65W
REPLACEMENT
LED DLC4S-10W105se
Fixture Class: 4” Slim Fixed
5CCT
Selectable
Product Description
The Euri Lighting DLC4S-10W105se ultra-slim, 5CCT selectable, recessed downlight
is designed to give you the option between 2700K/3000K/3500K/4000K/5000K all
conveniently in one downlight. Its spring-action clips allow for easy installation and reduce
maintenance worries. This 4-inch downlight eliminates housing and makes for hassle-free
installation. At 650 Lumens and 10 Watts (65-Watt equivalent) input power, the 4” downlight
has an average of 35,000 hours of life and is ENERGY STAR certified. The DLC4S-10W105se is
IC Rated, recessed and best suited for low residential ceilings working on AC 120V.
It’s edge-lit LED technology guarantees a long life of uniform light distribution.
5
Estimated Energy Cost: $1.20 per year
YEAR
*Note: Design, features and specifications subject to change without notice. Some features may not be available on all models.
Please visit www.eurilighting.com or call 1-310-787-1100 for more information.
Specications
Input Power Input Voltage Lumen Output Beam Angle Center Beam CCT
10 W 120V/60Hz 650 lm 120° N/A
2700 / 3000 / 3500 /
4000 / 5000K
CRI Luminous Ecacy Power Factor Input Current Base Lamp Lifespan
80 65 lm/W 0.9 0.1 A Junction Box 35,000 Hrs.
Product Features Product Dimensions Product Photometric Data
-/+180
Dimmable
4.8” (Ø)
-150
-120
Energy Efficient
0
63
125
188
251
0
IC
RATED
5CCT Selectable
Damp Rated
Abutted & Covered
20900 Normandie Avenue Bldg. B, Torrance, CA 90502 | Tel: 310.787.1100 | Fax: 310.787.1166 | www.eurilighting.com
0.87"
Euri Lighting | A Division of IRTRONIX Inc.
©2019 Euri Lighting. All Rights Reserved
-90
-60
-30
150
120
90
60
30
