Eureka 965, 960 User Manual [en, fr]

www.eureka.com

Household Type

Vacuum Cleaner

Owner’s Guide

960-965 Series

INDEX

Important Safeguards .............................. 2

Service Information .................................. 4

Thermal Cut Off.................................. 4 & 5

Use........................................................... 5

Accessories.............................................. 6

Maintaining............................................ 7-8

Dust Bag & Filters .................................... 8

Problem Solving ....................................... 9

Order Form............................................. 10

Warranty................................................. 12

Part No. 71729

©2001 White Consolidated Industries, Inc.

(7/01) Printed in China

IMPORTANT SAFEGUARDS

When using an electric appliance, basic precautions should always be followed,
including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER.

WARNING

To reduce the risk of fire, electric shock, or injury:

• Do not use outdoors or on wet surfaces.

• Do not leave vacuum cleaner when plugged in. Turn off the switch and unplug

the electrical cord when not in use and before servicing.

• Do not allow to be used as a toy. Close attention is necessary when used by or
near children.

• Use only as described in this manual. Use only manufacturer’s recommended
attachments.

• Do not use with damaged cord or plug. If vacuum cleaner is not working as it
should, has been dropped, damaged, left outdoors, or dropped into water, return it
to a service center before using.

• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull
cord around sharp edges or corners. Do not run vacuum cleaner over cord. Keep
cord away from heated surfaces.

• Hold plug when rewinding onto cord reel. Do not allow plug to whip when
rewinding.

• Do not use extension cords or outlets with inadequate current carrying capacity.

• Turn off all controls before unplugging.

• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

• Do not handle plug or vacuum cleaner with wet hands or operate without shoes.

• Do not put any object into openings. Do not use with any opening blocked; keep

free of dust, lint, hair, and anything that may reduce airflow.

• This vacuum cleaner creates suction. Keep hair, loose clothing, fingers, and all
parts of body away from openings and moving parts.

• Do not pick up anything that is burning or smoking, such as cigarettes, matches,
or hot ashes.

• Do not use without dust bag or filter(s) in place.

• Use extra care when cleaning on stairs.

• Do not pick up flammable or combustible liquids such as gasoline, or use in areas

where they may be present.

• Store your cleaner indoors in a cool, dry area.

• Keep your work area well lighted.

• Unplug electrical appliances before vacuuming them.

SAVE THESE INSTRUCTIONS

2

CONSEILS DE SÉCURITÉ

Lors de l’utilisation d’un appareil électrique, quelques précautions élémentaires doivent
être observées, incluant les suivantes:

LISEZ TOUTES LES INSTRUCTIONS AVANT D’UTILISER VOTRE ASPIRATEUR.

AVERTISSEMENT

Pour réduire le risque de feu, de choc électrique ou de blessure:

• Ne pas utiliser l’aspirateur à l’extérieur ou sur une surface mouillée.

• Ne pas laisser l’aspirateur seul quand il est branché. Mettre l’interrupteur sur

arrêt et débrancher l’appareil lorsque vous ne l’utilisez pas ou avant l’entretien.

• Ne pas permettre que l’aspirateur soit utilisé comme un jouet. Une attention particu-

lière est nécessaire lorsqu’il est utilisé par ou près d’un enfant.

• Suivre strictement les recommandations d’utilisation de ce manuel. Utiliser unique-

ment les accessoires recommandés par le fabricant.

• Ne jamais utiliser l’aspirateur si le cordon ou la fiche sont endommagés. Si l’aspira-

teur ne fonctionne pas comme il le devrait, s’il a été échappé, s’il est endommagé, s’il
a été laissé à l’extérieur ou échappé dans de l’eau, le retourner à un centre de service
avant de l’utiliser.

• Ne pas l’aspirateur ou le transporter par le cordon. Ne pas utiliser le cordon en guise

de poignée. Ne pas fermer une porte sur le cordon ou tirer le cordon sur des bordures
ou des coins pointus. Ne pas passer l’aspirateur sur le cordon. Tenir le cordon à
distance des surfaces chauffantes.

• Tenez la fiche à la main lorsque vous rebobinez le cordon. Ne permettez pas que la

fiche s’emporte brusquement lorsque vous rebobinez le cordon.

• Ne pas utiliser des cordons de rallonge ou des prises qui n’ont pas une capacité

suffisante pour transporter le courant.

• Mettre sur arrêt tous les boutons de commande avant de débrancher.

• Ne pas débrancher l’aspirateur en tirant sur le cordon. Pour débrancher saisir la fiche

et non pas le cordon.

• Ne pas manipuler la fiche ou l’aspirateur les mains mouillées ou faire fonctionner

pieds nus.

• Ne rien insérer dans les ouvertures. Ne pas utiliser l’aspirateur si des ouvertures sont

bloquées. Vous assurer qu’elles soient dégagées de poussière, de mousse, de che­veux ou de tout autre chose qui pourrait réduire le passage de l’air.

• Cet aspirateur crée de la succion. Tenir les parties mobiles et les ouvertures loin des

cheveux, du linge, des doigts et de toute partie du corps.

• Ne pas ramasser des objets qui brûlent ou fument comme les cigarettes, les allumet-

tes ou les cendres chaudes.

• Ne pas utiliser sans que le sac à poussière ou le(s) filtre(s) ne soient en place.

• Porter une attention particulière lorsque vous nettoyez les escaliers.

• Ne pas utiliser pour ramasser des liquides inflammables ou combustibles, comme de

l’essence. Ne pas utiliser dans les endroits ou ces liquides pourraient être présents.

• Entreposer votre aspirateur à l’intérieur, dans un endroit propre et sec.

• Maintenir un bon éclairage à l’endroit où vous travaillez.

• Débrancher les appareils électriques avant de les passer à l’aspirateur.

CONSERVEZ CES INSTRUCTIONS

3

T o reduce the risk of electric shock, this appliance has a polarized plug (one blade is
wider than the other). This plug will fit in a polarized outlet only one way . If the plug does
not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet. Do not change the plug in any way.

Afin de réduire le risque de choc électrique, cet appareil est muni d’une fiche polarisée
(une des lames est plus large). Cette fiche ne peut être insérée dans une prise polarisée
que d’une seule façon. Si la fiche ne peut être insérée dans la prise, retourner la fiche.
Si la fiche ne peut toujours pas être insérée dans la prise, faire installer une prise adéquate
par un électricien qualifié. Ne pas modifier la fiche.

GENERAL INFORMATION

The cleaner is designed to pick up dirt and dust particles. Avoid picking up hard or
sharp objects with the cleaner to avoid bag breakage, hose clogging, or possible
motor damage.

Service Information

The instructions in this booklet serve as a guide to routine maintenance. For additional
service information telephone our toll free number for the nearest Eureka Authorized
Warranty Station. You should know the model, type and serial numbers when you

call:

USA: 1-800-282-2886

Mexico: 5670-6169

Canada: 1-800-282-2886

If you prefer, you can write to The Eureka Company, Service Division, 807 North Main
Street, Bloomington, Illinois 61701, USA. In Canada write to The Eureka Company , 866
Langs Drive, Cambridge, Ontario N3H 2N7. Refer to The Eureka Warranty for complete
service information.

DO NOT OIL the motor at any time. The bearings are permanently
lubricated and sealed.

Rating Plate

The model, type, and serial numbers are
indicated on the rating plate located on the
under side of the cleaner. For prompt and
complete service information, always refer to
these numbers when inquiring about service.

Model & Type______________________ Serial No. _________________________

MODEL TYPE SERIAL NO.

VOLTS AMPS. HERTZ

SERVICE INFORMATION: 1-800-282-2886

THE EUREKA COMPANY

BLOOMINGTON, ILLINOIS 61701

Thermal Cut Off

This vacuum cleaner has a special thermostat that protects the cleaner in case of
motor overheating. If the cleaner suddenly shuts off, push the on/off button once and
unplug the cleaner. Check the cleaner for a possible source of overheating such as a
full bag, a blocked hose or clogged filter. If these conditions are found, fix them and
wait at least 30 minutes before attempting to use the cleaner. After the 30 minute
period, plug the cleaner back in and push the on/off button to start the cleaner. If the
cleaner still does not run, then take it to a Eureka Authorized Service Center for
repair.

4

IDENTIFY PARTS OF CLEANER

2

1

1. Carrying Handle

2. On/Off Button

3. Bag Cover Latch

4. Hose Inlet

5. Swivel Cord Hook

6. Disposable Dust Bag

7. Micron Filter Door

8. Stationary Cord Hook

9. Electrical Cord Stored on

Underneath of Cleaner

3

4

5

6

7

8

HOW TO USE

A carpet should be cleaned regularly over heavily traveled areas, and once a week
over the entire carpeted area. Vacuum slowly, making several passes (forward and
backward) over the carpet, covering small areas at a time. The time required to clean
the carpet will depend on several factors–including type of carpet and amount of dirt.

Connect Hose

1 2

Push ON/OFF Button

4

(A thermostat automatically
shuts the motor off if it
overheats, see Thermal Cut
Off )

Lift cleaner and hold with one hand while
unwrapping electrical cord from around cord
hooks (bottom of cleaner) with the other hand.

3

Plug into
electrical socket.

9

Swivel
Cord Hook

ON/OFF Button

5

Cleaning Accessories

Attach wands and cleaning tools

Slip the circular end of an accessory tool
onto the end of the hose handle and twist
slightly to secure. If additional reach is
needed, place a wand on the hose handle
first.

Open the Slip
Ring to reduce
suction.

Floor Tool

Mini Crevice Tool

*Bare Floor Brush

(optional)

*Bonus Hose (optional)

*Upholstery
Nozzle (optional)

*Full Size
Dusting Brush

(optional)

Mini Crevice Tool (stored on wand of cleaner): For

crevices, corners, baseboards, between cushions.

*Upholstery Nozzle: For curtains, draperies, cushions,

fabrics.

*Full Size Dusting Brush: For furniture, blinds, books,

lamp shades, shelves.

*Bare Floor Brush: For any type of hard surface floor.
*Bonus Hose: Extends reach of hose for easier cleaning.

*May be purchased separately.

6

HOW TO MAINTAIN

The instructions given in this booklet serve as a guide to routine maintenance. To
avoid unnecessary service calls, check the hose, bag and filter often. Clear a clogged
hose with the blower, change the bag if it is full, and clean the motor filter when it is
dirty.

Disposable Dust Bags and Filters

The dust bag and motor filter play a very important roll in the efficiency of the vacuum
cleaner. The purpose of the dust bag is to trap dirt, but at the same time, the paper
bag must be porous enough to allow air to pass through. If the bag or the motor filter
become clogged, no air can pass through the cleaner and no cleaning can take place
regardless of how powerful the unit is. To keep the cleaner operating at maximum
efficiency, change the dust bag frequently and clean the filter as needed. Some fine
particles can restrict airflow very quickly and will decrease performance even before
the bag appears to be full. For that reason, when vacuuming carpet fresheners or
cleaners, powder, plaster dust, or similar fine substances, the bag and filter may need
to be changed more often.

Look for the symbol.

GENUINE

EUREKA PRODUCT

How to Remove Disposable Dust Bags – Style L

NOTE: Turn off vacuum and unplug the electrical cord before changing dust

1
2

bag or cleaning motor filter. Never operate the vacuum cleaner without
the dust bag or filter.

Turn off and unplug cleaner.

Open bag cover by lifting up
on latch with fingers and rais­ing bag cover.

Latch

Bag
Cover

3

Lift dust bag out of bag holder
guides.

Bag
Holder
Guides

How to Install Disposable Dust Bags–Style L

NOTE: Turn off vacuum and unplug the electrical cord before changing dust

1. See above steps 1-3 to remove used dust bag. Discard used dust bag in a trash

bag or cleaning motor filter. Never operate the vacuum cleaner without
the dust bag or filter.

receptacle.

7

How to Install Disposable Dust Bags – Style T (continued)

Cardboard
Collar

2. Open bag folds slightly.

3. Place dust bag in dust bag holder by
placing cardboard collar into guides.
Push down until collar is into position.

Guides

4. Lower bag cover lid, lining it up with
grooves in base and placing long front tab
in opening between base and handle.
Press down until front tab latches onto
bottom of handle. The handle holds the
bag cover lid in place when properly
installed.

Long
Front
Tab

Grooves

How to Install Micron Filter

Check the Micron filter with each disposable dust bag change. Replace a minimum of
twice a year or after every six bag changes.

1. Push Micron filter door latch
to the left and pull door out
away from cleaner.

2. Micron filter is on the inside
of the filter door. Pull filter
away from the filter door and
clean or replace.

3. The Micron filter can be
cleaned by brushing over a
trash receptacle.

4. Return the Micron filter to the
back side of the filter door.
Push filter door hinge into slot
on cleaner and swing door
closed until it snaps shut.

Slot

Hinge

Latch

8

PROBLEM SOLVING

NOTE: T urn OFF the power switch and unplug the electrical cord before servicing.

PROBLEM CAUSE SOLUTION

3

Motor won’t start

No suction at end of
hose

Reduced suction

Cleaner shuts off

General questions

Electric plug

3

Power switch not
turned “ON”

3

Full paper bag

3

Hose

3

Front cover not
latched

3

Full paper bag

3

Slip ring open

3

Hose

3

Internal safety
thermostat trips

Assembly or related

3

attachments

Push plug securely into
outlet.

Try another outlet.
Check circuit breaker.
Make sure power switch is

“ON.”
Replace paper bag.

Remove any clogs from
hose that restrict airflow,
then try again.

Push front cover until it
latches firmly.

Replace paper bag.
Slide slip ring on wand until

hole is covered.
Remove any clogs from

hose that restrict airflow,
then try again.

Unplug cleaner and check
for obstructions in hose,
wands and attachments.

Check for full paper bag.
Clean/replace motor filter.

Call 1-800-282-2886
between 7:00 AM–8:00 PM
central standard time,
Monday through Saturday.
Know the Model number
and Serial number when
you call.

9

THE EUREKA LIMITED WARRANTY

hat This Warranty Covers

W

Your Eureka cleaner is warranted to be free from all defects in material and workmanship in normal household
use for a period of one year. The warranty is granted only to the original purchaser and members of his or her
immediate household. The warranty is subject to the following provisions.

hat This Warranty Does Not Cover

W

• Parts of the cleaner that require replacement under normal use, such as disposable dust bags, filters, drive belts,

light bulbs, and brush roll bristles

• Damages or malfunctions caused by negligence, abuse, or use not in accordance with the Owner’s Guide.

• Defects or damages caused by unauthorized service or the use of other than Genuine Eureka parts.

hat The Eureka Company Will Do

W

The Eureka Company will, at its option, repair or replace a defective cleaner or cleaner part that is covered by
this warranty. As a matter of warranty policy, the Eureka Company will not refund the consumer’s purchase
price.

btaining Warranty Service

O

To obtain warranty service you must return the defective cleaner or cleaner part along with proof of purchase
to any Eureka Authorized Warranty Station.

You will find the nearest location in the Yellow Pages, under “Vacuum Cleaners–Service and Repair.” Be
certain that the Warranty Station is “Eureka Authorized.”

For the location of the nearest Eureka Authorized Warranty Station or for service information, telephone toll
free:

If you prefer, you can write to The Eureka Company, Service Division, 807 North Main Street, Bloomington,
Illinois 61701, USA. In Canada write to The Eureka Company, 866 Langs Drive, Cambridge Ontario N3H 2N7.

If it is necessary to ship the cleaner outside your community to obtain warranty repair, you must pay the
shipping charges to the Eureka Authorized Warranty Station.

Return shipping charges will be paid by the Warranty Station. When returning parts for repair, please include
the model, type, and serial number from the data plate on the cleaner.

urther Limitations and Exclusions

F

Any warranty that may be implied in connection with your purchase or use of the cleaner, including any
warranty of Merchantability or any warranty for Fitness For A Particular Purpose is limited to the duration of
this warranty. Some states do not allow limitations on how long an implied warranty lasts, so the above
limitations may not apply to you.

Your relief for the breach of this warranty is limited to the relief expressly provided above. In no event
shall Eureka be liable for any consequential or incidental damages you may incur in connection with your
purchase or use of the cleaner. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.

This warranty gives you specific legal rights. You may also have other rights which vary by state.

USA: 1-800-282-2886

Mexico: 5670-6169

Canada: 1-800-282-2886

GENUINE

EUREKA PRODUCT

uestions & Answers about Genuine Eureka Products

Q

Q: Why should I use only Genuine Eureka paper bags, belts, and parts in my Eureka vacuum cleaner?
A: Using Genuine Eureka Products, which are made to our exacting specifications and engineered with

emphasis on quality, performance, and customer satisfaction, ensures the long life and cleaning

efficiency of your vacuum cleaner. Overall, this saves you money and helps to keep your home

clean.
Q: How can I be sure I am using only genuine Eureka products in my vacuum cleaner?
A: Typically, packaged products and paper bags can be identified by a “Genuine Eureka Product”

symbol (see illustration above). For further identification assistance, you may call our toll-free

number, 1-800-282-2886, for the location of a nearby Eureka Authorized Warranty Station.
Q: Are there any differences between “made to fit” or “imitation” and Genuine Eureka paper bags, belts,

and parts?

A: Yes, there are some very important differences in materials, quality , and reliability. Many customers

have mistakenly purchased “imitation” paper bags and parts while thinking they purchased genuine.

Unfortunately, many of these customers discovered the differences after they experienced related

difficulties.

For Genuine Eureka Value, Accept No Imitations!

THE EUREKA COMPANY

Bloomington, Illinois 61701
