EVA KOOL IB15, IB18 User Manual

Caution: Read the instructions and safety warnings carefully before using the refrigerator.

DESCRIPTION

IB15 /18 are portable refrigerators that can be used with most 12-24 VDC power sources (including vehicles and trucks).

They can be used both as a refrigerator or a freezer. The construction consists of:-

 Plastic External Cabinet  Plastic Lid  Fully Insulated Cabinet  Highly efficient Danfoss compress  Digital control panel  Power Cable.

They are also equipped with a carry strap. This means that they can be easily.

IB15/18

DC POWER CABL E

189A0470

DATA SHEET

MODEL

IB15

IB18

External dimensions (L x W x H )

565x235x360 (mm)

565x235x405 (mm)

Net weight

8.5 Kg

9.5 Kg

Power Usage

35 W

Supply voltage

DC 12-24 V

Internal Protection

Fuse 10A

Temperature Range setting

+10 to -18 °C

Cooling system

Danfoss BD Micro (Bd1.4F)

Refrigerant gas

R134a - CFC Free

Mounting kit

Optional

Insulation

CFC Free PU Foam

Specifications and Main Features
