EVERLIGHT A694B DATA SHEET

查询A694B/2UY/S530-A3供应商

EVERLIGHT ELECTRONICS CO.,LTD.

Technical Data Sheet

3.0mm Round Type LED Lamps

█ Features :

A694B/2UY/S530-A3

●

Low power consumption

●

High efficiency and low cost

●

Good control and free combinations

on the colors of LED lamps

●

Good lock and easy to assembly

●

Stackable and easy to assembly

●

Stackable vertically and easy to assembly

●

Versatile mounting on P.C board or panel

●

Stackable horizontally and easy to assembly

●

Pb free

█ Descriptions :

●

ARRAY=Plastic Holder+Combinations of Lamps

●

The array will easily mount the applicable lamps on any panel up to

█ Applications :

●

1.Used as indicators of indicating the Degree, Functions, Positions etc, in electronic instruments.

Chip

PART NO.

Material Emitted Color

234-10UYD/S530-A3 AlGaInP Super Yellow

EVERLIGHT ELECTRONICS CO.,LTD. http : //www.everlight.com REV.:

Device Number :

CDAE-069-094

Prepared date:

2004/7/17

CG0307065,R0302423

Prepared by:

Lens Color

Yellow Diffused

Page: 1 of 6

2

Guanxiu Yuan

EVERLIGHT ELECTRONICS CO.,LTD.

Technical Data Sheet

3.0mm Round Type LED Lamps

Package Dimensions

A694B/2UY/S530-A3

Notes:

1.All dimensions are in millimeters, tolerance is 0.25mm except being specified

2.Lead spacing is measured where the lead emerge from the package

█ Absolute Maximum Ratings at Ta = 25℃

Parameter Symbol Rating Unit

Forward Current I

Operating Temperature Topr -40 to +85 ℃

Storage Temperature Tstg -40 to +100 ℃

Soldering Temperature Tsol 260 ± 5 ℃

Electrostatic Discharge ESD 2000 V

Power Dissipation Pd 60 mW

Peak Forward Current I

Reverse Voltage V

Note: *1:I

FP Conditions --Pulse Width ≦ 1msec and Duty ≦ 1/10.

F

F(Peak) 160 mA

25

R 5V

mA

*2:Soldering time ≦ 5 seconds.

EVERLIGHT ELECTRONICS CO.,LTD. http : //www.everlight.com REV.:

Device Number : CDAE-069-094

Prepared date:

2004/7/17

Prepared by: Guanxiu Yuan

2

Page: 2 0f 6

EVERLIGHT ELECTRONICS CO.,LTD.

Technical Data Sheet

3.0mm Round Type LED Lamps

Electro-Optical Characteristics (Ta=25℃)

A694B/2UY/S530-A3

Parameter Condition

Forward Voltage

Reverse Current

Luminous Intensity

Viewing Angle

Peak Wavelength

Dominant Wavelength

Spectrum Radiation

Bandwidth

Symbol

F

V

IR
Iv

2θ1/2

λp
λd

△λ

V

=

I

20 mA

F

R=5V

=

I

F

I

=

F

=

I

F

=

I

F

=

I

F

mA

20

20 mA
20 mA
20 mA

20 mA

Min. Typ. Max. Unit

／ 2.0 2.4

V

／ ／ 10 μA

16 32 ／

／60／

／ 591 ／

／ 589 ／

／15／

mcd

deg

nm
nm

nm

EVERLIGHT ELECTRONICS CO.,LTD.

Device Number : CDAE-069-094

http : //www.everlight.com

Prepared date: Prepared by:

2004/7/17

REV.:

2

Guanxiu Yuan

Page: 3 of 6

EVERLIGHT ELECTRONICS CO.,LTD.

Technical Data Sheet

3.0mm Round Type LED Lamps

█

Typical Electro-Optical Characteristic Curves:

A694B/2UY/S530-A3

EVERLIGHT ELECTRONICS CO.,LTD.

Device Number : CDAE-069-094

http : //www.everlight.com

Prepared date: Prepared by:

2004/7/17

REV.:

Page: 4 of 6

2

Guanxiu Yuan

EVERLIGHT ELECTRONICS CO.,LTD.

Technical Data Sheet

3.0mm Round Type LED Lamps

█

Reliability test items and conditions:

A694B/2UY/S530-A3

NO Item Test Conditions

1 Solder Heat

2 Temperature Cycle ∫ 5 min 76 PCS

3 Thermal Shock ∫ 10 sec 76 PCS

4 High Temperature Storage TEMP : 100℃ 76 PCS

5 Low Temperature Storage TEMP : -40℃ 76 PCS

6 DC Operating Life

TEMP : 260℃ ± 5 ℃

H : +100℃ 15min

L : -40℃ 15min

H : +100℃ 5min

L : -10℃ 5min

TEMP : 25℃

IF = 20mA

Test

Hours/Cycle

SEC

300 CYCLES

300 CYCLES

1000 HRS

1000 HRS

1000 HRS

Sample

Size

76 PCS

76 PCS

Ac/Re

0/1

0/1

0/1

0/1

0/1

0/1

7

EVERLIGHT ELECTRONICS CO.,LTD. http : //www.everlight.com REV.:

Device Number :

High Temperature / High

Humidity

CDAE-069-094

85℃ / 85% RH 76 PCS

Prepared date: Prepared by:

2004/7/17

1000 HRS

2

0/1

Page: 5 of 6

Guanxiu Yuan

EVERLIGHT ELECTRONICS CO.,LTD.

E

Technical Data Sheet

3.0mm Round Type LED Lamps

Packing Quantity Specification

1. 270PCS/1Plate，4Plates/1Box

2. 10Boxes/1Carton

Label Form Specification

A694B/2UY/S530-A3

CPN: Customer’s Production Number

P/N : Production Number

QTY: Packing Quantity

A694B/2UY/S530-A3

Notes

1. Above specification may be changed without notice. EVERLIGHT will reserve authority on

material change for above specification.

2. When using this product, please observe the absolute maximum ratings and the instructions

for using outlined in these specification sheets. EVERLIGHT assumes no responsibility for

any damage resulting from use of the product which does not comply with the absolute

maximum ratings and the instructions included in these specification sheets.

3. These specification sheets include materials protected under copyright of EVERLIGHT corporation.
Please don’t reproduce or cause anyone to reproduce them without EVERLIGHT’sconsent.

CAT: Ranks

HUE: Peak Wavelength

REF: Reference

LOT No: Lot Number

MADE IN TAIWAN: Production Place

VERLIGHT ELECTRONICS CO., LTD. Tel: [phone]
Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Fax: [phone]
Tucheng, Taipei 236, Taiwan, R.O.C http:\\www.everlight.com

EVERLIGHT ELECTRONICS CO.,LTD. http : //www.everlight.com REV.:

Device Number :

CDAE-069-094

Prepared date:

2004/7/17

Prepared by:

Page: 6 0f 6

2

Guanxiu Yuan
