Euromaid CSAOL90PK, GEAOL90PK Specifications Sheet

RANGEHOOD

221mm

170mm

400-780mm

245mm

35mm

500mm

900mm

AAS9SE3

specications

900mm

features

• Stainless Steel

• Push Button

• 3 speed

• 3 x Aluminium Grease Filters

• 2 x halogen lights

• Ducted or recirculating operation*

Airow: 700 m3/hr
Sound level: 57 dB (A)
Ducting Spigot: 150mm ducting refer to website for choices
Extension Flue: IASXSE3 - 900mm in legnth
Cable: Insulated 1.5metre cable
Power: 240V/50Hz

*Optional
Carbon Filters for recirculating use Model No.AXFC1
Recirculating Kit IA150BSRK

dimensions

Product Dimensions: 645-1025mm (h) x 900mm (w) x 500mm (d)

warranty - customer service

Warranty

2 years Parts and Labour

Customer Service

Our Naonwide Service Team can be
contacted on our Toll Free Customer Service
Number 1800 805 300 or by logging on to

hp://customersupport.hapl.com.au/

AAS9SE2 HAPL April 2013 DE

20 Carlotta Street
Artarmon NSW 2064
T: 02 9958 3111
F: 02 9958 3555
E: [e-mail]

www.hapl.com.au
