MUSIC | AUDIO POST | VIDEO | FILM
connect and control your favorite media applications
the perfect mix
of form and function
Touch-sensitive Rotary Encoders (8) and Knob
1
Select/On Keys
Offer direct control over everything from panning and
gain to editing your most powerful plug-ins and EQ
– these knobs can also be pressed to select/deselect
and navigate through parameters
1
The new Artist Series MC Mix brings the unparalleled speed,
resolution and DAW integration of Euphonix’ high-end professional
consoles to your studio in a revolutionary ergonomic, slim-line
design. The MC Mix easily fits into any studio, sitting perfectly
between a computer keyboard and screen, and multiple units can
be connected to create a larger, integrated control surface.
The MC Mix lets you effortlessly switch between multiple
applications and even workstations at the touch of a button –
the touch-sensitive knobs, motorized faders, and high-resolution
OLED displays automatically set themselves to whatever application
is in the foreground to provide immediate access to multi-format
metering, plug-in parameters, EQ curves and much more.
Most importantly, Euphonix has worked closely with the world’s
leading software developers like Apple, Steinberg, MOTU, Apogee
and others to deeply integrate native support for Euphonix’ EuCon
control protocol into their DAWs to deliver an unmatched editing
and mixing experience.
MC Mix Power Features:
• Controls multiple audio/video applications via Ethernet
• 250X faster and 8X the resolution of MIDI
• Supports HUI and Mackie Control protocol
• Slim-line design for easy studio integration and portability
• Link up to four MC Mix controllers and/or an MC Control
for up to 36 faders
2
Touch-sensitive Motorized Faders (8)
High-quality ALPS 100mm long throw faders offer
accurate and smooth mixing - touching a fader will
automatically select the corresponding track
Record/Automation Keys
3
Enable direct arming of tracks for recording and/or
selection of each track’s automation mode
Select/Assign Keys
4
Lock the selected track to a dedicated fader while
allowing you to bank through tracks with the
remaining faders – perfect for master fader and submix
applications
Knob Set Selector Keys
5
Quickly assign the rotary encoders to control plug-ins,
EQs, panning, signal routing and much more – you can
either control the same parameter across all tracks or
assign all knobs to one track for easy editing of
multiple parameters at once
Function Keys (Shift Keys)
6
Used in conjunction with other keys on the MC Mix to
provide alternate functions
Footswitch Jack
7
Punch in and out of recording when footswitch is
connected
2
3
4
5
6
Channel Display
12
12
11
10
9
6
High-resolution 128 x 64 pixel OLED display provides
track name/number, detailed metering (from mono to
5.1 surround data), parameter name/value currently
being modified by its corresponding rotary encoder,
current automation mode and more
Track Navigation
11
Scroll through tracks using the Bank buttons (in
groups of eight tracks at a time) and Nudge buttons
(one track at a time)
10
Solo/Mute/Transport Keys
These keys solo/mute tracks and serve as transport
controls when the Function Key is depressed
Application/Workstation Change
9
Application Change lets you cycle through your
applications, while the Workstation Change allows
you to switch between multiple workstations
Ethernet Port
8
Connects the MC Mix to your Mac - Ethernet hub or
switch required to connect additional MC Mix unit(s)
and MC Control unit or connect to a network
7
8
Riser Brackets included
to increase height and viewing angle
EuCon is a high-speed Ethernet control protocol developed by Euphonix
that allows the MC Mix to connect to any Mac OS X application. EuCon
carries control information for faders, knobs, displays and more, between
the MC Mix and whatever application is in focus on your computer.
EuCon features:
• simultaneous control over multiple applications and workstations
via Ethernet
• high-resolution, high-speed control over almost all DAW functions
• 250X the speed and 8X the resolution of MIDI
• support for HUI and Mackie Control protocols
• universal control of any software application
Works with:
Apple LOGIC PRO
Apple SOUNDTRACK PRO
Steinberg NUENDO
Steinberg CUBASE
MOTU DIGITAL PERFORMER
ApplicationsControl Surfaces Workstations
Apple FINAL CUT PRO
Propellerheads REASON
Ableton LIVE
Digidesign PRO TOOLS
(HD/LE/M-Powered)
Any software application
The MC Mix is designed to work with up to three additional MC Mix
units and/or one MC Control to create a larger, integrated system with
up to 36 faders. MC Mix and MC Control units can be elegantly clipped
together or be situated anywhere on the network.
MC Mix Specifications
Dimensions: 16.8" (420mm) x 9.5"
(238mm) x 1.2" (30mm)
Weight: 4.8 lbs (2.2kg)
Line voltage: 100 – 240V AC
Frequency: 50Hz to 60Hz
e u p h o n i x. c o m
220 Portage Avenue l Palo Alto, CA 94306
p. 650.855.0400 l f. 650.855.0410
©2008 Euphonix Inc. All Rights Reserved. Euphonix, EuCon, MC Control & MC Mix are trademarks of Euphonix, Inc. Mac and Mac logo are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.
All other trademarks are the property of their respective owners.
