www.eurolite.de
EUROLITE LED KLS-1001 Compact Light Set
DMX LED spotlight set with 48 TCL LEDs for mobile use
• 12 TCL LEDs per spot with 3 watts each
• Comes pre-assembled with practical transport bag
• Can be controlled via DMX, sound or stand-alone mode
• Convenient control possible via optional 4-pedal foot pedal FP-1 or
IR remote control (separately available)
• 4 IEC outputs for power supply of further devices
EUROLITE LED KLS-801 Compact Light Set
DMX LED spotlight set with 28 TCL LEDs for mobile use
• 7 TCL LEDs per spot with 3 watts each
• Comes pre-assembled with practical transport bag
• Can be controlled via DMX, sound or stand-alone mode
• Convenient control possible via optional 4-pedal foot pedal FP-1 or
IR remote control (separately available)
• 4 IEC outputs for power supply of further devices
Mobile Light Systems
No. 42109875
Technical specifications:
Power su pply: 230 V AC, 50 H z ~
Power co nsumption: 180 W/340 VA
DMX control channels: 15
DMX512 connection: 3-pin XLR
Sound-control: via built-in microphone
LED ty pe: 3 W TCL
Numbe r of LEDs: 48
Beam an gle: 18°
TV spigot: D = 28 mm
Dimen sions (Lx WxH): 1200 x 65 x 315 mm
Dimen sions case (L xWxH): 1250 x 120 x 380 mm
Weigh t: 10 kg
No. 421098 51
Technical specifications:
Power su pply: 230 V AC, 50 H z ~
Power co nsumption: 90 W/130 VA
DMX control channels: 15
DMX512 connection: 3-pin XLR
Sound-control: via built-in microphone
LED ty pe: 3 W TCL
Numbe r of LEDs: 28
Beam an gle: 30°
TV spigot: D = 28 mm
Dimen sions (Lx WxH): 1200 x 65 x 315 mm
Dimen sions case (L xWxH): 1250 x 120 x 380 mm
Weigh t: 9 kg
EUROLITE LED KLS-401 Compact Light Set
DMX LED spotlight set with RGB LEDs for mobile use
• 180 x 10 mm LED per spot (60 x red, 60 x green, 60 x blue)
• Comes pre-assembled with practical transport bag
• Can be controlled via DMX, sound or stand-alone mode
• Convenient control possible via optional 4-pedal foot pedal FP-1 or
IR remote control (separately available)
• 4 IEC outputs for power supply of further devices
EUROLITE LED KLS-200 Compact Light Set
DMX LED spotlight set with RGB LEDs for mobile use
• Compact size and easy to transport
• 36 LEDs per color per spot
• Comes pre-assembled with practical transport bag
• Can be controlled via DMX, sound or stand-alone mode
• Convenient control possible via optional 4-pedal foot pedal FP-1
No. 42109781
Technical specifications:
Power su pply: 230 V AC, 50 H z ~
Power co nsumption: 55 W/100 VA
DMX control channels: 15
DMX512 connection: 3-pin XLR
LED ty pe: 10 mm
Numbe r of LEDs: 720 (240 red, 240 green , 240 blu e)
Beam an gle: 25°
TV spigot: D = 28 mm
Dimen sions (Lx WxH): 1200 x 55 x 310 mm
Weigh t: 7 kg
No. 42109700
Technical specifications:
Power su pply: 230 V AC, 50 H z ~
Power co nsumption: 55 W/70 VA
DMX control channels: 15
DMX512 connection: 3-pin XLR
LED ty pe: 10 mm
Numbe r of LEDs: 432 (144 r ed, 144 green, 14 4 blue)
Beam an gle: 25°
TV spigot: D = 28 mm
Dimen sions (Lx WxH): 1110 x 55 x 295 mm
Dimen sions bag (L xWxH): 1250 x 120 x 380 mm
Weigh t: 6.5 kg
Delivery, technical changes, errors and omissions exempted. Please take notice of the user manuals and latest information which can be downloaded from our site. All pictures are similar and partially symbolic.
