EUROCOM 888E DREAM MACHINE, 888ES Dream Machine User Manual

Preface

Notice

The company reserves the right to revise this publication or to
change its contents without notice. Information contained herein is
for reference only and does not constitute a commitment on the part
of the manufacturer or any subsequent vendor. They assume no re­sponsibility or liability for any errors or inaccuracies that may appear
in this publication nor are they in anyway responsible for any loss or
damage resulting from the use (or misuse) of this publication.
This publication and any accompanying software may not, in whole
or in part, be reproduced, translated, transmitted or reduced to any
machine readable form without prior consent from the vendor, man­ufacturer or creators of this publication, except for copies kept by the
user for backup purposes.

Brand and product names mentioned in this publication may or may
not be copyrights and/or registered trademarks of their respective

Preface

Trademarks

This product incorporates copyright protection technology that is
protected by method claims of certain U.S. patents and other intel­lectual property rights owned by Macrovision Corporation and other
rights owners. Use of this copyright protection technology must be
authorized by Macrovision Corporation, and is intended for home or
other limited viewing uses only unless otherwise authorized by Mac­rovision Corporation. Reverse engineering or disassembly is prohib­ited.

Intel and Pentium are registered trademarks of Intel Corporation.
Windows is a registered trademark of Microsoft Corporation.

Preface

Federal Communications Commission (FCC)
Statement

This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not in­stalled and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or televi­sion reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:

• Re orient or relocate the receiving antenna

• Increase the separation between the equipment and receiver



Warning

Use only shielded ca­bles to connect I/O de­vices to this
equipment.
You are cautioned that
changes or modifica­tions not expressly ap­proved by the
manufacturer for com­pliance with the above
standards could void
your authority to oper­ate the equipment.

Preface

IMPORTANT SAFETY INSTRUCTIONS

When using your telephone equipment, basic safety precautions
should always be followed to reduce the risk of fire, electric shock
and injury to persons, including the following:

1. Do not use this product near water, for example near a bath
tub, wash bowl, kitchen sink or laundry tub, in a wet basement
or near a swimming pool.

2. Avoid using a telephone (other than a cordless type) during an
electrical storm. There may be a remote risk of electrical shock
from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of
the leak.

4. Use only the power cord and batteries indicated in this manual.
Do not dispose of batteries in a fire. They may explode. Check
with local codes for possible special disposal instructions.

CAUTION

Always disconnect all telephone lines from the wall outlet before

Preface

IMPORTANTES MESURES DE SÉCURITÉ

Certaines mesures de sécurité doivent être prises pendant l’utilisa­tion de matérial téléphonique afin de réduire les risques d’incendie,
de choc électrique et de blessures. En voici quelquesunes:

1. Ne pas utiliser l’appareil près de l’eau,, p.ex., près d’une baignoire,
d’un lavabo, d’un évier de cuisine, d’un bac à laver, dans un sous-sol
humide ou près d’une piscine.

2. Éviter d’utiliser le téléphone (sauf s’il s’agit d’un appareil sans fil) pen­dant un orage électrique. Ceci peut présenter un risque de choc élec­trique causé par la foudre.

3. Ne pas utiliser l’appareil téléphonique pour signaler une fuite de gaz
s’il est situé près de la fuite.

4. Utiliser seulement le cordon d’alimentation et le type de piles indiqués
dans ce manuel. Ne pas jeter les piles dans le feu: elles peuvent
exploser. Se conformer aux règlements pertinents quant à l’émination
des piles.

ATTENTION

Preface

Instructions for Care and Operation

The notebook computer is quite rugged, but it can be damaged. To
ensure that does not happen, follow these suggestions:

1. Don’t drop it. Make sure it’s on a stable surface. If the compu-

ter falls, the case and other components could be damaged. Do
not expose it to any shock or vibration.

2. Don’t overheat it. Keep the computer and power supply away

from any kind of heating element. Keep the computer out of
direct sunlight. Don’t store or use the computer in a humid envi­ronment. Do not place the computer on any surface which will
block the vents.

3. Avoid interference. Keep the computer away from high capac-

ity transformers, electric motors, and other strong magnetic
fields. These can hinder proper performance and damage your
data.

Preface

5. Follow the proper working procedures for the computer.
Shut down the computer properly, and close all programs (don’t
forget to save your work). Do not turn off any peripheral devices
when the computer is on. Do not disassemble the computer by
yourself. Remember to periodically save your data as data may
be lost if the battery is depleted. Perform routine maintenance
on your computer.

6. Take care when using peripheral devices. Use only
approved brands of peripheral devices. Unplug the power cord
before attaching any peripheral device.

7. Do not place anything heavy on the computer.

Preface

Power Safety

The computer has specific power requirements:

• Only use a power adapter approved for use with this computer.

• Your AC adapter may be designed for international travel but it still
requires a steady, uninterrupted power supply. If you are unsure of your
local power specifications, consult your service representative or local
power company.

• The power adapter may have either a 2-prong or a 3-prong grounded
plug. The third prong is an important safety feature; do not defeat its
purpose. If you do not have access to a compatible outlet, have a quali­fied electrician install one.

• When you want to unplug the power cord, be sure to disconnect it by
the plug head, not by its wire.

• Make sure the socket and any extension cord(s) you use can support
the total current load of all the connected devices.

• Before cleaning the computer, make sure it is disconnected from any



Power Safety

Warning

Before you undertake
any upgrade proce­dures, make sure that
you have turned off the
power, and discon­nected all peripherals
and cables (including
telephone lines). It is
advisable to also re­move your battery in
order to prevent acci­dentally turning the
machine on.

Preface

Battery Precautions

• Only use batteries designed for this computer. The wrong battery type
may explode, leak or damage the computer.

• Recharge the batteries using the notebook’s system. Incorrect recharg­ing may make the battery explode.

• Do not try to repair a battery pack. Refer any battery pack repair or
replacement to your service representative or qualified service person­nel.

• Keep children away from, and promptly dispose of a damaged battery.
Always dispose of batteries carefully. Batteries may explode or leak if
exposed to fire, or improperly handled or discarded.

• Keep the battery away from metal appliances.

• Affix tape to the battery contacts before disposing of the battery.

• Do not touch the battery contacts with your hands or metal objects.



Battery Disposal

The product that you
have purchased con­tains a rechargeable
battery. The battery is
recyclable. At the end
of its useful life, under
various state and local
laws, it may be illegal
to dispose of this bat­tery into the municipal
waste stream. Check
with your local solid
waste officials for de­tails in your area for re­cycling options or
proper disposal.



Preface

Cleaning

Do not apply cleaner directly to the computer, use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any
part of the computer.

Servicing

Do not attempt to service the computer yourself. Doing so may vio­late your warranty and expose you and the computer to electric
shock. Refer all servicing to authorized service personnel. Unplug
the computer from the power supply. Then refer servicing to quali­fied service personnel under any of the following conditions:

• When the power cord or AC/DC adapter is damaged or frayed.

• If the computer has been exposed to rain or other liquids.

• If the computer does not work normally when you follow the operating
instructions.

• If the computer has been dropped or damaged (do not touch the poison-

Preface

Travel Considerations

Packing

As you get ready for your trip, run through this list to make sure the
system is ready to go:

1. Check that the battery pack and any spares are fully charged.

2. Power off the computer and peripherals.

3. Close the display panel and make sure it’s latched.

4. Disconnect the AC adapter and cables. Stow them in the carry­ing bag.

5. The AC adapter uses voltages from 100 to 240 volts so you
won’t need a second voltage adapter. However, check with
your travel agent to see if you need any socket adapters.

6. Put the notebook in its carrying bag and secure it with the bag’s
straps.

7. If you’re taking any peripherals (e.g. a printer, mouse or digital
camera), pack them and those devices’ adapters and/or
cables.

Preface

On the Road

In addition to the general safety and maintenance suggestions in this
preface, and Chapter 8: Troubleshooting, keep these points in mind:

Hand-carry the notebook.

For security, don’t let it out of your sight. In some areas, computer
theft is very common. Don’t check it with “normal” luggage. Bag­gage handlers may not be sufficiently careful. Avoid knocking the
computer against hard objects.

Beware of Electromagnetic fields.

Metal detectors & X-ray machines
These devices can damage the computer, hard disk, floppy disks, and
other media. They may also destroy any stored data - Pass your com­puter and disks around the devices. Ask security officials to hand-in­spect them (you may be asked to turn it on).
Note: Some airports also scan luggage with these devices.

Preface

Fly safely.

Most airlines have regulations about the use of computers and other
electronic devices in flight. These restrictions are for your safety, fol­low them. If you stow the notebook in an overhead compartment,
make sure it’s secure. Contents may shift and/or fall out when the
compartment is opened.

Get power where you can.

If an electrical outlet is available, use the AC adapter and keep your
battery (batteries) charged.

Keep it dry.

If you move quickly from a cold to a warm location, water vapor can
condense inside the computer. Wait a few minutes before turning it
on so that any moisture can evaporate.

Preface

Developing Good Work Habits

Developing good work habits is important if you need to work in
front of the computer for long periods of time. Improper work habits
can result in discomfort or serious injury from repetitive strain to
your hands, wrists or other joints. The following are some tips to re­duce the strain:

• Adjust the height of the chair and/or desk so that the keyboard is at or
slightly below the level of your elbow. Keep your forearms, wrists, and
hands in a relaxed position.

• Your knees should be slightly higher than your hips. Place your feet
flat on the floor or on a footrest if necessary.

• Use a chair with a back and adjust it to support your lower back com­fortably.

• Sit straight so that your knees, hips and elbows form approximately 90­degree angles when you are working.

• Take periodic breaks if you are using
the computer for long periods of

Preface

Remember to:

• Alter your posture frequently.

• Stretch and exercise your body several times a day.

• Take periodic breaks when you work at the computer for long periods
of time. Frequent and short breaks are better than fewer and longer
breaks.

Preface

Lighting

Proper lighting and comfortable display viewing angle can reduce
eye strain and muscle fatigue in your neck and shoulders.

• Position the display to avoid glare or reflections from overhead light­ing or outside sources of light.

• Keep the display screen clean and set the brightness and contrast to
levels that allow you to see the screen clearly.

• Position the display directly in front of you at a comfortable viewing
distance.

• Adjust the display viewing angle to find the best position.

Preface

Contents

Notice .......................................................................................................................................................I

Trademarks .........................................................................................................................................II

Federal Communications Commission (FCC) Statement ................................................................ III

Instructions for Care and Operation ................................................................................................. VI

Power Safety ..................................................................................................................................VIII

Battery Precautions .......................................................................................................................... IX

Cleaning .............................................................................................................................................X

Servicing ............................................................................................................................................X

Travel Considerations ...................................................................................................................... XI

Introduction ........................................................................1-1

Overview .............................................................................................................................................. 1-1

The Manual .......................................................................................................................................... 1-2

Advanced Users ..............................................................................................................................1-2

Beginners and Not-So-Advanced Users .........................................................................................1-2

Warning Boxes ...............................................................................................................................1-3

Not Included ......................................................................................................................................... 1-4

Preface

Top View .............................................................................................................................................. 1-7

Top View with LCD Panel Open ...................................................................................................1-8

LCD Panel .................................................................................................................................. 1-9

LED Power, Battery & E-Mail Status Indicators ....................................................................... 1-9

Microphone ................................................................................................................................. 1-9

Hot-Key Buttons .........................................................................................................................1-9

LED Status Indicators ...............................................................................................................1-10

Power Button ............................................................................................................................ 1-10

Close Cover Switch ..................................................................................................................1-10

Keyboard .................................................................................................................................. 1-11

TouchPad & Buttons ................................................................................................................ 1-11

Front View ......................................................................................................................................... 1-12

Audio “DJ” CD Player ............................................................................................................. 1-12

Stereo Speakers ........................................................................................................................ 1-13

Left Side View ...................................................................................................................................1-14

S/PDIF Out Port/Microphone-In Jack ......................................................................................1-14

Line-In Jack .............................................................................................................................. 1-15

Headphone-Out Jack ................................................................................................................ 1-15

Infrared Transceiver ................................................................................................................. 1-15

Preface

Hard Disk Drive ....................................................................................................................... 1-19

IP Sharing Module .................................................................................................................... 1-19

Right Side View ................................................................................................................................. 1-20

MP3 Player ...............................................................................................................................1-20

Vent .......................................................................................................................................... 1-21

Security Lock Slot .................................................................................................................... 1-21

Rear View .......................................................................................................................................... 1-22

DC-In Jack ................................................................................................................................ 1-22

Four USB Ports ......................................................................................................................... 1-23

S-Video-In Port (Optional with TV Tuner installed) ...............................................................1-23

S-Video-Out Port ...................................................................................................................... 1-24

External Monitor (CRT) Port ................................................................................................... 1-24

Coaxial TV Antenna Input .......................................................................................................1-24

Serial Port ................................................................................................................................. 1-25

IEEE 1394 Port ......................................................................................................................... 1-25

Printer/Parallel Port .................................................................................................................. 1-25

PS/2 Type Port .......................................................................................................................... 1-26

RJ-45 LAN Jack ....................................................................................................................... 1-26

RJ-11 Phone Jack ..................................................................................................................... 1-26

Preface

Using The Computer ..........................................................2-1

Overview .............................................................................................................................................. 2-1

The Power Sources ...............................................................................................................................2-2

AC Adapter ..................................................................................................................................... 2-2

Battery ............................................................................................................................................ 2-3

Recharging the Battery with the AC Adapter ................................................................................. 2-4

Proper handling of the Battery Pack ........................................................................................... 2-4

Turning on the Computer ..................................................................................................................... 2-5

LED Indicators ..................................................................................................................................... 2-6

LED Power, Battery & E-Mail Status Indicators ........................................................................... 2-7

LED Status Indicators .......................................................................................................................... 2-8

Check Mail Program ............................................................................................................................ 2-9

The Hard Disk Drive .......................................................................................................................... 2-12

The Floppy Disk Drive (FDD) ........................................................................................................... 2-13

Inserting/Removing Floppy Disks ................................................................................................2-13

The CD/DVD Device ......................................................................................................................... 2-14

Loading Compact Discs ................................................................................................................2-14

Handling CDs or DVDs ................................................................................................................ 2-15

Preface

Hot-Key Buttons ...........................................................................................................................2-19

Programming the Hot-Keys .......................................................................................................... 2-20

Function Keys ....................................................................................................................................2-22

The Numeric Keypad ......................................................................................................................... 2-23

Function Keys and Numeric Keypad ....................................................................................... 2-24

TouchPad and Buttons ....................................................................................................................... 2-25

Configuring the TouchPad and Buttons ....................................................................................... 2-26

Mouse ................................................................................................................................................. 2-27

Adding a Printer ................................................................................................................................. 2-28

USB Printer ................................................................................................................................... 2-28

Install Instructions: ................................................................................................................... 2-28

Parallel Printer .............................................................................................................................. 2-29

Install Instructions: ................................................................................................................... 2-29

Advanced Controls .............................................................3-1

Overview .............................................................................................................................................. 3-1

Advanced Video Controls .................................................................................................................... 3-2

Opening the LCD ............................................................................................................................3-2

Preface

Enabling Other Displays ....................................................................................................................3-10

Clone Mode .................................................................................................................................. 3-11

Extended Desktop Mode .............................................................................................................. 3-12

Enabling TV Display ......................................................................................................................... 3-14

Power Management Features ............................................................................................................. 3-15

Advanced Configuration and Power Interface (ACPI) ................................................................. 3-15

Advanced Power Management (APM 1.2) ................................................................................... 3-15

Enabling Power Options .................................................................................................................... 3-16

Conserving Power Through Individual Components ................................................................... 3-17

Monitor Standby ....................................................................................................................... 3-17

Hard Disk Standby ................................................................................................................... 3-17

Conserving Power Throughout the System ..................................................................................3-18

Hibernate Mode vs. Shutdown ..................................................................................................... 3-18

Standby Mode vs. Hibernate Mode .............................................................................................. 3-18

Standby ..................................................................................................................................... 3-19

Hibernate .................................................................................................................................. 3-20

Configuring the Power Button ...................................................................................................... 3-21

Battery Information ............................................................................................................................ 3-22

New Battery .............................................................................................................................. 3-22

Preface

Removing and Replacing the Battery ................................................................................................ 3-25

Audio “DJ” CD Player ....................................................................................................................... 3-26

Audio “DJ” CD Player Controls (Power On) ...............................................................................3-28

Configuring the Infrared Settings for FIR .......................................................................................... 3-32

Drivers & Utilities ..............................................................4-1

Overview .............................................................................................................................................. 4-1

What to Install ...................................................................................................................................... 4-2

Authorized Driver Message ............................................................................................................ 4-3

Version Conflict Message .............................................................................................................. 4-3

Windows 2000 Professional .................................................................................................................4-5

Chipset (Win2000) ......................................................................................................................... 4-5

DirectX 8.1 (Win2000) ...................................................................................................................4-5

Intel Application Accelerator (Win2000) ....................................................................................... 4-5

USB 2.0 (Win2000) ........................................................................................................................4-6

Audio (Win2000) ............................................................................................................................ 4-6

Video (Win2000) ............................................................................................................................ 4-6

LAN (Win2000) ............................................................................................................................. 4-7

Preface

Wireless LAN (Win2000) .............................................................................................................. 4-9

IP Sharing Module (Win2000) ..................................................................................................... 4-10

Check Mail (Win2000) .................................................................................................................4-10

Windows XP ......................................................................................................................................4-11

Chipset (WinXP) .......................................................................................................................... 4-11

DirectX 8.1 (WinXP) .................................................................................................................... 4-11

Intel Application Accelerator (WinXP) ........................................................................................ 4-12

USB 2.0 (WinXP) ......................................................................................................................... 4-12

Audio (WinXP) .............................................................................................................................4-13

Video (WinXP) ............................................................................................................................. 4-13

LAN (Win XP) .............................................................................................................................4-13

Modem (Win XP) ......................................................................................................................... 4-14

Hot-Key (WinXP) .........................................................................................................................4-15

TouchPad (WinXP) ......................................................................................................................4-15

Memory Stick (WinXP) ................................................................................................................4-16

Wireless LAN (WinXP) ............................................................................................................... 4-17

IP Sharing Module (WinXP) ........................................................................................................ 4-17

Check Mail (WinXP) .................................................................................................................... 4-18

Preface

Failing the POST ............................................................................................................................5-5

Fatal Errors ................................................................................................................................. 5-5

Non-Fatal Errors .........................................................................................................................5-5

The System Configuration Utility ........................................................................................................ 5-6

Entering Setup ................................................................................................................................5-6

SCU Menu ............................................................................................................................................ 5-7

Working with the Menu Bar ................................................................................................................ 5-8

Working with the Pull-Down Menu ..................................................................................................... 5-9

Working with Sub-Menus .................................................................................................................. 5-10

Startup Menu ...................................................................................................................................... 5-12

Fast Boot (Startup Menu) .........................................................................................................5-13

Boot Device (Startup Menu) ....................................................................................................5-13

Display (Startup Menu) ............................................................................................................5-13

Enable PNP OS Support (Startup Menu) ................................................................................. 5-14

Boot and SCU Passwords (Startup Menu) ............................................................................... 5-14

Other settings (Startup Menu) ..................................................................................................5-14

Disks Menu ........................................................................................................................................5-15

Components Menu ............................................................................................................................. 5-16

Power Menu. ...................................................................................................................................... 5-17

Preface

The MP3 Player ................................................................................................................................... 6-2

Inserting the MP3 Player ................................................................................................................6-3

Secure Digital Cards/MultiMedia Cards ........................................................................................ 6-4

MP3 Player Controls .................................................................................................................. 6-5

TV Tuner .............................................................................................................................................. 6-7

Installing the TV Tuner ..................................................................................................................6-8

IP Sharing Module .............................................................................................................................6-10

Cable Connections ....................................................................................................................6-11

Computer Setup ............................................................................................................................ 6-12

Windows 2000 Setup ................................................................................................................ 6-13

Windows XP Setup ...................................................................................................................6-14

Checking the Internet Connection ............................................................................................6-15

Upgrading The Computer .................................................7-1

Overview .............................................................................................................................................. 7-1

When Not to Upgrade ..................................................................................................................... 7-2

Upgrading the Primary Drive Bay (Bay One) CD Device ................................................................... 7-3

Upgrading the Modular Drive Bay (Bay Two) Device ........................................................................7-6

Preface

Some Things to Watch Out For .................................................................................................... 7-16

Software .................................................................................................................................... 7-16

Setting Up a New HDD ............................................................................................................ 7-16

Upgrading the System Memory ......................................................................................................... 7-17

Removing the System Memory ....................................................................................................7-18

Upgrading the Processor ....................................................................................................................7-23

Troubleshooting ..................................................................8-1

Overview .............................................................................................................................................. 8-1

Basic Hints and Tips ............................................................................................................................8-2

Backup and General Maintenance ....................................................................................................... 8-4

Viruses .................................................................................................................................................8-5

Upgrading and Adding New Hardware/Software ................................................................................ 8-6

Power ................................................................................................................................................... 8-8

Display ............................................................................................................................................... 8-12

Hard Disk Drive (HDD) .....................................................................................................................8-14

Boot Password ....................................................................................................................................8-15

Floppy Disk Drive (FDD) .................................................................................................................. 8-16

Preface

Operation ............................................................................................................................................ 8-24

Appendix A. Specifications ............................................... A-1

Processor Options ............................................................................................................................... A-1

Core Logic ........................................................................................................................................... A-2

Structure .............................................................................................................................................. A-2

Security ............................................................................................................................................... A-2

Memory ............................................................................................................................................... A-2

BIOS .................................................................................................................................................... A-2

LCD Options ....................................................................................................................................... A-3

Display ................................................................................................................................................ A-3

PC Card ............................................................................................................................................... A-3

Storage ................................................................................................................................................ A-4

Audio ................................................................................................................................................... A-5

Communication ................................................................................................................................... A-5

Interface .............................................................................................................................................. A-6

Power Management ............................................................................................................................. A-7

Power .................................................................................................................................................. A-7

Indicators ............................................................................................................................................. A-7

Introduction

1

Chapter 1: Introduction

Overview

What this chapter covers:

• The Manual — how to use it

• Quick Start Guide — the minimum you need to know

• System Map — navigating around your computer

Introduction

1

The Manual

This manual refers to the hardware and essential software required to
run your notebook computer. Depending on how your system is con­figured, some or all of the features described may already be set up.

Advanced Users

If you are an advanced user you may skip over most of this manual.
However you may find it useful to refer to the “What to Install” on

page 4 - 2, “BIOS Utilities” on page 5 - 1 and “Upgrading The
Computer” on page 7 - 1. You may also find the notes marked with

a  of interest to you.

Beginners and Not-So-Advanced Users

If you are new to computers, or do not have an advanced knowledge
of them, then you should try to look through all the documentation.
Do not worry if you do not understand everything the first time. Keep



Notes

Check the light colored
boxes with the mark
above to find detailed
information about the
computer’s features.

Introduction

1

Warning Boxes

No matter what your level please pay careful attention to the warning
and safety information indicated by the  symbol. Also please note
the safety and handling instructions as indicated in the Preface.

Introduction

1

Not Included

Operating Systems (e.g. Windows 2000 Professional, Windows XP
etc.) have their own manuals, as do applications (e.g. word process-

ing, spreadsheet and database programs). If you have questions
about the operating systems or programs then please consult the ap­propriate manuals.

System Software

Your computer may already come with system software pre-in­stalled. Where this is not the case, or where you are re-configuring
your computer for a different system, you will find this manual refers
to the following operating systems:

• Microsoft Windows 2000

• Microsoft Windows XP

Introduction

1

Quick Start Guide

This guide assumes that you are already familiar with computers and
can tell at a glance what and where all the key components are. If you
are not that comfortable with this type of device, then please refer to
the following pages, which give an overview of the system.

It is still best to review these steps, before taking any action. If there
is anything you are not sure about, then please refer to the appropri­ate chapter before continuing.

Unless you need to install an operating system, your computer
should be ready to work right out of the box. Before you begin please
follow the safety instructions in the Preface.

1. Remove all packing materials, CDs/DVDs, floppy disks, and any PC Cards.

2. Securely attach any peripherals you want to use with the notebook (e.g. key­board and mouse) to their ports.



Peripheral Devices

Please note that pe­ripherals (printers, dig­ital cameras, etc.)
which attach to your
computer by either
USB or IEEE1394
ports may be connect­ed after Windows is
up and running. All oth­er peripherals must be
connected before you
turn on the system.

Introduction

1

System Map

Your computer has a lot of built-in features. Most of these are ena­bled by your operating system. Further explanations of the various
subsystems are covered in the chapter or pages indicated.

Getting to Know Your Computer

The following graphics will help you to become familiar with the ba­sic functions, and to learn the location of the various ports and com­ponents of your computer.

Model Differences

This notebook series includes two different model types according to
their specifications. You can identify if your computer is Model A or

Model B by following the instructions in the sidebar. Only Model B
supports USB 2.0.



Model Differences

You may identify if
your computer is Mod-
el A or Model B from
the video card. After
you have installed the
video driver go to “Ad-

vanced Display Prop­erties” on page 3 - 5

and check the card
type. If the card is a

MOBILITY RADEON
7500, then the ma-

chine is Model A. If the
video card is a MOBIL-

ITY RADEON 9000

then the machine is
Model B, and supports

Introduction

1

Top View

To open the LCD display:

1. Place the computer on a stable surface.

2

1

Figure 1 - 2

Top View with LCD

Panel Closed

1. LCD Latch

2. LED Power,
Battery & E-Mail
Status Indicators

Introduction

1

Top View with LCD Panel Open

Figure 1 - 3

Top View with LCD

Panel Open

1. LCD

2. LED Power,
Battery & E-Mail
Status Indicators

3. Built-In
Microphone

4. Hot-Key buttons

5. LED Status
Indicators

6. Power Button

7. Close Cover
Switch

2

5

6

8

9

3

4

7

1

Introduction

1

LCD Panel

The computer comes with a 15.0", 15.7" OR 16" TFT (Liquid Crys­tal Display) screen, depending upon the configuration purchased.
See “LCD Options” on page A - 3 for details.

LED Power, Battery & E-Mail Status Indicators

These indicators display the system power status, and battery status
of the computer. The third indicator may be configured to give a vi­sual confirmation when e-mail is received in the default e-mail pro­gram.

Microphone

Record on your notebook computer with the built-in microphone.

Hot-Key Buttons

The three hot-keys allow you instant access to your default internet

Introduction

1

LED Status Indicators

These display the system’s operational status. Refer to “LED Status

Indicators” on page 2 - 8 for more information on what the lights

mean.

Power Button

Press this button to turn your computer on or off (see “Turning on

the Computer” on page 2 - 5). This button may also be used as a

suspend/resume key, once configured as such in the power
management control panel of your operating system (see

“Configuring the Power Button” on page 3 - 21).

Close Cover Switch

This switch acts as a sensor to tell when the LCD panel is closed.
When this LCD cover sensor is activated the default setting of your
operating system’s power scheme sends the computer into a power



Shutdown

Please note that you
should always shut
your computer down
by choosing the Shut

Down/Turn Off Com­puter command from
the Start menu in Win-

Introduction

1

Keyboard

The computer has a “Win Key” keyboard including a numeric key­pad. It has the same features as a full-sized desktop keyboard and can
easily be replaced with a different language keyboard should you de­sire.

TouchPad & Buttons

The pointing device features a sensitive glide pad for precise move­ments. It functions the same way as a two-button mouse. The right
TouchPad button is the same as the right mouse button; the left
TouchPad button is the same as the left mouse button. The central
buttons may be used to scroll up and down, or they may be config­ured to perform a variety of function (see “Configuring the Touch-

Pad and Buttons” on page 2 - 26).



Forced Off

If the system “hangs”,
and the Ctrl + Alt + Del
key combination
doesn’t work, press the
power button for 4 sec-
onds, or longer, to
force the system to
turn itself off.

Introduction

1

Front View

Audio “DJ” CD Player

The built-in standalone audio CD player gives you direct hardware
control for audio CDs when the computer is shut down, but has a
working power source.

3 4 5 6 7 8 9

10

1

2

10

Figure 1 - 4

Front View

1. LCD Latch

2. Audio “DJ” CD
Player Control
Panel On/Off
Switch

3. Previous Track

4. Next Track

5. LCD

6. Play/Pause

7. Stop

8. Volume Down

9. Volume Up

10. Speakers

Introduction

1

Note: If you are playing a CD in the audio player you will not be
able to use the power button to switch the computer on. Switch

the CD audio player off first, then press the power button to turn on
the computer.



Sound Volume Adjustment

How high the sound volume can be set using the volume control knob de­pends on the setting of the volume control within Windows. Click the
Speaker icon on the taskbar to check the setting.

The Volume controls on the Audio DJ player still control the volume set­tings if the computer’s operating system is running.

All peripherals must be connected before you turn on the system.

Introduction

1

Left Side View

S/PDIF Out Port/Microphone-In Jack

You can use this port for S/PDIF (Sony/Philips Digital Interface For­mat) output, and to record on your notebook computer with an exter-

2 3 41 5 6 7 8

9

10

8

1

11

Figure 1 - 5

Left Side View

1. S/PDIF Out Port/
Microphone-In Jack

2. Line-In Jack

3. Headphone-Out
Jack

4. Infrared Transceiver

5. Sony Memory
Stick™ Port

6. PC Card Slot Eject
Buttons

7. PC Card Slot

8. Floppy Disk Drive

9. Primary Drive
Bay (1)

10. Modular Drive
Bay (2)

11. Y-cable for S /PDIF
Out /Microphone-In

Introduction

1

Line-In Jack

Connect external audio sources to play through your computer’s
speakers to this jack.

Headphone-Out Jack

Headphones may be connected through this jack.
Note: Set your system’s volume to a reduced level before connecting
to this jack.

Infrared Transceiver

The infrared transceiver enables communication between the com­puter and another similarly equipped device, and is 4M bps FIR,
IrDA 1.1 compliant. For further information please refer to the man­ual of the device you wish to connect (see “Configuring the Infra-

red Settings for FIR” on page 3 - 32).



Infrared

Communication

The infrared transceiv­er operates on a “Line
of Sight”.

Make sure nothing is
blocking the “Line of



Introduction

1

Sony Memory Stick Port

This port accepts Sony’s Memory Stick™ cards which allow for the
exchange of data between various types of AV/IT appliances.

Dual PC Card Slots

There are two Type-II PC Card slots, or the slot may be used for one
Type III PC Card (PC Cards were also previously referred to as PC­MCIA). Refer to “The PC Card Slot” on page 2 - 18 for more infor­mation.

3.5" FDD (Floppy Disk Drive)

This is a 3.5", 1.44 MB fixed floppy disk drive. For more information
please refer to “The Floppy Disk Drive (FDD)” on page 2 - 13.



Media Warning

Don’t try to remove a
floppy disk while the
system is accessing it.

Introduction

1

Device Bays

There are two device bays on the left side of your notebook compu­ter:

The primary drive bay (Bay One) will have ONE of the following
interchangeable devices, depending on the configuration purchased:

•DVD-ROM

•CD-ROM

• CD-RW and DVD-ROM Combo drive

•CD-RW

•DVD-R/-RW

The modular drive bay (Bay Two) will have ONE of the following
fixed devices, depending on the configuration purchased:

•DVD-ROM

•CD-ROM

• CD-RW and DVD-ROM Combo drive



Overheating

To prevent your com­puter from overheating
make sure nothing
blocks the vent while
the computer is in use.

Introduction

1

CD Device

A CD-ROM drive, or DVD-ROM drive, or CD-RW drive, or Com­bination CD-RW and DVD-ROM drive, or DVD-R/-RW drive
(12.7mm height) is standard in the primary drive bay (Bay One) de­pending on the model you purchased. There may also be another CD
device in the modular drive bay (Bay Two). For more information
on using the drive please refer to “The CD/DVD Device” on page 2

- 14.

1. CD-ROM or DVD label to indicate which type

2. Busy Indicator



CD Emergency Eject

If you need to manually
eject a CD/DVD (e.g.
due to an unexpected
power interruption) you
may push the end of a
straightened paper clip
into the emergency
eject hole.

Do not use a sharp­ened pencil or similar
object that may break
and become lodged in
the hole.

3 4

1

2

Introduction

1

Hard Disk Drive

The internal hard disk drive is used to store your data. You can have
up to three hard disks in your computer depending on the configura­tion options purchased. You may have one main HDD, one optional
HDD in the modular drive bay (Bay Two), and one optional HDD in
the changeable drive bay (Bay Three). See information on pages 7 -

7, 7 - 11, & 7 - 13 for information on upgrading/replacing your hard

disk drive.



Drive Warning

Don’t try to remove the
hard disk (HDD) while
the system is on. This
could cause data loss
or damage.

Unauthorized removal
or tampering with the
HDD may violate your
warranty. If you are in
doubt, consult your
service representative.



Jumper Settings for Multiple Hard Disk Use

If you are using more than one hard disk in your computer, make sure to
set the jumpers on all your hard disks to the cable select option in order
for the system to recognize all the disks (see your hard disk manual or the
information printed on the hard disk itself for details on the jumper set­tings).

Introduction

1

Right Side View

MP3 Player

The optional, portable, MP3 player allows you to play MP3 music
files, and includes a Secure Digital card (SD)/MultiMedia Card



Software Installation

Warning

Make sure the MP3

1

2

3

4

5

6

Right Side - MP3 Player Out

Right Side - MP3 Player In

Figure 1 - 6

Right Side View

1. MP3 Player
(Optional)

2. MP3 Player SD/
MMC Slot

3. MP3 Player Release
Switch

4. Vent

5. Security Lock Slot

6. MP3 Player Slot (no
MP3 Player
installed)

Introduction

1

Vent

This enables airflow to prevent the notebook from overheating.

Security Lock Slot

To prevent possible theft, a Kensington-type lock can be attached to
this slot. Locks can be purchased at any computer store.

Introduction

1

Rear View

Figure 1 - 7

Rear View

1. DC-In Jack

2. 4 * USB Ports

3. S-Video-In Port
(Optional)

4. S-Video-Out Port

5. External Monitor
(CRT) Port

6. Coaxial TV
Antenna Input
(Optional)

7. Serial Port

8. IEEE 1394 Port

9. Parallel Port

10. PS/2 Type Port

11. RJ-45 LAN Jack

12. RJ-11 Phone Jack

3 4 5

6

7 8 9

10 11 12

1 2



IEEE 1394

The IEEE 1394 port only supports SELF POWERED IEEE 1394 devices.

Introduction

1

Four USB Ports

Depending on the model you purchase, the USB ports which come
with your notebook can be either USB 1.1 compatible or USB 2.0
compatible. USB 1.1 is for low-speed peripherals such as keyboards,
mice or scanners while USB 2.0 is for high-speed peripherals such as
external HDDs, digital video cameras or high-speed scanners and all
USB 1.1 compliant devices. Both support device hot-pluggability.
(Devices can be plugged into the computer, and unplugged from the
computer, without the need to turn the system off.) Only Model B
type computers in this series of notebooks support USB 2.0. For
help on identifying your model of computer see “Model Differenc-

es” on page 1 - 6. You may need to install a driver for USB 2.0 (see
“What to Install” on page 4 - 2).

S-Video-In Port (Optional with TV Tuner installed)

If you have the optional TV Tuner installed, you may plug in ex­ternal video sources to this port. Examples of sources include VCRs,

Introduction

1

S-Video-Out Port

Connect your television to your computer and view DVDs, VCDs or
anything else your computer can display. You will need an S-Video
cable to make the connection. Enable this port from the video driver
controls (see “Enabling TV Display” on page 3 - 14).

External Monitor (CRT) Port

Connect an external CRT monitor to this port to allow dual video or
simultaneous display on the LCD and external CRT monitor (see

“Attaching a Monitor (CRT)” on page 3 - 8).

Coaxial TV Antenna Input

If you have purchased the optional TV Tuner module with your note­book computer, the 75 Ohm Coaxial TV Antenna Input will allow
you to connect your cable TV/TV antenna to watch television, and
capture still images on your PC.



TV Remote

The remote control unit
provided with the op­tional TV tuner will only
function when the
computer is powered

Introduction

1

Serial Port

Connect a serial type mouse to this port.

IEEE 1394 Port

This allows high speed connection to various peripheral devices, e.g.
external disk drives and digital cameras (see note below).

Printer/Parallel Port

This port supports ECP (Extended Capabilities Port) and EPP (En-



IEEE 1394

The IEEE 1394 port only supports SELF POWERED IEEE 1394 devices.

Introduction

1

PS/2 Type Port

Connect an external PS/2 type mouse or keyboard to this port. You
can use a “Y” splitter if you want to attach both.

RJ-45 LAN Jack

This port supports LAN (Network) functions.
Note: Broadband (e.g. ADSL) modems usually connect to the LAN
port.

RJ-11 Phone Jack

This port connects to the built-in modem. You may plug the tele­phone line directly into this RJ-11 telephone connection.
Note: Broadband (e.g. ADSL) modems usually connect to the LAN
port.

Introduction

1

Bottom View

Figure 1 - 8

Bottom View

1. Vent/Fan Outlets

2. CPU Cover

3. Battery (the primary
HDD is located
under the battery)

4. Primary Hard Disk

5. Changeable Drive
Bay 3 (for TV Tuner
or HDD)

6. Modular Drive ­Bay 2

7. Primary Drive -

Bay 1

7

1

1

2

4

3

5 6



CPU

Introduction

1

Vent

This enables airflow to prevent the notebook from overheating.

Battery

See “Battery” on page 2 - 3 for instructions on battery use and care.

Wireless Network Module

Your notebook computer may have an optional Mini PCI Wireless
Networking module. If included, the antenna and other components
are not externally visible (please check with your service representa­tive). If your configuration includes the Wireless Network module,
make sure you install the driver (see “What to Install” on page 4 -

2).



Overheating

To prevent your com­puter from overheating
make sure nothing
blocks the vent/fan
outlet while the com­puter is in use.

Using The Computer

2

Chapter 2: Using The Computer

Overview

To learn more about using your computer, please read this chapter.

This chapter includes:

•The Power Sources

• Turning on the Computer

• LED Indicators

• Check Mail Program

• The Hard Disk Drive

• The Floppy Disk Drive

• The CD/DVD Device

•The PC Card Slot

•Hot-Keys

Using The Computer

2

The Power Sources

The computer can be powered by either an AC adapter or a battery
pack.

AC Adapter

Use only the AC adapter that comes with your computer. The wrong
type of AC adapter will damage the computer and its components.

1. Attach the AC adapter to the DC-in jack at the rear of the com­puter.

2. Plug the AC power cord into an outlet, then connect the AC
power cord to the AC adapter.

3. Raise the lid/LCD to a comfortable viewing angle.

4. Press the power button to turn “on”.



Shutdown

Please note that you
should always shut
your computer down
by choosing the Shut

Down/Turn Off Com­puter command from

the Start menu in Win­dows. This will help

prevent hard disk or
system problems.

Using The Computer

2

Battery

The battery allows you to use your notebook computer while you are
on the road or an electrical outlet is unavailable. Battery life varies
depending on the applications and the configuration you're using. To
increase battery life, let the battery discharge completely before re­charging.

We recommend leaving the battery inside the notebook at all times.
For more information on the battery, please refer to “Battery Infor-

mation” on page 3 - 22.

1 2 3 4



Battery Release

Remove screws

-

in Figure 2 - 2 (see

“Removing and Re­placing the Battery”
on page 3 - 25).

Figure 2 - 2

1

4

Using The Computer

2

Recharging the Battery with the AC Adapter

The battery pack automatically recharges when the AC adapter is at­tached and plugged into an electrical outlet. If the computer is pow­ered on, and in use, it will take several hours to fully recharge the
battery. When the computer is turned off but plugged into an electri­cal outlet, battery charge time is less (refer to “LED Indicators” on

page 2 - 6 for information on the battery charge status).

Proper handling of the Battery Pack

• DO NOT disassemble the battery pack under any circumstances.

• DO NOT expose the battery to fire or high temperatures, it may

explode.

• DO NOT connect the metal terminals (+, -) to each other (for more

information on how to maintain the battery pack, refer to

“Battery

Information” on page 3 - 22).

Using The Computer

2

Turning on the Computer

Now you are ready to begin using your computer. To turn it on sim­ply press the power button on the front panel.

When the computer is on, you can use the power button as a hot-key
button when it is pressed for less than 4 seconds. Use Power Op-
tions in the Windows Control Panel to configure this feature.



Power Button as

Standby or Hibernate

Button

If you are using a fully
ACPI-compliant OS,
(such as Windows

2000 Professional, or
Windows XP) you can

use the OS’s “Power
Options” control panel
to set the power button
to send the system into
Standby or Hibernate
mode (see your OS’s
documentation, or

“Configuring the
Power Button” on
page 3 - 21 for de-



Forced Off

If the system “hangs”, and the Ctrl + Alt + Del key combination doesn’t
work, press the power button for 4 seconds, or longer, to force the system

Using The Computer

2

LED Indicators

There are two sets of LED indicators (LED Power, Battery & E­Mail Status Indicators and LED Status Indicators) on your com-

puter that will display helpful information about the current status of
the computer.

The LED Power, Battery & E-Mail Status Indicators are also vis­ible when the top of your computer is closed.

Figure 2 - 3

LED Power,

Battery & E- Mail

Status Indicators

Figure 2 - 4

LED Status

Using The Computer

2

LED Power, Battery & E-Mail Status Indicators

Icon Color Description

Green The computer is on

Blinking Green The computer is in suspend mode

Orange The battery is being charged

Green The battery is fully charged

Blinking
Orange

The battery has reached critically low
power status

Blinking
Green*

There is a serious problem with the
battery*

Blinking Green New mail has arrived



Low Battery Warning

When the battery is
critically low, immedi­ately connect the AC
adapter to the comput­er or save your work,
otherwise, the un­saved data will be lost
when the power is de­pleted.

Table 2 - 1

LED Power,

Battery & E-Mail

Using The Computer

2

LED Status Indicators

Once your computer is on and in use, the LED status indicators will
display the system's operational status.

Icon Color Description

Green Floppy/Hard disk/CD Device activity

Green Number Lock is activated

Green Caps Lock is activated

Green Scroll Lock is activated



Scroll Lock

To enable and disable
the Scroll Lock feature,
press the Fn and
ScrLk keys simultane­ously.

Table 2 - 2

LED Status

Indicators

Using The Computer

2

Check Mail Program

After you have installed the driver for the Check Mail program (see

“What to Install” on page 4 - 2) you may then configure it to give

notification when new mail is received. You must be online to re­ceive this notification (note that this program only supports the
POP3 protocol), and your default mail program does not need to be
open.

If you have installed the driver using the default settings, the Check­Mail program appears in the Startup menu (Start > Programs >
Startup > CheckMail).

Figure 2 - 5

Check Mail Program

(Startup Menu)

Using The Computer

2

Clicking on Check Mail will bring up the following options menu.

You may then configure the options for your mail server, user name,
password. Click Enable Check Mail to have the program check the
mail server for new mail, and set the interval (in seconds). Click
SAVE to keep the settings, and Hide to minimize the program. After



Note

Check with your Inter­net Service Provider,
network administrator
or Mail Service provid­er for details on what to
put on these pages.

Figure 2 - 6

Check Mail

Account Setup

and Options

Using The Computer

2

You may also enable an audible warning for received mail by click­ing on Set Mail Wave, and browsing to a .WAV sound file to use for
mail notification. Click Enable play wave for mail arrival, and
SAVE to save the settings.

Figure 2 - 7

Check Mail Enabled

Figure 2 - 8

Set Mail Wave

Using The Computer

2

The Hard Disk Drive

The hard disk drive is used to store your data in the notebook com­puter. The primary hard disk is mounted in a removable case and can
be taken out to accommodate other 2.5" IDE hard disk drives with a
height of 9.5 mm. You may have a second, and third hard disk de­pending on the configuration purchased (see “Jumper Settings for

Multiple Hard Disk Use” on page 1 - 19).

The hard disk is accessible from the bottom of your computer un­der the battery, as seen below. Further details on removing and in­serting the hard disk are available in “Upgrading the Primary Hard

Disk” on page 7 - 7.



Power Safety

Before attempting to
access any of the inter­nal components of
your notebook please
ensure that the ma­chine is not connected
to the AC power, and
that the machine is
turned off. Also ensure
that all peripheral ca­bles, including phone
lines, are disconnected
from the computer.

1

Using The Computer

2

The Floppy Disk Drive (FDD)

The computer is equipped with a fixed 1.44 MB, 3.5" floppy disk
drive module. By default it is drive “A:” and can be used as a boot
device if properly set in the BIOS (refer to “Boot Device (Startup

Menu)” on page 5 - 13).

Inserting/Removing Floppy Disks

When using the floppy drive, always insert your floppy diskette with
the label-side facing up. To remove the inserted diskette, press the
eject button on the top-right corner of the floppy drive.



Media Warning

Don’t try to remove a
floppy disk while the
system is accessing it.
This may cause the
system to “crash”.

Figure 2 - 10

Floppy Disk

Using The Computer

2

The CD/DVD Device

There are two bays for a combination of a CD-ROM, or DVD-ROM,
or CD-RW, or Combination CD-RW and DVD-ROM drive, or
DVD-R/-RW drive, depending on the model you purchased. You
may alternatively have a hard disk or IP sharing module in the mod­ular drive bay (Bay Two). The CD Device is usually labeled drive
"D:" and may be used as a boot device if properly set in the BIOS
(“Boot Device (Startup Menu)” on page 5 - 13).

Loading Compact Discs

To insert a CD/DVD, press the open button and carefully place a CD/
DVD onto the disc tray with label-side facing up (use just enough
force for the disc to click onto the tray’s spindle). Gently push the
CD/DVD tray in until its lock “clicks” and you are ready to start. The
Busy Indicator will light up while data is being accessed, or while an
audio/video CD, or DVD, is playing. If power is unexpectedly inter-



Sound Volume

Adjustment

How high the sound
volume can be set de­pends on the setting of
the volume control
within Windows. Click
the Speaker icon on
the taskbar to check
the setting.

The volume controls
on the Audio DJ player
still control the volume
settings if the compu­ter’s operating system
is running.

Using The Computer

2

Handling CDs or DVDs

Proper handling of your CDs/DVDs will prevent them from being
damaged. Please follow the advice below to make sure that the data
stored on your CD-ROMs/DVD-ROMs can be accessed.

Remember to:

• Hold the CD or DVD by the edges; do not touch the surface of the disc.

• Use a clean, soft, dry cloth to remove dust or fingerprints.

• Do not write on the surface with a pen.

• Do not attach paper or other materials to the surface of the disc.

• Do not store or place the CD or DVD in high-temperature areas.

• Do not use benzene, thinner, or other cleaners to clean the CD or DVD.

• Do not bend the CD or DVD.

• Do not drop or subject the CD or DVD to shock.



Media Warning

When manually eject­ing a CD/DVD, DO
NOT use a sharpened
pencil or similar object
which may break, and
become lodged in the
hole.



CD Emergency Eject

Using The Computer

2

DVD Regional Codes

DVD region detection is device dependent, not OS-dependent. You
can select your module’s region code 5 times. The fifth selection is
permanent. This cannot be altered even if you change your operating
system or you use the module in another computer.

Figure 2 - 11

DVD Regional

Codes

(Windows XP)

Using The Computer

2

Changing DVD Regional Codes

Go to the Control Panel in WindowsXP/Windows 2000 and double­click System > Hardware (tab), click Device Manager, then click
the + next to DVD/CD-ROM drives. Double-click on the DVD­ROM device to bring up the Properties menu, and select the DVD
Region (tab) to bring up the control panel as seen in “DVD Regional

Codes (Windows XP)” on page 2 - 16.

DVD Regional Coding

Region

Geographical Location

1 USA, Canada

2 Western Europe, Japan, South Africa, Middle East & Egypt

3 South-East Asia, Taiwan, South Korea, The Philippines,

Indonesia, Hong Kong

4 South & Central America, Mexico, Australia, New Zealand

Table 2 - 3

DVD Regional

Coding

Using The Computer

2

The PC Card Slot

The computer is equipped with a PCMCIA 3.3V/5V slot for two
type II PC Cards, or one type III PC Card. Type III PC Cards only

fit into the lower socket.

Inserting and Removing PC Cards

• Align the PC Card with the slot and push the PC Card in until it locks

into place.

• To remove a PC Card, simply press the eject button "2" next to the slot.

Figure 2 - 12

PC Card Slot

12

Using The Computer

2

Hot-Keys

The computer has two sets of Hot-Keys, three Hot-Key buttons on
the computer, and the function key combinations on the keyboard.

Hot-Key Buttons

These keys access the internet, e-mail or a user-defined application
with one quick button press. To use the “user-defined Hot-Key”, you
must install the hot-key driver. Refer to “What to Install” on page 4

- 2 for driver installation steps.

Figure 2 - 13

Hot-Keys

Using The Computer

2

Programming the Hot-Keys

After installing the Hot-Key driver (see “What to Install” on page 4

- 2), you may have to configure or change the settings.

Hot-Key Function

Activate the default e-mail program

Activate the default Internet browser

Activate the user specified application e.g. Microsoft
Word or Excel



Non-Default E-Mail

and Browser

Programs

It is possible to config­ure both the email and
browser hot-keys to
open non-default mail
and browser pro­grams. Follow the pro­cedure outlined on
page 2 - 21 but high­light either the Brows-
er or Email in step 2.
Choose Custom to
browse to the program
of your choice as per
the remaining instruc­tions. The Hot-Key will

Using The Computer

2

1. Right click the Hot-Key driver icon on the taskbar and the

following menu will appear.

2. Select Setup from the menu and scroll to Application 1 and
press Enter.

3. An Open dialog box will appear on the screen.

4. Browse to the directory where the desired application.exe (see
the sidebar) program exists.

5. Double-Click on the program file or choose Open.

6. The Hot-Key is now set to execute that program.



Application.exe

You will need to locate
the actual application
executable (.exe) file,
not just the shortcut.
To find the application
right-click its shortcut
on the desktop and
click Properties. Click
the shortcut (tab) and
see where the execut­able file is located by
clicking the Find Tar-
get (button).

Using The Computer

2

Function Keys

On the bottom-left of the keyboard is the Fn key or Function key.
The Fn key allows you to change operational features instantly. To
use the following functions press and hold the Fn key, then press the
appropriate function key (Esc, F6, F10 etc.) located on your key­board (see “TouchPad and Buttons” on page 2 - 25).

Keys Description

Fn + Z Turn audio on/off

Fn + Esc Toggle between suspend/resume state

Fn + F6 Toggle between CRT/LCD/LCD and CRT

Fn + F9 Decrease LCD brightness

Fn + F10 Increase LCD brightness

Fn + F11 Decrease audio volume



Other Keyboards

If your keyboard is
damaged or you just
want to make a
change, you can use
any standard PS/2 or
USB keyboard. The
system will detect and
enable it automatically.
However special func­tions/hot keys unique
to the system’s regular
keyboard may not
work.

Using The Computer

2

The Numeric Keypad

The keyboard has a numerical keypad for easy numeric data input
(see “Function Keys and Numeric Keypad” on page 2 - 24).

To use the keypad simply:

Activate the Number Lock feature by pressing the NumLk key at
the top right of the keyboard. You may check if Number Lock is en­abled or not by looking at the LED status indicators (see “LED Sta-

tus Indicators” on page 2 - 8).

You can configure the BIOS to have Number Lock enabled when
you start up the computer (see “Components Menu” on page 5 - 16).



Special Characters

Some software appli­cations allow the
number-keys to be
used with Alt to pro­duce special charac­ters. These special
characters can only be
produced by using the
numeric keypad. Reg­ular number keys (in
the upper row of the
keyboard) will not
work. Make sure that
NumLk is on.

Using The Computer

2

Function Keys and Numeric Keypad

Figure 2 - 14

Function Keys &
Numeric Keypad

1. Fn Key

2. Audio ON/OFF Toggle

3. Suspend/Resume state Toggle

4. CRT/LCD/LCD and CRT Toggle

5. LCD Brightness Decrease

6. LCD Brightness Increase

2

4

5

3

9

10

8

1

6

7

Using The Computer

2

TouchPad and Buttons

The pointing device features a sensitive glide pad for precise move­ments. It functions the same way as a two-button mouse (the central
Rocker Switch may be configured to function as a “third” button if
you prefer). The right TouchPad button is the same as the right
mouse button; the left TouchPad button is the same as the left mouse
button.

Using The Computer

2

Configuring the TouchPad and Buttons

Once you have installed the TouchPad drivers (see “What to Install”

on page 4 - 2) you can configure the functions from the TouchPad

driver icon on the taskbar. You may then configure the Touch­Pad tracking, buttons and Rocker Switch etc. to your preferences.
You will find further information on this at www.synaptics.com.

Figure 2 - 15

Mouse

Properties

Using The Computer

2

Mouse

You can also add a mouse to your computer. You can use a mouse
either through the PS/2 interface or the USB ports (at the rear of the
computer).



Mouse Driver

If you are using an ex­ternal mouse your op­erating system may be
able to auto-configure
your mouse during its
installation or only ena­ble its basic functions.
Be sure to check the
device’s user docu­mentation for details.

Using The Computer

2

Adding a Printer

The most commonly used peripheral is a printer. The following con­ventions will help you to add a printer, however it is always best to
refer to the printer manual for specific instructions and configuration
options.

USB Printer

Most new printers have a USB interface connection. There are four
USB ports on your notebook computer and you may use any one of
the ports to connect the printer.

Install Instructions:

1. Set up the printer according to its instructions (unpacking,
paper tray, toner/ink cartridge etc.).

2. Turn ON the computer.

3. Turn ON the printer.

Using The Computer

2

Parallel Printer

This is still the most common type of printer.

Install Instructions:

1. Set up the printer according to its instructions (unpacking,
paper tray, toner/ink cartridge etc.).

2. Attach the parallel cable to the printer.

3. Connect the printer’s parallel cable to the parallel port at the
rear of the computer (see “Rear View” on page 1 - 22).

4. Turn ON the printer.

5. Turn ON the computer.

6. Windows will identify the printer and either load one of its own
drivers or ask you to supply one. Follow the on-screen instruc­tions.

Using The Computer

2

Advanced Controls

3

Chapter 3: Advanced Controls

Overview

This chapter covers:

• Advanced video controls

• Power and battery management features

• The Audio "DJ" CD player

• Configuring the Infrared settings for FIR



Drivers

You are unable to use
most advanced con­trols until the neces­sary drivers and
utilities are properly in­stalled (your service
representative may
have already done that
for you). If your system
hasn’t been properly
configured, refer to

“What to Install” on
page 4 - 2, for installa-

Advanced Controls

3

Advanced Video Controls

This section is about making adjustments for the LCD, and switching
display devices.

Opening the LCD

As you open the lid, adjust it so you can look at the screen straight
on, without any glare. If necessary, adjust the brightness controls (Fn
+ F9/F10) as in Figure 3 - 1.



Protecting the LCD

Do not allow any for­eign objects (i.e. paper
or plastic) to get be­tween the lid/LCD and
the work panel. They
could damage or
scratch the LCD and/or
accidentally activate
the close cover switch.

Figure 3 - 1

Brightness

Controls

F9

F10

Fn

Advanced Controls

3

Video Driver Controls

The video interface lets you change the screen resolution and color
output to whatever is most comfortable/efficient for you. This is a
matter of hardware, video memory and the driver for your operating
system. The driver interface shows the available options (see “LCD

Options” on page A - 3 for the LCD options).

You can switch display devices from the Display Properties control
panel in Windows as long as the video driver is installed (see “What

to Install” on page 4 - 2).



Screen Resolution/

Area Note

You may set the reso­lution to a higher set­ting than the panel
supports, however this
will require you to pan
(scroll) around the
screen as the display
area will be larger than
what you can see on
the LCD.

Advanced Controls

3

Making Adjustments for the Display

The higher the resolution you set the LCD for, the more information
the LCD can display on screen. To change the LCD’s resolution and
color depth go to the Display Properties control panel:

1. Click Start, point to Settings and click Control Panel.

2. Double-click Display (icon).

3. In the Display Properties dialog box, click Settings (tab).

4. In Screen area/resolution, move the slider to the preferred
setting for resolution.

5. In Colors/Color quality, click the arrow and scroll to the pre-
ferred setting for color depth.

You can also access Display Properties by right-clicking the ATI
icon in the taskbar. Point to Settings and click Display Settings, then
click the Settings (tab).

Figure 3 - 2

Advanced Controls

3

When the Display Properties control panel is open, click the Ad­vanced (button) to bring up the options tabs. Clicking through these

Figure 3 - 3

Advanced

Display

Properties

Advanced Controls

3

Access the menus from ATI taskbar to get further help on display op­tions, TV options etc. Right-click the ATI icon in the taskbar and
point to Help or Troubleshooting (Figure 3 - 4).

Figure 3 - 4

ATI Help &

Troubleshooting

Advanced Controls

3

Display Devices

Besides the built-in LCD, you can also use an external CRT connect­ed to the external monitor (CRT) port as your display device. You
may also connect a TV. The following are the display options:

1. The built-in LCD

2. A CRT (external monitor) connected to the VGA port

3. A TV connected to the S-Video connector



Drivers

You are unable to use
most advanced con­trols until the neces­sary drivers and
utilities are properly in­stalled. If your system
hasn’t been properly
configured (your serv­ice representative may
have already done that
for you), refer to “What

to Install” on page 4 ­2, for installation in-

structions.



Monitor (CRT) and TV Tuner

If you are connecting both a monitor (CRT) to the external monitor port,
and a cable/aerial to the optional TV Tuner module, make sure you attach
the cable/aerial to the TV Tuner first, then the monitor (CRT).

Advanced Controls

3

Attaching a Monitor (CRT)

If you prefer to use a monitor (CRT), connect it to the External Mon­itor (CRT) port on the rear panel (see “Rear View” on page 1 - 22).



Vertical Refresh Rate

The vertical refresh rate
of your CRT is impor­tant. If it is too low and/
or you’re using fluores­cent lighting, the screen
will appear to flicker. To
reduce flickering on a
CRT, use faster refresh
rates (we recommend a
refresh rate of 72Hz or
more). But first check
your monitor’s docu­mentation to make sure
it can support the rates
listed by the video driv­er. The default refresh
rate for VGA monitors
(without drivers) is

Advanced Controls

3

Display Options

Display Mode Windows XP Windows 2000

Single

33

Multiple - Clone Mode

33

Multiple - Extended
Desktop Mode

3

Not Available

Single - Either the LCD, CRT or TV as a display device.
Multiple (Clone) - The LCD, CRT or TV outputting the same view (you

can apply different display modes with different resolutions and refresh
rates).
Multiple (Extended Desktop) - The LCD, CRT or TV outputting a dif-

ferent view (Windows XP only)

- see “Extended Desktop Mode” on

page 3 - 12.



TV Support

You cannot set your
flat panel display and
TV to the same display
mode.

Table 3 - 1

Display Options

Advanced Controls

3

Enabling Other Displays

In the Advanced ATI Mobility Radeon Properties (Figure 3 - 3 on

page 3-5) click on Display to get the other display options, including

those for TV (different OS’s will appear with different options).
Click the enable/disable button for the display device you wish
to use. Select (at least) one display as Primary, the remaining may
operate in either Clone Mode, or Extended Desktop Mode.

Figure 3 - 6

Displays Tab

Advanced Controls

3

Clone Mode

Clone Mode simply shows an exact copy of the Primary display
desktop on the other display(s). This mode will drive multiple dis­plays with the same content. Use this feature to display the screen
through a projector for a presentation. Each display device can be
configured independently as this allows you to set the options for
overhead projectors etc., which require specific resolutions and re­fresh rates.

Advanced Controls

3

Extended Desktop Mode

The system supports Extended Desktop (the LCD and a CRT show­ing different views) in multiple display environments in Win-
dowsXP, but this mode is NOT supported in Windows2000. An
Extended Desktop creates a desktop spanning multiple displays and
acts as a large workspace.

To get this effect:

1. Attach your external monitor to the External Monitor (CRT)
port, and turn it on.

2. Go to the Advanced Display Settings (see “Advanced Display

Properties” on page 3 - 5).

3. Select the Displays tab (see “Displays Tab” on page 3 - 10).

4. Click the enable/disable button for the display device
you wish to use (Monitor).

5. Click Apply and image will appear on the display device.

6. Click Yes to accept the settings and OK to save the changes.

7. Use the Display Properties window to select the second mon-

Advanced Controls

3

Use the Display Properties control panel to drag the monitors to
match the physical arrangement you wish to use. In the example
shown in Figure 3 - 7 the primary monitor "1" is on the left, the other
display is on the right.

Select the monitor from the “Display:” pop-up menu and click “Ex-

Figure 3 - 7

Extended

Desktop Monitor

Arrangement



Help

Further help is availa­ble through the menus
accessed from the
taskbar (see “ATI

Help & Troubleshoot­ing” on page 3 - 6).
