assembly and use. Keep this manual for future reference.

SPECIFICATIONS

• Model number: 685305

• Voltage: 220 - 240V ∿ 50/60Hz 1.5A

• Power consumption: 150W

• Refrigerant type R600a - 41g Climate class: T

• Bullet size :

◊ Big size cube: 22x32mm
◊ Small size cube: 18x30mm

• Measurement: 288*255*262mm

• Product weight: 5.6 kg

PRODUCT FEATURES

This little beast cranks out a cool 12kg of ice every 24 hours, with a fresh batch ready
every six minutes! Whether you’re feeling small or large bullet ice, it’s got you covered
for whatever drink tickles your fancy.

• Makes 12kg of bullet ice every 24 hours

• Two sizes for small or large ice

• Super simple control panel, water shortage and ice full alerts

• Compact and portable design

SAFETY PRECAUTIONS

When using this electrical appliance, basic safety precautions should always be

followedtoreducetheriskofre,electricshock,and/orinjury,includingthefollowing:

1. Read all instructions before using.

2. Ensure the voltage is compliant with the voltage range stated on the rating label.

3. If the electrical cord is damaged, it must be replaced by the manufacturer or its

serviceagentorasimilarlyqualiedpersoninordertoavoidahazard.

4. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.

5. Children should be supervised to ensure that they do not play with the appliance.

EVERTEN ICY ICE MAKER 12KG • OWNER’S MANUAL 2

6. This appliance is intended to be used in household and similar applications such as:

A.Staffkitchenareasinshops,ofcesandotherworkingenvironments.

B. Farmhouses.
C. By clients in hotels, motels and other residential type environments.
D. By bed and breakfast type environments.

7. To protect against electric shock, do not place the cord, plug or the base of the
appliance in water or any other liquid.

8. Do not use attachments or accessories which are not recommended by the
manufacturer.

9. The product is only suitable for the purpose indicated in this manual. Do not use
this product or any part for other purposes. If it is operated incorrectly, it may cause

injury.

10. This appliance features a compressor. To ensure optimal performance and prevent
damage, please allow the appliance to stand upright for at least two hours before

rstuse.Thisstepisessential,astheappliancemayhavebeenstoredupsidedown

during shipping.

11. Do not upend this product or incline it over a 45° angle.

12. Placetheicemakeronasteady,atsurface,30cmfromotherobjectsandthewall
to ensure heat is easily released.

13. Donotusetheicemakerclosetoames,hotplatesorstoves.

14. Do not use outdoors.

15. Do not place anything on top of the appliance while in operation or when storing.

16. Always empty any water or ice from the ice maker and dry completely before
storing.

EVERTEN ICY ICE MAKER 12KG • OWNER’S MANUAL 3

Get to know the Everten Express Digital Air

GET TO KNOW THE EVERTEN ICY ICE MAKER

4

3

2

1

1. On/off button

2. Ice cube select button

3. Control panel indicators:
A. Small ice indicator
B. Large ice indicator

C. Ice full indicator
D. Add water indicator

4. Ice basket

5. Cover

6. Air outlet

7. Ice scoop

8. Detachable AC cord

9. Water drain cap (located at the

lower left rear of the unit)

5

7

6

9

8

EVERTEN ICY ICE MAKER 12KG • OWNER’S MANUAL 4

BEFORE FIRST USE

1. Beforeusingtheapplianceforthersttime,pleasewaittwohoursafter
positioning it, and keep the front lid open for at least two hours.

2. Remove all packing material and check your appliance to ensure it is in good
condition.

3. The appliance should be placed horizontally on a level surface. To ensure
proper ventilation, position it 30cm away from the wall and other appliances

andobjects.

4. Do not install the appliance near an oven, radiator, or any other heat source.

5. Ensurethewaterdraincapisrmlyinserted.

OPERATING INSTRUCTIONS

1

Lift the cover, remove

the ice basket, and ll

the water tank without
exceeding the MAX mark

(please refer to Fig. A).

Reinsert the ice basket

and close the cover. Plug
in the ice maker. Press the

power button to start the

ice making process.

3

If there is a water shortage
while the ice maker is
operating, it will stop
automatically, and the
add water indicator will
light up. Fill the water tank
with clean water (without
exceeding the MAX mark),
and the ice maker will
restart automatically.

2

The default ice size is set
to large, indicated by the
blinking light. After powering
on, press the select button
to adjust the ice size. If the
room temperature is below
15°C, it’s advisable to choose
the small setting to prevent

ice cubes from sticking

together.

4

The ice maker will
automatically stop when

the ice basket becomes

full. The ice full indicator
will light up to alert you.

EVERTEN ICY ICE MAKER 12KG • OWNER’S MANUAL 5

Figure A

CLEANING AND MAINTENANCE

1. Always unplug the appliance before cleaning.

2. Remove the ice basket to clean the water tank.

3. Use a mild detergent mixed with warm water to clean the tank and basket.

4. Remove the drain cap to drain out any remaining water. Leave it open to store.

5. Wipe the exterior with a mild detergent and warm water.

6. Dry all parts with a soft cloth before storing.

7. Always drain all water and dry the inside thoroughly before storage to avoid mould.

8. Vacuum the air vents on the back and sides monthly to remove dust and lint. This

helpsmaintainthemotor’sefciency.

TROUBLESHOOTING

Here are some possible issues with your ice maker and solutions for troubleshooting.
If problems persist or the machine is seriously damaged, please contact Kitchen
Warehouse Customer Service for assistance.

Issue Possible cause Solution

The unit does not
operate

EVERTEN ICY ICE MAKER 12KG • OWNER’S MANUAL 6

No power supply. Check your power source. Ensure

220 - 240V ∿ 50/60Hz supply.

Household fuse or circuit
breaker tripped.

Power cord not properly
connected.

Reset fuse or breaker.

Ensure the cord is securely plugged
into the outlet.

Issue Possible cause Solution

The add water
indicator
illuminates

The ice full
indicator
illuminates

Ice cubes stick
together

Ice making cycle
seems normal but
no ice

Add water and
ice full indicators
blinking

Water shortage. AddwateruptotheMAXllmark

on the water tank.

Ice basket is full. Remove ice from the basket.

Ice making cycle too
long.

Water temperature too
low.

Ambient or water
temperature too high.

Turn the unit off and on again.
Select the small ice size if needed.

Replace water (7°C to 32°C
recommended).

Operate in room temp below 32°C.
Use water between 7°C to 32°C.

Refrigerant leakage. Contact Kitchen Warehouse

Customer Service.

Cooling system pipe
blocked.

Ice stuck in ice making
box.

Contact Kitchen Warehouse
Customer Service.

Turn off, remove stuck ice, and
restart the unit.

Mechanical failure. If unresolved, unplug for two

minutes and restart. If the
problem persists, contact Kitchen
Warehouse Customer Service.

Components may be
damaged.

EVERTEN ICY ICE MAKER 12KG • OWNER’S MANUAL 7

Contact Kitchen Warehouse
Customer Service.

WARRANTY

Get in touch with Customer Service

If you experience any issues with your Everten Icy Ice Maker, get in touch with our
Customer Service team by email at [email protected] or
by phone on 1800 332 934 between the hours of 9am and 7pm (AEST) Monday to Friday.
Alternatively you can use the Live Chat function on our website by visiting
www.kitchenwarehouse.com.au/contact-us

90 day money back guarantee

Wepromiseyouafullrefundwithin90daysifyourEvertenproductdoesnotfullyour
expectations.ThisguaranteeappliestoqualiedpurchasesofallEvertenbranded

products from participating stockists online and in-store from eligible delivery locations.

Thequaliedproductmustbereturnedwithin90daysfromthedateofpurchase.We

shall issue a full refund when the customer presents proof of purchase. We shall issue
a store credit when proof of purchase is unavailable. The product packaging is not
required to avail of the refund. The amount refunded will be the price of the products in
the currency shown on the proof of purchase.

Warranty

Our goods come with guarantees that cannot be excluded under the Australian

ConsumerLaw.Youareentitledtoareplacementorrefundforamajorfailureand

for compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable

qualityandthefailuredoesnotamounttoamajorfailure.

Thebenetsofthiswarrantyareinadditiontoanyrightsandremediesimposedby

Australian State and Federal legislation that cannot be excluded. Nothing in this warranty

excludes,restrictsormodiesanyStateorFederallegislationapplicabletothesupplyof
goodswhichcannotbesoexcluded,restrictedormodied.

Guarantee

Wewarrantthat,subjecttotheexclusionsandlimitationsbelow,theProductwillbefree

from defects in materials and workmanship under normal domestic household use for
the 12 month warranty period. The warranty period commences on the date of sale by
the original retailer to the original purchaser. The warranty applies only while the Product
is owned by the original purchaser.

Use of the Product in a commercial capacity will void this warranty. If a defect appears

intheProductbeforetheendofthewarrantyperiodandwendtheProducttobe

defective in materials or workmanship, we will replace the Product with a product
comparable in quality and value.
We reserve the right to change or discontinue our product ranges at any time without
notice and without liability.

EVERTEN ICY ICE MAKER 12KG • OWNER’S MANUAL 8

Exclusions

This warranty does not apply if proper care and/or usage instructions are not
followed. This warranty does not cover scratches, stains, discoloration or damage
caused by misuse.

How to claim

Ifafault/defectisidentiedceaseusingtheProductimmediately.Tomakeaclaim

on this guarantee, take the Product, proof of purchase and full details of the alleged
defect to any Kitchen Warehouse store.

Limitations

We make no express warranties or representations other than as set out in this
guarantee. The replacement of the Product or the refund of the purchase price is the
absolute limit of our liability under this guarantee.

Distributed by Kitchen Warehouse.
Everten is a registered trademark of Kitchen Warehouse Pty Ltd. The printed material
appearing in this document and related packaging is protected by copyright.

Kitchen Warehouse Pty Ltd

1 Pensioner Guard Road
North Fremantle, WA, 6159
www.kitchenwarehouse.com.au
1800 332 934

[email protected]

EVERTEN ICY ICE MAKER 12KG • OWNER’S MANUAL 9
