www.eurolite.de
Accessories & Analyzers
EUROLITE Cable tie
HASE Gloves 3 finger
Professional gloves for roadies
• 3 fingers version
EUROLITE Floor cable channel 75mm silver
Rugged floor cable channel
• With slip-resistant surface on the cover
• Wheelchairs can easily overcome the channel
• Extreme stability
• Easy installation
• Low weight
No. 30006046 .......................................................200 x 2,2 mm, white
No. 30006051 ........................................................200 x 2,2 mm, black
No. 30006056........................................................200 x 2,5 mm, white
No. 30006061........................................................200 x 2,5 mm, black
No. 30006066 .......................................................200 x 2,9 mm, white
No. 30006076 .........................................................200 x4,5 mm, white
No. 30006081 .........................................................200 x4,5 mm, black
No. 30006086.........................................................200 x4,8 mm, white
No. 30006091.........................................................200 x4,8 mm, black
No. 78020396 .....................................................................................M
No. 78020401 ...................................................................................... L
No. 78020403 .................................................................................... XL
No. 51210852 ..................................................................................2 m
No. 51210854 ..................................................................................4 m
EUROLITE LM-50 Lux meter
Digital light meter for a fast illumination measurement
• 3 selectable measuring ranges from 0-50,000 lux
• Auto zero adjustment
EUROLITE LM-200 Lux meter
Digital light meter for a fast illumination measurement
• 4 selectable measuring ranges
• Peak function
No. 10360620
Technical specifications:
Power su pply: 9 V battery
Measuring ranges: 0-2000 lx, 2000-20000 lx (measurand x 10), 20000-50000 lx
(measu rand x 100)
Accuracy: ± 5 % + 2 digits within 2 2-28 °C
Calibration: Standard incandescent lamp at color temperature 2856 kelvin
Sampling rate: 0.4 measurements per second
Dimen sions (Lx WxH): 115 x 70 x 30 mm
Weigh t: 0.3 kg
No. 10360630
Technical specifications:
Power su pply: 9 V battery
Battery life: approx. 200 hrs.
Measu ring ranges lux: 0-200 l x, 200-2000 lx, 2000-20000 lx
(measurand x 10), 20000-200000 lx (measurand x 100)
Accuracy: ± 3 % rdg ± 5 % fs <= 2000 0 lux, ± 5 % rdg ± 10 dig its = 20000 l x)
Calibration: Standard incandescent lamp at color temperature 2856 kelvin
Repea tabilit y: ± 2 %
Temperature characteristic: ± 0,1 %/°C
Sampling rate: 2 measurements per second
Measuring electrode: Silicon photodiode with filter
Dimen sions (Lx WxH): 160 x 80 x 4 0 mm
Weigh t: 0.3 kg
Delivery, technical changes, errors and omissions exempted. Please take notice of the user manuals and latest information which can be downloaded from our site. All pictures are similar and partially symbolic.
