EverFocus EverPlex 4BQ User Manual

EverPlex 4BQ

USER'S MANUAL

Real time B/W quad processor

High resolution picture quality

4 Alarm input with buzzer

Notice

This manual is presented to the users of EverPlex 4BQ by EverFocus
Electronics Corp. With years of engineering researching, EverFocus has
spared no effort to provide the high quality products to the worldwide users.
For the policy of continual product improvement, EverFocus reserves the right
to make changes to the product specifications and documentation without
notice. All the components of the products, including accessories, components,
and outlook, are based on the agreements if each deals to satisfy all kinds of
users. Meanwhile, please be advised that every step s of operation must follow
the instruction of this manual to keep EverPlex 4BQ working under the best
condition. Please notice that EverFocus will not be charged any claims or
renewing cases resulted from inappropriate operation.

Table of Content

Safety Warning ...........................................................................................................1

Introduction................................................................................................................2

Specification...............................................................................................................3

Chapter I Front Panel Keypads.....................................................................4

1. Full Screen.........................................................................................................4

2. Quad Display.....................................................................................................4

3. Sequential Seitching ..........................................................................................4

4. VCR Playback……….. .....................................................................................4

Chapter II Back Panel Function......................................................................5

1. BNC Connectors................................................................................................5

1.1 Video In.........................................................................................................5

1.2 Video Out ......................................................................................................5

1.3 Monitor ......................................................................................................... 5

1.4 VCR out ........................................................................................................5

1.5 VCR In ......................................................................................................5

2. Level .........................................................................................................5

3. Terminator On/off..............................................................................................5

4. Alarm time.........................................................................................................6

5. Switch Time.......................................................................................................6

6. VCR Level.........................................................................................................6

7. Power .........................................................................................................6

8. Alarm Connectors (DB-15) ...............................................................................6

8.1 Alarm out ......................................................................................................7

8.1.1 Normally Open Connection................................................................7

8.1.2 Normally Closed Connection..............................................................7

8.2 Alarm in ........................................................................................................8

1

Safety Warning

1. To prevent fire or shock hazard, do not expose this equipment to the
environment of high humidity and dust. Do not use it in an unprotected
outdoor installation or any area classified as a wet area.

2. Installation environment: The temperature should be kept between 0

o

+50

C

3. For safety sake, do not disseminate the unit or put it on an unstable base.

4. Ventilation: Openings in the enclosure are provided for ventilation and to
ensure reliable operation of the unit and to protect it from overheating. These
openings must not be blocked or covered. This unit should not be placed in a
built-in installation unless proper ventilation is provided.

o

C ~

5. Cleanse: Unplug the unit from the outlet before cleansing. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth to clean it.

6. Overload: Do not overload outlets and extension cords as this may result in a
risk of fire or electric shock.

7. Power-cord Protection: Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience receptacles, and the
point where they exit from the appliance.

8. Object and Liquid Entry: Never push objects of any kind into this unit through
openings as they may touch dangerous voltage points or short-out parts that
could result in a fire or electric shock. Never spill liquid of any kind on the
unit.

9. Service: Do not attempt to service this unit yourself as opening or removing
covers may expose you to dangerous voltage of other hazards. Refer all
servicing to qualified service personnel.
