Everpure CGCL1 User Manual

Commercial Grade Water Chiller
Model CGCL1

Installation and Operating Guide

SPECIFICATIONS

Remote type, electric refrigerated, water chiller unit. Chilling capacity of

1.3 gallons per hour of 50°F drinking water, based upon 80°F inlet water
and 90°F ambient. (A.R.I. Standard Ratings).
Compact, highly efficient water chiller units are designed for use with
any drinking water faucet. Installs directly under kitchen counter, in
well-ventilated cabinet.

NO LEAD DESIGN

THIS WA TER CHILLER COMPLIES WITH THE LEAD-FREE
DEFINITION IN THE SAFE DRINKING WA TER ACT OF 1986
AND LEAD CONTAMINA TION CONTROL ACT OF 1988.

This Water Chiller is manufactured with a waterway system utilizing
stainless steel components and completely lead-free materials. These
waterways have no lead because all lead-containing materials, such as
leaded brass, have been removed. All joints are brazed using silver
solder only. No lead solder is permitted. Ideal for use with filter treated
water, domestic water supply or reverse osmosis systems.

This water chiller is classified by Underwriters Laboratories
Inc. in accordance with NSF/ANSI 61-2002e.

Inlet

Base
Rate

Water

Temp

(°F)

70

80

90

Model

Number

CGCL1 1.3 155 1.7 35

Rated watts shown are based on operational (run) time, in accordance with ARI
Standard 1010 conditions. Specific applications will determine the actual watts
consumed per hour. Watts consumed will be based on number of people served
per hour (usage), ambient temperatures, and inlet water temperature.

Multiple-outlet capacities. Service to 1 station only.

GPH of 50°F Drinking Water

Room Temperature °F

70

1.5

1.1

9080

1.82.02.1 1.6

1.31.4

.91.0

100

1.2

.8

Watts
Rated

Full

Load

Amps

COOLING SYSTEM

Motor Compressor: Hermetically sealed, reciprocating type,

1/18 HP, 115VAC, 60Hz single phase. Sealed in lifetime oil supply.

Power: Rated 1.7 Amps; 155 watts
Condenser: Fan cooled, copper tube with aluminum fins. Fan motor is

permanently lubricated.
Cooling Unit: Combination tube-tank type. Evaporator cooling coil of

continuous copper tubing. Tank is stainless steel. Tank volume is 0.7
gallons. All water contact surfaces are stainless steel. Fully insulated.

CGCL1 Remote Chiller

Ship

Wt.

Lbs.

CONSTRUCTION

Cabinet: Rust-resistant, galvanized steel.
Drain Plug: This chiller is provided with a plastic drain plug which

incorporates an o-ring seal. This fitting is designed for potable
water applications and should be replaced with a suitable fitting if
chiller is used with more aggressive liquids.

5 YEAR LIMITED WARRANTY on the refrigeration system of the
unit. Electrical components and water system are warranted for 12
months from date of installation. Warranty pertains to drinking
water applications only. Non-drinking water applications are not
covered under warranty. Sample Certificate available on request.

Note: In keeping with our policy of continuing product improvement,
Everpure reserves the right to change materials, design and
specifications without notice.

This Air Cooled Water Chiller is listed by Underwriters Laboratories
for Drinking Water Coolers and Drinking Water Coolers certified for
Canada, rated in accordance with A.R.I. Standard 1010 and meets
all known federal and state plumbing codes.

Refrigerant Control: Refrigerant HFC-134a is controlled by accurately
calibrated capillary tube for positively trouble-free operation.

Temperature Control: Enclosed adjustable thermostat is factory
preset. Requires no adjustment other than for altitude requirements.

Everpure, LLC
www.everpure.com

1040 Muirfield Dr.
Hanover Park, IL 60133

Manufactured for Everpure, LLC by Elkay Manufacturing Company.
This specification describes a product with design, quality and functional benefits to the user. When
making a comparison of other producers' offerings, be certain these features are not overlooked.

1.800.323.7873

Tech. Service 1.800.942.1153

PAGE 1 98256C (Rev. A - 4/06)

Model CGCL1

Everpure Commercial Grade Water Chiller Installation

A) WHITE
B) BLACK
C) GROUND
D) FAN
E) COLD CONTROL
F) INTERNAL OVERLOAD PROTECTOR
G) PTC STAR TER

WIRING DIAGRAM

PAGE 298256C (Rev. A - 4/06)
