Page 1
www.etiger.com
Secual Box
Quick start guide
Page 2
Only if you are using a SIM card
1
Insert the SIM card in the control panel
You will need a SIM card if you wish to interact with your Secual Box by
SMS and phone calls.
Important
- Make sure the SIM card is not protected by a PIN code.
- We advise you to choose a plan with unlimited text and 1 or 2
hours of call. The SIM card must be compatible with the GSM
network. Contact your carrier for more information.
SIM
SIM
Control panel’s
SIM card
Page 3
Turn the control panel on
1. Plug the power adapter to an AC socket.
2. Plug the output connector of the power adapter into the adapter input
on the side of your control panel.
3. Push the power switch.
SIM
Power switch
Power adapter input
2
Page 4
Get your app ready
1. Download the ”Secual Box” app on your smartphone (on the App Store
and Google Play).
2. Open the ”Secual Box” app on your smartphone.
“SIM card only” users
If you are using the Secual Box with a SIM card and cannot use
the iOS and Android apps, read the full manual to learn more
about interaction by SMS and phone call.
Full manual is available on etiger.com
WLAN
WLAN
ESWIFI_XXXXXX
Secual
Box
3
Page 5
Motion detector
We recommend to mount the detector
at a height of 2.2m. The detector does
not detect animals under 25 kg. Avoid
mounting the detectors in areas with a
large amount of metal or electrical devices.
2.2m
<25kg
Understanding the standby mode
If the detector is triggered more than twice within 3 minutes,
it switches to standby mode to save power. During standby
mode, the detector is inactive. If within the next 3 minutes a
new movement is detected, the standby mode is extended by 3
minutes. If no movement is detected within the next 3 minutes,
the sensor is activated again.
Door contacts
Mount the magnet with double-sided
tape on the door and the door frame
respectively.
1cm
max
Accessories
Page 6
Advanced settings
Connect more accessories
Additional accessories can be connected from the app, in the settings
of your control panel. Or you can press the “ ” button on the side of
your control panel, and trigger the accessory. You hear one beep: the
accessory is registered. If the control panel beeps twice, the accessory
was already connected.
Control by phone call (SIM card required)
Your alarm system can be controlled and monitored by phone call. For
more information on the control by phone call, read the full manual on
etiger.com
Full manual
For more settings, please refer to the user manual of the control
panel, available for download on etiger.com
Page 7
Precautions
ATTENTION
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS
INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sucient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the product.
To prevent re or shock hazards, do not expose this product to rain
or moisture. Apparatus shall not be exposed to dripping or splashing
and no object lled with liquids, such as vases, shall be placed on the
apparatus.
Page 8
Standards
This product bears the selective sorting symbol for waste electrical
and electronic equipment (WEEE). This means that this product must
be handled pursuant to European Directive 2002/96/EC in order to be
recycled or dismantled to minimize its impact on the environment.
For further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are
potentially dangerous for the environment and human health due to
the presence of hazardous substances.
In compliance with European laws. This product is in compliance with
the essential requirements and other relevant provisions of Directive
1999/5/EC.
This product was designed and manufactured in compliance with
Directive 2002/95/EC of the European Parliament and of the Council on
the restriction of use of certain hazardous substances in electrical and
electronic equipment (RoHS Directive - RoHS) and is deemed to comply
with the maximum concentration values set by the European Technical
Adaptation Committee (TAC).
Manufactured in China.
Images, illustrations and text are non-contractual. eTIGER and the
eTIGER logo are registered trademarks and the property of eTIGER.
Copyright © 2016 eTIGER. All rights reserved.
ESB-WS1A-QSG-EN20160808-2.0-W
