Euro-Pro F1100B User Manual
Professional 8 Liter Deep Fryer
Freidora de Inmersión Profesional de 8 Litros
Friteuse Professionnelle de 8 Litres
OWNER’S MANUAL
MANUAL DEL USUARIO
GUIDE D’UTILISATION
Model / Modelo / Modèle F1100B
120V., 60Hz., 1500 Watts
COPYRIGHT© EURO-PRO OPERATING LLC 2008
EURO-PRO OPERATING LLC
Boston, MA, 02465
1 (800) 798-7398
www: euro-pro.com
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions for use carefully
and look at the illustrations before you
start using the appliance.
2. Do not touch hot surfaces, always use
handles or knobs.
3. To protect against electrical shock, do
not immerse cord and plug of this
appliance in water or other liquids.
4. Close supervision is necessary when
any appliance is used by or near
children.
5. Unplug from outlet when not in use
and before cleaning. Allow to cool
before putting on or taking off parts
and before cleaning the appliance.
6. Do not operate any appliance with a
damaged cord or plug, or after the
appliance malfunctions, has been
dropped or damaged in any manner.
Return the appliance to EURO-PRO
Operating LLC for examination, repair
or adjustment. See warranty.
7. Never plug in before the control panel
is installed in the body of the fryer and
the heating element is placed in the oil
container.
8. Never overfill the fryer with oil. Fill
only between the minimum and
maximum levels, as indicated inside
the oil container.
9. Be sure handle is properly assembled
to the basket and locked in place.
See detailed assembly instructions.
10. The use of accessory attachments not
recommended by the appliance
manufacturer may cause injuries.
11. Always insert heating element in the
appliance first, then plug into the wall
outlet. To disconnect, remove plug
from wall outlet then wait for the unit
to cool completely before removing
the heating element.
12. Extreme caution must be used when
moving any appliance containing hot
oil or other hot liquids.
13. Do not leave appliance unattended
while in use.
14. Do not use outdoors.
15. Do not let cord hang over the edge of
the table, counter or touch hot
surfaces.
16. Do not place on or near a hot gas or
electric burner, or in a heated oven.
17. Do not use appliance for other than
intended household use.
SPECIAL SAFETY INSTRUCTIONS
• A short power supply cord is provided to
reduce the risk resulting from becoming
entangled in or tripping over a longer
cord. An extension cord (or longer
detachable cord) is not recommended
for use with deep fryers.
• Never plug in the control panel before it
is installed in the body of the fryer with
the heating element inside the oil
container.
• Do not immerse the control panel and
heating element in water.
• When opening the lid after frying, first
release the lid by pushing the latch with
your finger, then wait a moment to allow
the steam inside to escape before
opening fully.
• To avoid a circuit overload, do not
operate another high wattage appliance
on the same circuit.
GETTING TO KNOW YOUR DEEP FRYER
1. Deep Fryer Body
2. Middle Housing
3. Oil Container
4. Control Panel Guide Rails
5. Handle
6. Small Fry Basket (x2)
7. Medium Fry Basket
8. Large Divided Basket
9. Basket Handle (x3)
10. Basket Divider
11. Deep Fryer Cover
12. Viewing Window
13. Cover Handle Plate
14. Cover Handle
15. Washable Filter (*not shown)
16. Time/Temperature Knob
17. Time/Temperature Display
18. Ready Light
19. Clear Button
20. Power Button
21. Control Panel With Heating Element
22. Break Away Cord
23. Heating Element
24. Tongs
25. Thermostat Reset Button (*not shown)
WARNING: To reduce the risk of electric shock, this appliance has a
polarized plug (one blade is wider than the other). This plug will fit in a
polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician to
install the proper outlet. Do not modify the plug in any way.
POLARIZED PLUG
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
1
Rev. 03/05A
Technical Specifications
Voltage: 120V., 60Hz.
Power: 1500 Watts
Oil Capacity: 8.4 Qts (8 Liters)
Note: Illustrations may differ from actual unit.
2
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
Read all the sections of this booklet and follow all the instructions carefully.
Using for the First Time
Warning: Never attach the magnetic
power cord to the unit before the control
panel is inserted into the unit with the
heating element in the oil container. Do
not immerse the control panel, cord or
plug in water.
Note: When unpacking the unit, make
sure that you remove the oil container
from the deep fryer body and remove the
packaging material that is between the
main housing and the oil container.
Note: This unit should not be used to
boil water.
Prior To First Use, Clean The Unit
Thoroughly
Warning: Always let the fryer cool
completely for 2 hours before taking it
apart for cleaning. Never carry or move
the Deep Fryer with hot oil inside. Before
cleaning, always make sure the plug is
not in the wall socket.
• All components with the exception of
the electrical parts, can be washed in
warm soapy water. Dry thoroughly
before use.
• Always use basket handle to remove
the frying basket. Always make sure
the basket handle is securely attached
to the basket. To attach the handle to
the frying basket, pinch the handle
ends together to fit into the metal
bracket on the frying basket. Pull
handle towards you to lock into place.
(Fig. 1)
• Lift the control panel up and remove
from the unit
• Remove the oil container.
• Clean the oil container and the frying
basket with hot water, dishwashing
liquid or other non-poisonous detergent
and non-abrasive sponge.
MAX
Food Level
Warning: Never immerse the control
panel in water or any other liquids.
Caution: All components must be
completely dried before filling with oil or
using. Special care must be taken to
ensure the washable oil filter in the lid is
completely dry, otherwise the filter will not
function properly and may lead to steam
being trapped within the fryer during use.
Warning: Never exceed "MAX" line when
filling the basket with food.
Filling the Oil Container
Warning: Never plug in the deep fryer
before filling with oil to specified level.
Always make sure control panel is
securely in place in the body and the
heating element is inside the oil in the
container before plugging in.
• Use blended vegetable oil, pure corn oil
or canola (rapeseed) oil. Do not use olive
oil, margarine, lard or drippings.
• The oil level must always be maintained
between the minimum (12 cups / 2.8
liters) and the maximum (8.4 quarts / 8
liters) levels marked inside the oil
container. Check the oil level before
each use. For best results, keep the oil
close to the maximum level. (Fig. 2)
• Never mix different oils and fats
together. Do not mix old and new oil.
Fig. 2
Using Solid Fat
Warning: Do not put solid shortening in
the oil container or the frying basket.
• If using solid vegetable shortening,
melt it first in a separate pan and then
very carefully pour the melted fat into
the oil container.
• Previously used solid vegetable
shortening which has curdled and
hardened in the oil tank should be
removed from the oil container and
melted in a separate pan before
reusing.
Warning: If you try to melt the solidified
fat in the oil container, there is a risk of
warm melted fat suddenly sputtering from
below through the still solid top layer of fat.
Therefore use only the following
procedure:
• Make sure the fat is at room
temperature. If the fat is very cold, there
is a greater risk of splashing.
• Using a fork, carefully make some holes
in the fat. Make sure the lid is securely
closed while fat is melting. Set
temperature dial to 320º F (160º C).
Installing the “Control Panel With
the Heating Element” Into Place
• Lift up the control panel with heating
element. (Fig. 3)
• Insert the control panel into the
mounting boss on the deep fryer
body. (Fig. 4)
Note: The Automatic Safety Interlock
Switch ensures that the unit will not
operate unless the control panel has
been inserted into the mounting boss of
the deep fryer body correctly. This is not
a defect. This product is fitted with a
safety switch to prevent the unit from
turning on accidentally.
Mounting Boss
Using the Deep Fryer
Warning: Never plug in the Deep F ryer
before filling with oil to specified level.
Always make sure control panel is
securely in place in the body and the
heating element is inside the oil in the
container before plugging in.
Important: Ensure the contr ol panel is
fitted correctly to the main unit otherwise
the unit will not function. This is not a
defect. This product is fitted with a
safety interlock switch to prevent the
unit from turning on accidentally.
Frying Baskets
• You have a choice of three different
sizes of baskets for your frying needs.
• The small and medium baskets can
be used for appropriate portions of
food.
• The large divided basket can be used
to fry two different foods that require
the same frying temperature at the
same time or by removing the divider,
you can fry larger quantities. To
remove the divider make sure the
basket is cool.
• Place the divider in the guide rails of
the large basket. (Fig. 5)
Divider
Guide Rail
Fig. 5
Fig. 1
Control Panel
Fig. 3
3
Back of Deep Fryer Body
Fig. 4
4
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
Pre-Heating
Warning: In order to avoid injury or
burns, never touch any metal parts on
the deep fryer because they may be hot.
• Make sure the oil level in the oil
container is between the "minimum"
and "maximum" lines. Do NOT exceed
the "MAX" line on the oil container when
filling with oil.
• The frying basket should not be
immersed in the oil during the preheating.
• Replace the deep fryer cover.
• Plug the appliance into a 120-volt outlet.
The unit will beep and the ”Ready Light”
light will come on and it will be “Green”.
• Press the power button (Fig. 6) and the
unit will beep again. The upper screen
display will show 320°F and the lower
screen will display _ _: _ _ . The “Ready
Light” will now turn “Red”.
• Temperature: The temperature is
adjustable from 155°F to 385°F in 5ºF
increments. If you want to raise the
temperature, press the knob, make sure
the temperature
Power
On/Off
Ready
Clear
Button
Light
Display
Panel
Temperature
indicator is flashing and turn the knob
clockwise. When you press the knob,
the unit will beep. If you want to lower
the temperature, press and turn the
knob counter-clockwise. When you
press the knob, the unit will beep again.
The upper screen will display the
temperature that you set. The “Ready
Light” will remain “Red” while the oil is
heating to desired temperature. (Fig. 6)
Once the oil temperature has been
reached, the “Ready Light” will turn
“Green” again and flash.
• Timer: The MAX timer time is 15
minutes. When you turn the deep fryer
on, the display screen will show _ _:_ _.
This means that there is no time set.
You can set the timer up to a maximum
of 15 minutes. To set the timer, press
the knob, ensure that timer indicator is
flashing and turn the knob until you
reach the time desired.
• Clear function: If you press the clear
button, the unit will go to the default
status. The default temperature is
320°F and the default time is _ _:_ _.
Time/
Knob
Filling the Frying Baskets
• Select the appropriate fryer basket
for the task
• Do not fill the frying basket when it is
immersed in oil.
• Place the food in the frying basket.
Do not overfill it and never exceed
the maximum quantities. For
optimum results and shorter frying
times, basket should be only 1/2 full.
• Do not fill the baskets higher than the
MAX line on the basket with frozen
food. (Fig. 7)
MAX Line
Fig. 7
Frying Food
Note: When frying frozen food such as
French Fries, remove the frying basket
before filling with frozen food because oil
will spatter and may cause burns. You
should not fill the frying baskets more than
halfway. Remove any ice crystals from the
frozen food prior to frying. Failure to do so
may cause the oil in the deep fryer to
overflow when the food is placed in the oil.
• Always use the frying baskets to fry
food.
• When the oil is pre-heated, the ready
light will start flashing and turn green,
indicating that the desired temperature
is reached.
• Slowly lower the frying basket into the
hot oil. Lowering the frying basket too
quickly can result in the oil overflowing
and splashing.
• Replace the deep fryer cover carefully.
• It is normal for steam to escape through
the sides of the cover while frying.
• Avoid standing too close to the deep
fryer while it is working.
Warning: When opening the cover after
frying, lift up the cover slightly, then wait to
allow steam to escape before removing
the cover completely. Keep face away
from unit to avoid burns caused by
escaping steam.
Caution: When frying frozen foods such
as French Fries, you should not exceed
the max line on the fryer baskets. Clean
off any ice from frozen food prior to frying.
Failure to do so may cause fryer to
overflow when food is placed in oil.
Warning: When frying foods, always
remove the frying basket from the deep
fryer before filling with food because oil
will spatter and cause burns. Be
especially cautious when frying frozen
foods.
• Push the On/Off button to shut the unit
off.
• The ready light will remain lit when the
unit is turned “Off”
• Unplug the main cord from the
electrical outlet.
• Lift up the cover slowly and wait to
allow steam to escape before removing
the cover completely.
• Lift up the frying basket by the handle.
Place it on the oil container and allow
the food to drain for a minute.
• Once the oil has drained from the
frying basket, the basket may be lifted
off and the food served.
Warning: Always let the deep fryer cool
completely (approximately 2 hours)
before cleaning or storing. Never carry
or move the deep fryer with hot oil inside.
Fig. 6
5
6
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
Frying Tips
• Do not mix different oils or new and old oil together.
• Replace oil regularly. In general, oil will be tainted fast when frying food containing a
lot of protein, (such as poultry, meat and fish). When oil is used mainly to fry
potatoes and is filtered after each use, it can be used up to 8 to 10 times, but do not
use the same oil for more than 6 months.
• Always replace all oil as soon as it starts foaming when heated or when color
becomes dark or when it has a rancid smell or taste or becomes syrupy.
• Make sure that the food to be fried is dry.
• Remove loose ice from frozen food before frying. Rinse and pat dry.
• To cook evenly, pieces should be the same size and thickness.
• Thicker pieces will take longer to cook.
Temperature Settings
The following cooking times reflect only the approximate time needed to fry one
basket 1/2 full. The exact time may be different depending on actual quantity,
personal cooking preferences, size and thickness of pieces, etc...
Food Cooking Time Temperature
French Fries 2-3 minutes
Fish Fillets 3-4 minutes
Chicken Fingers 3-5 minutes
Chicken Pieces 10-15 minutes
Fried Zucchini 2-3 minutes
Fried Mushrooms 3-4 minutes
Onion Rings 2-3 minutes
Donuts 3-5 minutes
Apple Beignets 4 minutes
Shrimp 2-3 minutes
7
375°F
320°F
350°F
350°F
375°F
375°F
320°F
350°F
375°F
320°F
Filtering & Changing The Oil
• Make sure the deep fryer is unplu gged
and the oil has cooled before cleaning
or storing the deep fryer.
• The oil does not need to be c hanged
after each use. In general, the oil will
be tainted rather quickly when frying
food containing a lot of protein (such
as poultry, meat or fish). When oil is
mainly used to fry potatoes and is
filtered after each use, it can be used 8
to 10 times. However, do not use the
same oil for longer than 6 months.
• To filter the oil first make sure the oil
has cooled and then empty the oil from
the oil container into another container
or bottle. (Fig. 8) Wash and dry the oil
container and basket. Refill the oil
container with the oil, pouring the oil
through a wire strainer or paper filter.
(Fig. 9)
Fig. 8 Fig. 9
Detachable Power Cord
Your deep fryer has been specifically
designed with your safety in mind. Your
deep fryer has incorporated a unique
detachable power supply cord. This
power supply cord cord is designed to
“Break Away” from the fryer body in the
event that the supply cord is
inadvertently pulled. This is intended to
prevent the tipping of the appliance and
hazardous spillage of hot oil.
The female receptacle portion of the
power supply cord is permanently
attached to the rear of the the control
panel.
To connect the male power cord plug to
the female receptacle on the appliance,
orient the male plug so that it mates
with the female receptacle. The male
plug can only be inserted one way. If
the male plug will not go into the
receptacle on the appliance, rotate the
male plug 180°.
IMPORTANT: Should the male plug
become detached from the appliance
during use, it is important to:
1. Unplug the power cord from the wall
outlet. (Fig. 10)
2. Turn off the
appliance at the
control panel.
3. Re-attach the
power cord to
the appliance.
4. Re-connect to
electrical outlet.
5. Turn the appliance back on.
Fig. 10
Cleaning Instructions
Warning: Always remove the plug from
the wall socket before cleaning. Allow the
deep fryer and the oil to cool completely
(approximately 2 hours) before cleaning.
Never immerse the control panel, cord or
plug in water or any other liquid.
• Follow the cleaning instructions on
page 3.
• Never immerse the control panel, cord
or plug in water or any other liquid.
• Do not place the control panel, cord or
plug in the dishwasher.
• Clean the control panel only with a
damp cloth.
• The oil container and frying baskets can
be washed in the top rack of
dishwasher.
• The deep fryer cover can also be
washed in the dishwasher after you
have removed the filter.
• The filter can be rinsed. Do not
dishwasher.
• The body of the deep fryer can be
washed in warm soapy water. Do not
put the body of the deep fryer in the
dishwasher.
How To Reset Deep Fryer
If for some reason your deep fryer stops
heating, the reason might be that the
safety reset switch has disconnected. To
re-start the deep fryer, follow the
instruction below:
• Using the back end
of a pen, push the
re-set button that
is located on
the back of the
control panel. The
deep fryer will beep to
indicate that it has been re-set.
(Fig. 11)
8
Reset Button
place in
Fig. 11
Loading...
