Installation,
Operation and
Maintenance
Manual
DV 52 ST
See-through
Gas
Fireplace
Check local codes and read all
instructions prior to installation.
Warning:
Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Refer to this manual. For assistance or additional information consult a
qualied installer, service agency or the gas supplier.
Safety Notice:
Glass doors on gas replaces are extremely hot while the replace is on and remain hot even after the
replace has been turned o. Safety screens are available and can reduce the risks of severe burns.
Please keep children away from the replace at all times.
For Your Safety:
Do not store or use gasoline or other ammable vapors and liquids in the vicinity of this or
any other appliance.
®
Warning:
What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier,
call the re department.
• Installer: Leave this manual with
the appliance.
• Consumer: Leave this manual for
future reference.
DV 52 ST See-thru Gas Fireplace
Warning:
Read this manual before installing, operating or troubleshooting this appliance.
Please retain this owner's manual for future reference.
Congratulations
Congratulations on selecting a European Home gas replace, an elegant
and well-designed gas replace built with you in mind. The European
Home gas replace you have selected is designed to provide the utmost
in safety, reliability, and engineering standards.
As the owner of this new replace, you'll want to read and carefully
follow all the instructions contained in this Installation, Operations and
Maintenance manual. Pay special attention to all cautions, warnings, and
notices.
This owner's manual should be retained for future reference. We suggest
that you keep it with all your other important documents and product
manuals.
The information contained in this owner's manual, unless noted otherwise, applies to all models, and gas control systems.
Your new European Home gas replace will give you years of durable,
reliable use. Welcome to the European Home family of gas replace
products.
Safety Alert Key:
• DANGER!
Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Used to address practices not related to personal injury.
• Important: Used to address practices not related to personal injur y.
Table Of Contents
Congratulations
Safety Alert Key
Introduction ............................................................................................... 3
Installation
Installing and Framing the Fireplace ..............................................4
Installing the Gas Line ....................................................................5
Vent Installation ............................................................................. 5
Installation Requirements ................................................5
Installing the Remote Switch .................................................... 5
Vent Terminations ............................................................ 6
Installing the Nailing Flange ............................................ 6
Top Vent Runs ............................................................................ 7 - 8
Finishing Around the Fireplace
Fireplace Facing ............................................................... 9
Mantels and Surrounds .................................................... 9
Power Venting .............................................................................. 10
Wiring ...................................................................................... 10
Wiring for the Gas Control/Pilot ....................................................10
Removing and Installing the Door ................................................ 11
Operation .......................................................................................... 12 - 15
Maintenance .................................................................................... 15 - 17
Troubleshooting ......................................................................... 16 - 17
Spare Parts ...................................................................................17
Warranty .................................................................................................. 18
Appendix
A. Termination Locations .............................................................. 19
B State of Massachusetts/Amendment ........................................ 20
Notes ...................................................................................... 21
Page 2
rev.110329
DV 52 ST See-thru Gas Fireplace
Introduction
About this Fireplace:
The DV 52 ST (See-thru) are replaces with a linear-style burner. These replaces can
be converted to either a Top Vent or Rear Vent application.
The DV 52 ST (See-thru) is rated for Natural Gas at 40,000 Max. BTU/H (11.73 kW)
input and 34,000 Min. BTU/H (9.97 kW)
• DV 52 ST; Top Vent, Millivolt Pilot.
• DV 52 ST E; Top Vent, Electronic Ignition.
This manual covers installation, operation and maintenance. Lighting, operation
and care of this replace can be easily performed by the homeowner. However, all
installation and service work should be performed by a qualied or licensed installer,
plumber, or gas tter who is qualied or licensed by the state, province, region, or
governing body in which the appliance is being installed.
This manual covers all models and unless otherwise specied, the designation DV 52
ST refers to all variations of the model above. Sections which are specic to a particular
variation are marked with a symbol, plus the appropriate model number.
Warranty and Installation Information:
The European Home warranty will be voided by, and European Home disclaims any
responsibility for, the following actions:
• Modication of the replace and/or components including direct vent assembly
or glass doors.
• Use of any component part not manufactured or approved by European Home in
combination with this European Home replace system.
• Installation other than as instructed in this manual.
Consult your local Gas Inspection Branch on installation requirements for factorybuilt gas replaces. Installation and repairs should be done by a qualied contractor.
Installations in Canada must conform to the current CAN/CGA B-149.1 and .2
Gas Installation Code and local regulations. If the optional air-circulating fan kit is
installed, it must be electrically grounded in accordance with CSA C22.1 Canadian
Electrical Code Part 1 and/or local codes.
Installations in the USA must conform to local codes, or in the absence of local
codes to the National Fuel Gas Code, ANSI Z223.1-1988. If the optional air-circulating
fan is installed, it must be grounded in accordance with local codes or, in the absence
of local codes, with the National Electrical Code, ANSI/NFPA 70-1987. Within the
State of Massachusetts this replace must comply with NFPA-54 Chapter 10.
CAUTION!
Due to its high operating temperatures, the appliance should be
located out of trac and away from furniture and draperies.
• Children and adults should be alerted to the hazards of the
high surface temperature, which could cause burns or clothing
ignition.
• Young children should be carefully supervised when they are in
the same room as the appliance.
• Clothing or other ammable materials should not be placed on
or near the appliance.
What is Combustible?
Materials that can catch re and burn are considered combustible. Any material that
is made of, or faced with, wood, wood pulp, paper, plastic or any other material that
can catch re and burn is considered combustible. Even though these materials may
have been 'ame-proofed', made 're-resistant' or are 're-rated' they are considered
combustible.
The combustibility of a material can be tested per "ASTM E136 Standard Test Method
for Behavior of Materials in a Vertical Tube Furnace at 750 Degrees C". Note that 'reresistant' does NOT mean non-combustible.
Note: If a certain material has a core considered to be non-combustible (in accordance
with ASTM E136) but is faced with a combustible material then the material is
considered to be combustible.
When in doubt, ask for an ASTM E136 compliance statement.
What is Non-combustible?
A given material is said to be non-combustible when it cannot catch re and burn.
For example, materials made entirely, or in combinations, of, stone, brick, concrete,
tile, steel, plaster or glass are considered non-combustible.
For the purposes of the installations described in this Manual, those materials that
have passed the ASTM E136 tests are considered to be non-combustible.
As of this writing, the materials listed below are reported by their manufacturers to
be non-combustible (in accordance with ASTM E136):
rev.110329
• James Hardie Building Products, Inc.:
HardieBacker™ ¼” Cement Board
• U.S. Architectural Products, Inc.:
Versaroc® Cement Bonded Particle Board
Cem-Clad® Cement Panel
Page 3
DV 52 ST See-thru Gas Fireplace
Installation
Installing The Fireplace Shell
The replace may be installed in any location that maintains proper clearances to air
conditioning ducts, electrical wiring and plumbing. Safety, as well as eciency of
operation, must be considered when selecting the replace location. Try to select a
location that does not interfere with room trac, has adequate ventilation, and oers
an accessible pathway for direct vent installation. Refer to Page 4 - Vent Installation
for more information.
The replace dimensions are shown below:
Top View
6 3/4”
Framing
N
M
Framing Dimensions (inches)
M N O
DV 52 ST 39 60 23¾or 24¾*
* When facing with the Overlay Method the depth is increased by 1".
See Planning Guide for more information.
Figure 2. Framing dimensions.
40”
Both walls Typical.May
not be exactly as shown.
O
B
Front View
A B C D E F G H I J K
DV 52 ST 52 33¼ 47 2½ 21⁄ 1 24 58¼ 12 5 8
E
5 1/4”
Side View
Figure 1. Fireplace dimensions in inches.
Clearances
These clearances apply to all dimensions except the framed opening, where the
clearance to combustibles is 0". The DV 52 ST clearance to unprotected combustible
walls which are perpendicular to the replace opening, must not project beyond the
shaded area shown in Figure 24.
For protection against freezing temperatures, it is recommended that outer walls of
the chase be insulated with a vapor barrier. This will reduce the possibility of a cold-air
convection current on the replace.
Clearance to Combustibles
Top (Top Vent) 30"
Sides 1"
Floor 0"
Mantel 4"
Frame the replace cavity according to Figure 2.
Slide the replace into the cavity. Tack four studs (vertical) in place as shown in
Figure 2a. Secure the replace in position by nailing into these cleats. (Minimum
2" clearance must still be maintained around the vent pipes.)
60”
Figure 2a. Securing the replace to the framing.
WARNING!
When this appliance is installed directly on carpeting, tile or any combustible
material other than wood ooring, it must be installed on a metal or wood
panel extending the full width and depth of the appliance.
* Clearance from the top of the
enclosure.
** Refer to page 14.
to a combustible ceiling within the
Page 4
rev.110329
Installation
DV 52 ST See-thru Gas Fireplace
Installing The Gas Line
The gas line must be installed before nishing the DV 52 ST Fireplace. Natural Gas
requires a minimum inlet gas supply pressure of 5.5" w.c. and a manifold pressure of
3.5" w.c. Propane Gas requires a minimum inlet gas supply pressure of 11" w.c. and
a manifold pressure of 10" w.c. Provision must also be made for a ⁄" N.P.T. plugged
tapping and be accessible for test gauge connection immediately upstream of the
gas supply controls to the appliance. The replace gas connection and the main
operating gas valve is located behind the removable trim at the bottom of the unit
and need only be attached to the gas line with an approved tting, as required by
the applicable installation codes.
To access the replace gas connection the main burner must be removed
as shown below in Figure 5a.
• Only use gas shut-o valves approved for use by the state, province, region, or
governing body, in which the appliance is being installed, or as required by the
applicable installation codes.
• Flexible gas connectors must not exceed 3 feet in length, unless it is allowable within
applicable installation codes.
The appliance and its individual shut-o valve must be disconnected from the gas
Gasline Access
0.875
dia.
Vent Installation
This section covers the installation of direct venting and terminations.
Installation Requirements
• DV 52 ST replaces are certied for use with European Home 5"/8" venting components.
• Minimum clearance to combustible construction around the vent pipe is 1" on all sides,
except on horizontal venting where the top of the pipe must have a clearance of at least 2".
• Use only certied European Home vent components. (Use of other parts will void the
European Home warranty, and may impede the operation of the replace.)
• All joints must be secured with a minimum of two screws per joint
• Vent terminations must not be recessed in walls or siding
• Horizontal runs must be supported by a minimum of two supports per horizontal run. A
minimum of one screw on each side of support is also required
• Flex vent sections may be stretched up to 50% of their total length (e.g. a 24" section
may be stretched to 36")
• Flex vent sections over 6 feet must fall within the limits set by the venting graph and must
have a minimum vertical rise of 3 inches per foot of ex.
• Solid vent sections may be cut less than half way from the female end
• Venting components can be used in any combination of solid/rigid pipe or ex pipe and
in any orientation - male connectors can face in any direction
6
to center
2 1/2
Figure 5a. Gas line access.
supply piping system during any pressure testing of that system at test pressures in
excess of ½ psig (3.5 kPa).
The appliance must be isolated from the gas supply piping system by closing its
individual manual shut-o valve during any pressure testing of the gas supply piping
system at test pressures equal to or less than ½ psig (3.5 kPa).
Note: After gas line is connected, each appliance connection, valve and
valve train must be checked while under normal operating pressure
with either a liquid solution, or leak detection device, to locate any
source of leak. Tighten any areas where bubbling appears or leak is
detected until bubbling stops completely or leak is no longer detected.
DO NOT use a ame of any kind to test for leaks.
Cautions:
• Vent terminations can be very hot. If the termination is less than
7 feet above a public walkway, it should be tted with a certied
European Home Heat Guard. (Part no. PTKOG).
• Do not obstruct, or attempt to conceal, the vent termination.
These actions will aect the operation of the replace, and may
be hazardous.
• In heavy snow areas, take extra care to prevent snow buildup from
obstructing the vent termination.
• Use European Home VSS Vinyl Shield when using on applications
with vinyl siding to guard against possible damage.
Installing The Remote Switch
The DV 52 ST gas valve, located behind the lower horizontal panel, may be connected
to a wall switch. The valve generates its own power on a millivolt circuit. Use only
low voltage wire, and DO NOT connect any external power to it.
Note: The switch location must not exceed 30' from the replace.
rev.110329
Page 5
DV 52 ST See-thru Gas Fireplace
12
12
11
11
1212
12
Installation
Installing Terminations with Built-In Frames
PTO-4F (5"/8")
Figure 5a. Installing a PTO termination.
1. Frame the termination opening to 11" x 11".
2. Fasten the termination to the studs using a minimum of 4 screws.
Installing Terminations with MSR Frames
MSR
Installing Heat Guards over Terminations
PTKOG (5"/8")
Figure 5d. Installing a PTO termination heat guard.
1. Ensure that the two long mounting brackets are facing the bottom of the
termination. (See inset). This will provide more heat protection at the top of
the termination, where temperatures are highest.
2. Attach to the faceplate of the termination using four sheet metal screws.
3. If installing the termination over vinyl siding, use the VSS Vinyl Shield.
PTO-4 (5"/8")
Figure 5b. Installing a PTO termination with the MSR frame.
1. Frame the termination opening to 12" x 12".
2. Fasten the termination to the studs using a minimum of 4 screws.
Installing Terminations with MOSR Frames
MOSR
PTO-4 (5"/8")
Figure 5c. Installing a PTO termination with the MOSR frame.
1. Frame the termination opening to 12" x 12".
2. Fasten the MOSR frame to the interior side of the studs using a minimum of 4
screws.
3. Insert the termination into the MOSR frame as shown here and attach by screwing
through the four pilot holes in the termination.
Page 6
Figure 6. Installing the VSS Vinyl Shield.
rev.110329
Loading...
