Luminaires
EUROLITE LED Pixel Panel 16 DMX
DMX-controllable pixel panel with TCL LEDs
• 22 programs and color change with adjustable speed
• E ach of the 16 TCL LEDs can be controlled individually
• Wall or truss installation
• DMX-controlled or sta nd-alone operation with Master/Slave function
EUROLITE LED Pixel Panel 64 DMX
DMX-controllable pixel panel with TCL LEDs
• DMX-controlled or sta nd alone operation
• E ach of the 6 4 TCL LEDs can be controlled individu ally
• Installation on a wall or on a truss system possible
ww w.eurolite.de
No. 51928739
Technical specifications:
Power su pply: 90 - 240 V AC, 5 0/60 Hz ~
Power co nsumption : 17 W
Numbe r of DMX chann els: 48
DMX512 c onnectio n: 3-pi n XLR
Sound -contr ol: via bu ilt-in m icrophon e
LED ty pe: Tricolor, SMD 5050
Numbe r of LEDs: 16
Beam an gle: 120°
Pixe l pitch: 62.5 mm
Dimen sions (Lx WxH): 250 x 250 x 5 0 mm
Weigh t: 1.5 kg
No. 51928736
Technical specifications:
Power su pply: 100-240 V AC, 5 0/60 Hz
Power co nsumption : 20 W
Numbe r of DMX c hannels: 192
DMX-512 c onnecti on: 3-pi n XLR
Sound -contr ol: via bu ilt-in m icrophon e
LED Type: Tricolor LEDs, t ype SMD 5050
Numbe r of LEDs: 64
Beam an gle: 120°
Pixe l pitch: 31.2 mm
Dimen sions (Lx WxH): 250 x 250 x 5 0 mm
Weigh t: 1.5 kg
294
No. 51928840
EUROLITE LED Puzzle 5x5 QCL Panel
Pixel mapping panel with 8 W QCL LEDs
• Equipped with 25 x 8 W QCL LED with RGBW colors
• E ach LED can be controlled individually
• Flicker-free projection
• 3, 5, 8, 9 or 100 DMX channel mode selectable
• Super-light and durable aluminum constr uction
• Seamles s, modular display concept allows the build-up of large areas
Delivery, technical changes, errors and omissions exempted. Please take notice of the user manuals and latest information which can be downloaded from our site. All pictures are similar and partially symbolic.
Technical specifications:
Power su pply: 100-240 V AC, 5 0/60 Hz
Power co nsumption : 145 W
Numbe r of DMX chann els: 3/5/ 8/9/100
DMX512 c onnectio n: 3-pi n XLR
Sound -contr ol: via bu ilt-in m icrophon e
LED ty pe: 8 W, QCL
Pixe l pitch: 80 mm
Numbe r of LEDs: 25
Max. beam angle: 8 °
Dimen sions (Lx WxH): 102 x 399.5 x 3 99 mm
Weigh t: 6.8 kg
