Eurocom M620NC User Manual

Preface

Notice

The company reserves the right to revise this publication or to change its contents without notice. Information
contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or
any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear
in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse)
of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, trans­mitted or reduced to any machine readable form without prior consent from the vendor, manufactur er or creators
of this publication, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trade­marks of their respective companies. They are mentioned for identification purposes only and are not intended
as an endorsement of that product or its manufacturer.
©August 2006

Trademarks

This product incorporates copyright protection technology that is protected by method claims of certain U.S. pat ­ents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of
this copyright protection technology must be authorized by Macrovision Corporation, and is intended fo r home
or other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineer
ing or disassembly is prohibited.
Intel, Celeron, and Intel Core are trademarks/registered trademarks of Intel Corporation.

-

I

Preface

FCC Statement

(Federal Communications Commission)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in
stalled and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Re orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the service representative or an experienced radio/TV technician for help.



Warning

Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not ex­pressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the
equipment.

-

II

Preface

IMPORTANT SAFETY INSTRUCTIONS

Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury
to persons when using any electrical equipment:

1. Do not use this product near water, for example near a b ath tub, wash bowl, kitchen sink or laundry tu b, in a wet
basement or near a swimming pool.

2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There
may be a remote risk of electrical shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal instructions.

5. This product is intended to be supplied by a Listed Power Unit (DC Output 18.5V, 3.5A minimum AC/DC Adapter).

CAUTION

Always disconnect all telephone lines from the wall outlet before servicing or disassembling this equipment.

TO REDUCE THE RISK OF FIRE, USE ONLY NO. 26 AWG OR LARGER, TELE-

COMMUNICATION LINE CORD

This Computer’s Optical Device is a Laser Class I Product

III

Preface

Instructions for Care and Operation

The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:

1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.

Do not expose the computer
to any shock or vibration.

Do not place it on an unstable
surface.

Do not place anything heavy
on the computer.

2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-
ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly dam­aged.

Do not expose it to excessive
heat or direct sunlight.

Do not leave it in a place where
foreign matter or moisture may
affect the system.

Don’t use or store the computer
in a humid environment.

Do not place the computer on
any surface that will block the
Vents/Fan Intakes.

IV

Preface

3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other
strong magnetic fields. These can hinder proper performance and damage your data.

4. Follow the proper workin g procedu res for t he computer. Shut the computer down properly and don’t forget
to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.

Do not turn off the power until
you properly shut down all pro­grams.

Do not turn off any peripheral
devices when the computer is
on.

5. Take care when using peripheral devices.

Use only approved brands of
peripherals.

Do not disassemble the com­puter by yourself.

Unplug the power cord befor e
attaching peripheral devices.

Perform routine maintenance
on your computer.

V

Preface

Power Safety

The computer has specific power requirements:



Power Safety Warning

Before you undertake
any upgrade proce­dures, make sure that
you have turned off the
power, and disconnect­ed all peripherals and
cables (including tele­phone lines). It is advis­able to also remove your
battery in order to pre­vent accidentally turning
the machine on.

VI

• Only use a power adapter approved for use with this computer.

• Your AC/DC adapter may be designed for international travel but it still requires a steady,
uninterrupted power supply. If you are unsure of your local power specifications, consult
your service representative or local power company.

• The power adapter may have either a 2-pr ong or a 3-prong ground ed plug. The third prong
is an important safety feature; do not defeat its purpose. If you do not have access to a
compatible outlet, have a qualified electrician install one.

• When you want to unplug the power cord, be su re to disconnect it by the plug head, not by
its wire.

• Make sure the socket and any extension cord(s) you use can support the total current load
of all the connected devices.

• Before cleaning the computer, make sure it is disconnected from any external power sup­plies (i.e. AC/DC adapter or car adapter).

Do not plug in the power
cord if you are wet.

Do not use the power cord if
it is broken.

Do not place heavy objects
on the power cord.

Preface

Battery Precautions

• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.

• Do not remove any batteries from the computer while it is powered on.

• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even
if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly
result in fire.

• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.

• Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service repre sent ative or qual­ified service personnel.

• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries
may explode or leak if exposed to fire, or improperly handled or discarded.

• Keep the battery away from metal appliances.

• Affix tape to the battery contacts before disposing of the battery.

• Do not touch the battery contacts with your hands or metal objects.



Battery Disposal & Caution

The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with
your local solid waste officials for details in your area for recycling options or proper disposal.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the
manufacturer. Discard used battery according to the manufacturer’s instructions.

VII

Preface

Cleaning

Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.

Servicing

Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the
computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the
power supply. Then refer servicing to qualified service personnel under any of the following conditions:

• When the power cord or AC/DC adapter is damaged or frayed.

• If the computer has been exposed to rain or other liquids.

• If the computer does not work normally when you follow the operating instructions.

• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).

• If there is an unusual odor, heat or smoke coming from your computer.



Removal Warning

When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and
screw(s) before turning the computer on.

VIII

Preface

Travel Considerations

Packing

As you get ready for your trip, run through this list to make sure the system is ready to go:

1. Check that the battery pack and any spares are fully charged.

2. Power off the computer and peripherals.

3. Close the display panel and make sure it’s latched.

4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.

5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,

check with your travel agent to see if you need any socket adapters.

6. Put the notebook in its carrying bag and secure it with the bag’s straps.

7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters

and/or cables.

8. Anticipate customs - Some jurisdictions may have import restrictions or requ ire proof of ownershi p for both hard-

ware and software. Make sure your “papers” are handy.



Power Off Before Traveling

Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prevent your
computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.

IX

Preface

On the Road

In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting,
keep these points in mind:

Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very
common. Don’t check it with “normal” luggage. Baggage handlers may not be sufficiently careful. Avoid knock
ing the computer against hard objects.

Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the com­puter, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and
disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note:
Some airports also scan luggage with these devices.

Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight.
These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make
sure it’s secure. Contents may shift and/or fall out when the compartment is opened.

Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies)
charged.

-

Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer.
Wait a few minutes before turning it on so that any moisture can evaporate.

X

Preface

Developing Good Work Habits

Developing good work habits is important if you need to work in front of the computer for long periods of time.
Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or
other joints. The following are some tips to reduce the strain:

• Adjust the height of the chair and/or desk so that the keyboard is at or slightly belo w the
level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.

• Your knees should be slightly higher than your hips. Place your feet flat on the floor or on
a footrest if necessary.

• Use a chair with a back and adjust it to support your lower back comfortably.

• Sit straight so that your knees, hips and elbows form approximately 90-degree angles
when you are working.

• Take periodic breaks if you are using the computer for long periods of time.

Remember to:

• Alter your posture frequently.

• Stretch and exercise your body several times a day.

• Take periodic breaks when you work at the computer for long periods of time. Frequent
and short breaks are better than fewer and longer breaks.

XI

Preface

Lighting

Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and
shoulders.

• Position the display to avoid glare or reflections from overhead lighting or outside sources of light.

• Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

• Position the display directly in front of you at a comfortable viewing distance.

• Adjust the display-viewing angle to find the best position.

XII

Contents

Notice .................................................................................I

FCC Statement .............................................................II

Instructions for Care and Operation ..........................IV

Power Safety ..............................................................VI

Battery Precautions ...................................................VII

Cleaning .................................................................. VIII

Servicing ................................................................. VIII

Travel Considerations ................................................IX

Quick Start Guide

Overview ........................................................................1-1

Model Designs .............................................................1-2

Advanced Users ...........................................................1-2

Beginners and Not-So-Advanced Users ......................1-2

Warning Boxes ............................................................1-2

Not Included ................................................................1-3

System Software ..........................................................1-3

System Startup ...............................................................1-4

System Map: Top View with LCD Panel Open ............1-5

LED Indicators ................................................. .... ..........1-6

Keyboard & Hot Keys ...................................................1-7

Function Keys ...................................................... .... .... ..1-8

System Map: Front & Rear Views .................................1-9

System Map: Left View ...............................................1-10

Preface

System Map: Right View .............................................1-11

System Map: Bottom View ..........................................1-12

Windows XP Start Menu & Control Panel ..................1-13

Video Features .............................................................1-14

Display Devices & Options ......................................1-14

Power Management Features .......................................1-16

Features & Components

Overview ........................................................................2-1

Hard Disk Drive .............................................................2-2

Optical (CD/DVD) Device ............................................2-3

Loading Discs ..............................................................2-3

Handling CDs or DVDs ...............................................2-4

DVD Regional Codes ..................................................2-5

4-in-1 Card Reader .........................................................2-6

PC Card Slot .................................................. .... ............2-7

Inserting and Removing PC Cards ..............................2-7

TouchPad and Buttons/Mouse .......................................2-8

Audio Features ...............................................................2-9

Adding a Printer ................................................. .... ......2-10

USB Printer ..............................................................2-10

Parallel Printer ..........................................................2-10

XIII

Preface

Power Management

Overview ........................................................................3-1

Advanced Configuration and Power Interface ............ 3-1

The Power Sources .............................. .... .... ..................3-2

AC/DC Adapter ......................................................... ..3-2

Battery .........................................................................3-2

Turning on the Computer ...............................................3-3

Power Schemes ..............................................................3-4

System Power Options ................................................... 3-6

Hibernate Mode vs. Shutdown ....................................3-6

Stand by Mode vs. Hibernate Mode ............................3-6

Stand by ......................................................................3-7

Hibernate ....................................................................3-7

Configuring the Power Button ....................................... 3-8

Battery Information .......................................................3-9

New Battery ................................................................3-9

Battery Life .................................................................3-9

Recharging the Battery with the AC/DC Adapter .....3-10

Using the BIOS Utility to Calibrate the Battery ........3-10

Proper handling of the Battery Pack .........................3-11

Battery FAQ ..............................................................3-12

Drivers & Utilities

What to Install ............................................................... .4-1

Module Driver Installation ..........................................4-1

Service Packs ...............................................................4-3

Authorized Driver Message .........................................4-4

Version Conflict Message ...........................................4-4

Updating/Reinstalling Individual Drivers ..................4-4

Driver Installation ..........................................................4-5

Service Pack Installation .............................................4-6

New Hardware Found ..................................................4-6

Manual Driver Installation .........................................4-6

Chipset ........................................................................4-7

Video ..........................................................................4-7

Audio ..........................................................................4-7

LAN ............................................................................4-8

Modem ........................................................................4-8

PCMCIA/CardReader ................................................. 4-9

TPM (Trusted Platform Module) ................................4-9

Fingerprint Reader .................................................... 4-10

Hot Key Utility .........................................................4-10

Bluetooth ..................................................................4-10

Wireless LAN ...........................................................4-10

XIV

Preface

BIOS Utilities

Overview ........................................................................5-1

The Power-On Self Test (POST) ................................... 5-2

Failing the POST .........................................................5-3

Fatal Errors .................................................................5-3

Non-Fatal Errors .........................................................5-3

The Setup Program ........................................................5-4

Entering Setup .............................................................5-4

Setup Screens ......................................................... ......5-5

Main Menu .....................................................................5-6

CPU Type and Speed .....................................................5-6

System Time & Date (Main Menu) ...............................5-7

System Memory: (Main Menu) .....................................5-7

Advanced Menu .............................................................5-8

IDE Channel 0 Master/Slave (Main Menu) ...................5-8

Internal Pointing Device (Advanced Menu) ..................5-9

Onboard LAN Boot ROM (Advanced Menu) ...............5-9

Wake-Up On LAN (Advanced Menu) .......................... 5-9

Intel On-Screen Branding (Advanced Menu) ................5-9

Security Menu ..............................................................5-10

Set Supervisor Password (Security Menu) ..................5-10

Set User Password (Security Menu) ............................5-11

Password Check (Security Menu) ...............................5-11

Boot Sector Virus Protection (Security Menu) ............5-11

Set HDD Password (Security Menu) ...........................5-12

I/O Interface Security (Security Menu) .......................5-12

TPM Protection (Security Menu) ................................5-12

TPM Function (Security Menu) ...................................5-12

Power Menu .................................................................5-13

Power Menu .................................................................5-13

Start Battery Calibration (Power Menu) ......................5-14

Boot Menu ...................................................................5-15

Exit Menu ....................................................................5-16

Upgrading The Computer

Overview ........................................................................6-1

When Not to Upgrade ..................................................6-2

Removing the Battery ....................................................6-3

Upgrading the Hard Disk Drive .....................................6-4

Upgrading the Optical (CD/DVD) Device Drive ..........6-7

Upgrading the System Memory (RAM) ........................6-8

Modules & Options

Overview ........................................................................7-1

Bluetooth Module ..........................................................7-2

Bluetooth Driver Installation ......................................7-2

Intel PRO/Wireless WLAN Module ..............................7-4

Intel WLAN Driver Installation .................................7-5

Security Modules (Fingerprint & TPM) ........................7-6

Fingerprint Reader .........................................................7-7

XV

Preface

User Enrollment ........................................ .... .... ..........7-7

Trusted Platform Module .............................................7-10

Initializing TPM .......................................................7-10

TPM User Set Up .....................................................7-13

Initialize the TPM for use with the

Protector Suite Software ...........................................7-15

Troubleshooting

Overview ........................................................................8-1

Basic Hints and Tips ......................................................8-2

Backup and General Maintenance .................................8-3

Viruses ...........................................................................8-4

Upgrading and Adding New Hardware/Software ..........8-5

Problems & Possible Solutions ......................................8-7

Interface (Ports & Jacks)

Overview .......................................................................A-1

Notebook Ports and Jacks .............................................A-2

Built-In Microphone .....................................................A-2

Card Reader Port .......................................................... .A-2

DC-In Jack ....................................................................A-2

External Monitor (VGA) Port .......................................A -2

Headphone-Out Jack .....................................................A-2

Microphone-In Jack ......................................................A-2

Mini-IEEE 1394 Port ....................................................A-3

RJ-11 Phone Jack ..........................................................A-3

RJ-45 LAN Jack ............................................................A-3

Security Lock Slot ........................................................A-3

USB 2.0/1.1 Ports .........................................................A-4

Intel Video Driver Controls

Intel Video Driver Installation ......................................B-1

Dynamic Video Memory Technology ..........................B-2

Intel Graphics Properties ..............................................B-3

Scheme Options ..........................................................B-5

Attaching Other Displays ..............................................B-6

Display Modes ..............................................................B-7

Specifications

Processor

(CPU On Board) ...........................................................C-2

Core Logic ....................................................................C-2

Memory .........................................................................C-2

Security ......................................................................... C-2

BIOS .............................................................................C-2

LCD Options .................................................................C-2

Video Adapter ...............................................................C-3

Storage .......................................................................... C-3

Audio ............................................................................C-3

Keyboard & Pointing Device ........................................C-3

XVI

PCMCIA ....................................................................... C-3

Card Reader ..................................................................C-3

Interface ........................................................................ C-3

Communication .............................................................C-4

Power Management ......................................................C-4

Power ............................................................................ C-4

Environmental Spec ......................................................C-4

Dimensions & Weight ..................................................C-4

Optional ........................................................................ C-5

Preface

XVII

Preface

XVIII

Quick Start Guide

Chapter 1: Quick Start Guide

Overview

This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the
computer and to getting your system started. The remainder of the manual covers the following:

• Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk,
optical device, 4-in-1 card reader, PC Card), Touch Pad & Mouse, Audio & Printer.

• Chapter 3 The computer’s power saving options.

• Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the
computer’s subsystems.

• Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).

• Chapter 6 Instructions for upgrading your computer.

• Chapter 7 A quick guide to the computer’s Bluetooth, Wireless LAN and Security (Fingerprint & TPM)
Modules (some of which may be optional depending on your purchase configuration).

• Chapter 8 A troubleshooting guide.

• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external
devices.

• Appendix B Information on the Intel Video driver controls.

• Appendix C The computer’s specification.

1

Overview 1 - 1

1

Quick Start Guide

Model Designs

This notebook series includes two different model designs which vary slightly in color and appearance. However
both designs incorporate the same features, ports and jacks etc.

Advanced Users

If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful
to refer to

Chapter 4 (Drivers ), Chapter 5 (BIOS), Chapter 6 (Upgrading) and Chapter 7 (Modules & Op-

tions). You may also find the notes marked with a  of interest to you.

Beginners and Not-So-Advanced Users

If you are new to computers (or do not have an advanced knowledge of them) then the



Notes

Check the light colored
boxes with the mark
above to find detailed
information about the
computer’s features.

information contained in this Quick Start Guide should be enough to get you up and
running. Eventually you should try to look through all the documentation (more de
tailed descriptions of the functions, setup and system controls are covered in the re­mainder of the User’s Manual), but do not worry if you do not understand everything
the first time. Keep this manual nearby and refer to it to learn as you go. You may find
it useful to refer to the notes marked with a
detailed description of any of the interface ports and jacks see

 as indicated in the margin. For a more

“Interface (Ports &

Jacks)” on page A - 1.

-

Warning Boxes

No matter what your level please pay careful attention to the warning and saf ety information indicated by the 
symbol. Also please note the safety and handling instructions as indicated in the Preface.

1 - 2 Overview

Quick Start Guide

Not Included

Operating Systems (e.g. Windows XP) and applications (e.g. word processing, spreadsheet and database pro­grams) have their own manuals, so please consult the appropriate manuals.

System Software

Your computer may already come with system software pre-installed. Where this is not the case, or where you
are re-configuring your computer for a different system, you will find this manual refers to the Microsoft Win
dows XP (Home & Professional Editions) operating system.



Drivers

If you are installing new system software, or are re-configuring your computer for a different system, you will need to install
the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the com­puter and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the
order listed in Table 4 - 1, on page 4 - 6. You will be unable to use most advanced controls until the necessary drivers
and utilities are properly installed. If your system hasn’t been properly configured (your service representative may have
already done that for you), refer to “What to Install” on page 4 - 1 for installation instructions.

1

-

Overview 1 - 3

1

Quick Start Guide

System Startup

1. Remove all packing materials.

2. Place the computer on a stable surface.

3. Securely attach any peripherals you want to use with the
notebook (e.g. keyboard and mouse) to their ports.

4. Attach the AC/DC adap te r to the DC- In jack at the re ar of
the computer, the n plug the AC power cord into an outlet,
and connect the AC power cord to the AC/DC adapter.

5. Raise the lid/LCD to a comfortable viewing angle, and
press the power button to turn the computer “on”.

6. Adjust the LCD panel to a comfortable viewing angle.

7. The LED indicators show the power and battery status of
the computer.

Figure 1 - 1 - AC/DC Adapter Plugged In



Shutdown

Please note that you should always shut your computer dow n by choosing th e Turn Off Computer command from the
Start menu in Windows. This will help prevent hard disk or system problems.

1 - 4 System Startup

System Map: Top View with LCD Panel Open

Quick Start Guide

1



Wireless Device

Operation Aboard

Aircraft

The use of any portable
electronic transmission de­vices aboard aircraft is usu­ally prohibited. Make sure
the module(s) are OFF if
you are using the computer
aboard aircraft.

Use the key combination/
switch to toggle power to
the WLAN/Bluetooth mod­ules, and check the status
indicator icon to see if the
module is powered on or
not (see Table 1 - 1, on

page 1 - 6/Table 1 - 2, on
page 1 - 7/Table 1 - 3, on
page 1 - 8).

1. LCD

2. WLAN Power Switch

3. TouchPad Power Button

4. Power Button

5. Keyboard

1

6. TouchPad and Buttons

7. Fingerprint Reader

8. LED Indicators

9. LCD Latch

2

4

3

5

6

8

Figure 1 - 2 - Top View with LCD Panel Open

9

7



Security Modules

The encrypted channel between
the Trusted Platform Module
security chip and the fingerprint

reader with Protector Suite
Software provides a high level of

security for your computer. See

“Security Modules (Fingerprint
& TPM)” on page 7 - 6.

System Map: Top View with LCD Panel Open 1 - 5

1

Quick Start Guide

LED Indicators

The LED indicators on the computer display helpful information about the current status of the computer.

Icon Color Description Icon Color Description

Green The Computer is On Green The WLAN Module is Powered On

Blinking

Green

Orange The Battery is Charging Green Caps Lock Activated

Blinking

Orange

Green Hard Disk/ODD Activity

1 - 6 LED Indicators

The Computer is in Stand by Mode Orange The Bluetooth Module is Powered On

The Battery has Reached Critically

Low Power Status

Table 1 - 1 - LED Indicators

Green Number Lock Activated

Quick Start Guide

1

Keyboard & Hot Keys

The keyboard has a numerical keypad for easy numeric
data input, and features function keys to allow you to
change operational features instantly.

.

NumLk &

Numeric

Keypad

Fn Key

Figure 1 - 3 - Keyboard



Special Characters

Some software applications allow the number-keys to be
used with Alt to produce special characters. These spe­cial characters can only be produced by using the nu­meric keypad. Regular number keys (in the upper row of
the keyboard) will not work. Make sure that NumLk is
on.

ScrLk Keys

The touchpad (button) and WLAN (switch) hot keys give
instant access to the functions indicated in the table be
low. Visual indicators are available when the hot key
driver is installed (see

“Hot Key Utility” on page 4 - 10).

Table 1 - 2 - Hot Keys

Hot Key Function

WLAN Module

Toggle

Touchpad

Toggle



Other Keyboards

If your keyboard is damaged or you just want to make a
change, you can use any standard USB keyboard. The
system will detect and enable it automatically. However
special functions/hot-keys unique to the system’s regu­lar keyboard may not work.

-

Keyboard & Hot Keys 1 - 7

1

Quick Start Guide

Function Keys

The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the
basic function key combinations; visual indicators are available for certain key combinations/hot keys when the hot
key driver is installed (see

Key Function Key Function

“Hot Key Utility” on page 4 - 10).

Fn + F1 Sleep Togg le (Suspend) Fn + F7

Fn + F2

Fn + F5/

F6

Bluetooth Power Toggle

Decrease/Increase LCD Brightness

Table 1 - 3 - Function Keys

Fn + F8

Fn + F9/

F10

Display Toggle

Mute Toggle

Decrease/Increase Audio Volume



Other Keyboards

If your keyboard is damaged or you just want to make a change, you can use any sta ndard USB keyboard. The system
will detect and enable it automatically. However special functions/hot keys unique to the system’s regu lar keyboard may
not work.

1 - 8 Function Keys

System Map: Front & Rear Views

1

4

3 5

Battery Information

2



Quick Start Guide

Figure 1 - 4

Front & Rear Views

1. LED Indicators

2. LCD Latch

3. RJ-11 Phone Jack

4. RJ-45 LAN Jack

5. Battery

6. DC-In Jack

6

10 Cell Battery Warning

Please be careful when us­ing the 10 cell battery.



1

Always completely discharge, then fully charge, a new battery before usi ng it. Com­pletely discharge and charge the battery at least once every 30 days or after about 20
partial discharges.

System Map: Front & Rear Views 1 - 9

The battery is heavy and ex­tends beyond the case of the
computer. Moving the bat­tery, or exposing it to shock
or vibration may interrupt the
battery contacts and cause
the computer to shutdown.

1

Quick Start Guide

System Map: Left View

Figure 1 - 5 - Left View

1. Vent/Fan Intake/Outlet

2. External Monitor Port

3. 1 * USB 2.0 Port

4. Mini-IEEE 1394 Port

5. 4-in-1 Card Reader

6. PC Card Slot

1

3

42

5

6



Mini-IEEE 1394 Port



Overheating

To prevent your computer
from overheating make sure
nothing blocks the vent(s)/
fan intake(s)/outlet(s) while
the computer is in use.

1 - 10 System Map: Left View

The Mini-IEEE 1394 Port only supports SELF POWERED IEEE 1394 devices.

4-in-1 Card Reader

The card reader allows you to use the most popular digital storage card formats:

MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /

MS Pro (Memory Stick Pro)
