H I G H L I G H T S
M
icroscopes for education
10
years warranty
Binocular
model
BB.4260
Monocular model
BB.4220
BioBlue
Monocular, binocular and trinocular
Semi-Plan objectives and a reversed
Integrated mechanical stage
Digital and polarization models available
Standard LED illumination and 20W
Ergonomically carrying grip
Specifications
Eyepiece(s)
DIN WF10x/18mm. The eyepieces of monocular models are equipped with pointer and are secured with
Allen screw
Head
Monocular heads with 45° inclined tube and secured with Allen screw. Binocular and trinocular heads with
30° inclined tubes. Discussion head is also available.
The digital versions are equipped with a 1.3 Mpixel 1/3 inch CMOS Color USB2 camera @ 1280x 1024 pixels
Nosepiece
Revolving quadruple reversed nosepiece on ball-bearings
Polarization models equipped with swing-in analyzer
Objectives
Standard equipped with achromatic DIN semi-plan corrected 4x/0,13, 10x/0,25, S40x/0,65
Semi-plan achromatic corrected 20x, S60x and S100x/1.25 objectives also available
All optical parts are anti-fungus treated
Stage
Plain 120 mm x 120 mm stage with 2 object clamps or 130 mm x 130 mm stage with integrated
mechanical stage. Round 129 mm stage with 2 object clamps for polarization models
Condenser
In height adjustable N.A.1,25 Abbe condenser
Focusing adjustment
Coaxial coarse and 200 µm fine adjustments, 2 µm precision
Friction adjustment
Illumination
1 W intensity adjustable NeoLED illumination with internal power supply /charger and 3 NiMH AA batteries
Polarization models come standard with halogen illumination. LED polarization versions on request
BioBlue series – Microscopes for Education Page 1/3
quadruple nosepiece
halogen for polarization models
Mod
els Mono
Bino
Trino
Digital
Obj.
Obj.
Mechanical
LED Polarisation
(1)
Digital model
BB.4255
Polarisation model
BB.4240-P
Trinocular
BB.4243
Software
ImageFocus capture & analysis software is supplied with each digital microscope model.
The software is compatible with Windows XP, Vista and Windows 7 & 8, both 32 and 64 bits platforms
Specifications
BioBlue series – Microscopes for Education Page 2/3
head
S60x
S100x
stage
BB.4200 • •
BB.4220 • • •
BB.4240 • • • •
BB.4250 • • • •
BB.4260 • • • •
BB.4243 • • • •
BB.4253 • • • •
BB.4205 • • •
BB.4225 • • • •
BB.4245 • • • • •
BB.4255 • • • • •
BB.4267 • • • • •
BB.4220-P • •
BB.4240-P • • •
BB.4260-P • • •
Polarisation models are standard available in 20W 12V halogen versions. LED versions on demand
(1)
(1)
(1)
Datasheet
Accessories & spare parts
AE
.5572 WF 10x/18 mm eyepiece
AE.5573 HWF 15x/12 mm eyepiece
AE.
AE.5582
5581 HWF 10x/18 mm eyepiece with micrometer reticule
HWF 20x/12 mm eyepiece
BB.5511 Discussion head for BioBlue serie
AE
AE
AE
.5591 Achromatic Semi-Plan DIN 4x/0.13 objective
AE.5593 Achromatic Semi-Plan DIN 10x/0.25 objective
AE.5594 Achromatic Semi-Plan DIN 20x/0.40 objective
AE.5597 Achromatic Semi-Plan DIN S40x/0.65 objective
.5599 Achromatic Semi-Plan DIN S60x/0.85 objective
.5601 Achromatic Semi-Plan DIN S100x/1.25 objective
AE.5150 Simple polarization set. Polarizer mounted in eyepiece, analyser in filter holder
AE.5153 Simple polarization set for models without mechanical stage. Analyzer mounted under head
and 360° rotatable polarizer to be placed on stage
AE.5155 Microscope glass slides 76 x 26 mm, edges grinded, 50 pcs
AE.5168 Cover glasses 22 x 22 mm, thickness, 0.13-0.17, 100 pcs
AE.5245 Lens cleaning paper, 100 sheets
AE.5255 Immersion oil n = 1.482, 25 ml
SL.5527 Spare fuses, packed 10 pcs
SL.1379 Spare bulb halogen 12V 20W
