B E N E F I T S
A P P L I C A T I O N / S I Z I N G
I N S T A L L A T I O N T I P S
O P E R A T I O N T I P S
S-54 Cartridge
Delivers premium quality water for drinking water applications
S-54 Cartridge: EV9720-06
S-54 Cartridge: EV9720-06
Finely polishes treated water to premium quality
for drinking
Precoat submicron technology reduces dirt and
particles as small as 1/2 micron in size
Reduces health contaminants such as
Cryptosporidium and Giardia cysts
Does not remove fluoride
Sanitary cartridge replacement is simple, quick
and clean. Internal filter parts are never exposed
to handling or contamination
NSF Certified under NSF/ANSI Standards 42
and 53
Never use saddle valve for connection
Use 3/8” water line
Install vertically with cartridge hanging down
Allow 2-1/2” clearance below the cartridge for
easy cartridge replacement
Flush cartridge by running water through
filter for three minutes at full flow
Change cartridges on a regular 12 month
preventative maintenance program
Change cartridges when capacity is reached or
when pressure falls below 10 psi
Service flow rate must not exceed 0.5 gpm
Always flush the filter cartridge at time of
installation and cartridge change
For drinking water applications
Rated Capacity: 750 gallons (2,835L)
EV9720-06
S-54 Cartridge
Overall Dimensions:
10.25”H x 3.25”D
Service Flow Rate:
Maximum 0.5 gpm (1.9 Lpm)
Rated Capacity: 750 gallons (2,835L)
Pressure Requirements:
10 psi -125 psi (0.7 – 8.6 bar), non-shock
Maximum Temperature:
35°F - 100°F (2-38°C)
No electrical connection required
The contaminants or other substances
removed or reduced by this drinking water
system are not necessarily in your water. Do
not use with water that is microbiologically
unsafe or of unknown quality without
adequate disinfection before or after the
system. Systems certified for cyst reduction
may be used with disinfected water that may
contain filterable cysts.
Everpure
1040 Muirfield Drive
Hanover Park, IL 60133
Everpure water treatment systems (excluding replaceable elements)
are covered by a limited warranty against defects in material and
workmanship for a period of five years after date of purchase.
Everpure replaceable elements (filter cartridges and water treatment
cartridges) are covered by a limited warranty against defects in
material and workmanship for a period of one year after date of
purchase. See printed warranty for details. Everpure will provide a
copy of the warranty upon request.
