www.eurolite.de
EUROLITE LED IP T500 RGB 10mm 20°
Brilliant LED RGB outdoor color changer (IP65)
• Functions: static colors, automatic color ch ange, internal programs,
strobe effect, Master/Slave
• Control in stand-alone mode and DMX progr amming via optional IR remote
• Locking possibilit y at the mounting bracket
• Beam angle 20° or 40°
EUROLITE LED IP T500 TCL 9x3W 15°
LED RGB outdoor color changer with TCL LEDs (IP65)
• Color changer with 9 x 3 W LED
• Functions: static colors; automatic color change, 9 built-in programs and
strobe effect with variable speed; Master/Slave
• Control in stand-alone mode and switch to DMX mode via optional I R remote
• Beam angle 15°
EUROLITE LED IP T1000 BCL 12x5W 20°
Outdoor color changer (IP65) with 12 x 5 W BCL
• Equipped with 2in1 bicolor LEDs with white a nd amber
• Steplessly progr ammable color temperature and strobe ef fect
• Control in stand-alone mode and DMX progr amming via optional IR remote
• Functions: static colors, automatic color ch ange, internal programs,
strobe effect, Master/Slave
Outdoor
Technical specifications:
Power su pply: 230 V AC, 50 H z ~
Power co nsumption : 14 W
Numbe r of DMX control channels: 5
Prot ection g rade: IP 65
LED ty pe: 10 mm
Numbe r of LEDs: 114
Dimen sions (Lx WxH): 500 x 80 x 170 mm
Weigh t: 3 kg
No. 51914110 ................................................................................... 20 °
No. 51914112 ................................................................................... 40°
No. 51914113
Technical specifications:
Power su pply: 230 V AC, 50 H z ~
Power co nsumption : 30 W
Numbe r of DMX chann els: 3/4/5 /6
DMX c onnecti on: 3-pi n screwabl e connec tor plug
LED ty pe: 3 W
Numbe r of LEDs: 9
Beam an gle: 15°
Dimen sions (Lx WxH): 500 x 80 x 100 mm
Weigh t: 3 kg
No. 51913153
Technical specifications:
Power su pply: 230 V AC, 50 H z ~
Power co nsumption : 60 W/110 VA
Numbe r of DMX control channels: 4
Prot ection g rade: IP 65
LED-type: 5-W BCL
Numbe r of LEDs: 12
Beam an gle: 20°
Dimen sions (Lx WxH): 1000 x 80 x 100 m m
Weigh t: 5 kg
No. 51914121
EUROLITE LED IP T1000 HCL 9x12W
Ultra -flexible LED architec tural spot (IP65) with 12 W HCL LEDs
• Equipped with 9 HCL LEDs in the colors red, green, blue, amber,
white and UV
• Flicker-free projection
• For architectural lighting
• Fully convection cooled, no fans
• Different dimmer curves and dimmer speed (step response) adjustable
Technical specifications:
Power su pply: 100-240 V AC, 5 0/60 Hz
Power co nsumption : 75 W
Beam an gle: 30°
LED ty pe: 12 W HCL
Numbe r of LEDs: 9
DMX co ntrol channels : 4/5/6/7/9/12
DMX512 c onnectio n: 3-pi n screw con nector
Flash -rate: 18 Hz
Dimen sions (Lx WxH): 584 x 190 x 101 m m
Weigh t: 4 kg
No. 51914102
EUROLITE LED IP T2000 WW
Versatile LED architectural lighting (IP65) with 5 W LEDs
and 3800 K
• Special lenses offer a larger beam angle horizontally than vertically: 10x40°
• Fully convection cooled, no fan
• Different dimmer curves adjustable
• Addressing and setting via Control Board with LED display and
four operating but tons
Technical specifications:
Power su pply: 100-240 V AC, 5 0/60 Hz
Power co nsumption : 80 W
Prot ection g rade: IP 65
DMX co ntrol channels : 1/3
Flash -rate: 18 Hz
LED ty pe: 5 W W W
Numbe r of LEDs: 16
Color tempera ture: 3800 K
Dimen sions (Lx WxH): 999 x 184 x 95 mm
Weigh t: 7 kg
No. 51914101
EUROLITE LED IP T2000 QCL
Versatile LED architectural lighting (IP65) with 15 W QCL
LEDs by CREE
• Special lenses offer a larger beam angle horizontally than vertically: 10°x40°
• Fully convection cooled, no fan
• Different dimmer curves and dimmer speed (step response) adjustable
• Addressing and setting via Control Board with LED display and
four operating but tons
Delivery, technical changes, errors and omissions exempted. Please take notice of the user manuals and latest information which can be downloaded from our site. All pictures are similar and partially symbolic.
Technical specifications:
Power su pply: 100-240 V AC, 5 0/60 Hz
Power co nsumption : 175 W
Prot ection g rade: IP 65
DMX co ntrol channels : 3/4/5 /7/10
DMX512 c onnectio n: 3-pi n screw con nector
Flash -rate: 18 Hz
LED ty pe: 15 W QCL (R,G, B,W)
Numbe r of LEDs: 16
Dimen sions (Lx WxH): 999 x 184 x 95 mm
Weigh t: 7 kg
347
