Please setup Gmail account during initial device setup. If you are going to use a password
or a pattern unlock you must have a valid Gmail account setup in the event you forget either.
Forgot lock pattern? Here's a way to reset it.
Enter wrong pattern 5 times and wait for 30 seconds.
account usern9ame and password.
Make sure you use the same account that was used to activate the device and double check
the password by logging in to that Google account in a browser on laptop or PC.
If you don't have access to the original Gmail account, you will need to do a hard reset and lose
your settings and apps on the device. Data on the memory card will not be erased.
2
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 3
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
3
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 4
4
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 5
5
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 6
This manual contains important safety precautions and information for correct usage. Please be
sure to read this manual carefully before use to avoid any damage to the device.
Do not place the product in hot, wet or dusty environments.
Do not place the product in hot environments. Especially in summer, do not place it in a car with
all the windows closed or in the sun.
Avoid dropping or smashing the product and do not shake the TFT screen excessively as it may
cause damage or abnormal display screen.
Select a suitable volume and avoid loud sound while using headphone/earphones. Turn down
the volume or stop using the product if your ears start hurting or ringing.
In the following situations, please charge the product:
A. The device shows on the top of the screen.
B. System automatically shuts down, and it turns off soon after restart.
C. Operation buttons do not work properly.
D. The unit will not turn on.
Note: Chargers of other models cannot be used for this device because they may cause damage to
the device that will void the warranty. Please contact our customer service department if you
need a replacement charger.
Do not disconnect the device while formatting, downloading, and/or uploading; otherwise,
application errors may occur.
We are not responsible for any memory erasure or loss caused by damage or product
maintenance, or other personal reasons.
Do not disassemble the product, and avoid cleaning the product with ethyl alcohol, thinner, or
benzene.
Do not use this product in areas which prohibit the use of electronic devices, for example, in an
airplane.
Do not use this product while driving or walking in the street, as it may cause a car accident
Notes:
This device is not waterproof.
All images in this manual are for reference only. Specifications and appearance of the product
and the screens are subject to change without prior notice.
6
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 7
POWER SOURCE
U
Battery Recharge
The device has Recharging a built-in DC 3.7V rechargeable Lithium-ion batteries. Recharge as
follows:
Insert the micro USB plug from the supplied USB connection cable to the Micro USB jack on
the device. Plug the full-size USB jack of connection cable to supplied AC/USB Adaptor to wall
outlet having AC 100-240V~, 50/60 Hz.
During charging, the on-screen charging icon will turn on. When finished, it will show fully
charged icon.
This power unit is intended to be in a vertical or floor mount position.
Notes: Your battery will last longer if you follow these simple guidelines for caring for and storing it.
1. Using the supplied AC/USB
the device.
2. For charging first time, charge it approximately 10 hours. For normal charging, it needs
approximately 4 hours.
3. Recharge and store the device within the temperature range of 5°C~35°C (40°F~95°F).
4. Do not overcharge (longer than 24 hours). Excessive charging or running the unit until battery
goes empty will damage battery. Battery life will be extended if you keep the battery fully
charged.
5. Battery life naturally shortens slowly over time.
6. The rechargeable battery incorporated in this product is not user replaceable.
Using the touch screen
Touch the screen, slide it up from the bottom, enter the APP interface; scroll the page from left to
right.
Notes:
A: Do not use force when touching the touch screen, as it may damage to the screen.
B: To avoid damaging the touch screen, do not use any object other than your fingers.
C: Do not touch on the touch screen if your fingers are not clean.
D: Do not touch on the touch screen with gloves on.
E: The touch screen may not function if you use a fingernail or other instruments
7
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 8
Micro SD card
This device supports a Micro SD Memory Card (Card not included). To increase memory size, insert
a Micro SD card into the card slot on the side of unit as the figure below:
Notes:
A. Insert the card (Up to 32GB, not included) into the card slot on right side, The card metal chip
for your face
B. click is heard then pulls out the card.
C. Before replacing the storage card, make sure the unit has been powered off.
D. When inserting the storage card, make sure the direction you select is correct. Never insert
violently to avoid damaging the card or the unit. If the storage c
if the direction is correct.
E. When the card is used for the first time, or it has been used in another device, please format it
first through the Computer. You also need to download the desired music, photos and/or movie
onto the card before installing into the unit
Important: Formatting the Micro SD Card will delete all the data on the card. Download the
data to your computer before formatting the card.
Micro USB Port (USB OTG)
This device supports USB device for extending the memory size, or USB Thumb Drive, inserts the
USB cable (micro USB plug to Full size USB female jack not included) into the micro USB port on
the side of unit. Insert USB device into Full size USB female jack, like in the PC.
8
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 9
Notes:
Before replacing a USB drive, make sure the unit has been powered off.
When inserting the USB driver, make sure the direction you selected is correct. Never insert
direction is correct.
Power on/off the Device
A. Press and hold the button on the right cabinet approximately 5 seconds to power on the
unit. Touch and slide the key bar shown on the screen to from below to above unlock
B. In power on mode, press the button to turn off the screen for saving battery power. Press
again to turn it on.
C. To power off the device, press and hold the button until the
and show shut down message, the device will to power off
Reset:
If the device becomes abnormal, halts, freezes. Press the RESET Button in the reset hole on the
rear of device (see figure as below) with a small screwdriver (not included) to reset the device.
9
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 10
KEYBOARD
3
1.Keyboard
2.USB Connection Cable
2
with Micro USB Plug
3.Case
1
Operation:
1. Insert your tablet to the clips to hold the tablets, the top and right clips are
movable.
2. Connect the Micro USB Plug from the Keyboard to Micro USB Port on the
right of Tablet.
3. Connected as the following figure.
4. Power on the Tablet, the Keyboard will hook up to the Tablet automatically.
F (Function) Button s assignment:
F7- Play Music
F8- Photos
F9- Hangouts
F10- YouTubeTM
F11- Clock
F12- Settings
TM
TM
F1- Chrome
F2- Calculator
F3- Calendar
F4- Camera
F5- Gmail
F6- Files
10
PDF created with pdfFactory Pro trial version www.pdffactory.com
1. Fn+ ZZZ : Screen saver
Page 11
Location of Controls
1) Power On/Off button
2) Headphone Jack
3) Micro USB Port (For battery charging & OTG)
4) VOL + button
5)Micro SD Card Slot
6) VOL button
7) RESET button (Inside the hole)
8) Rear camera
9) Front camera
10) Speaker
11
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 12
Connections:
Connect to PC
A. Connect the Device to the PC via the Micro USB port on the side of cabinet to the USB port on
your PC by the supplied connection cable.
B. The tablet name CMP837 disk will display on your computer.
Earphone / Headphone jack:
For private listening, connect an Earphone/Headphone to the Headphone jack on the right side of
cabinet. The speaker will cut off automatically (Earphone/Headphone not included)
12
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 13
Getting Started
On home page, Touch screen slid from the bottom up to the application interface. The
following picture will appear on the screen:
Touch the Settings ( ) button on the screen, the setting menu will appear on the
screen, then:
Touch on the screen and move Up or down to show more selections.
Choose the corresponding button you need to set. The sub-setting menu will appear on the
screen, follow on screen instructions.
13
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 14
WIRELESS & NETWORKS
To browse the web; connecting to apps store, use E-mail, Facebook , Twitter
connect this unit to internet by Wi-Fi as below:
1. Touch on the Wi- -Fi ON, wait a few seconds, the
available Wi-Fi networks will appear.
2. Touch on the desired network to start connection as on-screen instructions. (Maybe ask for
password).
NB: After setting, you can turn it ON or OFF by touching the ( ) widget on the screen (Right top
corner).
The device automatically scans and lists all local Wi-Fi Network found.
Slide to thebottom of the screenand select + , followthe prompts to add your
network.
14
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 15
DISPLAY
Brightness level: To adjust the screen brightness by moving the scaling bar.
Adaptive brightness: Optimize brightness level for available light
Wallpaper: To choose and set the wallpaper screen.
Sleep: To enable sleep mode and select time to sleep while not in operation.
DESKTOP
Status Bar
15
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 16
Operation R
Below are some advising on how to operate the operation zone:
By touching the icon, you can decrease sound level.
touching the icon, you can get back to the previous screen.
touching the icon, you can get back to the homepage wherever interface you
are in.
touching the icon, a window popup which shows the all apps in operation.
touching the icon, you can Increase the sound level.
The icon for WIFI signal
The icon for battery status
The icon for Time
in menu interface, you can open and operate any app by touching on the icons to run
applications such as Files, Chrome, Music, Video, as well as during web browsing or PDF viewing,
you can drag the menu, by sliding the screen to scrolling up and down the page as well as to enable
the page to move different directions respectively.
Application Management
:
Google Play Store
Google Play has all of your favourite Android apps and games, as well as music, books,
magazines, movies & TV shows. You will need a Google account to access Google Play.
Downloading Android Applications direct from a Website
You can download Android applications directly from websites, and then quickly and easily install
them on your device.
Touch the Chrome application icon to launch the internet browser.
Enter the desired website URL and touch the download link for the application you want to
install on your device.
16
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 17
After the download is complete, touch on the download file (in the Apps under setting screen),
Touch Open .
Uninstalling Android Applications
You can also quickly and easily uninstall the Android applications that you have installed.
1. Touch Apps & notifications
2. Touch See all xx apps (xx is no. of installed app)
3. Touch the application you want to uninstall, .
4. Touch OK to confirm the Uninstall.
Clock
Touch the Clock application icon. You can see the time and date.
Alarm R
You can use your device as an alarm clock by setting multiple alarms.
Touch alarm icon which displayed on the left top of screen, it shows one or more alarms
have been set and are active.
Add Alarm
Touch the Clock application icon.
Touch alarm icon .
Set up your alarm as desired (Input alarm time)
Touch OK.
Delete Alarm
Touch the Clock application icon, touch alarm icon
Select the desired alarm you want to delete.
Touch icon of selected alarm
Alarm Deleted
Calendar
Touch the Calendar application icon.
For the first time using the Calendar, you need to add a Gmail account. Enter Gmail
address and password. Clic and follow the prompts to complete the account configuration.
17
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 18
Then you can use the Calendar. (Note: In Account Set up screen, manual change the server for
www. google.com.
Add Event
1. On the Calendar screen, touch on the date to which you want to add an event.
2. Touch on the event time, touch in each entry field to enter the desired event information.
3. Touch Done.
Gmail Go
Inside the apps menu, touch the icon to enter the Gmail c configure the account
information for the first time. Pre-register and set up your Gmail account is necessary. Please be
advised that Gmail account registration is necessary in order to access services provided by Google
and Android.
Flies
Touch the Files application icon to view the files on all storage devices (Internal Memory, SD
Card and USB), and to quickly & easily install Android application on your Tablet.
A:Tap the icon on the apps page, and tap the top left corner of the screen will be
shown in below picture.
B: Select the file or folder you want to do action as below, touch and hold the file about 2 seconds.
18
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 19
C: Tap the top right corner of the s Pop-up menu will display different options for
operation such as Open with, select all, copy to, Move to. ect.
D:Touch the and tap the top left corner of the screen Select
SanDisk SD card and USB storage ;
E: Tap the lower right corner of the screen the , the file will copy and display on the screen.
19
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 20
Music
Player to play audio files:
Audio file formats supported: MP3
r will automatically load the music files from the SD/USB/Internal Memory to the
Video
Video file formats supported: H.264, VC-1, AVI
In the app menu, touch the icon Video . It will list all the video files.
Choose video files from Internal Memory or SD card / USB storage device in the video player
playlist. The system will automatically load the video file form Internal Memory or SD card / USB
storage device to the playlist after turning on the Video app.
The playlist as shown in the below figure:
Frequently Asked Questions
Android
Q: What Android OS version is on my Device?
A: Android 8.1 Oreo Go edition
Basic Device Functionary
Q: Do I have to charge the battery before use?
charging. Use the included power adapter to charge; this device charge via USB cable.
20
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 21
Email
p
Q: Can I use any of my personal email addresses to send/receive email?
A: The device supports POP3 and SMTP accounts. Some free email accounts are not
supported on mobile devices. Check with your email provider to see if your account is
supported.
Media Cards
Q: Which media cards are compatible with my Device?
A: Micro SD card.
Music
Q: How do I add music files to my device?
A: Copy the music files from your computer onto a micro SD card or USB storage device,
and then use the Files application to copy the files into the device.
Photos
Q: How do I add photo files to my device?
A: Copy the photo files from your computer onto a micro SD card or USB storage device,
and then use the Files application to copy the files into the device.
Video
Q: Can I play YouTube videos on my device?
A: Yes. You can tap the YouTube application icon to quick access videos.
Q: How do I add video files to my device?
A: Copy the video files from your computer onto a micro SD card or USB storage device,
and then use the Files to copy the files into the device.
Wi-Fi
Q: Do I need a Wi-Fi adapter to connect to the Internet?
A: No. The Wi-Fi adapter is built-in to the device.
Storage:
Q: How do I turn the device into a USB storage device?
A: Connect the Devic
e to the PC via the Micro USB
ort on the side of cabinet to the USB
port on your PC by the supplied connection cable.
B: The tablet name MP837 disk will display on your computer.
Other Applications
YouTube Go
This Device has pre-loaded. Touch the icon to login with pre-registered login name and passwords;
otherwise, you may register online by following the on screen instructions.
21
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 22
Troubleshooting:
Cannot power on the Device
Connect the supplied AC/USB Adaptor.
T
Cannot go online
Check if your Wi-Fi setting is correct, proper password may be needed.
Check if your router is working properly.
Check your signal bar on the Device. It may not be connected due to weak signal.
Earphones do not transmit sound
Earphone volume is poor.
Try another music file.
Screen is flashing after power on is performed
Short of power, please charge the battery.
How to buy/download the applications from the internet
Make sure your device is already hooked up to Wi-Fi/ networks.
Press Google Play icon on the home page.
Search, Buy, Download and Install the desired applications by following the on-screen
instruction.
Warning: Personal details and Credit Card information may be required, please stay Alert!
Media files can't be found:
If new files were added onto the device; click the "Files" icon on the APPS menu to
search.
Use correct Apps to open corresponding media files. Click Video to play video files.
Click Photos to view photos. Click Music to play music.
How to enter the Settings menu while applications/programs are running
After turning on the application/program, Touch the Option button where is normally listed
on the bottom of the screen to enter settings menu. Set each setting as instructed by the
on-screen instructions (functions depend on the software of the applications).
Cannot hook up with Wi-Fi or the Wi-Fi signal is weak
Make sure Wi-Fi is available in your location and you are authorized (with correct
password) to hook up it.
The device may be too far from the signal source. Move your device closer to the signal
source.
IMPORTANT:
After Factory Data
e-mail accounts, Gmail accounts, media files etc...) will be deleted. Backup this
data before resetting.
22
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 23
PRODUCT SPECIFICATIONS
Hardware Configuration:
CPU Processing Speed Cortex A7, 1.2GHz QUAD Core processor
Memory/ROM 16GB (Internal 3.5 GB flash memory has be assigned for
Android operating system and pre-loaded Apps, existing
12.5GB flash space is available for further operation
needs.)
Memory/RAM DDR III 1GB
Memory Card Slot Micro SD card(Supports up to 32GB), not included
USB 1x Micro USB port for battery recharge and USB OTG
I/O ports 1x Micro SD Card Slot, 3.5mm Phones Jack,
Wireless Interface WiFi 802.11b/g/n
Adaptor Power source AC 100-240V~, 50/60Hz, 0.4A
Output of the supplied AC/USB
Adaptor
DC 5V,1.5A
Software Configuration:
Operating System
Browser Chrome,
Video file supported H.264, AVI,
Music file supported MP3,
Photo file supported JPEG, BMP, GIF, PNG
Email Support Web mail & Pop mail
Android 8.1 Oreo Go edition
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
Accessories:
1 x Instruction booklet
1 x AC/USB Adaptor
1 x USB Connection Cable
1 x Keyboard and Case
Disclaimer:
Google, Android, Google Play, YouTube and other marks are trademarks of Google LLC.Oreo
is a trademark of Mondelez International, Inc.
23
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 24
24
PDF created with pdfFactory Pro trial version www.pdffactory.com
Loading...
