Stands & Lifters
EUROLITE A1 Steel lighting stand
Inexpensive steel-stand
• With crossbeam for up to 4 spots
• For TV-pins up to d=17 mm
EUROLITE STV-20 Follow spot stand
Inexpensive follow-stand
• Stable follow-stand for mobile use
• The telescopic tube is additionally fixed with a safety pin
www.eurolite.de
No. 59006985
Technical specifications:
Max. carrying capacit y: 14 kg
Minimum height: 1.20 m
Maximum heigh t: 2.50 m
Maximum elevation: 1.30 m
Weigh t: 6 kg
No. 59007120
Technical specifications:
Type: Telescopic stand
Const ruction: DIN 15560-27, DIN EN ISO 12100-2
Certified by: CE
Sections: 1
Max. load: 18 kg
Max. height: 2 .10 m
Min. he ight: 1.35 m
Adapt er: D = 28.5 mm
Weigh t: 6.3 kg
EUROLITE STV stand
Lighting stand made of steel
• With TV pin (d=28 mm)
EUROLITE STC-300 Lighting stand
High-quality winch-stand
• Made of steel
• 1-gear winch for easy lifting of the loads
• Automatic braking system
Technical specifications:
Type: Telescopic stand
Const ruction: DIN 15560-27, DIN EN ISO 12100-2
Certified by: CE
Sections: 2
Max. load: 18 kg
Max. height: 3.40 m
Min. he ight: 1.50 m
Adapt er: D = 28.5 mm
Base ar ea: D = 1.20 m
Transpo rt dimensions: 1.59 x 0.18 x 0.15 m
No. 59006996 ..................................................... STV-40S, steel, 10 kg
No. 59007001 ..........................................................STV-40A, alu, 7 kg
No. 59007002 ..............................................STV-40-WOT, alu no T-bar
No. 59007004 .........................................STV-40S-WOT, steel no T-bar
No. 59007095 ......................... Carrying bag for one EUROLITE STV-40
No. 59007003
Technical specifications:
Type: Winch-driven stand
Const ruction: DIN 15560-27, DIN EN ISO 12100-2
Certified by: CE
Sections: 2
Max. load: 35 kg
Min. load: 25 kg
Max. height: 2.40 m
Min. he ight: 1.50 m
Adapt er: TV-Cone D:30 mm
Base ar ea: D = 1.20 m
Transpo rt dimensions: 1.47 x 0.18 x 0.14 m
Weigh t: 12 kg
610
Delivery, technical changes, errors and omissions exempted. Please take notice of the user manuals and latest information which can be downloaded from our site. All pictures are similar and partially symbolic.
