Queen Platform Bed with Squared Tapered Legs
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the bed frame, we recommend that it is assembled by two adults, on a carpeted
or padded area, in the room that it is intended for. Approx assembly time: 45 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.
Com
ponent:
1
5
Hardware:
8
A
B
C
D
E
Bolt M8x25mm x16
Bolt
M6x45mm x16
Screw
Flat Washer M6 x16
Flat Washer M8 x16
F Spring
G
H
PHILLIPHS HEAD SCREW DRIVER
Allen
Allen Wrench M5 x1
NOT PROVIDED
2
M4x35mm x12
Washer M8 x16
Wrench M4 x1
Board x2
Short
1
Leg Ⅰ x2
5
6
7
6
3
2
4
1
5
Long Board x2
2
Leg Ⅱ x2
6
Page
Center Rail x1
3
Slats x10
7
Support Leg x2
4
Metal Corner Plate x4
8
1 of 6
BED FRAME
STEP 1:
Put 1 piece of Short Board (1) upside down on a carpeted or padded area by two adults
Attach 1 piece of Leg (5) and 1 piece of Leg (6) into the Short Board (1) by using 4 pieces of Bolt (B) and 4 pieces
of Flat Washer (D) as shown.
Use Allen Wrench (G) to tighten the Bolts (B) clockwise until secure.
Repeat the same steps for the remaining 1 piece of Short Board (1) ,1 piece of Leg (5) and 1 piece of Leg (6).
B
G
B
B
D
B
D
1
B
6
1
B
5
Leg
6
Note: T
this Bed Frame.
B
x8 Dx8 Gx1
STEP 2:
Place 1 piece of L
Attach them by using 4 pieces of Bolt (B) and 4 pieces of Flat Washer (D) as shown.
Use Allen Wrench (G) to tighten the Bolts (B) clockwise until secure.
Repeat the same steps for the remaining 1 piece of Long Board (2).
ong Board (2) to 2 pieces of assembled Short Board (1) by two adults
here are two kinds of legs designed for
B
B
1
B
2
B
H
Leg
ardware & Tool required
D
2
B
D
1
B
2
Bx8 Dx8 Gx1
G
1
Hardware & Tool required
Pa
ge 2 of 6
BED FRAME
STEP 3:
At
tach 1 piece of Support Leg (4) into the Center Rail (3) as shown.
Secure the Support Leg (4) into the Center Rail (3) by using 2 pieces of Screw (C) as shown.
Tighten the Screws (C) with Phillips Head Screw Driver (Not provided).
3
4
4
3
C
C
4
C
x4
STEP 4:
Secure 1piece of M
with 4 pieces of Spring Washer (F), 4 pieces of Flat Washer (E) as shown.
Repeat the same steps for the remaining 3 pieces of Metal Corner Plate (8).
Place the assembled Center Rails (3) to the Short Board(1).
Insert the hook on the each end of Center Rail(3) into the notch on the Short Board (1).
Repeat the same steps for the remaining assembled Center Rail (3).
8
1
E
Phillips Head Screw
Driver( not provided)
etal Corner Plate (8) into the Short Board (1) and Long Board (2) by using 4 pieces of Bolt (A)
2
1
2
F
A
H
3
Hardware & Tool required
N
otch on the
Short Board
1
3
Ax16 Ex16 Hx1
Fx16
2
1
Hooks on the
end of Center Rail
Hardware & Tool required
Page 3 of 6
B
ED FRAME
STEP 5:
Pl
ace the Slats (7) to the Long Boards (2) as shown.
Secure 4 pieces of Slat (7) which have countersink Holes on each end into the Long Board (2) by using 8 pieces of
Screw (C) as shown.
Tight the Screw (C) with Phillips Head Screw Driver (Not provided).
2
7
7
7
7
7
2
C
7
7
7
7
7
7
2
NOTE:
Cx8
Assembly is completed. The bed frame is ready to use now!
Hardware may loosen over time. Periodically check that all connections are tight.
Phillips Head Screw
Driver( not provided)
Pa
Hardware & Tool required
ge 4 of 6
CONNECTING BED FRAME TO HEADBOARD
ASSEMBLY INSTRUCTIONS
Component:
Hardware:
A
C
D
F
Bolt
M6x45mm x4
Flat Washer M6xD22mm x4
Sprin
g Washer M6 x4
Allen Wrench M4 x1
Important: All the hardware is packed with the
headboard you are buying. Please only use the
above hardware from Headboard Hardware Package
to assemble the Bed Frame and Headboard.
1
2
1
Headboard x1
(Style may vary)
2
Bed
Frame x1
(Style may vary)
Page 5 of 6
CONNECTING BED FRAME TO HEADBOARD
STEP 1:
Line up the B
Secure the Headboard (1) to the Bed Frame (2) by using 2 pieces of Bolt (A) with 2 pieces of Spring Washer (D), 2 pieces
of Flat Washer (C) into the Bed Frame (2).
Then tighten the Bolts (A) by using the Allen Wrench (F).
Repeat the same procedure for each bolt and each side of the Bed Frame (2).
ed Frame (2) board’s pre-drilled holes to match those of the Headboard (1).
2
1
2
1
C
D
A
F
A
x4 Cx4 Dx4 Fx1
STEP 2:
Carefully position the assembled bed to the desired location by four adults.
A
ssembly is completed. The bed is ready to use now!
Hardware & Tool required
NOTE:
Hardware may loosen over time. Periodically check that all connections are tight.
Pa
ge 6 of 6
HEADBOARD
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the headboard, we recommend that it is assembled by two adults, on a carpeted
or padded area, in the room that it is intended for. Approx assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.
Hardware:
A
B
C
C
omponent:
1
Bolt M8x45mm x4
Flat Washer M8xD22mm x4
Allen Wrench M5 x1
1
adboard x1
He
le may vary)
(Sty
2
2
Low Post x2
2
Page 1 of 6
HEADBOARD
STEP 1:
Pu
t the Headboard (1) upside down on a carpeted or padded area by two adults
Then insert the Low Posts (2) into the bottom of Headboard (1) and align pre-drilled Low Post (2) holes to the predrilled Headboard (1) Holes according to your desired headboard height.
Attach each of Low Post (2) by using 2 piece of Flat Washer (B) and 2 pieces of Bolt (A) from the holes on the back
of Low Post (2) and Headboard (1). Tighten with Allen Wrench (C).
B
1
ack
C
2
A
B
Back
1
2
2
A
x4 Bx4 Cx1
STEP 2:
Carefully turn up the assembled H
2
Hardware & Tool required
eadboard (1) by two adults.
N
Assembly is completed. The headboard is ready to use now!
OTE:
Hardware may loosen over time. Periodically check that all connections are tight.
Page 2 of 6
CONNECTING HEADBOARD TO BED FRAME
ASSEMBLY INSTRUCTIONS
O
PTION 1
Component:
OPTION 1
Hardware:
A
B
C
D
E
F
Bo
lt M6x45mm x4
Bo
lt M6x65mm x4
Flat Washer M6xD22mm x8
Spring Washer M6 x4
H
ex Nut M6 x4
Allen Wrench M4 x1
1
Headboard x1
1
(Style may vary)
2
OPTION 1
Page 3 of 6
2
d Frame x1
Be
CONNECTING HEADBOARD TO BED FRAME
N
Extra hardware were provided for attaching the headboard to your Bed Frame (use is optional).
ote:
STEP 1:
L
ine up the Bed Frame (2) board’s pre-drilled holes to match those of the Headboard (1) .
Secure the Headboard (1) to the Bed Frame (2) by using 2 pieces of Bolt (B) for the thicker Bed Frame (2), and 2 pieces
of Bolt (A) for the thinner Bed Frame (2).
Before inserting each bolt, place 1 piece of Spring Washer (D) and Flat Washer (C) on each bolt. Then fit 1 piece of Flat
Washer (C) on the bolt as it protrudes through the other side of the Bed Frame (2).
Place 1 piece of Hex Nut (E) after the Flat Washer (C) at the end of each bolt. Then tighten the Bolts (A or B) by
using the Allen Wrench (F).
Repeat the same procedure for each bolt and each side of the Bed Frame (2).
1
1
2
A
or Bx4 Cx8 Fx1
Dx4
STEP 2:
arefully position the assembled bed to the desired location by four adults.
C
Ex4
F
E
C
B
C
D
2
Hardware & Tool required
NOTE:
A
ssembly is completed. The bed is ready to use now!
Hardware may loosen over time. Periodically check that all connections are tight.
Page 4 of 6
CONNECTING HEADBOARD TO BED FRAME
A
SSEMBLY INSTRUCTIONS
OPTION 2
Component:
OPTION 2
Hardware:
A
B
C
D
F
Bol
t M6x45mm x4
Bolt M6x65mm x4
Flat Washer M6xD22mm x4
Spri
ng Washer M6 x4
Allen Wrench M4 x1
1
Headboard x1
(Style may vary)
1
OPTION 2
2
2
Be
d Frame x1
(Style may vary)
Page 5 of 6
CONNECTING HEADBOARD TO BED FRAME
STEP 1:
Line up the B
Secure the Headboard (1) to the Bed Frame (2) by using 2 pieces of Bolt (B) with 2 pieces of Spring Washer (D), 2 pieces
of Flat Washer (C) for the thicker Bed Frame (2), and 2 pieces of Bolt (A) with 2 pieces of Spring Washer (D), 2 pieces of
Flat Washer (C) for the thinner Bed Frame (2).
Then tighten the Bolts (A or B) by using the Allen Wrench (F).
Repeat the same procedure for each bolt and each side of the Bed Frame (2).
ed Fame (2) board’s pre-drilled holes to match those of the Headboard (1).
2
1
2
1
C
D
A
F
A
or Bx4 Cx4 Dx4 Fx1
STEP 2:
Carefully position the assembled bed to the desired location by four adults.
A
ssembly is completed. The bed is ready to use now!
Hardware & Tool required
NOTE:
Hardware may loosen over time. Periodically check that all connections are tight.
Page 6 of 6
