www.eurolite.de
EUROLITE LED Mirror ball 13cm w/illuminated base
Rotating mirror ball
• 18 LEDs in the base (6x red, 3x blue, 3x green, 6x white)
• 12 rotations per minute
EUROLITE LED Mirror ball 20cm, with motor FC
20 cm mirrorball illuminated from the inside and outside
• All in one: Light, mirror ball and motor
• Fading color LEDs illuminate the rotating mirror ball
Mirror Effects
No. 42109269
Technical specifications:
Power su pply: 4.5 V DC via i ncluded powe r unit or 3 x AA ba ttery
Power co nsumption: 4.6 W
Rotation-speed: approx. 12 RPM
Numbe r of LEDs: 18
Dimen sions (Lx WxH): 130 x 130 x 210 mm
Weigh t: 0.5 kg
No. 42109265
Technical specifications:
Mirrorball motor:
Power su pply: 230 V AC, 50 Hz ~ (via AC 12 V power-unit i ncluded in th e delivery)
Power co nsumption: 7 W
Rotation-speed: approx. 5 RPM
Diame ter of base plate: 110 mm
Height: 80 mm
Mirrorball:
Diameter: 20 cm
Total weight: approx. 0.63 kg (power unit: 100g, mirror ball
with motor/overhead suspension: 530g)
EUROLITE Mirror ball set with pinspot
Set
• With motor, chain and color wheel
• With EUROLITE T-36 Pinspot, black
EUROLITE Mirror ball Set with LED spot
Set
• With motor and chain
• With EUROLITE LED PST-3 W pinspot, black
Technical specifications:
T-36 Pinspot:
Power su pply: 230 V AC, 50 H z ~
Power co nsumption: 40 W
Fit ting lamp: 6 V/30 W PAR- 36
Dimen sions (Lx WxH): 160 x 150 x 170 mm
Weigh t: 1 kg
Mirrorball motor:
Power su pply: 230 V AC, 50 H z ~
Power co nsumption: 4 W
Maximum charg e: 3 kg
Max. diameter o f mirror bal l: 20 cm
Rotation-speed: approx. 1.5 RPM
Diame ter of base plate: 112 mm
Height: 60 mm
Weigh t: 0.45 kg
No. 50101855 .............................................................................. 20 cm
No. 50101860 ..............................................................................30 cm
Technical specifications:
LED Pin spot:
Power su pply: 230 V AC, 50 H z ~
Power co nsumption: 13 W
LED bea m angle: 6°
Color temperature: 6000 K
Dimen sions (Lx WxH): 100 x 90 x 100 mm
Weigh t: 0.3 kg
Mirrorball motor:
Power su pply: 230 V AC, 50 H z ~
Power co nsumption: 4 W
Maximum charg e: 3 kg
Rotation-speed: approx. 1.5 RPM
Diame ter of base plate: 112 mm
Height: 60 mm
Weigh t: 0.45 kg
No. 50101856 ..............................................................................20 cm
No. 50101861 ..............................................................................30 cm
Delivery, technical changes, errors and omissions exempted. Please take notice of the user manuals and latest information which can be downloaded from our site. All pictures are similar and partially symbolic.
